PedalPCB Ultisol Distortion Guide de démarrage rapide

Copyright © 2020 - PedalPCB.com Page 1 of 6Ultisol Distortion

Ultisol Distortion

Revised 8/19/20

All trademarks and registered trademarks are the property of their respective owners. The company, product, and service names used in this web site are for identication purposes only.

Use of these names, logos, and brands does not imply endorsement.

• Contour

• Tone

• Master

• Gain

CONTROLS AND FEATURES

Copyright © 2020 - PedalPCB.com Page 2 of 6Ultisol Distortion

Ultisol Distortion

Parts List (Page 1 of 2)

LOCATION VALUE TYPE NOTES

R1 2M2 Resistor, 1/4W

R2 3K3 Resistor, 1/4W

R3 1M Resistor, 1/4W

R4 4K7 Resistor, 1/4W

R5 4K7 Resistor, 1/4W

R6 680K Resistor, 1/4W

R7 4K7 Resistor, 1/4W

R8 3K Resistor, 1/4W

R9 47K Resistor, 1/4W

R10 220K Resistor, 1/4W

R11 10K Resistor, 1/4W

R12 10K Resistor, 1/4W

R13 100K Resistor, 1/4W

R14 100K Resistor, 1/4W

R15 1K Resistor, 1/4W

R100 10K Resistor, 1/4W

R101 10K Resistor, 1/4W

R102 4K7 Resistor, 1/4W

C1 100p Ceramic capacitor

C2 10n Film capacitor, 7.2 x 2.5mm

C3 47n Film capacitor, 7.2 x 2.5mm

C4 100p Ceramic capacitor

C5 1n Film capacitor, 7.2 x 2.5mm

C6 68n Film capacitor, 7.2 x 2.5mm

C7 68p Ceramic capacitor

C8 100n Film capacitor, 7.2 x 2.5mm

C9 47n Film capacitor, 7.2 x 2.5mm

C10 220n Film capacitor, 7.2 x 5.0mm

C11 470p Ceramic capacitor

C12 6n8 Film capacitor, 7.2 x 2.5mm

C13 4n7 Film capacitor, 7.2 x 2.5mm

C14 33n Film capacitor, 7.2 x 2.5mm

C15 4n7 Film capacitor, 7.2 x 2.5mm

C16 470n Film capacitor, 7.2 x 5.0mm

C17 220p Ceramic capacitor

C18 4u7 Electrolytic capacitor, 5mm

C100 220u Electrolytic capacitor, 8mm

C101 100n Film capacitor, 7.2 x 2.5mm

C102 47u Electrolytic capacitor, 5mm

D1 GE Germanium diode

D2 1N4001 Signal diode, DO-41

D3 1N4001 Signal diode, DO-41

D4 1N4148 Signal diode, DO-41

D100 1N5817 Schottky diode, DO-41

Copyright © 2020 - PedalPCB.com Page 3 of 6Ultisol Distortion

Ultisol Distortion

Parts List (Page 2 of 2)

LOCATION VALUE TYPE NOTES

IC1 LM833N Dual op-amp, DIP8

IC2 LM833N Dual op-amp, DIP8

CONTOUR A50K 16mm right-angle PCB mount pot

TONE A100K 16mm right-angle PCB mount pot

MASTER A10K 16mm right-angle PCB mount pot

GAIN C100K 16mm right-angle PCB mount pot

Copyright © 2020 - PedalPCB.com Page 4 of 6Ultisol Distortion

Ultisol Distortion

Schematic Diagram

Copyright © 2020 - PedalPCB.com Page 5 of 6Ultisol Distortion

Ultisol Distortion

Wiring Diagram

Copyright © 2020 - PedalPCB.com Page 6 of 6Ultisol Distortion

Ultisol Distortion

Drill Template

125B enclosure

F

O

O

T

S

W

I

T

C

H

P

O

T

E

N

T

I

O

M

E

T

E

R

P

O

T

E

N

T

I

O

M

E

T

E

R

P

O

T

E

N

T

I

O

M

E

T

E

R

P

O

T

E

N

T

I

O

M

E

T

E

R

L

E

D

D

C

J

A

C

K

I

N

P

U

T

J

A

C

K

O

U

T

P

U

T

J

A

C

K

Contour Tone

Master Gain
