Philips AS170 Manuel utilisateur

www.philips.com/welcome

User manual

Always there to help you

AS170

Question?

Contact

Philips

Question?

Contact

Philips

1EN

Contents

1 Important 2

Important Safety Instructions 2

2 Your Docking System for Android™ 3

Introduction 3

What's in the box 3

Overview of the docking system 4

3 Get started 6

Connect power 6

Turn on 6

Select a source 6

Set time 6

4 Play through Bluetooth 8

Compatible with Android™ 8

Play audio through manual Bluetooth

connection 8

Play audio through auto Bluetooth

connection with Philips Bluetooth

Audio Connect 9

Disconnect a device 11

5 Dock and charge Android-

powered phone 13

Charge through Micro USB connector 13

Charge through USB socket 13

6 Listen to FM radio 15

Tune to FM radio stations 15

Store FM radio stations automatically 15

Store FM radio stations manually 15

Select a preset radio station 15

7 Play through audio cable 16

8 Other features 17

Set alarm timer 17

Set sleep timer 17

Adjust display brightness 17

9 Product information 18

General information 18

Bluetooth 18

Tuner (FM) 18

Amplier 18

Speakers 18

10 Troubleshooting 19

General 19

About Bluetooth device 19

11 Notice 20

Compliance 20

Recycling 20

Trademark notice 20

2EN

1 Important

Important Safety Instructions

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or

otherapparatus(includingampliers)that

produce heat.

• Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the apparatus.

• Onlyuseattachments/accessoriesspecied

by the manufacturer.

• Only use power supplies listed in the user

manual.

• Unplug this apparatus during lightning

storms or when unused for long periods

of time.

• Referallservicingtoqualiedservice

personnel. Servicing is required when

the apparatus has been damaged in any

way, such as power-supply cord or plug

is damaged, liquid has been spilled or

objects have fallen into the apparatus, the

apparatus has been exposed to rain or

moisture, does not operate normally, or

has been dropped.

• Apparatus shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on the

apparatus(e.g.liquidlledobjects,lighted

candles).

• Where the plug of the Direct Plug-in

Adaptor is used as the disconnect device,

the disconnect device shall remain readily

operable.

3EN

2 Your Docking

System for

Android™

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this docking system, you can:

• enjoy audio from your Bluetooth devices

or other external audio devices;

• charge your android-powered device;

• listen to FM radio; and

• wake up to buzzer alarm or radio.

What's in the box

Check and identify the contents of your

package:

• Main unit

• Power adapter

• Audio input cable (3.5 mm connectors)

• Short user manual

• Safety and notice

Quick start guide

4EN

Overview of the docking

system

a POWER

• Press to turn on the docking system or

switch it to standby mode.

b AUDIO IN

• Connect an external audio device.

c CHARGING

• Charge your mobile phone.

d FM ANTENNA

• Improve FM reception.

e DC IN

• Connect to the power adapter.

f SOURCE/SET

• Press to select a source: FM preset, FM,

Bluetooth, or AUX IN.

• Press and hold to start to set the clock.

• Press and hold to store preset radio

stations.

g Wheel

• Rotate to adjust the height of micro

USB connector.

h AL1/AL2

• Press and hold to start to set alarm.

• Press to view alarm settings.

• Press to activate or deactivate alarm

timer.

5EN

i SNOOZE/BRIGHTNESS/SLEEP

• Press and hold to set sleep timer.

• Press to adjust display brightness.

• Press to snooze alarm.

j Display panel

• Show current information.

k VOLUME +/-

• Press to increase or decrease the

volume.

l - TUNE/TIME/TUNE/TIME +

• Press and hold to search for FM radio

stations.

• Press to tune to FM radio stations in

FM mode.

• Press to select a preset radio station in

FM preset mode.

• Press to set the clock.

m Micro USB connector

6EN

3 Get started

Always follow the instructions in this chapter in

sequence.

Connect power

Caution

•Risk of product damage! Make sure that the power

supply voltage matches the voltage printed on the

bottom of the docking system.

•Risk of electric shock! When you unplug the AC

adapter, always pull the plug from the socket. Never

pull the cord.

Note

•The type plate is located on the bottom of the docking

system.

Connect the AC power adapter between

• the DC IN socket at the back of the

docking system, and

• the power supply.

Turn on

Press POWER.

» The docking system switches to the last

selected source.

Switch to standby mode

Press POWER again to switch the docking

system to standby mode.

» The clock (if set) is displayed.

Select a source

Press SOURCE/SET repeatedly to select a

source: FM preset, FM, Bluetooth, or AUX in.

Note

•When an android-powered device is docked, the

system automatically switches to Bluetooth mode.

Set time

1 Press and hold SOURCE/SET for two

seconds.

» [24H] or [12H] begins to blink.

2 Press - TUNE/TIME or TUNE/TIME+ to

select [24H] or[12H] for 12 or 24 hour

format.

3 Press SOURCE/SETtoconrm.

» The hour and minute digits begin to

blink.

4 Press - TUNE/TIME or TUNE/TIME+

repeatedly to set the hour.

ON Standby

POWER

7EN

5 Press SOURCE/SETtoconrm.

» Minute digits begin to blink.

6 Press - TUNE/TIME or TUNE/TIME+

repeatedly to set the minute.

7 Press SOURCE/SETtoconrm.

» The set time is displayed.

8EN

4 Play through

Bluetooth

With AS170, you can enjoy audio in two ways:

• through manual Bluetooth connection;

• through automatic Bluetooth connection

with Philips Bluetooth Audio Connect

app.

Compatible with Android™

To make full use of your docking system, your

Android-powered device should satisfy the

following requirements:

• With Android operation system

(Version 2.1 or above);

• With Bluetooth software (Version 2.1

or above); and

• With a micro USB connector.

For other devices with micro USB connector

and Bluetooth function, you can still use the

docking system to do the the following:

• Charge your device through the USB

connector;

• Enjoy audio through Bluetooth.

Play audio through manual

Bluetooth connection

The docking speaker uses Bluetooth wireless

technology to stream music from your portable

device to the speaker.

Note

•Philips does not guarantee the compatibility with all

Bluetooth devices.

•Before pairing a device with this docking speaker, read

its user manual for Bluetooth compatibility. Make sure

that the connected Bluetooth device supports the

AdvancedAudioDistributionProle(A2DP)andthe

AudioVideoRemoteControlProle(AVRCP).

•The product can memorize a maximum of 4 paired

devices.

•Make sure that Bluetooth function is enabled on your

device, and your device is set as visible to all other

Bluetooth devices.

•The operational range between this docking speaker

and a Bluetooth device is approximately 10 meters

(30 feet).

•Any obstacle between this docking speaker and a

Bluetooth device can reduce the operational range.

•Keep away from any other electronic device that may

cause interference.

Pair with Bluetooth devices

1 Press POWER to turn on the docking

system.

2 Press SOURCE/SET to select Bluetooth

mode.

» The Bluetooth indicator blinks on the

display panel.

3 On your Android-powered devices,

activate the Bluetooth feature and search

for AS170.

4 In the device list, tap PHILIPSAS170.

» After a successful connection, AS170

beeps twice and the Bluetooth

indicator turns steadily on.
