Installation and Assembly: Peerless Ultra-Thin Articulating

Mount for 32" to 46"* Flat Panel Displays

Model: SUA737

*Display Compatibility Requirements

• Depth of display must be less than 2".

• The depth of this mount (1.29") may not provide

sufﬁcient space for proper ventilation on some displays.

Please refer to the manufacturer's requirements for

mounting your display before installation.

• The display must have a ﬂat mounting surface, or the

mounting holes need to be on the furthest back surface

of the display.

• Input/Output connection must be properly oriented to

accommodate mounting 1.29" from the wall.

ISSUED: 12-15-11 SHEET #: 095-9371-2 03-08-12

2300 White Oak Circle • Aurora, Il 60502 • (800) 865-2112 • Fax: (800) 359-6500 • www.peerlessmounts.com

Max UL Load Capacity: 60 lb (27.2 kg)

2 of 23 ISSUED: 12-15-11 SHEET #: 095-9371-2 03-08-12

Tools Needed for Assembly

• stud ﬁnder ("edge to edge" stud ﬁnder is recommended)

• phillips screwdriver

• drill

• 5/16" (8mm) bit for concrete and cinder block wall

• 5/32" (4mm) bit for wood stud wall

• level

Note: Read entire instruction sheet before you start installation and assembly.

Table of Contents

Parts List.................................................................................................................................................................................3

Wall installation...................................................................................................................................................................4, 5

Installing Adapter Brackets to Display....................................................................................................................................6

Mounting Flat Panel Display...................................................................................................................................................7

• Do not begin to install your Peerless product until you have read and understood the instructions and warnings

contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, for US

customers please call Peerless customer care at 1-800-865-2112, for all international customers, please contact

your local distributor.

• This mount is designed to attach the display 1.29" from the wall. Please refer to manufacturer's installation guide

recommendations for required distance from wall to avoid risk of injury or property damage.

• This product should only be installed by someone of good mechanical aptitude, has experience with basic building

construction, and fully understands these instructions.

• Make sure that the supporting surface will safely support the combined load of the equipment and all attached

hardware and components.

• Never exceed the Maximum UL Load Capacity. See page one.

• If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs. Use of

an "edge to edge" stud ﬁnder is highly recommended.

• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.

• Tighten screws ﬁrmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding

power.

• This product is intended for indoor use only. Use of this product outdoors could lead to product failure and personal

injury.

• This product was designed to be installed on the following wall construction only;

WALL CONSTRUCTION HARDWARE REQUIRED

• Wood Stud Included

• Wood Beam Included

• Solid Concrete Included

• Cinder Block Included

• Brick Contact Qualiﬁed Professional (not evaluated by UL)

• Other or unsure? Contact Qualiﬁed Professional

WARNING

3 of 23 ISSUED: 12-15-11 SHEET #: 095-9371-2 03-08-12

Parts may appear slightly different than illustrated.

Before you begin, make sure all parts shown are included with your product.

Description Qty. Part #

wall arm assembly 1 046-P1260

Cwood screws 2 520-1202

Dconcrete anchors 2 590-0320

EM4 x 6mm screw 2520-1006

Fsecurity driver 1560-1133

G4mm allen wrench 1560-9646

Hfastener cap 2 590-1324

Icable anchor 1 046-P1134

Jcable clip 1 046-P1138

cable tie 2 046-0136

LM5 x 12mm screw 4 560-1732

MM5 x 25mm screw 4 560-1733

NM6 x 12mm screw 4 560-1734

OM6 x 25mm screw 4 560-1735

PM8 x 12mm screw 4 560-1736

QM8 x 25mm screw 4 560-1737

R3/4" spacer 4 540-1059

Sflat washer 4 540-9478

Parts List

CDE F

LMN O P Q R S

4 of 23 ISSUED: 12-15-11 SHEET #: 095-9371-2 03-08-12

Use a stud ﬁnder to locate the edges of the stud. Use of an edge-to-edge stud ﬁnder is highly recommended.

Based on their edges, draw a vertical line down the stud’s center. Measure 4.8" (122mm) left or right from stud's

center to determine center of display mounting plate. Place wall arm (A) on wall as template, level, and mark the

center of two mounting holes. Top mounting hole will be 6.66" above the center of display mounting plate as shown

in ﬁgure 1.1.

Drill two 5/32" dia. holes to a minimum depth of 2.5". Secure wall arm (A) to wall with two wood screws (C) as

shown in ﬁgure 1.2. For cable management option, install cable anchor (I) to bottom mounting hole with wood

screw (C). NOTE: Be sure arrow is pointing up when mounting wall arm (A) to wall as shown in ﬁgure 1.1. Level,

then tighten all fasteners.

Insert two fastener caps (H) into wall plate mounting holes.

ﬁg. 1.1

= CENTER OF DISPLAY

ARROW

DISPLAY

MOUNTING PLATE

6.66"

(169mm)

4.8"

(122mm)

Installation to Single Wood Stud Wall

• Installer must verify that the supporting surface will safely support the combined load of the equipment and all

attached hardware and components.

• Tighten wood screws so that wall plate is ﬁrmly attached, but do not overtighten. Overtightening can damage the

screws, greatly reducing their holding power.

• Never tighten in excess of 80 in. • lb (9 N.M.).

• Make sure that mounting screws are anchored into the center of the stud. The use of an "edge to edge" stud ﬁnder

is highly recommended.

• Hardware provided is for attachment of mount through standard thickness drywall or plaster into wood studs.

Installers are responsible to provide hardware for other types of mounting situations (not evaluated by UL).

WARNING

ﬁg. 1.2

5 of 23 ISSUED: 12-15-11 SHEET #: 095-9371-2 03-08-12

Place wall arm (A) on wall as template, level,

and mark the center of two mounting holes. Top

mounting hole will be 6.66" above the center of

display mounting plate as shown in ﬁgure 1.1 on

page 4. Drill two 5/16" dia. holes to a minimum

depth of 2.5". Insert anchors (D) into holes ﬂush

with wall as shown. Secure wall arm (A) to wall with

two wood screws (C) as shown in ﬁgure 1.3. For

cable management option, install cable anchor (I) to

bottom mounting hole with wood screw (C).

NOTE: Be sure arrow is pointing up when mounting

wall arm assembly (A) to wall as shown in ﬁgure

1.1. Level, then tighten all fasteners.

Insert two fastener caps (H) into wall plate mounting

holes.

SOLID CONCRETE CINDER BLOCK

Installation to Solid Concrete or Cinder Block

CUTAWAY VIEW

INCORRECT CORRECT

wall

plate wall

plate

plaster/

drywall plaster/

drywall

concrete concrete

• When installing Peerless wall mounts on cinder block, verify that you have a minimum of 1-3/8" (35mm) of actual

concrete thickness in the hole to be used for the concrete anchors. Do not drill into mortar joints! Be sure to mount

in a solid part of the block, generally 1" (25mm) minimum from the side of the block. Cinder block must meet ASTM

C-90 speciﬁcations. It is suggested that a standard electric drill on slow setting is used to drill the hole instead of a

hammer drill to avoid breaking out the back of the hole when entering a void or cavity.

• Concrete must be 2000 psi density minimum. Lighter density concrete may not hold concrete anchor.

• Make sure that the supporting surface will safely support the combined load of the equipment and all attached

hardware and components.

WARNING

• Tighten screws so that wall plate is ﬁrmly attached,

but do not overtighten. Overtightening can damage

screws, greatly reducing their holding power.

• Never tighten in excess of 80 in. • lb (9 N.M.).

• Always attach concrete expansion anchors directly

to load-bearing concrete.

• Never attach concrete expansion anchors to

concrete covered with plaster, drywall, or other

ﬁnishing material. If mounting to concrete surfaces

covered with a ﬁnishing surface is unavoidable (not

evaluated by UL), the ﬁnishing surface must be

counterbored as shown below. Be sure concrete

anchors do not pull away from concrete when

tightening screws. If plaster/drywall is thicker than

5/8" (16mm), custom fasteners must be supplied by

installer (not evaluated by UL).

WARNING

ﬁg. 1.3

Drill holes and insert anchors (D).

Place plate (A) over anchors (D) and secure with screws (C).

Tighten all fasteners.

concrete

surface

6 of 23 ISSUED: 12-15-11 SHEET #: 095-9371-2 03-08-12

For VESA 200 x 200 mounting pattern

Insert two 12mm screws (L, N, O) into top two holes of display, leaving approximately 1/4" (6mm) of exposed

thread. Hook screws onto keyslots of front plate as shown.

Insert two 12mm screws (L, N, O) into bottom holes of adapter plate as shown. Tighten all fasteners.

FRONT PLATE

• Tighten screws so display brackets are ﬁrmly attached to display. Do not tighten with excessive force.

Overtightening can cause stress damage to screws, greatly reducing their holding power and possibly causing

screw heads to become detached. Tighten to 40 in. • lb (4.5 N.M.) maximum torque.

• If screws don't get three complete turns in the display inserts or if screws bottom out and bracket is still not tightly

secured, damage may occur to display or product may fail.

WARNING

2-1

1/4"

L, N, O

7 of 23 ISSUED: 12-15-11 SHEET #: 095-9371-2 03-08-12

Roll Adjustment

Cable Management

Adapter plate may be rolled +/- 5°. Roll locking screw may be tightened or loosened using 4mm allen wrench (G).

NOTE: Do not remove roll locking screw.

Cables may be routed using cable clip (J).

Slip cable clip (J) onto bottom of center joint as shown in ﬁgure 5.1 and secure cables to cable clip using cable tie

(K) as shown in ﬁgure 5.2.

Secure cables to cable anchor (I) using cable tie (K) as shown below.

JOINT SCREWS

ROLL LOCKING SCREW

ﬁg. 5.1

CENTER

JOINT

ﬁg. 5.2

CABLES

• Do not tighten joint screws. Doing so may cause

damage to screws, greatly reducing their holding

power.

CAUTION

CABLES

All other brand and product names are trademarks or registered trademarks of their respective owners.

Peerless Industries, Inc.

2300 White Oak Circle

Aurora, Il 60502

www.peerlessmounts.com

* Requisitos para la compatibilidad de las pantallas

• La profundidad de la pantalla tiene que ser menos de 2".

• Es posible que la profundidad del soporte (1.29") no

proporcione suﬁciente espacio para la ventilación

adecuada de algunas pantallas. Por favor, repase los

requisitos del fabricante en relación con la instalación de

la pantalla antes de proceder.

• La pantalla tiene que tener una superﬁcie plana para la

instalación o tiene que tener los agujeros de montaje en

la superﬁcie trasera más alejada de la pantalla.

• La conexión de entrada / salida tiene que tener la

orientación adecuada para acomodar una instalación a

1.29" de la pared.

PUBLICADO: 12-15-11 HOJA #: 095-9371-2 03-08-12

2300 White Oak Circle • Aurora, Il 60502 • (800) 865-2112 • Fax: (800) 359-6500 • www.peerlessmounts.com

Máxima capacidad de carga para UL: 60 lb (27.2 kg)

Instalación y ensamblaje: Soporte Articulador Peerless

Ultra-Thin Para Pantallas Planas de 32" a 46"*

Modelo: SUA737

Español

9 de 23 PUBLICADO: 12-15-11 HOJA #: 095-9371-2 03-08-12

Contenido

Lista de piezas..................................................................................................................................................................... 10

Instalación en una pared................................................................................................................................................11, 12

Instalación de los soportes adaptadores............................................................................................................................. 13

Instalación y desinstalación de la pantalla plana ................................................................................................................ 14

Herramientas necesarias para el ensamblaje

• localizador de montantes (se recomienda uno de "borde a borde")

• destornillador phillips

• taladro

• broca de 5/16" (8mm) para paredes de concreto y de bloque de hormigón de escorias

• broca de 5/32" (4mm) para paredes con montantes de madera

• nivel

NOTA: Lea la hoja de instrucciones completa antes de comenzar la instalación y el ensamblaje.

• No comience a instalar su producto de Peerless hasta haber leído y entendido las instrucciones y las advertencias

contenidas en la Hoja de Instalación. Si tiene alguna pregunta acerca de cualquiera de las instrucciones o las

advertencias, por favor, llame a Servicio al Cliente de Peerless al 1-800-865-2112 si está en EE. UU. Si es un cliente

internacional, por favor, comuníquese con su distribuidor local.

• Este soporte está diseñado para sostener la pantalla a 1.29" de la pared. Por favor, repase las recomendaciones del

manual de instalación del fabricante con respecto a la distancia necesaria de la pared para evitar el riesgo de sufrir

lesiones o causar daños a la propiedad.

• Este producto sólo debe ser instalado por una persona que tenga una buena aptitud mecánica, que tenga

experiencia en construcción básica de ediﬁcios y que entienda estas instrucciones en su totalidad.

• Asegúrese de que la superﬁcie de apoyo sostendrá, con seguridad, la carga combinada del equipo y todos los

ﬁjadores y componentes.

• Nunca sobrepase la capacidad máxima de soportar carga para Underwriters Laboratories. Vea la página 8.

• Si va a instalar el producto en una pared con montantes de madera, asegúrese de que los tornillos de montaje estén

anclados en el centro de los montantes. Se recomienda utilizar un localizador de montantes de "borde a borde".

• Siempre cuente con la ayuda de un asistente o utilice un equipo mecánico de izar para levantar y colocar el equipo

con más seguridad.

• Apriete los tornillos con ﬁrmeza, pero no en exceso. Apretarlos en exceso puede dañar los artículos y puede

disminuir signiﬁcativamente su fuerza de ﬁjación.

• Este producto está diseñado para uso en interiores solamente. Utilizar este producto en exteriores podría causar

fallas del producto y lesiones a individuos.

• Este producto fue diseñado para ser instalado en paredes con la siguiente construcción solamente:

CONSTRUCCIÓN DE LA PARED ACCESORIOS NECESARIOS

• Montante de madera Incluido

•Viga de madera Incluido

•Concreto macizo Incluido

•Bloque de hormigón de escorias Incluido

•Ladrillo Comuníquese con un profesional caliﬁcado (no evaluados por UL)

•¿Otra superﬁcie o no está seguro? Comuníquese con un profesional caliﬁcado

ADVERTENCIA

Español

10 de 23 PUBLICADO: 12-15-11 HOJA #: 095-9371-2 03-08-12

Algunas partes pueden diferir un poco de las ilustradas.

Antes de comenzar, asegúrese de que su producto incluye todas las piezas ilustradas.

Descripción Cant. Nº de pieza

armazón del brazo de pared 1 046-P1260

Ctornillo para madera 2 520-1202

Danclaje para concreto 2 590-0320

Etornillo M4 x 6mm 2520-1006

Fllave de se

uridad 1560-1133

Lista de piezas

llave de seguridad

560 1133

Gllave allen de 4mm 1560-9646

Hcubierta para sujetadores 2 590-1324

Ianclaje para cables 1 046-P1134

Jclip para cables 1 046-P1138

sujetacables 2 046-0136

Ltornillo M5 x 12mm 4 560-1732

Mtornillo M5 x 25mm 4 560-1733

Ntornillo M6 x 12mm 4 560-1734

Otornillo M6 x 25mm 4 560-1735

Ptornillo M8 x 12mm 4 560-1736

Qtornillo M8 x 25mm 4 560-1737

Respaciador 3/4" 4 540-1059

Sarandela 4 540-9478

CDE F

LMN O P Q R S

Table des matières

Langues :

Autres manuels peerless-AV Support et étagère

peerless-AV

peerless-AV DS-VWC555-3x2 Mode d’emploi

peerless-AV

peerless-AV SMARTMOUNT WSP756 Manuel utilisateur

peerless-AV

peerless-AV YBA4X4 Manuel utilisateur

peerless-AV

peerless-AV MOD-FPSKIT100-CPF Manuel utilisateur

peerless-AV

peerless-AV SMARTMOUNT XT STX645 Manuel utilisateur

peerless-AV

peerless-AV KIL540 Manuel utilisateur

peerless-AV

peerless-AV SR542-KAPP Manuel utilisateur

peerless-AV

peerless-AV MOD-FPSKIT100 Manuel utilisateur

peerless-AV

peerless-AV HPF650 Manuel utilisateur

peerless-AV

peerless-AV DS-LEDKFS Kitted+ Free Standing Manuel utilisateur

peerless-AV

peerless-AV MOD-FPMD2 Manuel utilisateur

peerless-AV

peerless-AV WL-SA761PU-200 Mode d’emploi

peerless-AV

peerless-AV SUT670P Manuel utilisateur

peerless-AV

peerless-AV ACC340 Mode d’emploi

peerless-AV

peerless-AV ACC-SPARK70 Manuel utilisateur

peerless-AV

peerless-AV SHARP NEC WMK-7598T Manuel utilisateur

peerless-AV

peerless-AV SmartMount SF632 Manuel utilisateur

peerless-AV

peerless-AV ACC976 Manuel utilisateur

peerless-AV

peerless-AV LCT620A Mode d’emploi

peerless-AV

peerless-AV SP740P Manuel utilisateur

peerless-AV

peerless-AV RMI3-FLIP2 Manuel utilisateur

peerless-AV

peerless-AV SMARTMAUNT Series Manuel d'instructions

peerless-AV

peerless-AV LCH-100 Mode d’emploi

peerless-AV

peerless-AV DS-LEDLSAA-5X5 Manuel utilisateur

Manuels Support et étagère populaires d'autres marques

Salamander

Salamander Acadia AC/W/L400/WH Manuel utilisateur

Fohhn

Fohhn VAT-09 Guide de l'utilisateur

ricoo

ricoo FS0522 Manuel utilisateur

AMSOIL

AMSOIL BMK-22 Guide rapide

Kargo Master

Kargo Master 48220 Manuel utilisateur

Milestone AV Technologies

Milestone AV Technologies SIMPLICITY SLF2 Manuel utilisateur

ricoo

ricoo S1222 Manuel utilisateur

Ready-Set-Mount

Ready-Set-Mount RSMCM602 Manuel utilisateur

VidaBox

VidaBox VB MNT FFS2 Manuel utilisateur

Welch Allyn

Welch Allyn 48960 Manuel utilisateur

Arkon

Arkon CM035-ST-2 Manuel utilisateur

PROEL

PROEL PLWIN60C Manuel utilisateur

Agilent Technologies

Agilent Technologies E2609B Manuel utilisateur

Mustang

Mustang MV-ARM4 Manuel utilisateur

Mounting Solutions

Mounting Solutions WRM-320 Manuel utilisateur

Pyle

Pyle PMKSPAD1 Manuel utilisateur

ShelterIt

ShelterIt 21208 Manuel utilisateur

SPL

SPL RackPack?4 1040 Manuel utilisateur

peerless-AV SUA737 Mode d’emploi

Manuels Support et étagère populaires d'autres marques
