Slim Multisensor PST02-A/B/C

The slim multisensor PST02 has PIR, door/window, temperature and

illumination, 4 sensors function in one, based on Z-WaveTM technology.

It is the Z-WaveTM plus product, it support the security, OTA... Those

newest features of the Z-WaveTM technology. Z-WaveTM is a wireless

communication protocol designed for home automation, specifically to

remotely control applications in residential and light commercial

environments. The technology uses a low-power RF radio embedded or

retrofitted into home electronics devices and systems, such as lighting,

home access control, entertainment systems and household appliances.

This product can be included and operated in any Z-WaveTM network

with other Z-WaveTM certified devices from other manufacturers and/or

other applications. All non-battery operated nodes within the network

will act as repeaters regardless of vendor to increase reliability of the

network.

The device adopt the Z-Wave

TM 500 series chip, when your Z-WaveTM

network system is all made by Z-WaveTM 500 series devices. The

network system will have the advantages as below.

•Concurrent multi-channel support reduces external interference.

•Better RF range, improve about 10 meters in indoor.

•Support 100 Kbps transmit speed, speed up communication.

Function Compare A/B/C

PIR Door/Window Temp erat ure Illumination

PST02-A V V V V

PST02-B V V V

PST02-C V V V

Add to/Remove from Z-WaveTM Network

There are two tamper keys in the device, one is in the back side,

another is in the front side. Both of them can add, remove, reset or

association from Z-WaveTM network.

In the first time, add the device into the Z-WaveTM network. First, make

sure the primary controller is in the add mode. And then power on the

device, just take out the insulation Mylar in the back side of the device.

The device will auto start the NWI (Network Wide Inclusion) mode. And

it should be included in 5 seconds. You will see the LED light ON one

second.

Notice: Including a node ID allocated by Z-WaveTM Controller means

“Add” or “Inclusion”. Excluding a node ID allocated by Z-WaveTM

Controller means “Remove” or “Exclusion”.

Function Description

Add

1. Have Z-WaveTM Controller entered inclusion mode.

2. Pressing tamper key three times within 1.5 seconds

to enter the inclusion mode.

3. After add successful, the device will wake to

receive the setting command from Z-WaveTM

Controller about 20 seconds.

Remove

1. Have Z-WaveTM Controller entered exclusion mode.

2. Pressing tamper key three times within 1.5 seconds

to enter the exclusion mode.

Node ID has been excluded.

Reset

Notice: Use this procedure only in the event

that the primary controller is lost or

otherwise inoperable.

1. Pressing tamper key four times within 1.5 seconds

and do not release the tamper key in the 4th

pressed, and the LED will light ON.

2. After 3 seconds the LED will turn OFF, after that

within 2 seconds, release the tamper key. If

successful, the LED will light ON one second.

Otherwise, the LED will flash once.

3. IDs are excluded and all settings will reset to

factory default.

Association 1. Have Z-WaveTM Controller entered association

mode.

2. Pressing tamper key three times within 1.5 seconds

to enter the association mode.

Note: The device support 2 groups. The group 1 is for

receiving the report message, like triggered event,

temperature, illumination etc. The group 2 is for light

control, the device will send the “Basic Set” command

to this group. And each group support 8 nodes

maximum.

•Failed or success in add/remove the node ID can be viewed

from Z-WaveTM Controller.

Notice 1: Always RESET a Z-WaveTM device before trying to add it to a

Z-WaveTM network

Notice 2: When the device into NWI mode, the sensor functionality

will useless. The NWI mode will timeout after 30 seconds. You can

press the tamper key 3 times to abort the NWI mode.

Z-WaveTM Notification

After the device adding to the network, it will wake-up once per day in

default. When it wake-up it will broadcast the “Wake Up Notification”

message to the network, and wake-up 10 seconds for receive the

setting commands.

The wake-up interval minimum setting is 30 minutes, and maximum

setting is 120 hours. And the interval step is 30 minutes.

If the user want to wake-up the device immediately, please remove the

front cover, and press the tamper key once. The device will wake-up 10

seconds.

Z-WaveTM Message Report

When the PIR motion triggered or the door/windows triggered, the

device will report the trigger event and also report the battery status,

temperature and illumination level.

In default the device will using Notification Report to represent the

trigger event, it can be changed to Sensor Binary Report by setting the

configuration NO. 7 Bit4 to 1.

* Motion Report:

When the PIR motion detected, the device will unsolicited to send the

report to the nodes in the group 1.

Notification Report (V4)

Notification Type: Home Security (0x07)

Event: Motion Detection, Unknown Location (0x08)

Sensor Binary Report (V2)

Sensor Type: Motion (0x0C)

Sensor Value: 0xFF

* Door/Window Report:

When the door/window state changed, the device will unsolicited to

send the report to the nodes in the group 1.

Notification Report (V4)

Notification Type: Access Control (0x06)

Event: Door/Window is open (0x16)

Door/Window is closed (0x17)

Sensor Binary Report (V2)

Sensor Type: Door/Window (0x0A)

Sensor Value: 0x00 is closed, 0xFF is opened.

* Tamper Report:

Both the 2 tamper keys are pressed over 5 seconds. The device will

into the alarm state. In that state, if any one of the tamper keys be

released, the device will unsolicited to send the report to the nodes in

the group 1.

Notification Report (V4)

Notification Type: Home Security (0x07)

Event: Tamp e ri n g. Produ c t c ov er i ng re m ov ed (0x03)

Sensor Binary Report (V2)

Sensor Type: Tamper (0x08)

Sensor Value: 0xFF

* Temperature Report:

When the PIR motion detected or the door/window state changed, the

device will unsolicited to send the “Sensor Multilevel Report” to the

nodes in the group 1.

Sensor Type: Temperature (0x01)

Note: To disable this functionality by setting the configuration N0.5 bit5

to 1.

*** Temperature differential report ***

This function default is enabled, to disable this function by setting the

configuration NO.21 to 0.

In the default, when the temperature is changed to plus or minus one

degree Fahrenheit (0.56 degree Celsius), the device will report

temperature information to the nodes in the group 1.

The device will measure the temperature in every one minute. And if

the temperature is over 140 degree Fahrenheit (60 degree Celsius), the

device will always report in each measurement.

Caution 1:

Enable this functionality, it will cause the PIR Motion to

disable detection when the temperature measurement. In other words,

The PIR motion will blind one second in every one minute.

* Illumination Report:

When the PIR motion detected or the door/window state changed, the

device will unsolicited to send the “Sensor Multilevel Report” to the

nodes in the group 1.

Sensor Type: Luminance (0x03)

Note: To disable this functionality by setting the configuration N0.5

bit4 to 1.

*** Illumination differential report ***

This function default is disabled, to enable this function by setting the

configuration NO.22 not to zero.

Enable this functionality, the device will measure the illumination in

every one minute. And if the illumination is changed to plus or minus

the value (setting by the configuration NO.22), the device will report

illumination information to the nodes in the group 1.

Caution 1:

Enable this function will reduce the battery life about 15%

~ 20%. And another issue is setting the differential value too small, it

will cause report too frequency, shorter the battery life more.

Propose the setting differential value should not small than 10.

Caution 2:

If the configuration No.4 is setting to 0 or 100, this

functionality is useless.

Caution 3:

Enable this functionality, it will cause the PIR Motion to

disable detection when the illumination measurement. In other words,

The PIR motion will blind one second in every one minute.

* Timing Report:

Beside the event triggered could report message, the device also

support the timing unsolicited report of the status.

•Battery level report: Every 6 hours report once in default.

It could be changed by setting the configuration NO. 10.

•Low battery report: When the battery level is too low, every 30

minutes will report once.

•Door/window state report: Every 6 hours report once in default.

It could be changed by setting the configuration NO. 11.

•Illumination level report: Every 6 hours report once in default.

It could be changed by setting the configuration NO. 12.

•Temp erat ure repo rt : Ever y 6 hou rs re po rt on ce in d efault .

It could be changed by setting the configuration NO. 13.

Notice: The configuration NO. 10, 11, 12 and 13 could be setting to

zero to disable the auto report. And the configuration NO. 20 could

change the tick interval, the default value is 30, if setting to 1, that

means the minimum auto report interval will be one minute. And please

notice if setting this value to zero, that means disable all of the timing

report except the low battery detection.

Power Up Procedure

* Battery Power Check

When the device power up, the device will detect the power level of the

battery immediately. If the power level is too low, the LED will continue

flash about 5 seconds. Please change another new battery.

* PIR Warm Up

When the device power on, the PIR need to warm up before the

operation. The warm up time about 1 minute, the LED will flash in

every 2 seconds. After finish the procedure the LED will light ON three

times.

* NWI

When the device power on, the device will check is it already adding to

the network? If doesn't, it will auto start the NWI mode. The LED will

flash in every second and continue 30 seconds. Until timeout or the

device successful to inclusion by controller. The use can presses the

tamper key 3 times to abort the NWI mode.

* Wake

When the device power on, the device will wake about 20 seconds. In

this duration, the controller can communicate with the device. Normally

the device is always sleeping to save the battery energy.

Over The Air (OTA) Firmware Update

The device support the Z-Wave firmware update via OTA.

Before starting the procedure, please remove the front cover of the

device. Otherwise the hardware check will be failed.

Let the controller into the firmware update mode, and then press the

front tamper key once to start the update.

After finish the firmware download, the LED will start flash in every 0.5

second. At that time,

please don't remove the battery

, otherwise it

will cause the firmware broken, and the device will no function.

After the LED stop flash, it is recommended that the user power up the

device. Caution: After remove the battery, please wait about 30

seconds, and then re-install the battery.

Security Network

The device support the security function. When the device included

with a security controller, the device will auto switch to the security

mode. In the security mode, the follow commands need using Security

CC wrapped to communicate, otherwise it will not response.

COMMAND_CLASS_BATTERY

COMMAND_CLASS_NOTIFICATION_V4

COMMAND_CLASS_ASSOCIATION_V2

COMMAND_CLASS_CONFIGURATION

COMMAND_CLASS_SENSOR_BINARY_V2

COMMAND_CLASS_SENSOR_MULTILEVEL_V5

COMMAND_CLASS_WAKE_UP_V2

Function DIP Switch

There is one function DIP switch in front of the device.

Remove the front cover in the right top of the PCB, and also has mark

“M1” and “M2” for two switch.

Notice: PST02-C don't have DIP switch in hardware.

M1 M2 Description

ON ON Test M ode .

ON OFF Normal Mode.

OFF ON Normal Mode.

OFF OFF Customer Mode. According to the configuration setting

NO. 5 to set the operation mode.

Operation Mode

There are two modes “Test” and “Normal”.

“Test Mode” is for the user test the sensor function when installation.

“Normal Mode” for the normal operation.

When the event triggered, normally the LED won't indicated, unless the

battery is in the low level, the LED will flash once. But in the “Test

Mode” the LED also will light ON one second.

When the event triggered, the device will report the messages to the

nodes in the group 1. The messages also include the battery level, the

temperature and the illumination level. The user can switch the report

by setting the configuration NO. 5 bit4 (illumination) and bit5

(temperature), and the configuration NO. 7 bit6 (battery).

When the event triggered, if the environment luminance is less than

the setting of the value of the configuration NO. 4, the device will emit

the signal to turn ON the lighting equipment, those nodes are in the

group 2. And delay a while to turn OFF the lighting equipment. The

delay time is setting by the configuration NO. 9.

The PIR motion re-detected interval, in the “Test Mode” fixed to 6

seconds. In the “Normal Mode”, it according to the setting of the

configuration NO. 8.

Notice: When the tamper key of the back side is released, the device

always in the “Test Mode”, no matter the DIP switch setting.

Battery Installation

When the device report the low battery message. The user should

replace the battery to new one. The battery type is CR123A, 3.0V.

The way to open the front cover please follow below steps.

1. Using a tool to press the 1-1 position, to release the cover.

2. Hold the front cover and pull back

3. Hold the front cover and pull up

Replace the new battery and install the cover back.

1. Put the front cover bottom to 1-1, and press down.

2. Push the front cover top to 2-1.

Choosing a Suitable Location

1. The recommended mounting height is 160cm

2. Don't let the device facing the window or the sunlight.

3. Don't let the device facing the source of heat. For instance the

heater or the air-condition.

Installation

1. In the first time, add the device into the Z-WaveTM network. First,

make sure the primary controller is in the inclusion mode. And then

power on the device, just take out the insulation Mylar in the back side

of the device. The device will auto start the NWI (Network Wide

Inclusion) mode. And it should be included in 5 seconds. You will see

the LED light ON one second.

2. Let the controller associate with the device into the first group, any

light switch that intend to be turned on when the device trig please

associate with the device into the second group.

3. In the accessory pack. There are two type of double coated tape,

one is thicker (hereinafter referred to as A tape) and another is thinner

(hereinafter referred to as B tape), you can use A tape for the test at

the beginning. The right way for A tape installation is stick it to the

position below tamper key. The thicker tape won't let the tamper key

pressed, so the sensor will enter the test mode, You may test if

installed position is good or not by this way.

After finish the test and decide to fix, then you can remove tape A, and

mounting the sensor by using tape B. The tamper key will pressed and

let the sensor enter normal mode.

Z-Wave Configuration Settings

Notice:

* All of the configuration, the data size is 1.

* The configuration mark with star(*), means after the remove the setting

still keep, don't reset to factory default. Unless the user execute the

“RESET” procedure.

* The reserve bit or not supported bit is allowed any value, but no effect.

NO. Name Def. Valid A B C Description

2Basic Set

Level 0xFF All   

Setting the BASIC command value to

turn on the light. The 0xFF(-1) means

turn on the light. For dimmer

equipment 1 to 100 means the light

strength.

0 means turn off the light.

(*)

PIR

Sensitivity 80 0 ~

99   

PIR sensitivity settings.

0 means disable the PIR motion.

1 means the lowest sensitivity,

99 means the highest sensitivity.

High sensitivity means can detected

long distance, but if there is more

noise signal in the environment, it will

re-trigger too frequency.

4Light

Threshold 99 0 ~

100   

Setting the illumination threshold to

turn on the light. When the event

triggered and the environment

illumination lower then the threshold,

the device will turn on the light.

0 means turn off illumination detected

function. And never turn on the light.

1 means darkest.

99 means brightest.

100 means turn off illumination

detected function. And always turn on

the light.

Notice: In none test mode, only the

value in 1 to 99 will enable the

illumination detected function and

update the illumination value.

NO. Name Def. Valid A B C Description

(*)

Operation

Mode

0All Operation mode. Using bit to control.

0Bit0: Reserve.

0  

Bit1: 1 means test mode,

0 means normal mode.

Notice:

This bit only effect by the DIP Switch

setting to “customer mode”, otherwise

it decides by DIP Switch setting to Test

or Normal Mode.

0   Bit2: Disable the door/window

function. (1:Disable, 0:Enable)

0Bit3: Setting the temperature scale.

0: Fahrenheit, 1:Celsius

0Bit4: Disable the illumination report

after event triggered. (1:Disable,

0:Enable)

0Bit5: Disable the temperature report

after event triggered. (1:Disable,

0:Enable)

0Bit6: Reserve.

0Bit7: Disable the back key release

into test mode. (1:Disable,

0:Enable)

NO. Name Def. Valid A B C Description

(*)

Mult-

Sensor

Function

Switch

4All Multisensor function switch. Using bit

to control.

0  

Bit0: Disable magnetic integrate

illumination to turn ON the lighting

nodes in the association group 2.

(1:Disable, 0:Enable)

0  

Bit1: Disable PIR integrate

Illumination to turn ON the lighting

nodes in the association group 2.

(1:Disable, 0:Enable)

1  

Bit2: Disable magnetic integrate PIR

to turn ON the lighting nodes in the

association group 2. (1:Disable,

0:Enable) (Default is Disable)

0  

Bit3: When Bit2 is 0 (Enable), Are the

device and the lighting in the same

room?

0: In the same room(Default),

1: In the different room.

Notice: If this bit is 1, it is

recommended also set the Bit1 to 1,

cause the PIR triggered, doesn't

mean the people in that room.

0   Bit4: Disable delay 5 seconds to turn

off the light, when door/window

closed. (1:Disable, 0:Enable)

0   Bit5: Disable auto turn off the light,

after door/window opened to turn on

the light. (1:Disable, 0:Enable)

Notice: If bit2 is zero, this setting is

useless.

Notice: If the configuration No.9 is

zero, this setting is useless.

0Bit6: Reserve.

0Bit7: Reserve.

NO. Name Def. Valid A B C Description

(*)

Customer

Function

4All Customer function switch, using bit

control.

0Bit0: Reserve.

0  

Bit1: Enable sending motion OFF

report. (0:Disable, 1:Enable)

Note: Depends on the Bit4,

0: Report Notification CC,

Type: 0x07, Event: 0xFE

1: Sensor Binary Report,

Type: 0x0C, Value: 0x00

1   Bit2: Enable PIR super sensitivity

mode. (0:Disable, 1:Enable)

0   Bit3: Disable send out BASIC OFF

after door closed. (1:Disable,

0:Enable)

0Bit4: Notification Type,

0: Using Notification Report.

1: Using Sensor Binary Report.

0Bit5: Disable Multi CC in auto report.

(1:Disable, 0:Enable)

0Bit6: Disable to report battery state

when the device triggered. (1:Disable,

0:Enable)

0Bit7: Reserve.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philio Régulateurs de température

Philio

Philio PAT14 Manuel utilisateur

Manuels Régulateurs de température populaires d'autres marques

Swegon

Swegon LUNAd MB Manuel utilisateur

Lucky Reptile

Lucky Reptile Thermo Control II Manuel utilisateur

SENSORMETRIX

SENSORMETRIX Argon 100 Manuel utilisateur

Fuji Electric

Fuji Electric PXE4 Manuel utilisateur

Yuyao gongyi

Yuyao gongyi XMT-808 series Manuel utilisateur

Selec

Selec TC544C Manuel utilisateur

P.W. KEY

P.W. KEY rt-208gt Manuel utilisateur

Future Design

Future Design FDC-9200 Manuel utilisateur

BH Thermal

BH Thermal BriskONE Manuel utilisateur

Omron

Omron E5EX-H Manuel utilisateur

West Control Solutions

West Control Solutions KS 45 Guide de démarrage rapide

MCS

MCS RITC-15B Manuel utilisateur

SMC Networks

SMC Networks Thermo-con INR-244-639 Manuel utilisateur

eltherm

eltherm Ex-TC It Series Manuel utilisateur

Omron

Omron C200H-TV Series Manuel utilisateur

industrie technik

industrie technik CA1 Manuel utilisateur

KRAL

KRAL EET 32 Manuel utilisateur

dixell

dixell XR420C Schéma de câblage
