Infrared Thermometer PCE-660

User Manual

User manuals in various languages (français,

italiano, español, português, nederlands, türk, polski,

русский, 中文) can be found by using our

product search on: www.pce-instruments.com

Last change: 15 June 2018

v1.0

English


 © PCE Instruments


Contents
1Safety notes........................................................................................... 1
2Features ................................................................................................. 1
3Field of view........................................................................................... 2
4Technical specifications ...................................................................... 2
5Device description ................................................................................3
6Delivery contents ..................................................................................3
7Operation ............................................................................................... 3
7.1 How to make a measurement........................................................................................... 3
7.2 Settings............................................................................................................................ 4
7.3 Battery replacement......................................................................................................... 4
8Further information............................................................................... 5
8.1 Field of view..................................................................................................................... 5
8.2 Distance and spot size..................................................................................................... 5
8.3Locating a hot spot........................................................................................................... 5
8.4 Tips.................................................................................................................................. 5
9Emissivities ........................................................................................... 5
10 Warranty.................................................................................................6
11 Disposal ................................................................................................. 6


1 Safety notes

Please read this manual carefully and completely before you use the device for the first time. The

device may only be used by qualified personnel and repaired by PCE Instruments personnel.

Damage or injuries caused by non-observance of the manual are excluded from our liability and

not covered by our warranty.

•The device must only beused as described in this instruction manual.If used otherwise,

this can cause dangerous situations for the user and damage to the meter.

•The instrument may only be used if the environmental conditions (temperature, relative

humidity, …) are within the rangesstated in the technical specifications. Do not expose

the device to extreme temperatures, direct sunlight, extreme humidity or moisture.

•The meter must not be immersed in water.

•Do not expose the device to shocks or strong vibrations.

•The case should only be opened by qualified PCE Instruments personnel.

•Never use the instrument when your hands are wet.

•You must not make any technical changes to the device.

•The appliance should only be cleaned with a damp cloth. Use only pH-neutral cleaner,

no abrasives, solvents or volatile liquids.

•The device must only be used with accessories from PCE Instruments or equivalent.

•Before each use, inspect the case for visible damage. If any damage is visible, do not

use the device.

•Do not use the instrument in explosive atmospheres.

•The measurement range as stated in the specifications must not be exceeded under

any circumstances.

•Do not point the laser beam at yourself or other people / animals. Avoid eye contact

with the laser beam, either direct or from a reflective surface.

•Non-observance of the safety notes can cause damage to the device and injuries to

the user.

We do not assume liability for printing errors or any other mistakes in this manual.

We expressly point to our general guarantee terms which can be found in our general terms of

business.

If you have any questions please contact PCE Instruments. The contact details can be found at

the end of this manual.

2 Features

•Quick and easy measurement

•Precise non-contact measurement

•Built-in laser pointer increases the target accuracy

•Colour LCD

•Adjustable emissivity: 0.1 … 1.0

•Automatic measurement range selection with resolution 0.1 °C/0.1 °F

•Hold function

•Auto Power Off function

•Selectable units

•D:S = 13:1

3 Field of view / distance to spot ratio

The meter's field of view is 13:1, for example, if the meter is 13 inches from the target spot, the

diameter of the target must be at least 1 inch. Other distance ratios are shown below in the field

of view diagram.

4 Technical specifications

Measurement range

-50 … 380 ℃/ -58 … 716 ℉

-50 … 580 ℃/ -58 … 1076 ℉

Resolution

0.1 ℃/℉

Accuracy

-50 … 0 ℃/ -58 … 32 ℉:±4 ℃/ 7 ℉

Above 0 ℃: ±2 % from reading or ±2 ℃/ 3.6 ℉, whichever

is greater

Field of view / distance to spot

ratio

D:S = approx. 13:1 (D=distance, S=spot)

Response time

<1 s

Emissivity

Adjustable from 0.1 … 1.0

Spectral response

8 … 14 µm

Over-range indication

“HI” indicates that upper temperature limit is exceeded

“LO” indicates lower temperature limit is fallen below

Temperature display

Auto display, “-”means negative, positive value shown w/o

sign

Diode laser

Output <1mW, 630 … 670nm, class 2

Automatic Power Off

Meter shuts off automatically after 15 seconds of inactivity

Operating temperature

0 … 50 ℃/ 32 …122 ℉

Storage temperature

-20 … 60 ℃/ -4 …158 ℉

Operating humidity

10 …95 % RH

Storage humidity

<80 % RH

Power supply

9 V battery

Weight

121 g

Dimensions (H x W x D)

144.6 x 75.0 x 38.5 mm

5 Device description

①Laser pointer

②IR sensor

③LC display

④Unit key

⑤SET key

⑥Laser/backlight key

⑦Trigger button

⑧Battery compartment cover

Display

①Laser icon

②Backlight icon

③Temperature unit (℃/℉)

④Reading

⑤Measurement icon

⑥Hold icon

⑦Battery status indicator

6 Delivery contents

1 x infrared thermometer PCE-660

1 x 9 V battery

1 x user manual

7 Operation

7.1 How to make a measurement

①Hold the meter by its handle grip and point it towards the surface to be measured.

②Pull and hold the trigger button to turn on the meter. The "SCAN" icon will appear and the

measurement will start.

③The surface temperature being tested will be displayed on the LCD screen.

④Release the trigger. The "HOLD" icon will appear and the reading will be held for several

seconds. The meter will automatically shut off after 15 seconds.

Note:

If the meter is used in an environment with wide temperature changes, allow at least 30 minutes

for the meter to adjust.

7.2 Settings

Power on the meter，press and hold the SET key until the emissivity icon appears on the LCD

screen, then release the button. To adjust the emissivity, press the unit key to increase and the

laser/backlight key to decrease the emissivity value.

In measurement mode, press the unit key to switch the temperature unit from ℃to ℉or vice

versa.

To power on or disable the laser pointer, press the laser/backlight key.

7.3 Battery replacement

When the low battery icon appears, replace the battery.

Open the battery compartment, replace the 9 V battery and close the battery compartment cover.

Observe correct polarity.

8 Further information

8.1 Field of view

-The object under test should be larger than the spot size calculated by the field of view diagram.

-The smaller the target object is, the closer the meter should be to it for accurate measuring.

-When accuracy is critical, make sure the target is at least twice as large as the spot size.

8.2 Distance and spot size

As distance (D) from the object increases, the spot size (S) of the area measured by the unit

should become larger.

8.3 Locating a hot spot

To find a hot spot, first aim the thermometer at the area around the target, then scan up and down

until the hot spot is located.

8.4 Tips

-Not recommend for measuring shiny or polished metal surfaces like stainless steel, aluminium,

etc.

-You cannot make measurements through transparent surfaces such as glass.

-If the surface of the object under test is covered with frost, oil, grime, etc., clean it beforemaking

a measurement.

9 Emissivities

Substance

Asphalt

Concrete

Marble

Human skin

Ice

Cloth(black)

Aluminium

Emissivity

0.95

0.94

0.98

0.30

Substance

Rubber

Frozen food

Timber

Carbon

Brick

Plastic

Lacquer

Emissivity

0.95

0.90

0.94

0.85

0.90

0.85 …0.95

0.80 …0.95

Substance

Ceramic

Hot food

Fat-lute

Copper

Snow

Plaster

Glass

Emissivity

0.95

0.93

0.94

0.50

0.90

0.80 …0.90

0.90 …0.95

Substance

Leather

Water

Textiles

Lead

Sand

Paper

Iron oxides

Emissivity

0.95

0.93

0.94

0.50

0.90

0.70 …0.94

0.78 …0.82

10 Warranty

You can read our warranty terms in our General Business Terms which you can find here:

https://www.pce-instruments.com/english/terms.

11 Disposal

For the disposal of batteries in the EU, the 2006/66/EC directive of the European Parliament

applies. Due to the contained pollutants, batteries must not be disposed of as household waste.

They must be given to collection points designed for that purpose.

In order to comply with the EU directive 2012/19/EU we take our devices back. We either re-use

them or give them to a recycling company which disposes of the devices in line with law.

For countries outside the EU, batteries and devices should be disposed of in accordance with

your local waste regulations.

If you have any questions, please contact PCE Instruments.

PCE Instruments contact information

Germany France Spain

PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L.

Im Langel 4 23, rue de Strasbourg Calle Mayor, 53

D-59872 Meschede 67250 SOULTZ-SOUS-FORETS 02500 Tobarra (Albacete)

Deutschland France España

Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17 Tel. : +34 967 543 548

Fax: +49 (0) 2903 976 99 29 Numéro de fax: +33 (0) 972 3537 18 Fax: +34 967 543 542

[email protected] [email protected] [email protected]

www.pce-instruments.com/deutsch www.pce-instruments.com/french www.pce-instruments.com/espanol

United States of America United Kingdom Italy

PCE Americas Inc. PCE Instruments UK Ltd PCE Italia s.r.l.

711 Commerce Way suite 8 Unit 11 Southpoint Business Park Via Pesciatina 878 / B-Interno 6

Jupiter / Palm Beach Ensign Way, Southampton 55010 LOC. GRAGNANO

33458 FL Hampshire CAPANNORI (LUCCA)

USA United Kingdom, SO31 4RF Italia

Tel: +1 (561) 320-9162 Tel: +44 (0) 2380 98703 0 Telefono: +39 0583 975 114

Fax: +1 (561) 320-9176 Fax: +44 (0) 2380 98703 9 Fax: +39 0583 974 824

[email protected] [email protected] i[email protected]

www.pce-instruments.com/us www.pce-instruments.com/english www.pce-instruments.com/italiano

The Netherlands Chile Hong Kong

PCE Brookhuis B.V. PCE Instruments Chile S.A. PCE Instruments HK Ltd.

Institutenweg 15 RUT: 76.154.057-2 Unit J, 21/F., COS Centre

7521 PH Enschede Santos Dumont 738, local 4 56 Tsun Yip Street

Nederland Comuna de Recoleta, Santiago, Chile Kwun Tong

Telefoon: +31 (0)53 737 01 92 Tel. : +56 2 24053238 Kowloon, Hong Kong

Fax: +31 (0) 53 - 430 36 46 Fax: +56 2 2873 3777 Tel: +852-301-84912

[email protected] [email protected] [email protected]

www.pce-instruments.com/dutch www.pce-instruments.com/chile www.pce-instruments.cn

China Turkey

PCE (Beijing) Technology Co.,Ltd PCE Teknik Cihazları Ltd.Şti.

1519 Room, 6 Building Halkalı Merkez Mah.

Men Tou Gou Xin Cheng, Pehlivan Sok. No.6/C

Men Tou Gou District 34303 Küçükçekmece - İstanbul

102300 Beijing Türkiye

China Tel: 0212 471 11 47

Tel: +86 (10) 8893 9660 Faks: 0212 705 53 93

[email protected] [email protected].tr

www.pce-instruments.cn www.pce-instruments.com/turkish

Table des matières

Autres manuels PCE Instruments Thermomètre

PCE Instruments

PCE Instruments PCE-MIR 20 Manuel utilisateur

PCE Instruments

PCE Instruments hi temp 2400 Manuel utilisateur

PCE Instruments

PCE Instruments T 390 Manuel utilisateur

PCE Instruments

PCE Instruments PCE-889 Manuel utilisateur

PCE Instruments

PCE Instruments PCE-TC 31 Manuel utilisateur

PCE Instruments

PCE Instruments PCE-889B Manuel utilisateur

PCE Instruments

PCE Instruments PCE-T 390 Manuel utilisateur

PCE Instruments

PCE Instruments LOG 100 Manuel utilisateur

PCE Instruments

PCE Instruments PCE-T 330 Manuel utilisateur

PCE Instruments

PCE Instruments PCE-DPM 3 Manuel utilisateur

PCE Instruments

PCE Instruments PCE-313 Manuel utilisateur

PCE Instruments

PCE Instruments PCE-670 Manuel utilisateur

PCE Instruments

PCE Instruments PCE-779N Manuel utilisateur

PCE Instruments

PCE Instruments PCE-IR 5 Manuel utilisateur

PCE Instruments

PCE Instruments PCE-313 S Manuel utilisateur

PCE Instruments

PCE Instruments PCE-T312N Manuel utilisateur

PCE Instruments

PCE Instruments PCE-779N-ICA Manuel utilisateur

PCE Instruments

PCE Instruments PCE-IR 425 Manuel utilisateur

PCE Instruments

PCE Instruments PCE-IR 80 Manuel utilisateur

PCE Instruments

PCE Instruments PCE-IR-100 Manuel utilisateur

PCE Instruments

PCE Instruments PCE-ITF 5 Manuel utilisateur

PCE Instruments

PCE Instruments PCE-IR 80-ICA Manuel utilisateur

PCE Instruments

PCE Instruments PCE-IR 6 Manuel utilisateur

PCE Instruments

PCE Instruments PCE-TC 29 Manuel utilisateur

Manuels Thermomètre populaires d'autres marques

Delton

Delton 981A Manuel utilisateur

Baker

Baker MM2P Manuel utilisateur

Tarmo

Tarmo 320281 Manuel utilisateur

Citizen

Citizen CTD 504 Manuel utilisateur

TFA

TFA 14.1500 Manuel utilisateur

Vive

Vive DMD1010 Manuel utilisateur

Gotemp

Gotemp THB4002 Manuel utilisateur

GREISINGER

GREISINGER G 1202 Manuel utilisateur

Amprobe

Amprobe TMD-53W Manuel utilisateur

Trotec

Trotec BP10 Manuel utilisateur

Radiance instruments

Radiance instruments RT616 Series Manuel utilisateur

Eurolec

Eurolec IR151 Manuel utilisateur

Scaneo

Scaneo TS42B Manuel utilisateur

Sper scientific

Sper scientific 800043 Manuel utilisateur

Microlife

Microlife NC 200 Mode d’emploi

Motorola

Motorola MBP69SN Guide de configuration

The MeatStick

The MeatStick The MeatStick Manuel utilisateur

Hama

Hama TH35-A Manuel utilisateur
