Peerless-AV CMJ450 Mode d’emploi

Model: CMJ450

Installation & Assembly:

Suspended Ceiling Kit

Max UL Load Capacity: 250 lb (113 kg)

ISSUED: 12-16-16 SHEET NO: 128-9180-1

2300 White Oak Circle • Aurora, Il 60502 • (800) 865-2112 • Fax: (800) 359-6500 • www.peerlessmounts.com

Compatible model/series* AEC*

EXT*

ADD*

2 of 6 ISSUED: 12-16-16 SHEET NO: 128-9180-1

Table of Contents

Parts List.................................................................................................................................................................................3

Flush Mount Tube or Extension Column Installation..............................................................................................................3

Installation to Solid Concrete or Wood Joists.........................................................................................................................5

NOTE: Read entire instruction sheet before you start installation and assembly.

Tools Needed for Assembly

• phillips screwdriver

• drill

• 1/4" (6 mm) bit for concrete

• 5/32" (4 mm) bit for wood joist or beams

• level

• Before installing make sure the supporting surface will support the combined load of the equipment and hardware.

• Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail.

• Never exceed the Maximum UL Load Capacity. See page one.

• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.

• This product is intended for indoor use only. Use of this product outdoors could lead to product failure and personal

injury.

• Be careful not to pinch ﬁngers when operating the mount.

• For support please call customer care at 1-800-865-2112.

• To properly tighten screws: Tighten until screw head makes contact, then tighten another half turn. Do not

overtighten screws.

WARNING

3 of 6 ISSUED: 12-16-16 SHEET NO: 128-9180-1

DLM

Description Qty. Part #

Aceiling tray 1 1455-476W

BM6 x 10 mm long phillips screw 8 520-9401

CM6 x 20 mm long phillips screw 4 520-9402

Dhanger bracket 4 1452-278

Ehanger bracket clamp 4 1452-279

Fturnbuckle 4 560-9620

G20’ (6.1m) tie wire (not shown) 1 1450-522

Hsafety cable (not shown) 1 1450-517

Isafety cable clamp 2 1450-518

Jeye bolt 5 580-0006

Kconcrete anchor 5 580-0005

LM5 x 10 mm penta pin screw 1 505-9010

MM5 x 1" penta pin drive

1 520-9249

Parts List

Before you begin, make sure all parts shown are included with your product.

Parts may appear slightly different than illustrated.

IMPORTANT PRE-ASSEMBLY INFORMATION:

Ceiling Tray (A) is designed to ﬁt within a 24" (610 mm) x 24" (610 mm) section of a conventional suspended ceiling

system. Ceiling runners (see DETAIL 1, page 5) should have a "T" cross section and a minimum height of 1.5" (38

mm). In cases where 24" (610 mm) x 48" (1219 mm) ceiling tiles are used, cut one tile in half and add another 24"

(610 mm) ceiling runner in order to make a 24" (610 mm) x 24" (610 mm) section.

For certain installations it may be best to install ceiling anchors (step 4) before installing the ceiling tray (step 3).

For FLUSH MOUNT TUBE Installation: From the

top, thread the Flush Mount Tube (not included)

through center of ceiling tray (A).

Skip to step 3.

For EXTENSION COLUMN Installation: From the

bottom up, thread extension column (not included)

up through retaining collar in adjustable collar mount

plate. Align notch in extension column with hole in

collar and fasten using M5 x 10 mm penta pin screw

(L) with M5 penta pin driver (M) as shown below.

UL LISTED PEERLESS MODEL

AEC, EXT,ADD SERIES SOLD

SEPARATELY; (800) 865-2112

4 of 6 ISSUED: 12-16-16 SHEET NO: 128-9180-1

Attach four Hanger Brackets (D) to four corners of Ceiling Tray (A) using 10 mm long phillips screws (B). Place

Ceiling Tray (A) into 24" (610mm) x 24" (610mm) opening in ceiling (in place of a ceiling tile). Clamp Ceiling Tray

(A) to Ceiling Runners using Hanger Bracket Clamps (E) and 20 mm long phillips screws (C). Hook Turnbuckles

(F) into Hanger Brackets (D).

TOP VIEW - CEILING TRAY

Black rectangles show correct

positions for Hanger brackets.

5 of 6 ISSUED: 12-16-16 SHEET NO: 128-9180-1

Cut tie wire (G)into four pieces of equal length. Insert wires through ends of turnbuckles. Twist each wire around

itself at least four times. Drill holes for four ceiling anchors (see “Various Anchoring Methods"). Position the holes

so that when the tie wires (G) when attached and taut will angle out at 15O. Drill a ﬁfth anchor hole directly above

the center of the ceiling tray. Pull tie wires tight and attach to ends of ceiling anchors (or truss). Again twist each

wire around itself at least four times. When this step is complete, the weight of the ceiling tray should be supported

by the tie wires. Note: 20’ (6.1 m) of tie wire (G) is provided. If space between the true ceiling and suspended

ceiling is more than 36" (914 mm), additional wire (12 gauge annealed, steel, black) will be needed.

VARIOUS ANCHORING METHODS Max. UL Load Capacity : 250 lbs. (113 kg)

Solid Concrete

Drill 1/4" (6 mm) dia. holes 1.5" (38 mm)

deep. Hammer in Concrete Anchor (K) using

Rawl #3250 setting tool or equivalent.

Truss Ceiling

No anchor required. After attaching tie

wire to turnbuckle loop upper end around

ceiling truss. Pull tie wire tight and twist it

around itself at least four times.

Run the safety cable (H) through the remaining

ceiling anchors. Pass each end through holes in

ceiling plate reinforcements and join with cable

clamp (I). DO NOT TIGHTEN YET!

Suspended Ceiling Kit installation is now complete.

After all components (Mount, Extension Column,

etc.) and equipment (monitor, VCR, etc.) have

been attached, tension the tie wires by adjusting

turnbuckles (F). Load must be carried by tie wires

- not suspended ceiling runners. Finally, take up

the slack in safety cable (H) leaving it slightly loose.

Tighten both safety cable clamps (I).

GG G G

DETAIL 1

Ceiling Runner

DETAIL 2

Safety Cable and

Cable Clamp

Knockout panels are

provided for electrical outlet

boxes and antenna leads.

• When installing Peerless ceiling mounts on

wood joist/beam covered with gypsum board

(drywall), verify that the joists or beams are a

minimum of 2" x 4" nominal size. Do not install

over gypsum board thicker than 5/8".

WARNING

• Installer must verify that the ceiling will safely

support four times the combined weight of all

attached equipment and hardware.

WARNING

• When installing Peerless ceiling mounts on a

concrete ceiling, the ceiling must be at least 8"

thick with a minimum compressive strength of

2000 psi. Never attach expansion anchors to

concrete covered with plaster, drywall or other

ﬁnishing material.

WARNING

Wood Joists or Beams

Use stud ﬁnder to locate and mark

stud center lines. Drill 5/32" (4 mm)

dia. holes 2" (51 mm) deep. Fully

insert eye bolts (J). Mounting hole

must center on stud.

All other brand and product names are trademarks or registered trademarks of their respective owners.

Peerless Industries, Inc.

2300 White Oak Circle

Aurora, Il 60502

www.peerlessmounts.com

6 of 6 ISSUED: 12-16-16 SHEET NO: 128-9180-1

Peerless Industries, Inc. (“Peerless”) warrants to original end-users of Peerless®products will be free from defects in material and workmanship, under

normal use, for a period of ﬁve years from the date of purchase by the original end-user (but in no case longer than six years after the date of the product's

manufacture). At its option, Peerless will repair or replace, or refund the purchase price of, any product which fails to conform with this warranty.

In no event shall the duration of any implied warranty of merchantability or ﬁtness for a particular purpose be longer than the period of the

applicable express warranty set forth above. Some states do not allow limitations on how long a implied warranty lasts, so the above limitation may not

apply to you.

This warranty does not cover damage caused by (a) service or repairs by the customer or a person who is not authorized for such service or repairs by

Peerless, (b) the failure to utilize proper packing when returning the product, (c) incorrect installation or the failure to follow Peerless' instructions or warnings

when installing, using or storing the product, or (d) misuse or accident, in transit or otherwise, including in cases of third party actions and force majeure.

In no event shall Peerless be liable for incidental or consequential damages or damages arising from the theft of any product, whether or not

secured by a security device which may be included with the Peerless® product. Some states do not allow the exclusion or limitation of incidental or

consequential damages, so the above limitation or exclusion may not apply to you.

This warranty is in lieu of all other warranties, expressed or implied, and is the sole remedy with respect to product defects. No dealer, distributor, installer or

other person is authorized to modify or extend this Limited Warranty or impose any obligation on Peerless in connection with the sale of any Peerless®product.

This warranty gives speciﬁc legal rights, and you may also have other rights which vary from state to state.

LIMITED FIVE-YEAR WARRANTY

www.peerless-av.com
