CopperLink™ Model CL1300

Long Range Ethernet Extender

Quick Start Guide

Important—This is a Class A device and is intended for use in a light indus-

trial environment. It is not intended nor approved for use in an industrial or

residential environment.

Part Number: 07MCL1300-QS, Rev. B

Revised: July 31, 2019

Sales Office: +1 (301) 975-1000

Technical Support: +1 (301) 975-1007

E-mail: support@patton.com

2CopperLink 1300 Quick Start Guide

1.0 Hardware Installation

1.1 Contents of Package

•CL1300 Long Range Ethernet Extender

•External power supply for CopperLink Model CL1300

1.2 Identify the connector and attach the cables

CL1300 connectors are shown in.figure 1 on page 3.

CL1300R connectors are shown in figure 2 on page 3.

•This device contains no user serviceable parts. The

equipment shall be returned to Patton Electronics for

repairs, or repaired by qualified service personnel.

•The external power adapter shall be a listed Limited

Power Source. The mains outlet that is utilized to power

the devise shall be within 10 feet (3 meters) of the

device, shall be easily accessible, and protected by a

circuit breaker.

•If an AC power adapter is used, ensure that the power

cable used meets all applicable standards for the coun-

try in which it is to be installed, and that it is connected

to a wall outlet which has earth ground.

•Hazardous network voltages are present in WAN ports

regardless of whether power to the unit is ON or OFF. To

avoid electric shock, use caution when near WAN ports.

When detaching the cables, detach the end away from

the device first.

•Do not work on the system or connect or disconnect

cables during periods of lightning activity.

WARNING

CopperLink 1300 Quick Start Guide 3

Figure 1. CL1300 Ethernet Extender rear panel

Figure 2. CL1300R Ethernet Extender front panel

Connect the Line Interface

To function properly, the CL1300 must be connected using a twisted-pair, uncondi-

tioned, dry, metal wire, between 19 (0.9mm) and 26 AWG (0.4mm). Leased circuits that

run through signal equalization equipment are not acceptable.

The Ethernet Extender is equipped with a RJ-45 interface jack (Line), which conforms

to the T568B standard. As such, any standard Category 5e cable can be used to directly

connect two extenders. Depending on the extender model, it will have a two-wire or

four-wire interface.

Observe the signal/pin relationship on the CL1300’s Line interface jack for each pair in

figure 3 on page 4.

4CopperLink 1300 Quick Start Guide

Figure 3. CL1300 (RJ-45) twisted pair line interface

2.0 Connecting Interfaces

2.1 Connect the Ethernet Interface

The Long Range Ethernet Extender has four unshielded RJ-45 auto-MDIX10/100Base-T

interfaces. These are designed to connect directly to a 10/100Base-TX network. shows

the signal/pin relationships on this interface. You may connect this port to a hub or PC

using a straight through or crossover cable that is up to 328 ft long.

2.2 Connect the Power Source

Refer to the appropriate section to connect power:

•Section “CL1300 Series” to install the AC power supply or optional DC power con-

verter

•Section “CL1300R Series” on page 7 to install the AC power supply or connect to

the internal DC power converter

CL1300 Series

AC power supply. The CL1300 comes standard with an AC power supply:

•There is one fuse in the equipment rated at 250V, 500 mA, 2 sec.

•Rated voltage: 5 VDC

•Rated current: 1 A DC

•Output from power supply: 5 VDC, 2A

•Input to power supply: universal input 100–240 VAC 50/60 Hz 0.3A

Do the following:

1. Plug the AC switching power supply (see figure 4 on page 5) barrel jack into the

CL1300 Power port (see figure 5 on page 5)

(Line 1 TIP)

(Line 1 (RING)

(no connection)

(Line 0 TIP)

(Line 0 RING)

(no connection)

CopperLink 1300 Quick Start Guide 5

2. If it hasn’t already been done, slide the AC plug that came with the AC switching

power supply (see figure 4) onto the AC switching power supply.

3. Connect the AC plug end of the AC switching power supply into an AC power out-

let.

Figure 4. AC Switching Power Supply

Figure 5. CL1300 Power port

The external power adapter shall be a listed limited power

source that incorporates a disconnect device and shall be

positioned within easy reach of the operator. Ensure that

the AC power cable meets all applicable standards for the

country in which it is to be installed, and that it is con-

nected to a wall outlet which has earth ground.

CAUTION

6CopperLink 1300 Quick Start Guide

DC power supply. The CL1300 is available with an optional DC power converter (p/n

48V-PSM5)

•Input: Rated voltage:

- 36–60 VDC

- Rated current: 0.25 A DC

•Output:

- Rated voltage: 5 VDC ± 5%, 5W

- Rated current: 1 A DC

- 6-inch cable terminated with 2.5 mm barrel plug, center positive

•Isolation: 500 VDC

•Environment: 0–40°C; 5–95% relative humidity, non-condensing

Do the following:

1. Plug the DC power converter (see figure 6) barrel jack into the CL1300 Power

port (see figure 5 on page 5)

2. Connect the DC power converter’s red and black wires to the 36–60 VDC power

source.

Figure 6. DC Power Converter (p/n 48V-PSM5)

The external DC adapter shall be a listed limited power

source that incorporates a disconnect device and shall be

positioned within easy reach of the operator. The intercon-

necting cables shall be rated for the proper voltage, cur-

rent, anticipated temperature, flammability, and

mechanical serviceability.

CAUTION

CopperLink 1300 Quick Start Guide 7

CL1300R Series

The CL1300R comes standard with an AC switching power supply or an internal DC

power converter.

AC power supply. The CL1300R comes standard with an AC power supply:

•There is one fuse in the equipment rated at 250V, 500 mA, 2 sec.

•Rated voltage: 5 VDC

•Rated current: 1 A DC

•Output from power supply: 5 VDC, 2A

•Input to power supply: universal input 100–240 VAC 50/60 Hz 0.3A

Do the following:

1. Plug the AC switching power supply (see figure 7) terminal block plug into the

CL1300R terminal block (see figure 8 on page 8)

2. If it hasn’t already been done, slide the AC plug that came with the AC switching

power supply (see figure 7) onto the AC switching power supply.

3. Connect the AC plug end of the AC switching power supply into an AC power out-

let.

Figure 7. AC Switching Power Supply with Terminal Block Plug

8CopperLink 1300 Quick Start Guide

Figure 8. CL1300R Terminal Block Plug

DC power supply. The CL1300R has a built-in internal DC power converter:

•Input: Rated voltage:

- 12–60 VDC

- Rated current: 0.25 A DC

Do the following: Connect the 12–60 VDC power source wires to the CL1300R terminal

block (see figure 9 on page 9) in the order shown in figure 10 on page 9.

The external power adapter shall be a listed limited power

source that incorporates a disconnect device and shall be

positioned within easy reach of the operator. Ensure that

the AC power cable meets all applicable standards for the

country in which it is to be installed, and that it is con-

nected to a wall outlet which has earth ground.

CAUTION

CopperLink 1300 Quick Start Guide 9

Figure 9. CL1300R Terminal Block

Figure 10. Terminal Block Label

2.3 Ethernet Extender Status LEDs

The LEDs indicate the status of power, CopperLink, and Ethernet connections (see

figure 2 on page 3 for CL1300R or figure 11 on page 10 for CL1300).

Note When extinguished, the LED indicators are clear; when lit, the indicators are yel-

low.

10 CopperLink 1300 Quick Start Guide

Figure 11. CL1324 front panel

3.0 Configuration

Your CopperLink Ethernet Extenders are pre-configured to work in pairs. If the factory

installed configuration needs to be adjusted, you can configure the device by using:

•DIP switches (while powered off)

•Web Wizards through HTTP access

•Command line interface (CLI) through SSH

•A combination of the above.

For simple and common configurations, you may only need to use the dip switches.

Note If you will not have physical access to the device, it is best to leave the DIP

switches disabled, as they will always override the other configuration access

methods for some settings. This will be problematic if you need to change these

settings remotely.

Table 1. CL1300 front panel LEDs

LED Name LED Function Description

Power ON Indicates power is applied.

CopperLink Pair

One LED for each

port (1 on CL1314/

CL1314R or 2 on

CL1324/CL1324R)

OFF

SLOW BLINK

FAST BLINK

Port is configured as DOWN.

Port is in data mode.

Port is in handshake mode (looking for a

remote signal).

Port is in training mode (active communi-

cation with remote).

Ethernet

(0/0–0/3)

OFF

Port is linked.

Data is passing over the port.

ETH3

Power

Line 1

Line 2

ETH2 ETH1 ETH0

ETH3—ETH0

LEDs

Power

LED Line 1 & 2

LEDs
