PCB Piezotronics 482C15/NP Manuel utilisateur

Model 482C15/NP

Four-Channel, ICP Sensor Signal Conditioner

Installation and Operating Manual

For assistance with the operation of this product,

contact PCB Piezotronics, Inc.

Toll-free: 800-828-8840

24-hour SensorLine: 716-684-0001

Fax: 716-684-0987

E-mail: [email protected]

Web: www.pcb.com

Manual 21354 Rev E

ECN 50523

Repair and Maintenance

PCB guarantees Total Customer Satisfaction through its

“Lifetime Warranty Plus” on all Platinum Stock Products

sold by PCB and through its limited warranties on all other

PCB Stock, Standard and Special products. Due to the

sophisticated nature of our sensors and associated

instrumentation, field servicing and repair is not

recommended and, if attempted, will void the factory

warranty.

Beyond routine calibration and battery replacements

where applicable, our products require no user

maintenance. Clean electrical connectors, housings, and

mounting surfaces with solutions and techniques that will

not harm the material of construction. Observe caution

when using liquids near devices that are not hermetically

sealed. Such devices should only be wiped with a

dampened cloth—never saturated or submerged.

In the event that equipment becomes damaged or ceases

to operate, our Application Engineers are here to support

your troubleshooting efforts 24 hours a day, 7 days a

week. Call or email with model and serial number as well

as a brief description of the problem.

Calibration

Routine calibration of sensors and associated

instrumentation is necessary to maintain measurement

accuracy. We recommend calibrating on an annual basis,

after exposure to any extreme environmental influence,

or prior to any critical test.

PCB Piezotronics is an ISO-9001 certified company whose

calibration services are accredited by A2LA to ISO/IEC

17025, with full traceability to SI through N.I.S.T. In

addition to our standard calibration services, we also offer

specialized tests, including: sensitivity at elevated or

cryogenic temperatures, phase response, extended high

or low frequency response, extended range, leak testing,

hydrostatic pressure testing, and others. For more

information, contact your local PCB Piezotronics

distributor, sales representative, or factory customer

service representative.

Returning Equipment

If factory repair is required, our representatives will

provide you with a Return Material Authorization (RMA)

number, which we use to reference any information you

have already provided and expedite the repair process.

This number should be clearly marked on the outside of

all returned package(s) and on any packing list(s)

accompanying the shipment.

Contact Information

PCB Piezotronics, Inc.

3425 Walden Ave.

Depew, NY14043 USA

Toll-free: (800) 828-8840

24-hour SensorLine: (716) 684-0001

General inquiries: in[email protected]

Repair inquiries: rma@pcb.com

For a complete list of distributors, global offices and sales

representatives, visit our website, www.pcb.com.

Safety Considerations

This product is intended for use by qualified personnel

who recognize shock hazards and are familiar with the

precautions required to avoid injury. While our equipment

is designed with user safety in mind, the protection

provided by the equipment may be impaired if equipment

is used in a manner not specified by this manual.

Discontinue use and contact our 24-Hour Sensorline if:

Assistance is needed to safely operate equipment

Damage is visible or suspected

Equipment fails or malfunctions

For complete equipment ratings, refer to the enclosed

specification sheet for your product.

Definition of Terms and Symbols

The following symbols may be used in this manual:

DANGER

Indicates an immediate hazardous

situation, which, if not avoided, may

result in death or serious injury.

Manual 21354 Rev E

ECN 50523

CAUTION

Refers to hazards that could damage

the instrument.

NOTE

Indicates tips, recommendations and

important information. The notes

simplify processes and contain

additional information on particular

operating steps.

The following symbols may be found on the equipment

described in this manual:

This symbol on the unit indicates that

high voltage may be present. Use

standard safety precautions to avoid

personal contact with this voltage.

This symbol on the unit indicates that

the user should refer to the operating

instructions located in the manual.

This symbol indicates safety, earth

ground.

Manual 21354 Rev E

ECN 50523

PCB工业监视和测量设备 - 中国RoHS2公布表

PCB Industrial Monitoring and Measuring Equipment - China RoHS 2 Disclosure Table

部件名称

有害物质

铅(Pb)

汞

(Hg)

镉

(Cd)

六价铬(Cr(VI))

多溴联苯 (PBB)

多溴二苯醚(PBDE)

住房

PCB板

电气连接器

压电晶体

环氧

铁氟龙

电子

厚膜基板

电线

电缆

塑料

焊接

铜合金/黄铜

本表格依据 SJ/T 11364 的规定编制。

O：表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。

X：表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。

铅是欧洲RoHS指令2011/65/ EU附件三和附件四目前由于允许的豁免。

CHINA RoHS COMPLIANCE

Manual 21354 Rev E

ECN 50523

Component Name

Hazardous Substances

Lead (Pb)

Mercury (Hg)

Cadmium (Cd)

Chromium VI

Compounds

(Cr(VI))

Polybrominated

Biphenyls (PBB)

Polybrominated

Diphenyl Ethers

(PBDE)

Housing

PCB Board

Electrical Connectors

Piezoelectric Crystals

Epoxy

Teflon

Electronics

Thick Film Substrate

Wires

Cables

Plastic

Solder

Copper Alloy/Brass

This table is prepared in accordance with the provisions of SJ/T 11364.

O: Indicates that said hazardous substance contained in all of the homogeneous materials for this part is below the limit

requirement of GB/T 26572.

X: Indicates that said hazardous substance contained in at least one of the homogeneous materials for this part is above the limit

requirement of GB/T 26572.

Lead is present due to allowed exemption in Annex III or Annex IV of the European RoHS Directive 2011/65/EU.



PCB PIEZOTRONICS, INC. 3425 WALDEN AVENUE DEPEW, NY 14043-2495 PHONE 716-684-0001 FAX 716-684-0987

®ICP is a registered trademark of PCB Group, Inc. KS398

MANUAL #: 38410

MANUAL REV: B

ECO: 50033

10/31/2019

SIGNAL CONDITIONER

Models 482C05/482C15

GENERAL OPERATION

MANUAL

For powering ICP®sensors and in-line charge converters, this signal conditioner provides a cost

effective method for powering small numbers of sensor channels.

The 482C Series is available with many different options from PCB. This manual describes the

functions of the most economical signal conditioner with unity gain (482C05) and x1, x10, x100

jumper selectable gain (482C15), of that series.

Table of Contents

Table of Contents i

1-1. Introduction 1

1-2. Safety Considerations 1

1-3. Equipment Rating 2

1-4. Model 482C15 System Description 2

1-5. Model 482C05 System Description 4

1-6. Installation 4

1-7. Grounding Techniques 4

1-8. Unit Power 5

1-9. Maintenance and Repair 5

Appendix

Specification Sheet

Outline Drawing

MULTICHANNEL SIGNAL CONDITIONER MODEL 482C GENERAL OPERATION MANUAL

1-1. Introduction

The Model 482C05 is a basic ICP signal conditioner that provides an adjustable current source to drive ICP®sensors.

Additionally it has Open, Short and Overload Input fault condition indicators.

The Model 482C15 is an ICP®signal conditioner that has all the features of the 482C05 plus jumper selectable (x1, x10,

and x100) Gain options and an Overload range selection. An easy to open cover, allows access to the jumper selections.

The following sections describe these devices in more detail.

1-2. Safety Considerations

WARNING SYMBOLS AND TERMS

The following symbols and terms may be found on the equipment described in this manual.

This symbol on the unit indicates that the user should refer to the operating instructions located in the manual.

This symbol on the unit indicates that high voltage may be present. Use standard safety precautions to avoid

personal contact with this voltage.

This symbol indicates that the test fixture, Model 482C15, must be connected to earth ground via the power cord.

The WARNING heading used in this manual explains dangers that might result in personal injury or death. Always

read the associated information very carefully before performing the indicated procedure.

The CAUTION heading used in this manual explains hazards that could damage the instrument.

WARNING 1: The power supply/signal conditioner should not be opened by anyone other than qualified service

personnel. This product is intended for service by qualified personnel who recognize shock hazards and are familiar

with the safety precautions required to avoid injury.

WARNING 2: This equipment is designed with user safety in mind; however, the protection provided by the equipment

may be impaired if the equipment is used in a manner not specified by PCB Piezotronics, Inc.

CAUTION 1: Cables can kill your equipment. High voltage ElectroStatic Discharge (ESD) can damage electrical

devices. Similar to a capacitor, a cable can hold a charge caused by triboelectric transfer, such as that which occurs in

the following:

Laying on and moving across a rug.

Any movement through air.

The action of rolling out a cable.

Contact to a non-grounded person

The solution for product safety: 1) Connect the cables only with the AC power off. 2) Temporarily “short” the end of

the cable before attaching it to any signal input or output.

MULTICHANNEL SIGNAL CONDITIONER MODEL 482C GENERAL OPERATION MANUAL

CAUTION 2: ESD considerations should be made prior to performing any internal adjustments on the equipment.

Any piece of electronic equipment is vulnerable to ESD when opened for adjustments. Internal adjustments should

therefore be done ONLY at an ESD-safe work area. Many products have ESD protection, but the level of protection may

be exceeded by extremely high voltage that is typically present in normal situations.

1-3. Equipment Rating

For complete specifications, please refer to the enclosed Specification Sheet. This equipment operates optimally at +32

to +120°F (0 to +50°C), in an environment having <85% relative humidity. Its line power frequency range is 47-63 Hz.

The 482C15/482C05 devices require 34-38 VDC with 200 mA to operate. In turn, they supply 26 VDC @ 2 to 20 mA

excitation voltage to connected ICPsensors or in-line charge converters. The units get power via AC power adaptor

PCB Model 488A04, 36VDC battery pack, or a car adapter which all plug into a receptacle on the rear panel (PCB

Model 488A11).

1-4. Model 482C15 System Description

The Model 482C15 is a four channel signal conditioning unit designed to interface measurement signals to readout or

recording devices.

The following are features that come standard on 482C15 units:

Input fault and overload LED’s with jumper selectable overload level of +/-5V or +/-10V

Variable ICP®source current, 0 to 20 mA

Jumper selectable Voltage input mode

Jumper selectable gain of x1, x10, x100 (482C15 Only)

Lighted power indicator on the front panel

Rear panel BNC input/output connectors

Optional L.P. plug in filters (477A series type) various 2-pole frequencies avail. Consult factory

1-4.1. Model 482C15 ICP®Input/Output Mode

The Model 482C15 contains a regulated 26 VDC power supply that provides constant current for up to 4 individual

channels. Both the output and input connections utilize BNC connectors and are brought out through the rear panel. The

unit is AC coupled only. The 482C series offers optional DC Coupling. Consult factory

1-4.2. Adjusting the Current Source

The Current adjustment is located on the rear of the unit. Use a standard small flat screwdriver to adjust the “I ADJ”

potentiometer. Turning the adjustment slot clockwise will increase the current, while counterclockwise will decrease the

current. Do this adjustment only while a DC mA meter or DMM set to mA is connected to any “ICP” BNC. One

adjustment controls all channels. The unit is factory set to 4mA and can be adjusted between 0mA-20mA.

1-4.3. Fault Indications

The three red LED’s on the front panel are all indicators of some type of problem. The normal good operation state is

when all fault lights are off. The “OPEN” light indicates that the Bias voltage is over that of most sensors and is close to

an open circuit voltage of 26VDC. The photo on the cover is shown with the unit on, and no sensors attached, so the

“OPEN” LED is on. The “SHORT” light indicates a very low Bias voltage close to 0VDC. The “OVERLOAD” light

MULTICHANNEL SIGNAL CONDITIONER MODEL 482C GENERAL OPERATION MANUAL

indicates a signal level of +/-10V Peak has been detected and the signal may be in danger of clipping. These fault lights

are active for all channels, at the same time.

1-4.4. Gain selection / Jumper definition

The 482C15 has internal jumpers that are accessed by opening the top cover. The top cover is secured by four (4)

Philips head screws on the bottom of the unit. Place the unit on a clean, flat surface (Electrical Static Discharge

protection recommended) and remove the four screws. Carefully rotate the unit and place it on its feet, then gently

remove the cover.

The various jumpers are all labeled on the PC board. Each channel can be set to your selected gain and other options.

The selection of all these features with jumpers allows the 482C15 to have the functionality of many other higher priced

units at an economical cost. See the table that explains the function and number of each jumper. “X” represents channel

number. Once jumpers have been placed as needed, replace cover –taking special care to align the front and back

panels with the slots in the top cover. Insert the four (4) screws and tighten to 5 in-lbs.

Gain 1 10 100 JX02 1 jumper per channel

Overload 5V/10V J1 Controls all channels

Voltage Mode JX03 2 jumpers per channel

Bypass Filter JX00 Remove to install filter module

477A Filter FILX00 Install filter here per channel

Gain IC

Optional 477A

5V or 10V (J1)

Voltage mode selection (JX03)

Pin 1 Indicator (FILX00)

Gain x10

ICPmode

Gain x100

JX00 open 477A ENA

Table des matières

Autres manuels PCB Piezotronics Équipement de test

PCB Piezotronics

PCB Piezotronics 498A-0016 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 498A-0093 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-0113A Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 482C Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-0112A Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 481A02 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 394A10 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-0152A Manuel utilisateur

PCB Piezotronics

PCB Piezotronics F8159-0112A Manuel utilisateur

PCB Piezotronics

PCB Piezotronics ICP 482C54/04 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-1112A Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 301A04 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 482A23/NP Manuel utilisateur

PCB Piezotronics

PCB Piezotronics F8159-1012A Manuel utilisateur

PCB Piezotronics

PCB Piezotronics PCB-137B29B Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 498A-0063 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics Larson Davis CAL250 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 480E09 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-0045B Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 482B11 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 482C27 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics ICP 481A Series Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 498A-0015 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159 Series Manuel utilisateur

Manuels Équipement de test populaires d'autres marques

SMART

SMART KANAAD SBT XTREME 3G Series Manuel utilisateur

Agilent Technologies

Agilent Technologies BERT Serial Manuel utilisateur

Agilent Technologies

Agilent Technologies N3280A Manuel utilisateur

Vernier

Vernier Go Direct Voltage Manuel utilisateur

Lifeloc

Lifeloc R.A.D.A.R. Manuel utilisateur

Fluke

Fluke T5-600 Instructions d'utilisation et d'installation

Mercury

Mercury TSL01 Manuel utilisateur

MAHA

MAHA MBT Series Manuel utilisateur

Fuji Electric

Fuji Electric P-61 Manuel utilisateur

ETC

ETC SealerAtor Manuel utilisateur

Skyfine

Skyfine ETHYWAY V2 Manuel utilisateur

Appion

Appion G5 Twin Manuel utilisateur

BW Technologies

BW Technologies MicroDock II Manuel utilisateur

Sun Nuclear

Sun Nuclear 1027 Manuel utilisateur

Biomark

Biomark HPR LITE READER Manuel utilisateur

Hioki

Hioki 3169-20 Manuel utilisateur

Ashcroft

Ashcroft ATE-100 Manuel utilisateur

Rohde & Schwarz

Rohde & Schwarz RTA4000 Manuel utilisateur
