Patton electronics CopperLink Ethernet Booster 2110 Manuel utilisateur

USER

MANUAL

MODEL 2110

CopperLink Ethernet Booster

SALES OFFICE

(301) 975-1000

TECHNICAL SUPPORT

(301) 975-1007

Part# 07M2110-UM

Rev. B

Revised 3/5/10

An ISO-9001Certiﬁed

Company

This is a Class A device and is intended for use in a

light industrial (commercial) environment. It is

not intended nor approved for use in a heavy

industrial or residential environment.

CONTENTS

1.0 Warranty Information ................................................................. 3

1.1 Compliance................................................................................... 3

EMC Compliance:......................................................................... 3

Safety Compliance: ...................................................................... 3

PSTN Compliance:....................................................................... 3

1.2 Radio and TV Interference (FCC Part 15) .................................... 4

1.3 CE Declaration of Conformity ....................................................... 4

1.4 Authorized European Representative........................................... 4

1.5 Service.......................................................................................... 5

1.6 Safety When Working With Electricity .......................................... 5

2.0 General Information.................................................................... 6

2.1 Features........................................................................................ 6

2.2 Description.................................................................................... 6

3.0 Installation................................................................................... 7

3.1 Connecting the POE and 10/100Base-T Ethernet Interface......... 8

3.2 Connecting Power (EUI Models) .................................................. 9

4.0 Operation..................................................................................... 9

4.1 Power Up ...................................................................................... 9

4.2 LED Status Monitors................................................................... 10

ASpecifications ........................................................................... 11

A.1 Ethernet Connection ................................................................... 11

A.2 LED Status Indicators ................................................................. 11

A.3 Power ......................................................................................... 11

A.4 Operating Temperature .............................................................. 11

A.5 Operating Humidity ..................................................................... 11

A.6 Power vs. Distance ..................................................................... 11

BModel 2110 Series Factory

Replacement Parts and Accessories...................................... 12

1.0 WARRANTY INFORMATION

Patton Electronics

warrants all Model 2110 components to be free from

defects, and will—at our option—repair or replace the product should it

fail within one year from the ﬁrst date of the shipment.

This warranty is limited to defects in workmanship or materials, and does

not cover customer damage, abuse or unauthorized modiﬁcation. If this

product fails or does not performs as warranted, your sole recourse shall

be repair or replacement as described above. Under no condition shall

Patton Electronics

be liable for any damages incurred by the use of this

product.These damages include, but are not limited to, the following: lost

proﬁts, lost savings and incidental or consequential damages arising

from the use of or inability to use this product.

Patton Electronics

spe-

ciﬁcally disclaims all other warranties, expressed or implied, and the

installation or use of this product shall be deemed an acceptance of

these terms by the user.

Note

Conformity documents of all Patton products can be viewed

online at www.patton.com under the appropriate product page.

1.1 COMPLIANCE

EMC Compliance:

• FCC Part 15, Class A

• EN55022, Class A

• EN55024

Safety Compliance:

• IEC/EN 60950-1

PSTN Compliance:

Note

This device is not intended nor approved for connection to the

PSTN.

1.2 RADIO AND TV INTERFERENCE (FCC PART 15)

This equipment generates and uses radio frequency energy, and if not

installed and used properly—that is, in strict accordance with the manu-

facturer's instructions—may cause interference to radio and television

reception. This equipment has been tested and found to comply with the

limits for a Class A computing device in accordance with the speciﬁca-

tions in Subpart B of Part 15 of FCC rules, which are designed to provide

reasonable protection from such interference in a commercial installa-

tion. However, there is no guarantee that interference will not occur in a

particular installation. If the equipment causes interference to radio or

television reception, which can be determined by disconnecting the

cables, try to correct the interference by one or more of the following

measures: moving the computing equipment away from the receiver, re-

orienting the receiving antenna, and/or plugging the receiving equipment

into a different AC outlet (such that the computing equipment and

receiver are on different branches).

1.3 CE DECLARATION OF CONFORMITY

We certify that the apparatus described above conforms to the require-

ments of Council Directive 2004/108/EC on the approximation of the

laws of the member states relating to electromagnetic compatibility; and

Council Directive 2006/95/EC on the approximation of the laws of the

member states relating to electrical equipment designed for use within

certain voltage limits.

The safety advice in the documentation accompanying this product shall

be obeyed. The conformity to the above directive is indicated by the CE

sign on the device.

1.4 AUTHORIZED EUROPEAN REPRESENTATIVE

D R M Green

European Compliance Services Limited.

Avalon House, Marcham Road

Abingdon,

Oxon OX14 1UD, UK

1.5 SERVICE

All warranty and non-warranty repairs must be returned freight prepaid

and insured to Patton Electronics. All returns must have a Return Materi-

als Authorization number on the outside of the shipping container. This

number may be obtained from Patton Electronics Technical Services at:

•Tel:

(301) 975-1007

• Email:

[email protected]

• URL:

http://www.patton.com

Note

Packages received without an RMA number will not be

accepted.

1.6 SAFETY WHEN WORKING WITH ELECTRICITY

• This device contains no user serviceable parts. The

equipment shall be returned to Patton Electronics for

repairs, or repaired by qualiﬁed service personnel.

• For units with an external power adapter, the adapter

shall be a listed Limited Power Source (LPS). The

power cable used shall meet all applicable standards

for the country in which it is to be installed.

• Hazardous network voltages are present in WAN ports

regardless of whether power to the unit is ON or OFF. To

avoid electric shock, use caution when near WAN ports.

When detaching the cables, detach the end away from

the device ﬁrst.

• Do not work on the system or connect or disconnect

cables during periods of lightning activity.

In accordance with the requirements of council direc-

tive 2002/96/EC on Waste of Electrical and Electronic

Equipment (WEEE), ensure that at end-of-life you sepa-

rate this product from other waste and scrap and deliver

to the WEEE collection system in your country for recy-

cling.

WARNING

2.0 GENERAL INFORMATION

Thank you for your purchase of this Patton Electronics product. This

product has been thoroughly inspected and tested and is warranted for

one year for parts and labor. If any questions or problems arise during

installation or use of this product, contact Patton Electronics Technical

Support at +1 (301) 975-1007.

2.1 FEATURES

• PoE Ethernet Booster - No conﬁguration necessary

• Plug ‘n Play

• Auto-MDIX Ethernet

• 10/100, Full/Half Duplex Ethernet

• Extends network connections and delivers power to an end device

• LED indicators for Power, Input Link/Activity and PoE Link

• Made in the USA

2.2 DESCRIPTION

The Patton Electronics Model 2110 is a Power-over-Ethernet (PoE),

IEEE 802.3af Ethernet booster. Standard Ethernet is limited to 100

meter lengths over CAT5 twisted pair cable. Multiple 2110s overcome

this distance while delivering power to an end device without the use of

many wall adapters at each unit location.The 2110 exists in three ver-

sions:

• 2110/P – PoE Ethernet Booster

• 2110/PSE/EUI-48 – PoE Injector/ Ethernet Booster, 48VDC, 500m

• 2110/EUI – Ethernet Booster without PoE

Figure 1.

Typical application

When using a Model 2110, in conjunction with a PoE Switch, the user

extends the 802.3af PoE and 10/100 Ethernet an additional 100 meters

(328ft). POE-enabled IP Cameras can be placed 200 feet away from the

Ethernet switch and can be powered up via PoE by the 2110. (See

Appendix A.6 on page 11 for power and distance speciﬁcations).

3.0 INSTALLATION

To install the 2110 PoE Booster, do the following:

1. Connect the Ethernet interface (refer to section 3.1, “Connecting the

POE and 10/100Base-T Ethernet Interface” on page 8).

2. EUI Models only: Connect the power plug (refer to section 3.2, “Con-

necting Power (EUI Models)” on page 9).

If used externally, interconnecting cables shall be rated

for the proper application with respect to voltage, cur-

rent, anticipated temperature, ﬂammability, and

mechanical serviceability.

CAUTION

Figure 2.

Model diagram (2110/PSE model shown)

3.1 CONNECTING THE POE AND 10/100BASE-T ETHERNET

INTERFACE

The shielded RJ-45 port is the Auto-MDIX10/100Base-T interface. This

port is designed to connect directly to a 10/100Base-T network. Figure 3

shows the signal/pin relationships on this interface.You may connect this

port to a switch, IP camera, hub or PC using a straight through or cross-

over cable that is up to 328 ft long.

Figure 3.

Model 2110 10/100Base-T RJ-45 Connector Pinout.

If used externally, interconnecting cables shall be rated

for the proper application with respect to voltage, cur-

rent, anticipated temperature, ﬂammability, and

mechanical serviceability.

Model 2110

(Front and Top)

Model 2110

(Back and Bottom)

PoEIN

PoE and/or Ethernet

Output

RJ-45 port

PoE and/or Ethernet

Input

RJ-45 port

Power jack

(EUI models only)

COMPLIESWITHPART15CLASSA

OFTHEFCCRULES.

SEEINSTALLATIONINSTRUCTIONS

BEFORECONNECTINGTOSUPPLY.

_____________________________

PattonElectronicsMadeintheUSA

2110 Model Types:

2110/P - PoE/Ethernet

2110/PSE - PoE/Ethernet

2110/EUI - Ethernet only

PoEOUT

Model2110/PSE

PoE&Ethernet

Injector

Gaithersburg,Maryland,USA

CAUTION

1 TX+/RX+

2 TX-/RX-

3 RX+/TX+

4 (NC) or PoE

5 (NC) or PoE

6 RX-/TX-

7 (NC) or PoE

8 (NC) or PoE

The 2110/P, 2110/PSE/EUI-48, and 2110/PSE/EUI inject power on the

data pair pins 1/ 2 (POE+) and 3/ 6 (POE-) of the connector labeled “PoE

OUT.” The 2110/P accepts POE power on either pin pairs 1/ 2 and 3/ 4,

or 4/ 5 and 7/ 8 on the connector labeled “PoE IN.”

Note

The POE power on the 2110/P is rectiﬁed and thus polarity of

the power is irrelevant.

3.2 CONNECTING POWER (EUI MODELS)

The Model 2110 does not have a power switch, so it powers up as soon

as it is plugged in.

An external AC or DC power supply may be included and must be a Lim-

ited Power Source (LPS). This connection is made via the barrel jack on

the bottom panel of the Model 2110. No conﬁguration is necessary for

the power supply (See Appendix A.3 on page 11 and Appendix B on

page 12 for Model 2110 power supply and cord options). The center pin

is positive. The barrel type plug has a 2.5/5.5/10mm I.D./O.D./Shaft

Length dimensions.

4.0 OPERATION

Once the Model 2110 is properly installed, it should operate transpar-

ently. No user settings required.

4.1 POWER UP

Models 2110/PSE and 2110/EUI:

Before applying power to the Model

2110, please review section 3.2, “Connecting Power (EUI Models)” on

page 9 to verify that the unit is connected to the appropriate power

source.

The Interconnecting cables shall be acceptable for

external use and shall be rated for the proper applica-

tion with respect to voltage, current, anticipated tem-

perature, ﬂammability, and mechanical serviceability.

CAUTION

4.2 LED STATUS MONITORS

The Model 2110 features two top panel LEDs that monitor PoE output

and Ethernet activity, and two bottom panel LEDs that monitor power

input and Ethernet activity. Figure shows the locations of each LED.

Table 1 describes the LED functions.

* = applies to 2110/P and 2110/PSE models only

Table 1:

LED descriptions

LED Description

PoE OUT

(Top Panel)

PoE Link* Indicates link with down-stream PoE

device. (Not present on 2110/EUI)

Link/Act Indicates link and activity on output

port.

Ethernet IN

(Bottom Panel)

Power* Indicates 2110 is receiving power

from up-stream PoE device or power

adapter.

Link/Act Indicates link and activity on input

port.

Table des matières

Autres manuels Patton electronics Extenseur

Patton electronics

Patton electronics 2113 Manuel utilisateur

Patton electronics

Patton electronics CopperLINK 2172 Manuel utilisateur

Patton electronics

Patton electronics CopperLink 2160 Series Manuel utilisateur

Patton electronics

Patton electronics COPPERLINK 2151 Manuel utilisateur

Patton electronics

Patton electronics CopperLink 2160 Series Manuel utilisateur

Patton electronics

Patton electronics 2173R Manuel utilisateur

Patton electronics

Patton electronics CopperLink 07M2160-GS Manuel utilisateur

Patton electronics

Patton electronics 2156 Manuel utilisateur

Patton electronics

Patton electronics CopperLink 2168 Manuel utilisateur

Patton electronics

Patton electronics 2156 Manuel utilisateur

Patton electronics

Patton electronics EnviroNET 2100 Series Manuel utilisateur

Patton electronics

Patton electronics CopperLink 2158 Manuel utilisateur

Patton electronics

Patton electronics CopperLink 2172R Manuel utilisateur

Patton electronics

Patton electronics EnviroNET EHA2168 Manuel utilisateur

Patton electronics

Patton electronics 2100 Series Manuel utilisateur

Patton electronics

Patton electronics EnviroNET EHA2172 Manuel utilisateur

Patton electronics

Patton electronics 1068 Manuel utilisateur

Patton electronics

Patton electronics SmartNode 2294 Manuel utilisateur

Patton electronics

Patton electronics 1173R Manuel utilisateur

Patton electronics

Patton electronics EnviroNET 2100 Series Manuel utilisateur

Patton electronics

Patton electronics 2113 Manuel utilisateur

Patton electronics

Patton electronics SmartNode 2290 Series Manuel utilisateur

Patton electronics

Patton electronics CopperLink Ethernet Extenders 2158A Manuel utilisateur

Patton electronics

Patton electronics CopperLINK 2158B Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
