Petcube Bites 2 Manuel utilisateur
1
MEET YOUR
Petcube Bites 2
2
PETCUBE BITES SPECS
AND SYSTEM REQUIREMENTS
Petcube Bites 2 features:
• 160º wide angle view
• 1080p HD video
• Treat dispenser
• 2-way audio
• Alexa Built-in
• Night vision
• 4x digital zoom
• Sound and motion alerts
Petcube Bites requires:
• Wi-Fi 802.11b/g/n, 2.4-5GHz, password protected
• Bluetooth Low Energy (BLE)
• iOS 10.3.3 + and higher or Android 7.1.2 and higher
• Min 1 Mbps Upload speed on the Petcube (recommended 2Mbps)
• Min 1 Mbps Download speed on the mobile device (recommended 2Mbps)
1
3
SAFETY
AND HANDLING
2
To avoid injuries or causing harm, read all safety information and operating instructions
prior to using Petcube.
• Don’t drop, hit, shake, or tumble your Petcube camera
• Don’t stain, scratch, or otherwise damage the front panel
• Treats dispensed by Petcube Bites should not replace your pet’s normal meals
• Petcube Bites should not be used to dispense medication to your pet
• Keep in mind treat expiration dates and ensure you are only providing your pets
with fresh treats
• To prevent mechanical problems, use only compatible treats
• Be aware that using treats with your pet exposes them to choking hazards.
Ensure your pet is familiar with the treats you are using and, that you monitor
the consumption. You are not required to use any specific treats
with Petcube Bites.
• Petcube should not be used by minors without supervision from an adult
• Don’t expose to liquid, moisture, dust, excessive heat, or naked flame
• To avoid overheating, don’t leave Petcube in direct sunlight
• Protect the power cord from being walked on, pinched or chewed on by pets
4
HOW TO ACCLIMATE
YOUR PET TO PETCUBE BITES 2
Some pets may need an adjustment period to get used to Petcube Bites 2. Follow these
simple steps to successfully introduce Bites 2 to your pet:
• Take time to positively introduce Bites 2 to your pet. Let them smell and inspect
the device before you start operating it.
• Introduce them to the idea that treats will come out and give your pet a positive
association with the device. Toss treats to your pet as though they’re coming from
the device. Put a treat into the dispensing hole and let them smell and see it.
• Disable the sound in settings to avoid your pet being alarmed by the speaker
• Stay in the room with your pet the first time you launch treats to provide
encouragement and comfort
• Make sure your pet is not directly in front of the launcher. It is recommended
to setup the device on a counter/shelf or wall mount it.
3
5
GETTING
STARTED
4
1. Setting up your Petcube camera on iOS device
Step 1. To set up your Petcube,
download Petcube application (fig 4.1.1)
to your iOS device. The Petcube app
requires iOS 10.3.3 or greater and can
be downloaded in the App Store
or at the link below:
www.petcu.be/ios-app-download
Step 2. Connect your Petcube
to a power source and wait up
to a minute until the LED light starts
blinking green (fig 4.1.2).
Step 3. Open the Petcube app
on your iOS device, log in or sign up
for a Petcube account using your email
or Facebook account (fig 4.1.3).
Step 4. Select ‘Connect your device’
and pick your Petcube from the list
of options (fig 4.1.4). Make sure to turn
on the Bluetooth before you continue.
In case the option to ‘connect your
device’ is not showing, tap on your
profile icon at the very top and hit
‘connect new device’ in the center.
Step 5. When the LED light
on the camera is blinking green,
hit ‘Next’ (fig 4.1.6).
Fig. 4.1.1 Fig. 4.1.2
Fig. 4.1.3 Fig. 4.1.4
6
Step 6. To identify your device,
tap ‘Select’. When the light
on the device blinks green rapidly,
tap ‘Next’ (fig 4.1.7).
Step 7. Wait for the app to exchange
data with the Petcube and scan
for available Wi-Fi networks (fig 4.1.8),
then select your home Wi-Fi network
from the list, put in your network
password and hit ‘Connect’ (fig 4.1.9).
If you don’t see your home network
on the list or if you’re using a hidden
network, connect to your home Wi-Fi
by entering the name of your network
and password manually and then hit
‘Connect’ (keep in mind that it is case
sensitive).
Step 8. Your Petcube device is almost
set! Please wait until it connects and
the light on the front turns white
(fig 4.1.10).
Step 9. Once the LED light on your
Petcube changes to solid white,
you are ready to play with your Petcube
(fig 4.1.11).
Fig. 4.1.5 Fig. 4.1.6
Fig. 4.1.7 Fig. 4.1.8
7
Reminder: It is likely that your Petcube
will need a firmware update right after
it is connected. The firmware update
will be downloaded to your camera
within 24 hours. When the LED light
on the Petcube will start blinking green
rapidly (fig 4.1.14), do not disconnect
your device. The installation only takes
5 minutes.
Fig. 4.1.9
Fig. 4.1.12
Fig. 4.1.13 Fig. 4.1.14
Fig. 4.1.10
Fig. 4.1.11
8
2. Setting up your Petcube camera on Android device
Step 1. To set up your Petcube,
download the Petcube app to your
Android device (fig 4.2.1). The Petcube
app requires Android 7.1.2 or greater
and can be downloaded in the Google
Play Store or at the link below:
www.petcu.be/android-app-download
Step 2. Connect your Petcube
to a power source and wait up
to a minute until the LED light starts
pulsing green (fig 4.2.2).
Step 3. Open Petcube app on your
Android device, log in or sign
up for a Petcube account using your
email or Facebook account (fig 4.2.3).
Step 4. Go to the ‘Home’ menu
in the top left corner of the app
(fig 4.2.4), select ‘Add Camera’
(fig 4.2.5), and pick your Petcube from
the list of options (fig 4.2.6). Make sure
to turn on the Bluetooth before you
continue.
Step 5. When the LED light
on the camera is blinking green,
hit ‘Next’ (fig 4.2.8).
Fig. 4.2.1
Fig. 4.2.2
9
Step 6. To identify your device,
tap ‘Select’. When the light
on the device blinks green rapidly,
tap ‘Next’ (fig 4.2.10).
Step 7. Wait for the app to exchange
data with the Petcube and scan for
available Wi-Fi networks, then select
your home Wi-Fi network from
the list (fig 4.2.12), put in your network
password and hit ‘Connect’ (fig 4.2.13).
If you don’t see your home network
on the list or if you’re using a hidden
network, connect to your home Wi-Fi
by entering the name of your network
and password manually and then hit
‘Connect’ (keep in mind that it is case
sensitive).
Step 8. Your Petcube device is almost
set! Please wait until it connects and
the light on the front turns white
(fig 4.2.15).
Step 9. Once the LED light on your
Petcube changes to solid white,
you are ready to play with your Petcube
(fig 4.2.16).
Fig. 4.2.3 Fig. 4.2.4
Fig. 4.2.5 Fig. 4.2.6
10
Reminder: It is likely that your Petcube
will need a firmware update right after
it is connected (fig 4.2.15). The firmware
update will be downloaded to your
camera within 24 hours. When the LED
light on the Petcube will start blinking
green rapidly (fig 4.2.17), do not
disconnect your device. The installation
only takes
5 minutes.
Fig. 4.2.7 Fig. 4.2.8
Fig. 4.2.9 Fig. 4.2.10 Fig. 4.2.11 Fig. 4.2.12
