Paradox Spectra Manuel utilisateur

Press & hold for

3 sec. to activate:

_______________

(i.e. garage door, smoke

reset, ect.)

On = Partition armed

Off = Partition disarmed

Flash = Partition Stay Armed

Fast Flash = Partition in Alarm

User’s Quick

Reference Guide

On = AC power on

Off = Power failure

On = All zones are closed

Off = Zone(s) opened or armed

Flashing = Exit Delay indicates the

system will become armed soon

ARMING & DISARMING

To Arm

When Staying

STAYarms perimeter zones only:

Press & enter your [ACCESSCODE]*

Or, if enabled , press & hold

for 3 seconds*

INSTANTsame as stay, except zones will

instantly cause an alarm if breached:

If enabled , after StayArming, press

& hold for 3 seconds*

Made a mistake?

Press to re-

enter data, exit the

current mode or

cancel an action.

ZONE DISPLAY

A numerical button turns on if

the corresponding zone is open.

In this example, zone 5 is open.

*NOTE1: If buttons and flash, you must specify which partition you

wish to arm or disarm by pressing the corresponding button. Appropriate System

Options must be enabled by your installer. ]= Feature Enabled

Disarming

Enter your [ACCESSCODE]*

To Arm

When Leaving

REGULARarms entire system:

Enter your [ACCESSCODE]*

Or, if enabled , press & hold for

3 seconds*

FORCElets you arm entire system without having

to wait for all zones to be closed:

Press & enter your [ACCESSCODE]*

Or, if enabled , press & hold for

3 seconds*

Spectra 1686V LED Keypad

“READY” LIGHT

“ARM” LIGHTS

“AC” LIGHT

[

]

KEY

When is lit, press it to view the

Trouble Display(button flashes). Each

button that is lit represents a trouble

condition as shown in the keypad door.

When the [8] button is on, press [8] to re-program

the time HH:MM. When the [9] button is on, press

If enabled by your installer , press

and hold buttons:

& for Panic Alarm

& for Medical Alarm

& for Fire Alarm

TROUBLE DISPLAY

When the button is lit, an alarm has

occured. Press the button (button

flashes) andlit numerical buttons will

correspond to zones that were in alarm.

ALARM MEMORY

PRINTED IN CANADA 03/99 - 1686EQ-00

When the button is lit, zones in the

system are currently bypassed

Method 1:

1) Press

2) Enter your [ACCESSCODE]*

3) Illuminate the buttons corresponding to

the zones you wish to bypass or press

1 to recall previous bypass entries

4)Press

Method 2:

1) Press and hold thebutton for 3

seconds*

2) Go to step 3 in Method 1

*see note1 on reverse side

BYPASS PROGRAMMING

ACCESS CODES

PANIC ALARMS

Press and hold the numerical button

corresponding to the desired zone to

enable or disable chiming for that zone.

CHIME PROGRAMMING

How Do I Program Access Codes?

1) Press

2) Enter your [MASTERCODE]

3) Enter 3-digit [SECTION](see below)

4) Enter the 4 or 6-digit [ACCESSCODE]

Return to step 3 or press

How Do I Delete Access Codes?

1) Repeat steps 1 to 3 (see above)

2) Instead of entering your access

code, press the button once for

each digit in the access code (4 or 6

times) until the keypad emits a

"confirmation beep"

Section [001] = System Master Code

Section [002] = Master Code 1

Section [003] = Master Code 2

Section [004]-[048] = Users 004-048 respectively

Spectra

1686H

LED

Keypad

[9] to view which zones were tampered.
