PERFECTPRO Cubi Manuel utilisateur
GB
NL
D
S
F
Operating instruction
Gebruiksaanwijzing
Bedienungsanleitung
Bruksanvisning
Mode d’emploi
iPod is a trademark of Apple Inc.,
registered in the U.S. and other countries.
“Made for iPod” means that an electrical accessory
has been designed to connect specifically to
iPod and has been certified by the developer to
meet Apple performance standards.
Apple is not responsible for the operation of the device or its
compliance with safety and regulatory standards.
1
GB
2
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with
the instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves or other apparatus (including amplifiers)
that produce heat.
9. Protect the power cord from being walked on or pinched
particularly at plug, convenience receptacles, and the point
where they exit from the apparatus.
10. Only use attachments/accessories specified by
the manufacturer.
11. Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
3
12. Unplug this apparatus during lightning storms or when unused
for long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
14. To reduce the risk of fire or electric shock, do not expose this
appliance to Rain or Moisture.
15. The Shock Hazard Marking and Associated Graphical Symbol is
provided on the back of unit.
16. Apparatus shall not be exposed to dripping or splashing and no
objects filled with liquids, shall be placed on the apparatus.
17. For outdoors use, to avoid electric shock, use battery only
during a raining day or the weather is wet.
18. The power plug should be close to the radio, and easy to be
approached that during the emergency, to disconnect the
power from the radio, just unplug the power plug from the
AC power slot.
19. Notice:
The changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority
to operate the equipment.
4
GB
5
Controls and connections
Volume control knob / Mute
Tuning control knob / Seek / Select
Charge LED
Source button
Loudness button
LCD display
EQ button (Equalizer)
FM Stereo / Mono button
Remote control sensor
FM Antenna
iPod Compartment
Backlight button
Fast Forward / Preset 6
Play or Pause / Preset 5
Rewind / Preset 4
Speakers
Preset 3
Select / Preset 2
Menu / Preset 1
Power Standby (On/Off)
Battery compartment
AC Power cord
Aux In 1 socket
10-14V DC In socket
USB / DC charging socket
Aux In 2 socket
Batteries switch
Back-up batteries compartment
Main battery compartment
Passive bass speaker
Storage compartment
iPod compartment door
locking clip
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
6
GB
Display icons
Remote control
Battery power
iPod indicator
Radio band
Clock
Loudness indicator
Stereo indicator
Preset indicator
EQ setting
Frequency display
Volume indicator
Source indicator
Source
Menu / Preset 1
Rewind / Preset 4
Loudness
Tune Up / Down
FM Stereo / Mono
Volume Up / Down
Play/Pause / Preset 5
Fast Forward / Preset 6
Preset 3
Select / Preset 2
Power off
EQ
A
B
C
D
E
F
I
H
K
G
J
a
b
c
d
e
f
g
h
i
j
k
l
m
7
Remote control functions
Many functions of the Cubi worksite radio can be operated using
the remote control. Some operations require a longer press of
the button. In this case simply keep your finger held on the remote
control button for 2-3 seconds until the display on the radio shows
that the command has been accepted.
Before the first operation: please remove the small
transparent foil from the battery holder to activate the battery.
8
GB
Remote control battery replacement
1. Open the battery holder by pulling the holder out in
direction shown.
2. Remove battery from holder.
3. Replace battery (CR2025 or equivalent) ensuring that the
positive side of the battery faces you with holder positioned
as shown.
4. Replace the battery holder.
IMPORTANT:
The batteries should not be exposed to excessive heat such as
sunshine, fire or the like. After use, disposable batteries should if
possible be taken to a suitable recycling center. On no account
should batteries be disposed of by incineration.
2025
PULL
9
Power the Radio
A. Battery Operation
1. Installing the batteries, first pull out the battery compartment
locker to release battery compartment following the diagram
shown on the right. There are the main battery pack
compartment and the back up battery compartment.
Note:
Before you insert the batteries, if you use non-rechargeable
batteries, make sure the NiMH/NiCad/Alkaline switch which located
inside the battery compartment is switched to Alkaline position.
If you use rechargeable batteries, make sure to switch
NiMH/NiCad/Alkaline switch to NiMH/NiCad position.
2. Insert 6 x D size (UM-1) battery into the compartment.
Ensure the battery is inserted in accordance with the diagram
shown on page 10.
3. Insert 2 x AA size (UM-3) battery into the back up
battery compartment.
Note:
The back up battery is for time and memory station back up during
power failure. It is suggested to replace the back up battery every
six months to avoid battery leakage.
Run time of the radio on batteries varies strongly depending on
quality and capacity (mAh) of the batteries, temperature,
volume level etc.
