EN 1

English

Contents

1 Important 2

Safety 2

Notice 2

2 Your car audio system 4

Introduction 4

What’s in the box 4

Overview of the main unit 5

3 Get started 7

Install the car audio 7

Turn on 11

Set clock 11

4 Listen to radio 13

Tune to a radio station 13

Store radio stations in memory 13

Tune to a preset station 13

5 Play audio ﬁles 14

Play a disc 14

Play from USB/SD/SDHC/MMC device 14

Control play 15

Search for an MP3/WMA track 15

View play information 15

Intro play 15

Shufﬂe play 16

Repeat play 16

Connect external sound source 16

6 Adjust sound 17

Adjust volume 17

Mute 17

Turn Dynamic Bass Boost (DBB) on/off 17

Select preset equalizer 17

Other sound settings 17

7 Adjust system settings 18

Select blackout setting 18

Turn demo mode on/off 18

Change button backlight color 18

Select start volume 18

Turn beep sound on/off 19

Turn display scroll on/off 19

Select shock-protect setting 19

Reset 19

8 Additional information 20

Detach the front panel 20

Replace fuse 20

Remove the unit 20

9 Product information 21

10 Troubleshooting 22

11 Glossary 23

2EN

1 Important

Safety

Read and understand all instructions•

before you use your apparatus. If damage is

caused by failure to follow instructions, the

warranty does not apply.

This apparatus is designed for negative•

ground (earth) 12 V DC operation only.

To ensure safe driving, adjust the volume to•

a safe and comfortable level.

Improper fuses can cause damage or•

ﬁre.When you need to change the fuse,

consult a professional.

Use only the supplied mounting hardware•

for a safe and secure installation.

To avoid short circuit, do not expose the•

apparatus to rain or water.

Never insert objects into the ventilation•

slots or other openings on the apparatus.

Clean the apparatus and frame with a soft,•

damp cloth. Never use substances such as

alcohol, chemicals or household cleaners

on the apparatus.

Never place any objects other than discs•

into the apparatus.

Never use solvents such as benzene,•

thinner, cleaners available commercially, or

anti-static sprays intended for discs.

Visible and invisible laser radiation when•

open. Avoid exposure to beam.

Risk of damage to the apparatus screen!•

Never touch, push, rub or strike the screen

with any object.

Caution

Use of controls or adjustments or performance of•

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

Notice

The making of unauthorized copies of copy-

protected material, including computer

programs, ﬁles, broadcasts and sound

recordings, may be an infringement of

copyrights and constitute a criminal offence.

This equipment should not be used for such

purposes.

This apparatus includes these labels:

Class II equipment symbol

This symbol indicates that the apparatus has a

double insulation system.

Recycling

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

When you see the crossed-out wheel bin

symbol attached to a product, it means the

product is covered by the European Directive

2002/96/EC:

EN 3

English

Never dispose of your product with other

household waste. Please inform yourself about

the local rules on the separate collection of

electrical and electronic products.The correct

disposal of your old product helps prevent

potentially negative consequences on the

environment and human health.

Your product contains batteries covered by the

European Directive 2006/66/EC, which cannot

be disposed of with normal household waste.

Please inform yourself about the local rules on

separate collection of batteries.The correct

disposal of batteries helps prevent potentially

negative consequences on the environment and

human health.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separate into three materials: cardboard (box),

polystyrene foam (buffer) and polyethylene

(bags, protective foam sheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

packaging materials, exhausted batteries and old

equipment.

Any changes or modiﬁcations made to this

device that are not expressly approved by

Philips Consumer Lifestyle may void the user’s

authority to operate the equipment.

2009 © Koninklijke Philips Electronics N.V. All

rights reserved.

Speciﬁcations are subject to change without

notice.Trademarks are the property of

Koninklijke Philips Electronics N.V. or their

respective owners. Philips reserves the right

to change products at any time without being

obliged to adjust earlier supplies accordingly.

4EN

2 Your car audio

system

Congratulations on your purchase, and

welcome to Philips! To fully beneﬁt from the

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With the in-car audio system, you can enjoy

your drive while you listen to:

FM or AM (MW) radio•

Audio from CD or MP3 disc•

Audio from a USB drive•

Audio from a SD/MMC card•

Audio from external devices•

What’s in the box

Check and identify the contents of your

package:

aIn-car audio system

bRubber cushion

cScrew (4 pieces)

dDisassembly tool ( 2 pieces)

eFront panel

fTrim plate

gCarrying case for front panel

hUser manual

iQuick start guide

jStandard connector

dce

EN 5

English

Overview of the main unit

Select tuner band.•

Select MP3/WMA folder.•

Scroll up or down menu.•

bDBB

Turn on or off Dynamic Bass Boost•

(DBB) sound.

cSOURCE

Select audio source.•

d/MUTE

Turn the unit on or off.•

Adjust volume.•

Conﬁrm selection.•

abdghi

xwut

r q po nml kj

Enter characters for search.•

Mute or restore volume.•

eMENU / DISP

Display radio frequency, clock and•

radio program type (if available).

Display track, elapsed time, artist,•

album, title, folder, ﬁle and clock.

Access system menu.•

Return to previous menu.•

Stop search.•

Disable screen blackout.•

gDisplay panel

6EN

Unlock the panel•

iUSB socket

jExternal device socket

Select preset station no. 6•

Select preset station no. 5•

mSHUF, 4

Activate or deactivate shufﬂe mode.•

Select preset station no. 4•

n3, REP

Set repeat play mode.•

Select preset station no. 3•

oINTRO, 2

Turn intro play on or off.•

Select preset station no. 2•

p1,

Start play•

Pause or resume play.•

Select preset station no. 1•

Tune to a radio station•

Skip/search for a track.•

rEQ/Audio

Select equalizer (EQ) setting.•

Access audio setting menu.•

sSEARCH

Store radio stations automatically.•

Search a track or folder.•

tPanel power connection

uDisc slot

Take disc out.•

wRESET

Restore default settings•

xSD/MMC card slot

EN 7

English

3 Get started

Caution

Use the controls only as stated in this user manual.•

Always follow the instructions in this chapter in

sequence.

If you contact Philips, you will be asked for the

model and serial number of your apparatus.The

model number and serial number are on the

bottom of your apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Install the car audio

These instructions are for a typical installation.

However, if your car has different requirements,

make the corresponding adjustment. If you have

any questions regarding installation kits, consult

your Philips car audio dealer.

Caution

This unit is designed for negative ground (earth) 12 V DC•

operation only.

Always install this unit in the car dashboard. Other

•

locations can be dangerous as the rear of the unit heats

up during use.

To avoid short-circuit: before you connect, ensure that

•

the ignition is off.

Ensure that you connect the yellow and red power

•

supply leads after all other leads are connected.

Ensure that all loose leads are insulated with electrical

•

tape.

Ensure that the leads do not get caught under screws

•

orin parts that will move (e.g. seat rail).

Ensure that all ground (earth) leads are run to a common

•

ground (earth) point.

Use only the supplied mounting hardware for a safe and

•

secure installation.

Improper fuses can cause damage or ﬁre.When you

•

need to change the fuse, consult a professional.

Note on the power supply lead (yellow)

When you connect other devices to this•

apparatus, ensure that the rating of the car

circuit is higher than the total fuse value of

all the connected devices.

Notes on speaker connection

Never connect speaker wires to the metal•

body or chassis of the car.

Never connect speaker wires with stripes•

to one another.

Overview of parts

These are the supplied parts needed to

connect and install this unit.

aIn-car audio system

bSleeve

cFront panel

dTrim plate

eRubber cushion

fDisassembly tools

gScrews (4 pieces)

hISO connector

efgh

8EN

Connection: for cars with ISO

connectors

Caution

Ensure that all loose leads are insulated with electrical•

tape.

1Pull out the ISO connectors from car

dashboard and connect them to the bigger

end of the supplied standard connector.

2Connect the other end of the supplied

standard connector to the unit.

3Connect the antenna and ampliﬁer as

illustrated, if applicable.

Connector Connect to

1 REAR LINE OUT R Rear right speaker

2 REAR LINE OUT L Rear left speaker

3 SUB OUT Subwoofer

4 ANTENNA Antenna

Connection: for cars without ISO

connectors

Caution

Be sure to connect the black ground (earth) lead ﬁrst.•

A1A2 A3 A4 A5 A6 A7 A8

B1B2 B3 B4 B5 B6 B7 B8

abcd

EN 9

English

1Connect the antenna and ampliﬁer as

illustrated, if applicable.

Connector Connect to

1 REAR LINE OUT R Rear right speaker

2 REAR LINE OUT L Rear left speaker

3 SUB OUT Subwoofer

4 ANTENNA Antenna

2Cut off the bigger end of the supplied

standard connector.

3Check the car’s wiring carefully and

connect them to the supplied standard

connector.

A1A2 A3 A4 A5 A6 A7 A8

B1B2 B3 B4 B5 B6 B7 B8

abcd

1 Green/black strip Left speaker (Rear)

2 White/black strip Left speaker (Front)

3 Gray/black strip Right speaker (Front)

4 Purple/black strip Right speaker (Rear)

e RED Ignition key +12V DC

when ON/ACC

f BLUE Motor/electric antenna

relay control lead/Ampliﬁer

relay control lead

g BLACK Ground

h PINK Illumination switch

i YELLOW To the +12V car battery

which is energized at all

times

bcd

ghi

Autres manuels pour CEM220

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Récepteur de voiture

Philips

Philips CarStudio CEM5100 Manuel utilisateur

Philips

Philips CEM250X/78 Manuel utilisateur

Philips

Philips Sonicare 400 Series Manuel utilisateur

Philips

Philips CEM3000/51 Manuel utilisateur

Philips

Philips CED320 Manuel utilisateur

Philips

Philips CarStudio CEM3100 Manuel utilisateur

Philips

Philips CEM1100/00 Manuel utilisateur

Philips

Philips CEM2101/98 Manuel utilisateur

Philips

Philips CED1900BT Manuel utilisateur

Philips

Philips CE235BT Manuel utilisateur

Philips

Philips CEM2250/51 Manuel utilisateur

Philips

Philips CED228/58 Manuel utilisateur

Philips

Philips CarStudio CEM3100 Manuel utilisateur

Philips

Philips CEM250/93 Manuel utilisateur

Philips

Philips CEM2100 Manuel utilisateur

Philips

Philips CE152 Manuel utilisateur

Philips

Philips CEM5000/55 Manuel utilisateur

Philips

Philips CEM3000 Manuel utilisateur

Philips

Philips CEM3000X/78 Manuel utilisateur

Philips

Philips CED228 Manuel utilisateur

Philips

Philips CE150 Manuel utilisateur

Philips

Philips CEM3000B/05 Manuel utilisateur

Philips

Philips CMD305A/05 Manuel utilisateur

Philips

Philips CEM2000B/05 Manuel utilisateur

Manuels Récepteur de voiture populaires d'autres marques

Motorola

Motorola VWA63 Manuel utilisateur

Nextar

Nextar D3201 Manuel utilisateur

Alpine

Alpine CDE-163BT Manuel utilisateur

Pioneer

Pioneer DEH-P645R Manuel utilisateur

Axxera

Axxera XDMA7600 Mode d'emploi

XM OnyX Manuel utilisateur

Sound Storm

Sound Storm STM93R Manuel utilisateur

Soundstream

Soundstream VIR-5000 Manuel utilisateur

Avson

Avson MKT Platform Manuel utilisateur

Sony

Sony MEX-1HD - Audio Library System Manuel utilisateur

Pioneer

Pioneer DVH-P500UB Manuel utilisateur

JVC

JVC KD-AHD69 Manuel utilisateur

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manuel utilisateur

Sony

Sony CDX-4160 - Cd Receiver Manuel utilisateur

XFIRE AUDIO

XFIRE AUDIO BMW42S Manuel utilisateur

VDO

VDO CD 2253 Manuel utilisateur

Volvo

Volvo 13 84 580 Manuel utilisateur

ZENEC

ZENEC ZE-160DVD Manuel utilisateur
