Peavey TLM 5X Manuel utilisateur

FFrreeqquueennccyy rraannggee ((--1100 ddBB,, hhaallff

ssppaaccee))::

58 Hz to 1 kHz

FFrreeqquueennccyy rreessppoonnssee ((±±33 ddBB,, hhaallff

ssppaaccee))::

79 Hz to 17 kHz

SSeennssiittiivviittyy ((11WW//11MM))::

98 dB

PPoowweerr rraattiinngg ((pprrooggrraamm))::

500 Watts

PPoowweerr ccaappaacciittyy ((ppeeaakk))::

1000 Watts

MMaaxxiimmuumm SSPPLL::

1 7 dB

TTrraannssdduucceerr ccoommpplleemmeenntt::

Sheffield®Pro 1500+™15"

premium woofer and 14XT™1.4"

titanium diaphragm dynamic

compression driver on a 90 x

40˚ coverage constant

directivity horn

DDrriivveerr pprrootteeccttiioonn::

Sound Guard™IV for the

compression driver provides

long- and medium-term

overload and overdrive

protection

NNoommiinnaall ccoovveerraaggee ppaatttteerrnn::

90˚ x 40˚

EElleeccttrroo--aaccoouussttiicc ccrroossssoovveerr

ffrreeqquueennccyy::

.8 kHz

NNoommiinnaall iimmppeeddaannccee::

8 Ohms

IInnppuutt ccoonnnneeccttiioonnss::

Two 1/4" phone jacks in parallel

EEnncclloossuurree mmaatteerriiaallss aanndd ffiinniisshh::

Trapezoidal, black carpet-

covered enclosure with dado

joined 1/ " MDF (Medium

Density Fiberboard), and a full-

length, black powder-coated

steel grille

DDiimmeennssiioonnss ((HH xx WW xx DD))::

5" x 17.75" x 1 .563"

63.5 cm x 45.085 cm x

31.910 cm

WWeeiigghhtt::

43 lbs. (19.54 kg)

MMoouunnttiinngg oorr ssuussppeennssiioonn::

Die-cast aluminum 1-3/8" pole-

mount cup for stand-mounting

FFeeaattuurreess::

• Two-way sound reinforcement

monitor enclosure

• 30˚ and 45˚ dual angle

monitoring

• Peavey exclusive Sheffield Pro

1500+ woofer with .5" voice

coil

• 1.4" 14XT™titanium diaphragm

compression driver

• Sound Guard IV tweeter

protection

• 500 Watt program/1000 Watt

peak power handling

• Heavy duty crossover network

for driver protection and EQ

• Lightweight trapezoidal

enclosure

• 90˚ x 40˚ coverage constant

directivity horn for better off-

axis tonality

• High quality, heavy duty carpet

covering

• Steel handle

• Rugged dado and rabbet

construction for lightweight-

yet-strong joints

• T-Nut speaker mounting

• Heavy duty, full-length steel

grille

• SA-1 die-cast aluminum pole

mount

SPECIFICATIONS TLM™5X

Features and specifications subject to change without notice.

Peavey Electronics Corporation • 711 A Street • Meridian • MS • 39301 (601) 483-5365 • FAX (601) 486-1 78 • www.peavey.com

80305061

20 50 100 200 500 1k 2k 5k 10k 20k

Frequency (Hz)

100

110

dB SPL (re 20 Pa)

Amplitude Response (1W 1m On-Axis)

Figure 1

SPECIFICATIONS TLM™5X

DDeessccrriippttiioonn

The TLM5X is a two-way floor

monitor utilizing a Pro 1500+

woofer and a 14XT titanium

diaphragm dynamic compression

driver mounted on a 90˚ x 40˚

coverage constant-directivity horn.

The lightweight, yet rugged,

carpet-covered monitor enclosure

with stand-mount cup facilitates

portable use as a stage monitor or

in other sound reinforcement

applications. The dual-angle

enclosure provides a choice of 30˚

and 45˚ monitoring angles for full

monitoring utility. A full-length,

black powder-coated steel grille

provides driver protection and a

professional appearance.

The TLM 5X speaker system is

rated at 500 Watts program power

handling, and the full crossover

network includes high voltage film

capacitors and Sound Guard™IV

tweeter protection for clear,

punchy sound and excellent long-

term reliability. Two 1/4" phone

jack input connectors make hook-

up and daisy-chaining to other

monitors a breeze.

33 ++ YYEEAARR LLIIMMIITTEEDD WWAARRRRAANNTTYY

NNOOTTEE::For details, refer to the

warranty statement. Copies of

this statement may be obtained

by contacting Peavey Electronics

Corporation, P.O. Box 898,

Meridian, Mississippi 39301-

898.
