User manual

AJ3400/93

www.philips.com/support

Always there to help you

Question?

Contact

Philips

Contents

1 Important 3

2 Your clock radio 4

What's in the box 4

3 Get started 4

Install battery 4

Connect power 5

Set time 5

4 Listen to FM radio 6

Tune to FM radio stations 6

Store FM radio stations manually 6

Select a preset radio station 6

Adjust volume 6

5 Other features 7

Set alarm timer 7

Set sleep timer 8

Adjust brightness 8

6 Product information 8

Specications 8

7 Troubleshooting 9

8 Notice 9

3EN

1 Important

• Read these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources such

as radiators, heat registers, stoves, or

otherapparatus(includingampliers)that

produce heat.

• Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the clock radio.

• Onlyuseattachments/accessoriesspecied

by the manufacturer.

• Unplug this clock radio during lightning

storms or when unused for long periods

of time.

• Referallservicingtoqualiedservice

personnel. Servicing is required when

the clock radio has been damaged in any

way, such as power-supply cord or plug

is damaged, liquid has been spilled or

objects have fallen into the clock radio, the

clock radio has been exposed to rain or

moisture, does not operate normally, or

has been dropped.

• Battery usage CAUTION – To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

clock radio:

• Install the battery correctly, + and - as

marked on the clock radio.

• Remove the battery when the clock

radio is not used for a long time.

• The battery shall not be exposed to

excessiveheatsuchassunshine,reor

the like.

• This clock radio shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on the

clockradio(e.g.liquidlledobjects,lighted

candles).

• Where the plug of the Direct Plug-in

Adapter is used as the disconnect device,

the disconnect device shall remain readily

operable.

4EN

2 Your clock radio

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

What's in the box

3 Get started

Always follow the instructions in this chapter in

sequence.

Install battery

If there is power interruption, the clock

memory backup allows your alarm and clock

settings to be stored for up to a day.The display

backlight will be off.

Caution

•Risk of explosion! Keep the battery away from heat,

sunshineorre.Neverdiscardbatteryinre.

•The battery contains chemical substances, so it should

be disposed of properly.

Insert2x1.5VAAAbattery(notsupplied)with

correctpolarity(+/-)asillustrated.





5EN

Connect power

Caution

•Risk of product damage! Make sure that the power

voltage corresponds to the voltage printed on the back

or underside of the clock radio.

•Risk of electric shock! When you unplug the power

adapter, always pull the plug from the socket. Never

pull the cord.

Note

•The type plate is located at the bottom of the clock

radio.

Set time

Note

•You can only set time in standby mode.

2 sec

PRESET/

SET TIME

PRESET/

SET TIME

HOUR

MIN

6EN

4 Listen to FM

radio

Note

•Keep the clock radio away from other electronic

devices to avoid radio interference.

•For better reception, fully extend and adjust the

position of the FM antenna.

Tune to FM radio stations

2 sec

RADIO

ON/OFF

MIN

TUNING

2 sec

HOUR

TUNING

- VOLUME +

Store FM radio stations

manually

You can store up to 10 FM radio stations.

1 Tune to an FM radio station.

2 Press and hold PRESET for two seconds.

» The preset number begins to blink.

3 Press TUNING repeatedly to select a

number.

4 Press PRESETagaintoconrm.

5 Repeat steps 1 to 4 to store other stations.

Tip

•To remove a pre-stored station, store another station

in its place.

Select a preset radio station

In tuner mode, press PRESET repeatedly to

select a preset number.

Adjust volume

While listening, press - VOLUME + to adjust

volume.

» Thevolumelevel(1~15)showsinthe

display.

7EN

5 Other features

Set alarm timer

Set alarm

Note

•You can only set the alarm in standby mode.

•When alarm sounds, volume rises gradually.You cannot

adjust the alarm volume manually.

•Make sure that you have set the clock correctly.

Followtheillustrationtosettherstalarm.

• AL1:settherstalarm.

• AL2: set the second alarm.

2 sec

AL1

HOUR

MIN

AL1

Tip

•The clock radio exits alarm setting mode when being

idle for 10 seconds.

Select alarm source

You can select FM radio or buzzer as the alarm

source.

» The corresponding alarm icon lights up.

• The AL2 setting is the same as AL1.

Activate/deactivate alarm timer

Press AL1 or AL2 repeatedly to activate or

deactivate the alarm timer.

» If the alarm timer is deactivated, the

alarm indicator turns off.

» The alarm repeats ringing for the next

day.

Snooze alarm

When alarm sounds, press SNOOZE.

» The alarm snoozes and repeats ringing

nine minutes later.

AL1FM

AL1

8EN

Set sleep timer

This clock radio can switch to standby mode

automatically after a preset period.

To deactivate the sleep timer:

• Press SLEEP repeatedly until [OFF]

(off)appears.

Adjust brightness

Press BRIGHTNESS repeatly to adjust display

brightness.

120 90 60 30 15

OFF

SLEEP

BRIGHTNESS

6 Product

information

Note

•Product information is subject to change without prior

notice.

Specications

Amplier

Total Output Power 0.4W RMS

Tuner (FM)

Tuning range 87.5-108 MHz

Tuning grid 50 KHz

Sensitivity

- Mono, 26 dB S/N Ratio

- Stereo, 46 dB S/N Ratio

<22 dBf

<49.5 dBf

Total Harmonic

Distortion <2%

Signal to Noise Ratio >50 dBA

General information

AC power

(poweradapter)

Brand name: Philips;

Model: AS030-050-

EB050;

Input: 100-240 V~,

50/60 Hz; 0.15 A;

Output: 5.0 V 0.5 A

Operation Power

Consumption 1.2 W

Standby Power

Consumption <1 W

Dimensions:

Main Unit

(WxHxD) 191 x 104 x 69 mm

Weight:

-Main Unit 0.33 kg

9EN

7 Troubleshooting

Warning

•Never remove the casing of this apparatus.

To keep the warranty valid, never try to repair

the system yourself.

If you encounter problems when using this

apparatus, check the following points before

requesting service. If the problem remains

unsolved, go to the Philips web site (www.

philips.com/welcome).Whenyoucontact

Philips, ensure that the apparatus is nearby

and the model number and serial number are

available.

No power

•Ensure that the AC power plug of the unit

is connected properly.

•Ensure that there is power at the AC

outlet.

No sound

•Adjust the volume.

No response from the unit

•Disconnect and reconnect the AC power

plug, then turn on the unit again.

Poor radio reception

•Increase the distance between the unit and

your TV or VCR.

•Fully extend the FM antenna.

Alarm does not work

•Set the clock/alarm correctly.

Clock/alarm setting erased

•Power has been interrupted or the power

plug has been disconnected.

•Reset the clock/alarm.

8 Notice

Any changes or modifications made to this

device that are not expressly approved by

WOOX Innovations may void the user’s

authority to operate the equipment.

Disposal of your old product

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

Do not throw away the product with the

normal household waste at the end of its life,

buthanditinatanofcialcollectionpointor

recycling. By doing this, you help to preserve the

environment.

Environmental information

All unnecessary packaging has been omitted. We

have tried to make the packaging easy to separate

intothreematerials:cardboard(box),polystyrene

foam(buffer)andpolyethylene(bags,protective

foamsheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

packaging materials, exhausted batteries and old

equipment.

Specifications are subject to change without notice

Philips and the Philips’ Shield Emblem are registered

trademarks of Koninklijke Philips N.V. and are used by WOOX

Innovations Limited under license from Koninklijke Philips N.V.

AJ3400_UM_93_V3.0
