Perlegear PGSS2 Manuel utilisateur

V1.0

Speaker Floor Stand Instruction Manual

Model: PGSS2

Thank you for choosing this Perlegear product! At Perlegear we strive

to provide you with the best quality products and services in the

industry. Should you have any issues, please don't hesitate to contact

us at [email protected](US/CA)

•Check package contents against Supplied Parts and Hardware List to assure that all

components were received undamaged. Do not use damaged or defective parts. lf you

require replacement parts, contact customer service at [email protected].

•Carefully read all instructions before attempting installation. If you do not

understand the instructions or have any concerns or questions, please contact customer

service at [email protected].

•This product may contain moving parts. Use with caution.

•Do not use this product for any purpose that is not explicitly speciﬁed in this manual. Do

not exceed weight capacity. We cannot be liable for damage or injury caused by improper

mounting, incorrect assembly or inappropriate use.

IMPORTANT SAFETY INSTRUCTIONS

Phillips Screwdriver

TOOLS NEEDED (NOT INCLUDED)

SUPPLIED PARTS

Tempered Glass Base

[01] x2

Decorative Cover

[04] x2

Speaker Bracket

[06] x2

Support Post

[02] x4

Connector

[03] x2

Sponge

[05] x4

HARDWARE KIT

Rubber Pad

[D] x10

M4 Allen Key

[E] x1

Bolt

M6x16mm

[A] x2

Plastic washer

Ø8.4*Ø19*T0.8mm

[B] x2

Inner Hexagon Bolt

M6x25mm

[C] x2

01 02 03 04 05

STEP 1 Secure the Support Post to the Tempered Glass Base

C02

01 02 03 04 05

STEP 2 Assemble the Support Post

①

②

③

01 02 03 04 05

STEP 3 Secure the Speaker Bracket to the Support Post

01 02 03 04 05

STEP 4 Adjust the Width of Speaker Bracket According to the

Speaker

Loosen

Speaker

Tighten

01 02 03 04 05

Thank you again for

choosing this Perlegear product!

All of us at Perlegear do appreciate your product purchase. We hope that you

are as happy with your product as we designing and manufacturing it for you.

We strive to provide you with the best quality products and services in the

industry. If you have any questions please don't hesitate to contact us at

[email protected](US/CA)
