Pentax Optio E10 Instructions de montage

EN-1

GETTING TO KNOW YOUR CAMERA

Front View

Name Description

Shutter release

button Focuses and locks the exposure of the camera when

pressed halfway down, and takes the picture when

pressed all the way down.

Flash Provides flash illumination.

Power switch Turns the camera power on and off.

Mode dial Sets the camera mode.

Self-timer LED Blinks blue during self-timer mode until picture is taken.

Microphone Allows you to record sound with the recorded movie clips.

PC/AV terminal Allows you to connect a USB cable or an AV cable to the

camera.

DC input terminal Allows you to connect AC adapter to the camera to

operate the camera without battery.

Lens 3x optical zoom lens allows you to take telephoto and

wide-angle pictures.

Shutter release button

Flash

Mode dial

Power switch

Self-timer LED

Microphone

PC/AV terminal

DC input terminal

Lens

EN-2

Rear View

Name Description

LED indicator Indicates the camera’s current state.

/ button Zooms the lens to wide-angle position.

Changes the display into nine images (thumbnail) in the

playback mode.

/button Zooms the lens to telephoto position.

During zoom playback, it changes the size of the Zoom Display

image displayed on the LCD monitor.

button Switches to Playback mode. The latest image and information

appear on the LCD monitor.

MENU button Switches to Menu settings.

button Allows you to delete the picture.

Four-way controller Allows you to scroll through menus and pictures, and then

select choices.

/ SSelects the drive and self-timer modes in capture mode.

/ XSelects the focus mode in capture mode.

/ WSelects the flash mode in capture mode.

/ TAdjusts the EV compensation value.

/DISPLAY button Confirms the menu item selection.

DISPLAY - Turns the LCD monitor display and live view on and

off.

Strap holder Camera strap attachment.

Battery/card cover Allows you to access to the battery and insert or remove the SD

memory card.

Tripod socket Allows tripod mounting.

LCD monitor Provides menu information to operate the camera, and

previews the picture before taking it and review it afterwards.

LED indicator

MENU button

button

Battery/card cover

Tripod socket

Strap holder

DISPLAY button

/button /button

Four - way controller

LCD monitor

EN-3

Mode Dial

Mode Description

Program Lets the camera set the functions automatically.

Portrait Lets you take portrait-type pictures.

Landscape Lets you take landscape views.

Sport Lets you take sport pictures.

Night Scene Lets you take dark scenes such as night views.

Setup Lets you select the camera preferences.

Movie Lets you take moving pictures.

Simple The basic picture-taking mode.

Mode dial

EN-4

GETTING STARTED

Attaching the Camera Strap

Attach the camera strap as shown in the

illustrations.

Inserting the Battery

1. Open the battery/card cover.

2. Insert the battery in the correct

orientation as shown on the right.

3. Close the battery/card cover.

You can use 2 AA size batteries (alkaline or Ni-MH rechargeable)

to power the camera.

Due to the characteristics of AA alkaline battery, camera

performance may deteriorate. AA alkaline battery is not

recommended except in emergencies and checking the camera’s

functionality.

EN-5

Inserting the SD Memory Card (Optional Accessory)

1. Open the battery/card cover.

2. Insert the SD memory card in the

correct orientation as shown on the

right.

Hold the SD memory card with its

metal contact end surface facing the

rear side of the camera, and then

insert the card as far as it can go.

3. Close the battery/card cover.

Turning the Power On

Press the power switch to turn the power

on.

Power switch

EN-6

Choosing OSD (On-Screen Display) Language

1. Rotate the mode dial to and turn

your camera on by pressing the

power switch.

2. [Set-up1] is displayed.

3. Use the four-way controller (T) to

select [Language], then press the

button.

4. Use the four-way controller (ST) to

select the language you want.

5. Press the button to confirm.

EN-7

Setting the Date and Time

1. Rotate the mode dial to and turn

your camera on by pressing the

power switch.

2. [Set-up1] is displayed.

3. Use the four-way controller (T) to

select [Date Adjust] and the four-

way controller (WX) to switch the

date types, then press the button.

4. Press the four-way controller (WX)

to select Day, Month, Year and Time

fields.

To increase a value, press the

four-way controller (S).

To decrease a value, press the

four-way controller (T).

The time is displayed in 24-hours

format.

5. Press the button after all fields

are set.

EN-8

Taking Still Pictures

1. Set the mode dial to .

2. Press the power switch to turn on the camera.

3. Compose your image in the LCD monitor.

4. Press the shutter release button halfway down to automatically focus

the image. Proper exposure is determined and locked at the same time.

5. Press the shutter release button down fully to take the pictures.

Playing Back Still Pictures

1. Press the button.

The last image appears on the screen.

2. Use the four-way controller (WX) to view the pictures.

Four-way controller (W): go back to the previous image.

Four-way controller (X): advance to the next image.

Power switch

OK button

Shutter release button

LCD monitor

Mode dial

/ / / button

Power switch

Playback button

Four - way controller

LCD monitor

EN-9

Recording Movie Clips

This mode allows you to record movie clips with sound via built-in

microphone.

1. Rotate the mode dial to and turn

your camera on by pressing the

power switch.

2. Press the shutter release button to

start recording.

3. To stop recording, press the shutter

release button again.

Playing Back Movie Clips

You can play back the recorded movie clips on the LCD monitor.

However, the sound recorded with movie clips can only be played back

on a TV or a computer.

1. Press the button.

2. Use the four-way controller (WX) to

go through the images until the movie

clip you want to play back is displayed.

To view the previous image, press

the four-way controller (W).

To view the next image, press the

four-way controller (X).

3. Press the button to start playing

back the movie clips.

To pause or resume movie

playback, press the button again.

100-0001

1/7

01/01/2006

12:01

00:05

EN-10

Erasing Images

1. Press the button.

The last image will be displayed

on the screen.

2. Use the four-way controller (WX) to

select the image you want to delete.

3. Press the button.

4. Use the four-way controller (ST) to

select [This Image] or [All Images]

by your preference, then press the

button.

5. When the delete message appears,

use the four-way controller (ST) to

select [OK], then press the

button to confirm the deletion.

If you wish to cancel the deletion,

select [Cancel].
