FrameSaverrDSL 9783 Router

Installation Instructions

Document Number 9783-A2-GN11-00

December 2000

Contents

FrameSaver DSL 9783 Router Overview 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Wiring and Cables You May Need 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Installing the FrameSaver DSL 9783 Router 7. . . . . . . . . . . . . . . . . . . . . . . . . .

Status LEDs 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Troubleshooting 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Finalizing the Router Configuration Setup 12. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Verifying that Self-Test Passed 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Using the FrameSaver Easy Install Screen 15. . . . . . . . . . . . . . . . . . . . . . . . . . .

Completing Setup From the NOC 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Provisioning Data Circuits in OpenLane 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Provisioning the Router Interface 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Technical Specifications for DSL 9783 Router 23. . . . . . . . . . . . . . . . . . . . . . . . .

Important Safety Instructions 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

FrameSaver DSL 9783 Router Overview

The FrameSaverrDSL (Digital Subscriber Line) 9783 Router is a component in the

FrameSaver system. This system allows you to perform end-to-end service level

management across a hybrid FrameSaver DSL/ATM/Frame Relay network. QoS

(Quality of Service) capabilities of ATM (Asynchronous Transfer Mode) transport

protocol assures quality of service across the network. Service providers can isolate

and correct problems remotely from their NOC (Network Operations Center).

The FrameSaver DSL 9783 Router has an SDSL front end and is a manageable frame

relay aware endpoint. The router operates as a bridge or an IP router connecting a DSL

link to an Ethernet network.

The FrameSaver DSL 9783 Router is available as a:

HBasic Feature Set 1

HAdvanced SLV (Service Level Verification) Feature Set 2

Basic FrameSaver DSL 9783 Router

The FrameSaver DSL 9783 Router is used for data only and provides corporate LAN

access over traditional twisted-pair copper telephone wiring. Copper pairs run from the

central office (CO) to the customer premises (CP) to create the local loop. The local

loop terminates on the customer premises at the demarcation point in a punchdown

block or network interface device (NID).

DSL

Access

Network

00-16915a

ALARMS

MajorMinor

Fan

POWER

SERIAL

SMCM

CLOCK

ALARM

24681012141618

1357911131517

LAN/WANSLOT

CLOCKB

SERIAL

MCCAC

ALARM

48VRTN

48VNEG

POWERENTRYMODULE

LEFTUNIT:LINEA

RIGHTUNIT:LINEB

WARNING!

POWERMUSTBEDISCONNECTED ATTHESOURCE

BEFOREREMOVINGORINSTALLINGTHISPWR ENTRY MODULE

48VRTN

48VNEG

POWERENTRYMODULE

LEFTUNIT:LINEA

RIGHTUNIT:LINEB

WARNING!

POWERMUSTBEDISCONNECTED ATTHE SOURCE

BEFOREREMOVINGORINSTALLINGTHISPWRENTRYMODULE

ATM

Switches

Hotwire

GranDSLAMs

ALARMS

MajorMinor

Fan

POWER

SERIAL

SMCM

CLOCK

ALARM

24681012141618

1357911131517

LAN/WANSLOT

CLOCKB

SERIAL

MCCAC

ALARM

48VRTN

48VNEG

POWERENTRYMODULE

LEFTUNIT:LINEA

RIGHTUNIT:LINEB

WARNING!

POWERMUSTBEDISCONNECTEDAT THE SOURCE

BEFOREREMOVINGORINSTALLINGTHISPWRENTRY MODULE

48VRTN

48VNEG

POWERENTRYMODULE

LEFTUNIT:LINEA

RIGHTUNIT:LINEB

WARNING!

POWERMUSTBEDISCONNECTED ATTHE SOURCE

BEFOREREMOVINGORINSTALLINGTHISPWR ENTRYMODULE

TDM

Access

Network

LAN

FR Network

FR/ATM

IWF

ATM

Switches FR

Switches

Frame Relay NSP's Network

ATM

NNI(s)

Aggregation

Switch

(Optional)

Copper

Loop

DSL

FrameSaver

DSL 9783

Bridge/Router

Endpoint

Customer

Premises–

Remote Site

Router

FrameSaver

Endpoint

Customer Premises–

HQ Site

Central Office

ATM

Services LAN

ATM – Asynchronous Transfer Mode

DSL – Digital Subscriber Line

FR – Frame Relay

HQ – Headquarters

IWF – Interworking Function

LAN – Local Area Network

NSP – Network Service Provider

TDM – Time Division Multiplexer

The FrameSaver DSL 9783 Router includes:

HFrame aware diagnostic Feature Set 1

HBasic frame relay statistics

HInteroperability with all existing FrameSaver products

HEthernet port for local management

HMulti-level password protection for three user interfaces:

—ASCII terminal management via menu-driven interface

—Command Line Interface for router configuration

—Telnet

HManagement Traffic IP Routing Table display

HCommand Line Interface (CLI) for router functionality

HFRF.8 (Frame Relay Forum) conversion of frame relay to ATM. Transparent and

translational modes are supported.

HRouter security features include:

—Firewall IP filtering capabilities

—Packet filtering defined by user

—NAT (Network Address Translation) for one-to-one mapping and NAPT

(Network Address Port Translation) for many-to-one mapping

—Multi-level password protection to management tools

—Bridge filters

—Filtering on the IP protocol type, source/destination address, and

source/destination port number

HRouter utilities for ICMP Ping and Traceroute

HBridging with Spanning Tree

HDHCP Server and DHCP Relay

HNondisruptive PVC (Permanent Virtual Circuit) diagnostics

HPVC burst table

HATM OA&M (Operations, Administration, & Maintenance) loopbacks

HRMON2 (Remote Monitoring) event log and user history statistics

HReal-time end-to-end connectivity test and latency snapshots

HDual flash storage areas & in-band FTP software download

Upgrading a Basic Unit to SLV

The FrameSaver DSL 9783 Router can perform full end-to-end SLV when full SLV

capability is activated in a basic FrameSaver DSL model. The Advanced SLV Feature

Set 2 adds:

HQoS verification across the network

HPVC/VC provisioning

HMultiplexed management PVCs

HCommand activated advanced SLM & reporting features

HContinuous round trip (RT) latency report

HRMON2 alarms and proactive thresholds

HNetwork user history synchronization between RMON2 statistics and SLV devices

HReal-time and historical network performance monitoring and SLA (Service Level

Agreement) reporting capabilities for FrameSaver devices and the network

HService level performance reporting in compliance with FRF.13

HFDR/DDR (Trueputt) reporting to precisely measure throughput

HCIR (Committed Information Rate) relationship statistics

Order an SLV Activation Certificate for each FrameSaver unit to be upgraded. The

OpenLanerSLM system, Release 5.3 or later, is required to schedule the activation of

the SLV features and to manage the number of certificate activations.

Contact your sales representative for additional information.

Product Documentation on the World Wide Web

We provide complete product documentation online. This lets you search the

documentation for specific topics and print only what you need, reducing the waste of

surplus printing. It also helps us maintain competitive prices for our products.

Complete documentation for this product is available at www.paradyne.com.

Select Library →Technical Manuals →FrameSaver Frame Relay Devices.

Select the following documents:

Document Number Document Title

9000-A2-GB20 Configuring Frame Relay Service Over DSL

9000-A2-GK43 FrameSaver SLV Activation Instructions

9783-A2-GB20 FrameSaver DSL 9783 User’s Guide

To order a paper copy of a Paradyne document:

HWithin the U.S.A., call 1-800-PARADYNE (1-800-727-2396)

HOutside the U.S.A., call 1-727-530-8623

Package Checklist

In addition to these instructions, verify that your package contains the following:

-FrameSaver DSL 9783 Router

-Power cord with power transformer

-Tie wrap for power cord strain relief

-DSL network access cable with 8-pin connectors (U.S. models only)

-Ferrite choke –International models only

-FrameSaver DSL 9783 Router Quick Reference (Document No. 9783-A2-GL11)

Be sure to register your warranty at www.paradyne.com/warranty.

Wiring and Cables You May Need

The following wiring and standard connectors are used with this product:

-DSL cabling: New or existing unshielded twisted-pair wiring (CAT3 or better).

The CAT3 wiring must meet EIA/TIA-568 specifications with 24 AWG (.5 mm) or

26 AWG (.4 mm). Standard RJ48C or RJ11 wall jack for the DSL network

connection.

-Ethernet cabling: Standard Ethernet 8-pin, non-keyed modular plug for a host.

Use an Ethernet shielded twisted-pair CAT5 or better straight-through or crossover

cable.

Refer to Cables & Connectors on page 20 for standard pin numbers. Contact your

sales representative to order cables.

Port Cable Options Paradyne

Part #

COM port with a

DB-25 modular

connector to a PC

DB25-to-8-pin modular: Standard EIA-232

straight-through cable (14 feet –4.3 m) 035-0314-1431

connector to a PC

or async terminal HDB-25-to-RJ45 8-pin adapter

H8-pin modular-to-DB9: Standard EIA-232

straight-through cable (14 feet –4.3 m)

002-0069-0031

035-0313-1431

ETHERNET port

with USOC 8-pin

connectors to a

Ethernet shielded crossover cable: Standard

EIA-232-D (14 feet –4.3 m) 035-0336-1431

connectors to a

modem Ethernet shielded straight-through cable:

Standard EIA-232-D (14 feet –4.3 m) 035-0349-1431

NETwork

connection to DSL RJ48C DSL network cable with 8-pin

connectors –RJ48C-to-RJ48C/RJ49C

(20 feet –6.1 m). Supplied cable for U.S. use.

035-0209-2031

RJ11 DSL network cable with 6-pin connectors

(14 feet –4.27 m) 035-0266-1431

00-16888

ETHERNET

COM

POWER

ETHERNET

Ferrite

Choke

Installing the FrameSaver DSL 9783 Router

Place the FrameSaver DSL 9783 Router on a flat surface with clearance for the rear

connectors.

"Procedure

1. Use an RJ48C 8-pin or an RJ11 6-pin network interface cable for the DSL

connection (cable supplied for U.S. use). Insert one end of the cable into the jack

labeled NET. Insert the other end into the wall jack for DSL data communications.

DSL

Network

00-16878

ETHERNET

COM

POWER

NET

DSL 9783 Router

2. Use an 8-pin Ethernet cable for the Ethernet connection. Insert one end of the

cable into the jack labeled ETHERNET.

—Domestic models: go to Step 3.

—International models:

Place the supplied ferrite choke on

the Ethernet cable as closely as

possible to the rear panel.

Close the two halves around the

cable and snap the ferrite choke

shut. Press down on the plastic

latch to secure the ferrite choke

in place around the cable.

3. Use a straight-through cable to connect the other end to an Ethernet hub.

(To connect to a hub’s Uplink connection, use an Ethernet crossover cable).

00-16879

ETHERNET

COM

POWER

NET

Ethernet

Straight-Through

Cable

ETHERNET

DSL 9783 Router

Hub

4. Use a VT100-compatible asynchronous terminal or a PC to set up management

access to the unit. Insert the DB25 end of the EIA-232 cable into the FrameSaver

unit’s COM port. Tighten the screws on each side of the connector. Insert the other

end of the cable into the terminal or PC. For an external modem connection, refer

to External Modem Connection on page 22.

COM

Port

00-16876

ETHERNET

COM

POWER

NET

VT100

Terminal

DSL 9783 Router

5. Insert the supplied power cord’s round end into the jack labeled POWER. Plug the

transformer into an AC outlet. Install the supplied tie wrap.

ALM

TEST

ATM

DSL

NetworkSystem Port

9783-C

SLV

FrameSaver

DSL

SDSL

00-16877

ETHERNET

COM

POWER

NET

Grounded

Power

Outlet

Tie

Wrap

Power

Jack

ALM

TEST

ATM

DSL

NetworkSystem Port

9783

Router

FrameSaver

SLV

FrameSaver

®DSL

SDSL

The hardware installation is now complete. When the power cord is installed, the unit

goes through a power-on self-test. Refer to Finalizing the Router Configuration Setup

on page 12 for additional information.

The NOC can now remotely access the unit for additional configuration. Refer to

Completing the Setup of the Unit from the NOC on page 16.

Power-On

When power is applied, the unit performs self-diagnostics and the PWR LED is on. The

self-diagnostics includes a power-on self-test where all of the LEDs are on.

00-16857

ALM

TEST

ATM

DSL

NetworkSystem Port

9783

Router

SLV

FrameSaver

DSL

SDSL

System OK –green

Alarm –red

Test –yellow

ATM –green/yellow

DSL –green

Ethernet Port –green

Refer to Troubleshooting for LED indications requiring action.

Status LEDs

All of the LEDs turn on and off during the power-on self-test. After a successful

self-test, the LEDs should appear as indicated in BOLD in the Condition column below.

LED Condition Status

System LEDs

OK ON The DSL router has power.

ALM OFF

ON There are no active alarms.

An alarm condition exists.

TEST OFF

ON There are no active tests.

The TEST LED is on during the power-on self-test and

during a test initiated by the service provider.

Network LEDs

ATM OFF

ON –Green

ON –Yellow

The ATM link is not active.

The ATM LED is active with cell delineation in sync.

The ATM LED is active with loss of cell delineation.

DSL Blinking

OFF

The DSL router is establishing the active DSL link. The LED

blinks on and off about five times per second.

The DSL link is ready to transmit and receive data.

The DSL link has not been established.

Port LED

OK ON

OFF The Ethernet connection is transmitting and receiving data.

No Ethernet device is detected.

Troubleshooting

Refer to the User’s Guide for additional troubleshooting suggestions.

Autres manuels pour FrameSaver 9783

Table des matières

Autres manuels Paradyne Routeur réseau

Paradyne

Paradyne Hotwire 6341 Manuel utilisateur

Paradyne

Paradyne Hotwire 6381 Manuel utilisateur

Paradyne

Paradyne 1740 SHDSL Manuel utilisateur

Paradyne

Paradyne 1740 SHDSL Manuel utilisateur

Paradyne

Paradyne HotWire 5246 Manuel utilisateur

Paradyne

Paradyne FrameSaver DSL 9788 Router Manuel utilisateur

Paradyne

Paradyne 1752 SHDSL Manuel utilisateur

Paradyne

Paradyne Hotwire 6212 Instructions d'utilisation d'origine

Paradyne

Paradyne Hotwire 6321 Manuel utilisateur

Paradyne

Paradyne 1740 SHDSL Instructions d'utilisation d'origine

Paradyne

Paradyne iMarc SLV 9126 Manuel utilisateur

Paradyne

Paradyne Hotwire 6351 Manuel utilisateur

Paradyne

Paradyne Hotwire 6321/6322 IDSL Router Manuel utilisateur

Paradyne

Paradyne Hotwire 6212 Manuel utilisateur

Paradyne

Paradyne Hotwire 6381 Manuel utilisateur

Paradyne

Paradyne 6211-I1 Manuel utilisateur

Paradyne

Paradyne FrameSaver DSL 9783 CSU/DSU Manuel utilisateur

Paradyne

Paradyne Hotwire 6301 Manuel utilisateur

Paradyne

Paradyne FrameSaver 9783 Manuel utilisateur

Paradyne

Paradyne 6382 Manuel utilisateur

Paradyne

Paradyne iMarc 9550 DS3 Manuel utilisateur

Paradyne

Paradyne FrameSaver 9123 Manuel utilisateur

Paradyne

Paradyne BitStorm 6211 CPE Manuel utilisateur

Paradyne

Paradyne 1740 SHDSL Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
