Peerless-AV ACCXT400 Mode d’emploi

ISSUED: 07-09-12 SHEET #: 120-9158-1

2300 White Oak Circle • Aurora, Il 60502 • (800) 865-2112 • Fax: (800) 359-6500 • www.peerlessmounts.com

Installation and Assembly:

Accessory In-Wall Box for SAX762PU and SAX772PU

Models: ACCXT400

ARM ASSEMBLY

(sold separately)

2 of 8 ISSUED: 07-09-12 SHEET #: 120-9158-1

NOTE: Read entire instruction sheet before you start installation and assembly.

Tools Needed for Assembly

•phillips screwdriver

• Do not begin to install your Peerless product until you have read and understood the

instructions and warnings contained in this Installation Sheet. If you have any questions

regarding any of the instructions or warnings, for US customers please call Peerless customer

care at 1-800-865-2112, for all international customers, please contact your local distributor.

• This product should only be installed by someone of good mechanical aptitude, has

experience with basic building construction, and fully understands these instructions.

• Make sure that the supporting surface will safely support the combined load of the equipment

and all attached hardware and components.

• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.

• Tighten screws ﬁrmly, but do not overtighten. Overtightening can damage the items, greatly

reducing their holding power.

• This product is intended for indoor use only. Use of this product outdoors could lead to

product failure and personal injury.

WARNING

Parts may appear slightly different than illustrated.

Before you begin, make sure all parts shown are included with your product.

Parts List

Description Qty. Part #

Ain-wall box 1 125-0325

Boutlet box 1 125-0326

Csurge suppressor w/ screws 1 600-1190

D#6 x 3/8" screw 4 500-9007

3 of 8 ISSUED: 07-09-12 SHEET #: 120-9158-1

See accompanying instruction manual for installation of wall arm to wall.

Remove center wall plate cover from wall arm assembly (sold separately).

Use wall arm assembly as a template to draw outline of accessory hole as shown below.

Remove drywall inside cut outline.

CENTER WALL

PLATE COVER

WALL ARM

ASSEMBLY

WOOD STUD

ACCESSORY HOLE

CUT OUTLINE

FRONT PLATE

NOT SHOWN

FOR CLARITY

4 of 8 ISSUED: 07-09-12 SHEET #: 120-9158-1

Attach surge protector (B) to outlet box (C) and in-wall box (A) with four #6 x 3/8" screws (D).

NOTE: Service of an electrical gang box and wiring shall be performed by a qualiﬁed service

personnel in accordance with the NEC.

Insert in-wall box (A) through accessory hole in left or right position.

BCD

SURGE PROTECTOR

SCREWS

5 of 8 ISSUED: 07-09-12 SHEET #: 120-9158-1

THIS PAGE INTENTIONALLY LEFT BLANK

6 of 8 ISSUED: 07-09-12 SHEET #: 120-9158-1

THIS PAGE INTENTIONALLY LEFT BLANK

7 of 8 ISSUED: 07-09-12 SHEET #: 120-9158-1

THIS PAGE INTENTIONALLY LEFT BLANK

Peerless Industries, Inc. (“Peerless”) warrants to original end-users of Peerless®products will be free from defects in material and

workmanship, under normal use, for a period of ﬁve years from the date of purchase by the original end-user (but in no case longer than

six years after the date of the product's manufacture). At its option, Peerless will repair or replace, or refund the purchase price of, any

product which fails to conform with this warranty.

In no event shall the duration of any implied warranty of merchantability or ﬁtness for a particular purpose be longer than the

period of the applicable express warranty set forth above. Some states do not allow limitations on how long a implied warranty lasts,

so the above limitation may not apply to you.

This warranty does not cover damage caused by (a) service or repairs by the customer or a person who is not authorized for such service

or repairs by Peerless, (b) the failure to utilize proper packing when returning the product, (c) incorrect installation or the failure to follow

Peerless' instructions or warnings when installing, using or storing the product, or (d) misuse or accident, in transit or otherwise, including

in cases of third party actions and force majeure.

In no event shall Peerless be liable for incidental or consequential damages or damages arising from the theft of any product,

whether or not secured by a security device which may be included with the Peerless® product. Some states do not allow the

exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

This warranty is in lieu of all other warranties, expressed or implied, and is the sole remedy with respect to product defects. No dealer,

distributor, installer or other person is authorized to modify or extend this Limited Warranty or impose any obligation on Peerless in

connection with the sale of any Peerless®product.

This warranty gives speciﬁc legal rights, and you may also have other rights which vary from state to state.

LIMITED FIVE-YEAR WARRANTY

Peerless-AV

2300 White Oak Circle

Aurora, IL 60502

Email: [email protected]

Ph: (800) 865-2112

Fax: (800) 359-6500

www.peerless-av.com
