Philips KEY007 Manuel utilisateur
key007/ 0078/ 0079
key008
wearable digital camera user manual
2
Contents
Quick start .............................................................................. 3
Safety / Maintenance ............................................................. 4-5
Controls ................................................................................... 6-7
Minimum computer system requirements ...................... 8
About KEY camera ............................................................... 8
Supplied accessories ............................................................. 9
Neck strap................................................................................ 9
Power supply .......................................................................... 10
POWER indicator .................................................................. 11
Switching on/ off .................................................................... 12
MEMORY indicator ................................................................ 13
Taking pictures, lighting level ............................................... 14
Transferring/ viewing pictures ............................................. 15-18
Mass storage ........................................................................... 18
Photo Manager ....................................................................... 19
Troubleshooting ..................................................................... 20-21
Technical data ......................................................................... 22
© Koninklijke Philips Electronics N.V. ,2003.
All rights reserved. Reproduction, copying, usage, modifying, hiring, renting, public performance,
transmission and / or broadcasting in whole or in part is prohibited without the written consent of Philips.
3
Quick start
Thank you for buying this Philips wearable digital camera.To get started, follow
the steps as shown.
1 Charging
• Charge up your camera (3 hours) before using it. Detach the USB cover
and connect the camera to your computer's USB port. (Windows 98
users, please install required drivers first*).Your computer should be
switched on.While charging the POWER (green) indicator blinks.
2 Switch on & Snap
• Now your camera is ready for action -
simply turn the lens cap clockwise to
power ON. Hold the camera upright
and frame your subject through the
viewfinder. Press the shutter button.
3 Transfer
• Turn your camera OFF and connect it to your
computer's USB port.
Open Windows Explorer* and drag and drop
your pictures from your camera to your desired
destination folder.Alternatively, use Photo Manager
to transfer, enhance, edit and organize your
pictures.To install Photo Manager insert the by-
packed CD into your computer's CD-ROM drive.
The installation menu is automatically launched for first time users.
Find more information on the by-packed CD-ROM or visit
www.philips.com/support
*CAUTION!
For Windows 98 users only:
WHEN CONNECTING THE CAMERA FOR THE VERY FIRST TIME TO CHARGE
UP/ TRANSFER FILES, MAKE SURE YOU ONLY DO SO AFTER YOU HAVE
INSERTED THE SUPPLIED CD-ROM INTO THE CD-ROM DRIVE FOR
INSTALLATION OF THE REQUIRED DRIVERS.
4
Safety / maintenance
Take care when using KEY camera
•Traffic safety: do not use while driving or cycling as you may cause an
accident.
•Child safety: KEY camera neck strap is not a toy. Special care should be
taken if handled by young children.Avoid placing the neck strap around the
neck of a child to prevent strangulation!
To avoid damage or malfunction:
• this product is not waterproof: do not allow your camera to be
submersed in water, avoid exposing the USB socket to water.Water
entering the camera may cause major damage and rusting.
• do not use any cleaning agents containing alcohol, ammonia, benzene, or
abrasives as these may harm the set.
•avoid touching the lens Aand viewfinder Bwith your fingers.To
remove fingerprints, use a soft damp cloth.
• prevent damage to your eyes: do not look at the sun through the
viewfinder!
• Avoid sudden changes of temperature as this may cause condensation on
the lens and viewfinder.Allow the camera to adjust to the surrounding
temperature.
• do not drop your camera or allow objects to fall on camera. Strong shocks
and vibrations may cause malfunction.
• active mobile phones & strong magnetic fields in the vicinity may
cause interference.
Safety & satisfaction
• To enjoy your Philips product,please read and operate the set according to
the instructions inside our user manual (on the CD-ROM.)
• the supplied software CD-ROM is not an audio CD. Playing CD-ROMs on
audio equipment may damage your audio equipment!
5
Safety / maintenance
Environmental information
We have reduced the packaging to its minimum and made it easy to separate
into mono materials: PET, paper and aluminum foil.
Your set consists of material which can be recycled if disassembled by a
specialized company. Please observe the local regulations to dispose of
packaging, and old equipment.
Controls
6
KEY007/0078/0079
KEY008
1
2
3
4
5
6
7
8
1
3
9
10
11
Controls
7
1shutter button
press halfway down to help check
lighting levels.Press all the way
down to take your picture.
2metal strap hole
attach the supplied neck strap
here.
3viewfinder window
to help frame your picture subject
4lens
automatically opens when power
on.The lens is closed when the
power is off.
TIP:
– Make sure the lens is not obstructed /
covered when taking snaps!
5power on/ off
turn clockwise to switch on,
turn anti-clockwise to switch off.
6grip
place your finger/ thumb here to
turn the power control.
7USB port
Connect to your computer’s USB
port to charge the camera/
transfer files.
8USB cover
detach the protective USB cover
to reveal the camera’s USB port.
9Light level sensor
When you press the shutter
button halfway, the sensor lights
up red/ blinks/ remains unlit
according to surrounding light
level conditions.
0POWER
indicator lights up green/ blinks
according to power status/ file
transfer.
!MEMORY
indicator lights up yellow/ blinks/
remains unlit according to the
available memory on the camera.
The model and production numbers can be found next to the USB port
(please remove the USB cover to see)
Windows system requirements
– Pentium® MMX 166MHZ processor or better
– USB port withWindows® 98 / Me / 2000 / XP
– 96MB RAM
– 50MB free hard disk space
– CD ROM drive
– video display card
Minimum computer system requirements
8
CAUTION!
Computers that were upgraded from Windows 95 may not have USB
compatibility!
For Windows 98 users only:
• WHEN CONNECTINGTHE CAMERA FORTHEVERY FIRSTTIMETO
CHARGE UP/TRANSFER FILES, MAKE SUREYOU ONLY DO SO AFTER
YOU HAVE INSERTEDTHE SUPPLIED CD-ROM INTOTHE CD-ROM
DRIVE FOR INSTALLTION OFTHE REQUIRED DRIVERS.
Mac system requirements
– G3 or better
– Mac OS 9 - X
About KEY camera
KEY camera is a solid state, wearable, digital camera:
– capturesVGA (640 x 480) resolution still images
– stores hundreds of still images in JPEG format
– 1.3 Mega pixel output when you use with the supplied picture
enhancement software
– transfers image files usingWindows File Manager or Windows
Explorer, when the camera is connected via USB to your computer
– directly powered through your computer during file transfer to the camera.
Supplied accessories
9
Make sure these items are in the package. If any item is missing, please contact
your dealer.
1x CD-ROM (Photo Manager software & user manuals)
1x Quick Start Guide
1x neck strap
1x Safety &Warranty booklet
Neck strap
Thread the neck strap through the hole as
shown.
Power supply
10
This camera is powered by a built-in USB
rechargeable lithium battery which you can
charge direct from your computer.
TIP:
– When you use the camera for the very first time,
you’ll need to charge the battery before taking
pictures.
USB rechargeable battery
1Check the camera is in the power off
position. Detach the USB cover.
2Turn on your computer.
3Connect the camera’s USB port to the USB
port of your computer.
➜You will hear a double beep. Charging
starts immediately.While charging the
POWER (green) indicator blinks.
➜Make sure you leave your PC switched
on during charging. After approx. 3
hours, the battery is fully charged,
4Disconnect the camera and replace the USB
cover.
TIP:
– When you detach the USB cover, keep it in a safe place.
– To avoid damaging the USB port, always replace the USB cover when not connecting to
your computer.
– During USB connection/ battery charging, by default taking pictures is not possible.
–For Mac users: When connecting the camera to your computer, avoid using the USB
connection on your Mac keyboard as it doesn't have sufficient power to detect your
camera.
