Philips Home Access 4000 Series Manuel utilisateur
User
Manual
Smart deadbolt
Home Access
Register your product and get
support at www.philips.com/support
4000 series
Contents
1 Warnings & Safety 02
2 How to Install
03
4 Z-Wave Network Setup 18
Parts List
Assembly View
Install the Lock
5 Lock & Unlock 19
6 Troubleshooting 21
3 How to Use 12
Factory Reset & Default Settings
Format of Entry Methods
Program the Lock
Safety
Caution
Returns & Disposal
7 Warranty 23
24
9 ISED Statement 24
8 FCC Statement
1
◆Before using this product, please read and understand all instructions. Damage caused
by failure to follow the instructions is not covered by the warranty.
◆Only use components the manufacturer provided and suggested accessories.
◆Only use AA alkaline batteries.
◆Do not forcibly disassemble the product to trigger an alarm or damage the product.
◆Do not remove the batteries during lock setup and operation.
Caution
◆
◆Do not connect the 2 poles of the batteries to metals to avoid a short circuit and
potential explosion.
◆Any replacement component should be performed by Philips, a Philips-authorized
service center, or a professional technician.
◆Do not use parts or accessories manufactured by others, except batteries.
◆Do not expose products to places that have water leakage or splashing.
Returns & Disposal
◆Locks can be returned at an authorized Philips service center. Appropriate compensation
will be provided if the returned product meets Philips's conditions.
◆Please follow local regulations and do not throw the used products or batteries into
normal household waste.
1 Warnings & Safety
Safety
2
2 How to Install
Parts List
Upper Screw & Screw
Post (Optional)
Mechanical Keys Drive-In Collar Drilling Template
Exterior Assembly Latch Bolt Mounting Plate
AA Batteries (4) Battery Cover Interior Assembly
Screws (2)
Mounting Plate
Screws (2)
Reinforcement
Plate (Optional)
Strike Plate Strike Plate Screws (2) Latch Bolt Screws (2)
Reinforcement Plate
Screws (2)
(Optional)
Interior Assembly
4
Quick Start Guide
18
User
Manual
User Manual
17
Quick Start
Guide
3
Assembly View
2 3
7812
1.
2.
3.
4.
5.
Exterior Assembly
Latch Bolt
Mounting Plate
Interior Assembly
AA Batteries (4)
6. Battery Cover
7. Interior Assembly Screws (2) 13.Upper Screw and Screw Post (Optional)
14.Mechanical Keys (2)
8. Mounting Plate Screws (2)
9.
11.
12.
Reinforcement Plate (Optional)
Strike Plate Screws (2)
Reinforcement Plate Screws (Optional) (2)
10.Strike Plate
Latch Bolt Screws (2)
65
1
13 (Optional)14
413 (Optional)
1011 9
4
Exterior Assembly
Interior Assembly
Reset Button
Privacy Button
Thumb Turn
Battery Cover
Installation Buckle
1
2
3
4
5
1
2
4
3
5
1
2
4
3
6
5
Status Indicator
Touchscreen Keypad
Cancel Key
1
2
3
4
Keyhole Cover
5
Keyhole
6
5
door is 1-1/2’’ or 2-1/8" (38mm or 54mm).
door edge is 1" (25mm).
Install the Lock
1
either 2-3/8" or 2-3/4" (60mm or 70mm).
2
1’’
25 mm
Prepare the Door and Check the Dimensions
Required Tools
2-3/8’’ or 2-3/4’’
(60mm or 70mm)
Backset
1-3/8" to 2" (35mm to 50mm) thick.
3Make sure the hole in the door frame is
drilled a minimum of 1’’ (25mm) deep to
leave enough space for the deadbolt to
extend into the door frame when the
door is locked.
4
1-3/8’’ to 2’’
(35mm to 50mm)
1’’
25mm
Make sure the door frame is aligned with the door
and there are no obstructions in the door frame.
Attention
1-1/2" or 2-1/8"
(38mm or 54mm)
#2 Phillips Screwdriver
6
Determine the backset and adjust the
Latch Bolt.
6
Hold the Latch Bolt in front of the door hole,
door edge. Is the slotted hole centered in
the door hole?
No adjustment is required.
Proceed to the next step.
YES
The slotted hole is
NOT centered.
Rotate and pull the
Latch Bolt as
shown to extend it.
900
1800
NO
OPTIONAL: Drill a hole for Upper Screw.
5
Installing this screw onto the Exterior Assembly is OPTIONAL. It is used for additional security or when a door is weak
or warped.
Attention
2-3/4"
(70mm)
2-3/8"
(60mm)
Drilling Template
7
For a 1-1/2" (38 mm) bore hole, use a 1" (25 mm) Drill Bit to extend the latch hole
at least 13/64" (5 mm) deep.
No need to extend the latch hole for a 2-1/8" (54 mm) bore hole.
NO
1”
25 mm
At Least 13/64"
(5 mm) Deep
1" Drill Bit for Wood
Install the Latch Bolt.
7
Latch Bolt Screws
Chiseled
1
Not chiseled
1
Drive-In
Collar
234
2
Install the Latch Bolt and rotate it with a
If it cannot rotate smoothly because the door
hole is too small.
Remove the Latch Bolt and chisel out a small
channel at the top of the hole to give the cam
of the Latch Bolt room to rotate.
8
Chisel
Cam
8
