Philips CED229/56 Manuel utilisateur

CED229/55

CED229/56

www.philips.com/welcome

Português do Brasil 49English 3

Spanish - Argentinean 23

English

Contents

1 Important 4

2 Your car audio system 5

Introduction 5

3 Play 6

Load and eject discs 6

Insert and remove USB device 6

Insert and remove SD/MMC card 7

Skip/search 7

Intro play 8

Repeat play 8

Random play 8

Select Language 9

Dynamic Bass Boost 9

MAX sound 9

Zoom 10

4 Radio 11

Select tuner sensitivity 11

Manual tune to a radio station 11

Auto tune to a radio station 12

Store stations manually 12

Store stations automatically 12

Select the preset station 12

Select stereo or mono broadcasting 12

5 System settings 14

Adjust general settings 14

Select DVD video settings 14

Select language settings 15

Adjust radio settings 15

6 Other settings 16

Select equalizer settings 16

Control zone settings 16

Other sound settings 17

SelectVideo Output format 18

Turn on or off the screen backlight 18

Reset 18

Replace fuse 18

7 Product information 19

General 19

Disc player 19

Tuner 19

LCD 19

Compatible USB devices 20

Supported formats 20

Unsupported formats 20

8 Troubleshooting 21

9 Notice 22

4EN

1 Important

 Read and understand all instructions

before you use the apparatus. If damage is

caused by failure to follow instructions, the

warranty does not apply.

 Use of controls or adjustments or

performance of procedures other than

herein may result in hazardous radiation

exposure or other unsafe operation.

 This unit is designed for negative ground

(earth) 12V DC operation only.

 

watch video during driving.

 To ensure safe driving, adjust the volume to

a safe and comfortable level.

 Improper fuses can cause damage or



consult a professional.

 Use only the supplied mounting hardware

for a safe and secure installation.

 To avoid short circuit, do not expose the

apparatus, remote control or remote

control batteries to rain or water.

 Never insert objects into the ventilation

slots or other openings on the apparatus.

 Never place any objects other than discs

into the disc tray/slot.

 Visible and invisible laser radiation when

open.Avoid exposure to beam.

 Risk of damage to the screen! Never touch,

push, rub or strike the screen with any object.

 Never use solvents such as benzene,

thinner, cleaners available commercially, or

anti-static sprays intended for discs.

 Clean the apparatus with soft, damp cloth.

Never use substances such as alcohol,

chemicals or household cleaners on the

apparatus.

English

2 Your car audio

system

Congratulations on your purchase, and

welcome to Philips!



Philips offers, register your product at

www.Philips.com/welcome.

Read this user manual carefully before you

install and use the unit. Save it for future

reference.

Introduction



your drive while you listen to:

 

 Audio from a USB drive, a SD/SDHC card,

external devices.

 Music CDs

 DVD and VCD video

6EN

3 Play

Make sure that the disc or device contains

playable music or video.

Note

 

session is played.

 Does not support MP3 Pro audio format.

 It may not support and display special characters track

name (ID3) or album name properly.

 

Management (DRM).

 

that exceed the supporting limit.

Warning

 

video during driving.

Load and eject discs

1 Press to open the front panel.

2 Insert the disc into the disc slot with label

side facing up.

» Play resumes from the point where it

was last stopped.

3 To remove the disc, press the button.

» 

unit switches toTUNER mode

automatically.

4 Close the front panel.

» After a few seconds, the screen

illuminates.

 For video discs, press or to select

an item, then press to start playing.

 

JPEGs, press or to select a folder,

track or picture. Press to start playing.

Tip

 If the disc is blocked in the disc compartment, press and

hold the button until the disc comes out.

Insert and remove USB device

1 Slide down the USB socket cover.

2 Insert the USB device into the USB socket.

» The unit starts playing from the USB

device automatically.

English

3 To remove the USB device, press to

turn off the unit.

4 Remove the USB device.

Insert and remove SD/MMC

card

1 Press to open the front panel.

2 Insert SD or SDHC card into the card slot.

» The unit starts playing from the SD/

SDHC card automatically.

3 To remove the SD or SDHC card, press

to turn off the unit.

4 Press the card until you hear a click sound.

» The card is now disengaged.

Skip/search

During video and audio disc play

 

press the numeric buttons.

 To skip to the previous or next chapter or

track, press or .

 To search backward or forward quickly,

press or for 3 seconds.

 Press to resume normal play.

During MP3/WMA play

 

twice to display the folder list. Press

or to select, and then press to



 or within

the folder. Press 

8EN

 

press the numeric buttons.

Intro play



audio track.

Press the button to enable and

disable this function.

Repeat play

There are 3 standard modes of repeat play for



Press the button repeated to select.

 [REP ONE]: play the current chapter or

track repeatedly.

 [REP DIR]: play the current folder

repeatedly.

 [REP ALL]: play all chapters in the title or

all tracks repeatedly.

 [REP CANCEL]: cancel repeat play.

Random play

There are 3 standard modes of random play for



Press the button repeatedly to select.

 [SHUFFLE ALL]: start random play for all

tracks.

 [SHUFFLE DIR]: start random play in

current folder.

 [SHUFFLE OFF]: cancel random play.

English

Select Language

Subtitle

You can select the subtitle language if the DVD

discs contain two or more subtitle languages.

During play, press on the remote

control repeatedly until the language is selected.

Audio

You can select the audio language if the video

discs contain two or more audio channels.

During play, press on the remote control

repeatedly until the language is selected.

Dynamic Bass Boost

1 Press / on the car audio

system for 3 seconds or press on the

remote control.

» [DBB ON]:The Dynamic Bass Boost

(DBB) function is on.

» [DBB OFF]:The DBB function is off.

2 Press again to change the DBB setting.

MAX sound

1 Press / to produce an

instant boost in bass and maximize volume.

2 Press / again to turn off.

10 EN

Zoom

To zoom in and out of video images and

pictures:

1 Press on the remote control

repeatedly.

» [ZOOM] is displayed.

2 Press the navigation buttons to pan across

the display.

English

4 Radio

Select tuner sensitivity

Before you start to search for radio station, you

can select tuner sensitivity.

1 Press .

» The main menu is displayed.

2 Press the navigation buttons to select

[SETTINGS], then press on remote

control or 

3 Press or button to select .

4 Press to select [LOC_DX],

5 Press again to reach the [LOC_DX]

option list.

 [LOC]: only broadcast local stations

with strong signals.

 [DX]: broadcast any stations with

strong and weak signals.

6 Press or button to select [LOC]

or[DX] , then press on remote control

or 

Manual tune to a radio

station

1 Press until you select radio.

2 Press and hold or to select band.

» [FM-1], [FM-2], [FM-3], [FM], [MW-1],

or [MW-2] is display.
