CopperLink™ 1214E Series

Extended Temperature

Ethernet Extender

Quick Start Guide

Important—This is a Class A device and is intended for use in a light

industrial environment. It is not intended nor approved for use in an

industrial or residential environment.

REGULATORY MODEL NUMBER: 03340D4-001

Part Number: 07MCL1214E-QS, Rev. D

Revised: March 13, 2020

Sales Office: +1 (301) 975-1000

Technical Support: +1 (301) 975-1007

E-mail: support@patton.com

WWW: www.patton.com

2CopperLink 1214E Series Quick Start Guide

• Do not open the device when the power cord is con-

nected. For systems without a power switch and with-

out an external power adapter, line voltages are

present within the device when the power cord is con-

nected.

• For devices with an external power adapter, the power

adapter shall be a listed Limited Power Source The

mains outlet that is utilized to power the device shall

be within 10 feet (3 meters) of the device, shall be eas-

ily accessible, and protected by a circuit breaker in

compliance with local regulatory requirements.

• For AC powered devices, ensure that the power cable

used meets all applicable standards for the country in

which it is to be installed.

• For AC powered devices which have 3 conductor power

plugs (L1, L2 & GND or Hot, Neutral & Safety/Protec-

tive Ground), the wall outlet (or socket) must have an

earth ground.

• For DC powered devices, ensure that the interconnect-

ing cables are rated for proper voltage, current, antici-

pated temperature, flammability, and mechanical

serviceability.

• WAN, LAN & PSTN ports (connections) may have haz-

ardous voltages present regardless of whether the

device is powered ON or OFF. PSTN relates to inter-

faces such as telephone lines, FXS, FXO, DSL, xDSL,

T1, E1, ISDN, Voice, etc. These are known as “hazard-

ous network voltages” and to avoid electric shock use

caution when working near these ports. When discon-

necting cables for these ports, detach the far end con-

nection first.

• Do not work on the device or connect or disconnect

cables during periods of lightning activity.

This device is NOT intended nor approved for connection

to the PSTN. It is intended only for connection to customer

premise equipment.

In accordance with the requirements of council directive

2002/96/EC on Waste of Electrical and Electronic Equip-

ment (WEEE), ensure that at end-of-life you separate this

product from other waste and scrap and deliver to the

WEEE collection system in your country for recycling.

WARNING

CopperLink 1214E Series Quick Start Guide 3

1.0 Configure the DIP Switches

The CL1214E has eight DIP switches (S1) for configuring the unit for a wide variety of

applications. Once the Cl1214E’s are properly installed, they should operate transpar-

ently. No user settings required.

Note Before applying power to the CL1214E, please review section 2.0,

“Power up the CL1214E Series” on page 5 to verify that the unit is con-

nected to the appropriate power source.

1.1 Configuring the Hardware DIP Switches

The DIP switches are externally accessible from the underside of the CL1214E.

Figure 1 shows the orientation of the DIP switches in the ON and OFF positions.

Figure 1. DIP switch orientation

Configuring DIP Switch S1

DIP Switch S1 is where you configure the CopperLink line. The following tables

describe the configuration for the CL1214E.

Table 1. S1 Summary

Position Description

S1-2 Line Rate/Symmetry

S1-3 Line Rate/Symmetry

S1-4 Reserved

S1-5 SNR Margin

S1-6 Reserved

4CopperLink 1214E Series Quick Start Guide

Switch S1-1: Local/Remote Configuration

Use Switch S1-1 to configure the unit as Remote or Local in the CL1214E.

Switches S1-2 and S1-3: Symmetric/Asymmetric Operation

Use Switches S1-2 and S1-3 to configure the CopperLink line rate type and operation.

Switch S1-5: General Protection (Signal to Noise Ratio)

Use Switch S1-5 to configure line noise protection.

•6dB: Original line noise protection with 6dB SNR

•9dB: Better line noise protection with SNR up to 9dB

S1-7 Reserved

S1-8 Reserved

Table 2. Local/Remote Unit Configuration

S1-1 Setting

ON CPE/Remote

OFF CO/Local

Table 3. Symmetric/Asymmetric Selection Chart

S1-2 S1-3 Setting

OFF OFF High-Speed “Symmetric”

OFF ON High-Speed “Asymmetric”

ON OFF FastPath High-Speed “Asymmetric”

ON ON Long-Range “Asymmetric”

Table 4. Signal to Noise Ratio

S1-5 Setting

ON 6dB

OFF 9dB

Table 1. S1 Summary

Position Description

CopperLink 1214E Series Quick Start Guide 5

2.0 Power up the CL1214E Series

The CL1214E Series comes with an external AC power supply (see figure 2).

Figure 2. Power Supply Installation

2.1 Models with external AC adapter

1. To connect the AC power supply, determine the positive lead and negative lead on

the power adapter.

2. Insert the positive lead into the opening on the terminal block labeled + and the

negative lead into the opening on the terminal block labeled -.

3. Tighten the screws on the block to secure the wires.

When applying direct DC power, it must be regulated 12 VDC ±5%, 1.0A minimum.

Center pin is +12V.

The CL1214E Series powers up as soon as it is connected to an AC power source—

there is no power switch.

2.2 Power up indication

Verify that the Power LED on the front panel (see figure 3) illuminates and remains lit.

Figure 3. CL1214E front panel

This device is not intended for use with power supplies

that provide high instantaneous current (for example:

lead acid batteries).

CAUTION

6CopperLink 1214E Series Quick Start Guide

3.0 Connect the CopperLink interface

1. Obtain single-twisted-pair cable with an RJ-45 plug connector at each end.

2. Plug one end of the cable into the RJ-45 socket (labeled Line) on the CL1214E.

Verify that the other end of the cable is connected to the Line port on the other

CL1214E and that the port is correctly configured.

3. When a link is established, the Line Link LED will turn on.

4.0 Connect the Ethernet port(s)

The RJ-45 ports labeled Eth 0 through Eth 3 are the Auto-MDIX 10/100Base-T inter-

face. These ports are designed to connect directly to a 10/100Base-T device or network.

You may connect this port to a hub or PC using a straight through or crossover cable

that is up to 328 ft (100 m) long.

5.0 Additional information

For detailed information about installing, configuring, and operating the CopperLink,

refer to the CopperLink 1214E Series User Manual at www.patton.com/manuals/

CL1214E-UM.pdf.

A.0 Compliance Information

A.1 Compliance

EMC:

•EN55022, Class A

•EN55024

Safety:

•IEC/EN60950-1, 2nd edition

PSTN:

•This device is not intended nor approved for connection to the PSTN

1.2 Radio and TV Interference (FCC Part 15)

This equipment generates and uses radio frequency energy, and if not installed and

used properly—that is, in strict accordance with the manufacturer's instructions—may

cause interference to radio and television reception. This equipment has been tested

and found to comply with the limits for a Class A computing device in accordance with

the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide

reasonable protection from such interference in a commercial installation. However,

CopperLink 1214E Series Quick Start Guide 7

there is no guarantee that interference will not occur in a particular installation. If the

equipment causes interference to radio or television reception, which can be deter-

mined by disconnecting the cables, try to correct the interference by one or more of the

following measures: moving the computing equipment away from the receiver, re-ori-

enting the receiving antenna, and/or plugging the receiving equipment into a different

AC outlet (such that the computing equipment and receiver are on different branches).

A.3 CE Declaration of Conformity

(See section A.4 “EG-Konformitätserklärung” for German version.)

Product Description: CopperLink 1214E Series

This equipment conforms to the requirements of Council Directive 1999/5/EC on the

approximation of the laws of the member states relating to Radio and Telecommunica-

tion Terminal Equipment and the mutual recognition of their conformity and the Direc-

tive 2011/65/EC relating to RoHS compliance.

The signed Declaration of Conformity can be downloaded from www.patton.com/certi-

fications/.

A.4 EG-Konformitätserklärung

(see section A.3 “CE Declaration of Conformity” for English version)

Produktbezeichnung: CopperLink 1214E Series

Die bezeichneten Produkte stimmen in der von uns in Verkehr gebrachten Ausführung

mit den Vorschriften folgender Richtlinie überein:

R&TTE 1999/5/EG

Richtlinie des europäischen Parlaments und des Rates zur Angleichung der

Rechtsvorschriften der Mitgliedstaaten über Funkanlagen und

Telekommunikations-Endeinrichtungen und die gegenseitige Anerkennung

ihrer Konformität.

Die unterzeichnete Konformitätserklärung kann heruntergeladen werden von:

www.patton.com/certifications/.

A.5 Authorized European Representative

Martin Green

European Compliance Services Limited

The safety advice in the documentation accompanying the

products shall be obeyed. The conformity to the above direc-

tive is indicated by the CE sign on the device.

Die Sicherheitshinweise in der mitgelieferten

Produktdokumentation sind zu beachten. Die Konformität mit

der oben erwähnten Richtlinie wird durch das CE-Zeichen

auf dem Gerät bestätigt.

8CopperLink 1214E Series Quick Start Guide

Milestone house

Longcot Road

Shrivenham

SN6 8AL, UK

The information in this document is subject to change without notice. Patton Electron-

ics assumes no liability for errors that may appear in this document.

Trademarks statement

The term CopperLink is a trademark of Patton Electronics Company. All other trade-

marks presented in this document are the property of their respective owners.

Patton support headquarters in the USA

•Online support: Available at www.patton.com

•E-mail support: E-mail sent to [email protected] will be answered within 1 busi-

ness day

•Telephone support: Standard telephone support is available five days a week—from

8:00 am to 5:00 pm EST (1300 to 2200 UTC/GMT)—by calling +1 (301) 975-1007

•Support via VoIP: Contact Patton free of charge by using a VoIP ISP phone to call

sip:[email protected]

•Fax: +1 (301) 869-9293

Alternate Patton support for Europe, Middle East, and Africa

(EMEA)

•Telephone support: Standard telephone support is available five days a week—from

8:00 am to 5:00 pm CET (0900 to 1800 UTC/GMT)—by calling +41 (0)31 985 25 55

•Fax: +41 (0)31 985 25 26

Note For additional service and support information, refer to the “Contacting

Patton for assistance” chapter of the CopperLink 1214E Series User

Manual available online at www.patton.com/manuals/CL1214E-

UM.pdf.

Warranty, Trademark, & Compliance Information

For warranty, trademark and compliance information, refer to the CopperLink 1214E

Series User Manual available online at www.patton.com/manuals/CL1214E-UM.pdf.

Autres manuels pour CopperLink 1214E

Table des matières

Autres manuels Patton Extenseur

Patton

Patton 2158 Manuel utilisateur

Patton

Patton copperlink 1101 Manuel utilisateur

Patton

Patton CopperLink E2168A Manuel utilisateur

Patton

Patton CopperLink CL2300 Manuel utilisateur

Patton

Patton CopperLink 2300 Manuel utilisateur

Patton

Patton CopperLink 1314MDE Manuel utilisateur

Patton

Patton CopperLink CL1300 Manuel utilisateur

Patton

Patton CopperLink CL2300 Manuel utilisateur

Patton

Patton CopperLink 1314R Manuel utilisateur

Patton

Patton SmartNode 2290 Series Manuel utilisateur

Patton

Patton SmartNode 4830 Series Manuel utilisateur

Patton

Patton CopperLINK 2113A Manuel utilisateur

Patton

Patton CopperLink CL1300MDE Manuel utilisateur

Patton

Patton SmartNode 2290 Series Manuel utilisateur

Patton

Patton CopperLink 1214E Manuel utilisateur

Patton

Patton CopperLink 1101E Manuel utilisateur

Patton

Patton CopperLink 1101E/IP67 Manuel utilisateur

Patton

Patton CopperLink 1314R Manuel utilisateur

Patton

Patton CopperLink 1214 Manuel utilisateur

Patton

Patton CopperLink 1211 Manuel utilisateur

Patton

Patton 2172R Manuel utilisateur

Patton

Patton CopperLink 1314 Manuel utilisateur

Patton

Patton CopperLink 1300R Manuel utilisateur

Patton

Patton 1052AS Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
