USER MANUAL
01
Specifications
0202
Drop-in Dock
Charging
Electrical Outlet
Charging
Data Transferring
Data Transferring
PC
Charging
Charging
03
Before Use Getting Started
04
ŸFully charge the camera using the included USB cable and charging
dock for 3-4 hours. The charging indicator will turn blue when
charging. When the device is fully charged, the blue light will turn off.
ŸConfirm that the date and time on your device is correct and enter
your device lD and badge ID through Cam Manager.
Wearing your Body Camera Properly
On your chest (uniform):
ŸAttach the camera clip to the front of your uniform.
ŸRotate the camera clip 45° and clip it to the top of your uniform.
On your shoulder:
ŸUsing the optional epaulette mount, clip the camera to the bracket on
the mount and attach the mount to your uniform.
KlickFast Mounts:
Optional magnet, molle and epaulette mounts now available.
Basic Operation
1) Press and hold the Power button (located on right side of camera)
for about 2 seconds. You will hear a beep and the camera will power
on. The standby indicator LED will turn green and the standby
indicator will remain green while the device is in standby mode.
2) The device settings, battery life, storage space, and saved media
files can now be viewed and edited via Cam Manager (starting on
page 7) or the smartphone app (starting on page 29). The smartphone
app will also allow for previewing the camera before and during
recordings.
3) Once Cam Manager is installed, login and click "Open File Explorer"
to view or delete the camera's files. Your camera will be shown as a
"Removable Disk", usually D: or E: drive in “This PC”. Double click on
the cameras drive and open the VIDEO/PHOTOS folder to view,
transfer, and delete files. See page 23 for folder details.
Audible Notifications
The camera uses audio chirps as a way of notifying you when your
cameras storage is full, low battery levels, and GPS notifications.
1 beep every 10 seconds indicates your storage is now lower than
10% free
1 beep every 2 seconds indicates your storage is now almost full and
the camera will stop recording soon
1 beep every 5 seconds indicates that your battery is lower than 2%
and your camera will shutdown soon
LED Indicators
Battery: Green = 50-100% battery life
Yellow = 2-50% battery life
Red = Less than 2% battery life
Standby/WiFi: Green = Standby mode
Blinking White = Searching for/Establishing WiFi
Solid White = WiFi connected/Active
Charging/Activity: Blue = Charging (will turn off when fully charged)
Purple = Recording + Charging
Solid Red = Recording
Blinking Red = Pre/Post Event recording
Recording
05
Video Recording
To record a video from standby, press the record button (located on
the front of the device). The device will beep five times and the activity
indicator LED will turn solid red, indicating that the camera is now
recording.
Press and hold the record button for 2 seconds to stop recording. The
device will beep seven times and the activity indicator will turn off and
the standby indicator will now turn green.
One Touch Recording
When the unit is powered off, press and hold the record button for 2
seconds until you hear a beep. The device will turn on and
automatically start video recording.
Pre and Post Recording
When pre or post event recording is enabled, the activity LED will blink
red. Pre record event recording can be set for up to two minutes while
post event recording can be set for up to one minute. To start normal
recording while in pre event recording mode, press the record button
and the activity LED will go from blinking red to solid red.
Power on Auto-Record
When the "Power on Auto-Record" function is switched on in Cam
Manager, the device will automatically start recording video when the
device is powered on.
Photograph Feature
To take a photo, press the photo button once. The activity indicator
will switch from green to red and the camera will beep 3 times.
Camera Management Software
06
To take pictures while video recording, press the Photo button. The
camera will beep one time and the camera will take a picture without
interrupting the video recording.
WiFi Feature
When powered on, you can turn the WiFi on or off without interruption
even while the camera is recording. Press the power button once in
order to turn WiFi on. A flashing white LED will indicate that the device
is searching for or creating a WiFi connection. When the device has
established a connection, the white LED will turn solid. To turn WiFi off,
press the power button once and the white LED will turn off.
Stealth Mode Feature
When powered on, you can turn the stealth mode feature on or off
without interruption even while the camera is recording. To turn stealth
mode on, press and hold the photo button down for 2 seconds. All LED
indicators and vibration sounds will be disabled, however the device
will still be operating. To turn stealth mode off, press and hold the
photo button down for 2 seconds. The camera will beep twice and the
LED indicators and vibration (if enabled in settings) will be re-enabled.
Transfer & Manage Files on Your Computer
(Compatible with Windows 7, 8 and 10)
Drop the camera into the charging station and connect it to your
computer via the included USB cable. You can also connect the cable
to your cameras USB-C port to connect to your PC. Open Cam
Manager and enter your password to sign in (instructions on page 8).
Note: Installing Cam Manager allows for managing saved data
and changing device settings.
Management Software Login
Visit stuntcams.com/dv10-pro to download the "Cam Manager"
software on your computer and follow the instructions to install.
a. Place your camera into the charging station, and connect it to your
computer via the USB cable. Your camera will automatically power on
once connected. You can also connect your camera to the PC directly
via the USB-C port on the side of the camera.
b. Choose the "User Type" and enter the password. There are two
User Types, each with a different default password.
1. General User: This mode allows for viewing and downloading
media files only. The default password is: 000000
2. Administrator: This mode allows for changing device settings as
well as viewing and downloading media files. The default password is:
888888
07
Management Software-Login
08
Camera Info
a. After login, Cam Manager will open on the “Camera Info” tab.
b. From here you can change Device lD and User ID, as well as view
battery level and free space on the camera. Enter the new settings into
the text boxes, and click “Apply" to save.
c. Click "Refresh" to update battery levels and free space.
Management Software-Camera Info
d. Click "Open File Explorer" to view the camera's files. Cam Manager
will close and the "Removable Disk" for the camera will appear in File
Explorer. Open the VIDEO/PHOTO folder and from here you can view,
transfer, and delete files.
e. Click "Sync PC Date Time" to update your camera's date and time.
The new settings will be updated to your PC's current date and time.
f. Click "Format Disk" to format the camera’s memory. The files will be
DELETED immediately, and the free space status will be updated.
Barcode
This setting displays the unique ID of your device.
Firmware Version
This setting displays the latest firmware programmed on your device.
Battery Left
This setting displays how much battery life is remaining.
Free Space
This setting displays how much storage is remaining on your camera
before the built in memory is full.
Watermark
Entering text in the watermark setting box will result in a stamped
watermark in the lower right-hand corner of the file on any photo or
video.
09
Management Software-Camera Info
10
Camera Settings
a. Click the "Camera Settings" tab in Cam Manager.
b. From here you can change device settings. Select the setting you
wish to change, and a drop down will appear with all available options.
c. Click "Apply" to update settings with the new chosen options.
Management Software-Camera Settings
Resolution
a. Click the "Resolution" drop down. There are three settings to
choose from:
1. 1920x1080p @30fps
2. 1280x720p @30fps
3. 848x480p @30fps
b. Click the setting you prefer and click "Apply" to save.
Picture Size
a. Click the "Picture Size" drop down. There are four settings to
choose from:
1. 16M
2. 12M
3. 8M
4. 4M
Video Splitter
a. Click the " Video Splitter " drop down. There are nine settings to
choose from:
1. 1 minutes
2. 2 minutes
3. 3 minutes
4. 5 minutes
5. 10 minutes
6. 15 minutes
7. 20 minutes
8. 30 minutes
11
Management Software-Camera Settings
12
Note: Video splitter refers to the length of video segments while the
device is recording. The minute amount is the length of each video
segment before the device begins a new video file. This will NOT stop
the device from recording, it will just split your videos into smaller,
more manageable files.
Recording Notification
Click the "Recording Notification" drop down. There are six settings to
choose from:
1. Off
2. 5 seconds
3. 10 seconds
4. 15 seconds
5. 30 seconds
6. 60 seconds
Click the setting you prefer and click "Apply" to save.
Note: Recording prompt is an audio notification that will beep at the
specified interval to notify you that the device is still recording. This will
not affect the notifications at the start and end of recordings.
TV Out
Click the "TV out" drop down. There are two settings to choose from:
1. NTSC (for US customers)
2. PAL (for EU customers)
Click the setting you prefer and click "Apply" to save.
Management Software-Camera Settings
14
Streaming Resolution
Click the "Streaming Resolution" drop down. There are three settings
to choose from:
1. 1280x720 (P30)
2. 848x480 (P30)
3. 432x240 (P30)
Click the setting you prefer and click "Apply" to save.
Note: Streaming Resolution is the resolution of video which is
transmitted to the WiFi app when camera is connected via WiFi.
Streaming Bitrate
Click the "Streaming Bitrate" drop down. There are seven settings to
choose from:
1. 5000 Kbs
2. 4000 Kbs
3. 3000Kbs
4. 2000Kbs
5. 1000Kbs
6. 500Kbs
7. 300Kbs
Click the setting you prefer and click "Apply" to save.
Note: Streaming Bitrate is the bitrate of the WiFi stream. Setting this
to a higher value will increase the streaming quality.
Management Software-Camera Settings
Post Recording
Click the "Post Record" drop down. There are six settings to choose
from:
1. Off
2. 5 seconds
3. 10 seconds
4. 20 seconds
5. 30 seconds
6. 60 seconds
Mute Recording
Click the "Mute Recording" drop down. There are three settings to
choose from: Off (Audio will be recorded), On (Mute function
will be enabled and audio will NOT be recorded), Pre
recorded (Audio will NOT be recorded for pre-record files
only).
Pre Recording
Click the "Pre Record" drop down. When checked, the camera will
record prior to the video recording button being pressed with length
depending on video settings. The higher the resolution, the lower the
pre record length.
1. Off
2. 5 seconds
3. 10 seconds
4. 15 seconds
5. 20 seconds
6. 30 seconds
7. 60 seconds (available in 1080p mode only)
8.120 seconds (available in 720p/480p mode only)
13
Management Software-Camera Settings
16
Management Software-Camera Settings
Auto lR
Click the "Auto lR" drop down to control your devices infrared LED’s.
There are three settings to choose from:
1. Off
2. During Recording
3. Auto (recommended)
Click the setting you prefer and click "Apply" to save.
Auto Power Off
Click the “Auto Power Off " drop down. There are seven settings to
choose from:
1. Off
2. 30 seconds
3. 1 minute
4. 3 minutes
5. 5 minutes
6. 10 minutes
7. 30 minutes
b. Click the setting you prefer and click "Apply" to save.
Note: Auto Power Off will only power off the device when it has been
in standby mode for the selected interval. This will NOT power off the
device during recordings.
Streaming Control
Click the "Streaming Control" drop down. There are six settings to
choose from:
1. OFF
2. Audio
3. Video
4. AV (audio & video)
5. Text
6. ALL
Click the setting you prefer and click "Apply" to save.
Note: This option controls the file type that can be streamed via WiFi.
Quality
Click the "Quality" drop down. There are three settings to choose
from:
1. High
2. Medium
3. Low
Click the setting you prefer and click "Apply" to save.
Note: This refers to the video bitrate. The higher the setting, the
better the video quality and larger the file size. To achieve the most
battery life, please set this to low.
Car Mode
Click the “Car Mode” box to have the camera automatically power on
and start recording when connected to power.
15
Management Software-Camera Settings
18
GPS
Click the "GPS" box to turn GPS on or off. When GPS signal is
received, the device will beep four times. GPS coordinates will be
created as a watermark on all saved videos and photos. If the device
beeps twice, it means the GPS signal is too weak and has been lost.
Timezone
Click the "Timezone" drop down to select the correct UTC time zone,
and the GPS will change the date and time accordingly. Example, New
York City is EST and will be set to UTC-4.0. Central time zones are
UTC-5.0.
Power on Auto-Record
Click the "Power on Record" box to allow the device to start recording
automatically after powering on without pressing the record button.
Vibration
Click the "Vibration" box to turn on/off vibration alerts.
Loop Recording
Click the “Loop Record” box to turn on the loop recording function.
When loop recording is enabled (if memory becomes full), the camera
will automatically save new videos and delete only the oldest files first.
When loop recording is off, the camera will stop recording when the
memory is full.
Picture Quality
Click the “Picture Quality” drop down. There are three settings to
choose from:
1. High
2. Medium
3. Low
Click the setting you prefer and click "Apply" to save.
Management Software-Camera Settings
17
Management Software-Camera Settings
Refresh Rate
Click the "Refresh Rate" drop down. There are three settings to
choose from:
1. 60 Hz
2. 50 Hz
3. Auto
Click the setting you prefer and click "Apply" to save.
Burst Mode
Click the “Burst Mode” drop down. There are eight settings to choose
from:
1. Off
2. 2 pictures
3. 3 pictures
4. 5 pictures
5. 10 pictures
6. 15 pictures
7. 20 pictures
8. 30 pictures
Date Format
Click the "Date Format" drop down. There are three settings to choose
from:
1. DD-MM-YYYY
2. MM-DD-YYYY
3. YYYY-MM-DD
Click the setting you prefer and click "Apply" to save.
Table des matières
Autres manuels Patroleyes Appareil photo numérique
Patroleyes
Patroleyes SC-DV6 Manuel utilisateur
Patroleyes
Patroleyes SC-DV7 Ultra Manuel utilisateur
Patroleyes
Patroleyes PE-MAX Manuel utilisateur
Patroleyes
Patroleyes Ultra 1296P Manuel utilisateur
Patroleyes
Patroleyes EDGE Manuel utilisateur
Patroleyes
Patroleyes MAX Manuel utilisateur
Patroleyes
Patroleyes DV5-2 Manuel utilisateur
Patroleyes
Patroleyes SC-DV1 Manuel utilisateur
