2 RF coaxial

cable

3 Video/Audio cable

(yellow/red/white)

Remote control and

two AAA batteries

Quick Start Guide DVDR3588H

1 Hard Disk/DVD Recorder

CABLE

SATELLITE

ANTENNA

c/2d

Move cursor to "SETUP MENU - DATE/TIME" option, then

press key. Press keys to select "Date (dd/mm/yyyy)"

option. Press key to change the setting and press OK.

Move cursor to "SETUP MENU - GENERAL" option, then

press key. Press keys to highlight "Auto Scan" option

and press OK to search for stations.

Connect the existing Antenna/Cable TV signal (or from the Cable

Box/Satellite Receiver {RF OUT or TO TV} to the ANTENNA IN

jack on the recorder.

Use the supplied RF coaxial cable to connect the ANTENNA OUT

on the recorder to the ANTENNA IN jack on your TV (VHF/UHF

RF IN).

Use the supplied audio/video cable (yellow plug) to connect the

VIDEO (CVBS) OUTPUT jack on the recorder to the VIDEO IN

jack on your TV.

Use the supplied audio/video cable (red/white plugs) to connect

the AUDIO OUTPUT jacks on the recorder to the AUDIO IN jacks

on your TV.

Helpful hint:

please see page 16-23 of user manual for more connections.

Press STANDBY-ON on the recorder.

Turn on the TV and other connected devices (e.g. Cable

Box, Satellite Receiver).

Set it to the correct video-in channel. You should see the

blue DVD background screen.

Press SETUP and press keys for moving preview.

Press key to select the options needed and press OK.

Connect the power cable from the recorder to an AC power outlet.

4e To pause the recording, press PLAY/PAUSE. Press REC to resume

recording and press STOP key to stop recording.

4d Press DVD, then press SOURCE or DVD/USB to select matching

input source, and press REC to record to DVD.

4b To select external program source. Press SOURCE repeatedly

to select the source to record from.

Input Source: CAM 1, R CVBS, R Y/C, R YUV, CHXXX or press

DV/USB twice to select input source of DV.

4Press OPEN/CLOSE to open the disc tray, load a recordable

DVD+R/+RW with the label facing up.

Playback from disc

Switch to TV program

Quality Maximum recording time

for a disc (4.7GB, DVD)

Maximum recording time

for a disc (160GB, HDD)

HQ(High quality)

SP(DVD quality)

SP+( )DVD quality

LP( )VHS quality

SLP( )VHS quality

EP(VHS quality)

To select recording media. Press DVD REC repeatedly

to select "Rec to: Optical disc" or "Rec to: Hard disc".

Press ADD/CLEAR to toggle between the different modes

of record quality.

5c To stop playback press STOP key.

5b Playback will begin automatically, otherwise press OK or

PLAY/PAUSE to start playback. If a User Interface appears,

keep pressing keys to preview disc menu and

highlight the preferred option, press OK or PLAY/PAUSE

to play the selected file.

5Press OPEN/CLOSE to open the disc tray, load a recordable

DVD+R/+RW with the label facing up.

5d Press TUNER, then press CH+ and CH- keys to select a TV channel.

Press HDD to access to title recordings in hard disc.

Press DVD to access to title recordings in disc.

Supported disc formats:

Need help please read supplied manual or browse our website at www.philips.com/support

ALL

Check video input jacks on TV, it can be FRONT A/V IN

or VIDEO jacks on the back.

Toggle among different modes with remote control.

Or, select channels by TV's remote control, then press CH+ and

CH- keys repeatedly until picture display.

Please refer to user manual for more information

Acquiring picture

Acquiring sound

Connect Audio L/R (red/while) jacks on back of DVD recorder to

AUDIO INPUT jacks of TV, stereo system or receiver. Switched on

connected systems and choose matching channel.
