DATA SHEET
Product specification
File under Discrete Semiconductors, SC16 February 1994
DISCRETE SEMICONDUCTORS
Philips Semiconductors
BGD602
CATV amplifier module
February 1994 2
Philips Semiconductors Productspecification
CATV amplifier module BGD602
FEATURES
•Excellent linearity
•Extremely low noise
•Silicon nitride passivation
•Rugged construction
•Gold metallization ensures
excellent reliability.
DESCRIPTION
Hybrid high dynamic range amplifier
module designed for applications in
CATV systems with a bandwidth of
40 to 600 MHz operating with a
voltage supply of 24 V (DC).
PINNING - SOT115J
PIN DESCRIPTION
1 input
2 common
3 common
5+V
B
7 common
8 common
9 output Fig.1 Simplified outline.
f
page
789
2351
Side view
MSA319
QUICK REFERENCE DATA
LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 134).
SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT
Gppower gain f = 50 MHz 18 19 dB
f = 600 MHz 19 −dB
Itot total current consumption (DC) VB= 24 V −435 mA
SYMBOL PARAMETER MIN. MAX. UNIT
ViRF input voltage −65 dBmV
Tstg storage temperature −40 +100 °C
Tmb operating mounting base temperature −20 +100 °C
February 1994 3
Philips Semiconductors Productspecification
CATV amplifier module BGD602
CHARACTERISTICS
Bandwidth 40 to 600 MHz; VB= 24 V; Tmb = 35 °C; ZS= ZL= 75 Ω.
Notes
1. fp= 55.25 MHz; Vp= 44 dBmV;
fq= 541.25 MHz; Vq= 44 dBmV;
measured at fp+ fq= 596.5 MHz.
2. Measured according to DIN45004B:
fp= 590.25 MHz; Vp= Vo;
fq= 597.25 MHz; Vq= Vo−6 dB;
fr= 599.25 MHz; Vr= Vo−6 dB;
measured at fp+ fq−fr= 588.25 MHz.
3. The module normally operates at VB= 24 V, but is able to withstand supply transients up to 30 V.
SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT
Gppower gain f = 50 MHz 18 19 dB
f = 600 MHz 19 −dB
SL slope cable equivalent f = 40 to 600 MHz 0.2 2.2 dB
FL flatness of frequency response f = 40 to 600 MHz −±0.3 dB
S11 input return losses f = 40 to 80 MHz 20 −dB
f = 80 to 160 MHz 19 −dB
f = 160 to 600 MHz 18 −dB
S22 output return losses f = 40 to 80 MHz 20 −dB
f = 80 to 160 MHz 19 −dB
f = 160 to 600 MHz 18 −dB
S21 phase response f = 50 MHz −45 +45 deg
CTB composite triple beat 85 channels flat;
Vo= 44 dBmV;
measured at 595.25 MHz
−−62 dB
Xmod cross modulation 85 channels flat;
Vo= 44 dBmV;
measured at 55.25 MHz
−−66 dB
CSO composite second order distortion 85 channels flat;
Vo= 44 dBmV;
measured at 596.5 MHz
−−60 dB
d2second order distortion note 1 −−70 dB
Vooutput voltage dim = −60 dB; note 2 63 −dBmV
F noise figure f = 600 MHz −8dB
I
tot total current consumption (DC) note 3 −435 mA
February 1994 4
Philips Semiconductors Productspecification
CATV amplifier module BGD602
CHARACTERISTICS
Bandwidth 40 to 550 MHz; VB= 24 V; Tmb = 35 °C; ZS= ZL= 75 Ω.
Notes
1. fp= 55.25 MHz; Vp= 44 dBmV;
fq= 493.25 MHz; Vq= 44 dBmV;
measured at fp+ fq= 548.5 MHz.
2. Measured according to DIN45004B:
fp= 540.25 MHz; Vp= Vo;
fq= 547.25 MHz; Vq= Vo−6 dB;
fr= 549.25 MHz; Vr= Vo−6 dB;
measured at fp+ fq−fr= 538.25 MHz.
3. The module normally operates at VB= 24 V, but is able to withstand supply transients up to 30 V.
SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT
Gppower gain f = 50 MHz 18 19 dB
f = 550 MHz 18.8 −dB
SL slope cable equivalent f = 40 to 550 MHz 0.2 2.2 dB
FL flatness of frequency response f = 40 to 550 MHz −±0.3 dB
S11 input return losses f = 40 to 80 MHz 20 −dB
f = 80 to 160 MHz 19 −dB
f = 160 to 550 MHz 18 −dB
S22 output return losses f = 40 to 80 MHz 20 −dB
f = 80 to 160 MHz 19 −dB
f = 160 to 550 MHz 18 −dB
S21 phase response f = 50 MHz −45 +45 deg
CTB composite triple beat 77 channels flat;
Vo= 44 dBmV;
measured at 547.25 MHz
−−66 dB
Xmod cross modulation 77 channels flat;
Vo= 44 dBmV;
measured at 55.25 MHz
−−68 dB
CSO composite second order distortion 77 channels flat;
Vo= 44 dBmV;
measured at 548.5 MHz
−−62 dB
d2second order distortion note 1 −−72 dB
Vooutput voltage dim = −60 dB; note 2 64 −dBmV
F noise figure f = 550 MHz −7.5 dB
Itot total current consumption (DC) note 3 −435 mA
February 1994 5
Philips Semiconductors Productspecification
CATV amplifier module BGD602
CHARACTERISTICS
Bandwidth 40 to 450 MHz; VB= 24 V; Tmb = 35 °C; ZS= ZL= 75 Ω.
Notes
1. fp= 55.25 MHz; Vp= 46 dBmV;
fq= 391.25 MHz; Vq= 46 dBmV;
measured at fp+ fq= 446.5 MHz.
2. Measured according to DIN45004B:
fp= 440.25 MHz; Vp= Vo;
fq= 447.25 MHz; Vq= Vo−6 dB;
fr= 449.25 MHz; Vr= Vo−6 dB;
measured at fp+ fq−fr= 438.25 MHz.
3. The module normally operates at VB= 24 V, but is able to withstand supply transients up to 30 V.
SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT
Gppower gain f = 50 MHz 18 19 dB
f = 450 MHz 18.6 −dB
SL slope cable equivalent f = 40 to 450 MHz 0.2 1.8 dB
FL flatness of frequency response f = 40 to 450 MHz −±0.3 dB
S11 input return losses f = 40 to 80 MHz 20 −dB
f = 80 to 160 MHz 19 −dB
f = 160 to 450 MHz 18 −dB
S22 output return losses f = 40 to 80 MHz 20 −dB
f = 80 to 160 MHz 19 −dB
f = 160 to 450 MHz 18 −dB
S21 phase response f = 50 MHz −45 +45 deg
CTB composite triple beat 60 channels flat;
Vo= 46 dBmV;
measured at 445.25 MHz
−−67 dB
Xmod cross modulation 60 channels flat;
Vo= 46 dBmV;
measured at 55.25 MHz
−−66 dB
CSO composite second order distortion 60 channels flat;
Vo= 46 dBmV
measured at 446.5 MHz
−−60 dB
d2second order distortion note 1 −−75 dB
Vooutput voltage dim = −60 dB; note 2 67 −dBmV
F noise figure f = 450 MHz −7dB
I
tot total current consumption (DC) note 3 −435 mA
February 1994 6
Philips Semiconductors Productspecification
CATV amplifier module BGD602
DEFINITIONS
LIFE SUPPORT APPLICATIONS
These products are not designed for use in life support appliances, devices, or systems where malfunction of these
products can reasonably be expected to result in personal injury. Philips customers using or selling these products for
use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such
improper use or sale.
Data sheet status
Objective specification This data sheet contains target or goal specifications for product development.
Preliminary specification This data sheet contains preliminary data; supplementary data may be published later.
Product specification This data sheet contains final product specifications.
Limiting values
Limiting values given are in accordance with the Absolute Maximum Rating System (IEC 134). Stress above one or
more of the limiting values may cause permanent damage to the device. These are stress ratings only and operation
of the device at these or at any other conditions above those given in the Characteristics sections of the specification
is not implied. Exposure to limiting values for extended periods may affect device reliability.
Application information
Where application information is given, it is advisory and does not form part of the specification.
