Paradox Insight™ HD77 Installation Guide 1

paradox.com

Paradox Insight

™

HD77

Installation Guide

Revision 1.00

2Paradox Insight ™ HD77 Installation Guide

Warranty

For complete warranty information on this product, please refer to the Limited Warranty Statement found on

the website www.paradox.com/terms. The terms and conditions are subject to change without notice, from

time to time, at Paradox’s sole discretion. We invite you to visit our website on a regular basis for the latest

Limited Warranty Statement. Your use of the Paradox product signifies your acceptance of all warranty terms

and conditions. Please ensure that your use of the Paradox product is in compliance with local, national, and

international laws.

Canadian and international patents may apply. Paradox Insight and Paradox are a trademarks or registered

trademarks of Paradox Security Systems (Bahamas) Ltd. or its affiliates in Canada, the United States and/or

other countries.

This product is manufactured in Canada.

Paradox

780 Industrial Boulevard

St-Eustache, Quebec

Canada, J7R 5V3

Tel: (450) 491-7444

Fax: (450) 491-2313

Paradox Insight™ HD77 Installation Guide 3

Contents

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Chapter 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.1 HD77 Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

1.2 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

1.3 LED Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Chapter 2 Hardware Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.1 Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.2 Cabling Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.3 Location and Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Chapter 3 Creating an Account in BabyWare . . . . . . . . . . . . . . . . . . . . . . . . 20

3.1 Required Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.2 Required Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Chapter 4 Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4.1 Programming Through BabyWare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4.2 Receive Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4.3 HD77 Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.4 HD77 Server Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.5 Static IP for the WAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4.6 Reserved/Static IP Configuration for the LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Chapter 5 PIR Parameters Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

5.1 Programming Through the TM50 Touchpad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

5.2 Programming Through the K641 series Keypads and K656 Keypad . . . . . . . . 33

Chapter 6 ParadoxMyHome (PMH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

6.1 To Open a ParadoxMyHome Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

6.2 Registering/Unregistering your devices to ParadoxMyHome . . . . . . . . . . . . . . 35

6.3 Deleting a Site from PMH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Chapter 7 Using a Static IP for the WAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Chapter 8 Upgrading Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4Paradox Insight ™ HD77 Installation Guide

Appendix: A Trouble Shooting ......................................................................40

For DHCP ...............................................................................................................................................40

For Static IP ...........................................................................................................................................42

Appendix: B Specifications ............................................................................45

HD77 Specifications ...........................................................................................................................45

Appendix: C PIR Detector Beam Pattern .......................................................46

Appendix: D Certifications .............................................................................47

FCC Statement Class B ......................................................................................................................47

Appendix: E Un-Assemble Swivel Bracket ....................................................48

Disassemble Swivel ............................................................................................................................48

Appendix: F Configure IP Router (1 Example) ..............................................52

Setting Up the Router for Port Forwarding ...............................................................................52

Reserve the IP or Bind the IP to a MAC .......................................................................................56

Paradox Insight™ HD77 Installation Guide 5

List of Figures

Figure 1 Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Figure 2 LED Arrangement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Figure 3 HD77 Hardware Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Figure 4 Recommended Wiring Option#1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Figure 5 Recommended Wiring Option#2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Figure 6 Ethernet Cable Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Figure 7 Mounting Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Figure 8 HD77 Swivel Bracket Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Figure 9 Separating the Module from the HD77 Housing . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Figure 10 Install the Wall Plate (part #1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Figure 11 Run the Cable through the Swivel Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Figure 12 Connect the Bracket Assembly to the Wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Figure 13 Screw on HD77 Back Plate to Swivel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Figure 14 Screw Location to Adjust Camera Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Figure 15 Wire the HD77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Figure 16 Knockout Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Figure 17 Wire the HD77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Figure 18 HD77 Video Stream in BabyWare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Figure 19 BabyWare Account Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Figure 20 IP150 Settings Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Figure 21 Locate IP Device on Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Figure 22 IP Device Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Figure 23 BabyWare Homepage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Figure 24 HD77 Receive Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Figure 25 Write Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Figure 26 Communication Drop Down Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Figure 27 Server Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Figure 28 Command Prompt ipconfig . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Figure 29 DHCP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Figure 30 Port Numbering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

6Paradox Insight ™ HD77 Installation Guide

Figure 31 PIR Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Figure 32 Flow Through the TM50 Touchscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Figure 33 Main Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Figure 34 Menu Selections Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Figure 35 Advanced Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Figure 36 Installer Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Figure 37 Installer Programming Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Figure 38 Installer Programming Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Figure 39 Module Serial Number Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Figure 40 Programming Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Figure 41 Options Selection Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Figure 42 Select an HD77 to Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Figure 43 Registration to PMH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Figure 44 Register/Unregister to PMH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Figure 45 ParadoxMyHome Registration Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Figure 46 Registration Successful . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Figure 47 ParadoxMyHome Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Figure 48 Poll PMH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Figure 49 Select HD77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Figure 50 Update button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Figure 51 Click Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Figure 52 HD77 — Settings Update Graphic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Figure 53 HD77 Settings Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Figure 54 HD77 — Settings Update Graphic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Figure 55 HD77 Settings Window Update Graphic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Figure 56 Locates Devices Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Figure 57 IP Device Configuration Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Figure 58 PIR Detector Beam Pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Figure 59 HD77 Swivel Bracket Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Figure 60 Assembled Swivel Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Figure 61 Screw the Slider, HD77 Camera Housing and Back Housing Together . . . . . 49

Figure 62 Separating the Module from the Camera Housing . . . . . . . . . . . . . . . . . . . . . . . . 49

Paradox Insight™ HD77 Installation Guide 7

Figure 63 Install the Wall Plate (part #1) and Wall Housing (part #2 . . . . . . . . . . . . . . . . . . 49

Figure 64 Screw the Slider, HD77 Camera Housing and Back Housing Together . . . . . 50

Figure 65 Screw on Camera Back Plate to Swivel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Figure 66 Wire the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Figure 67 Command Prompt ipconfig . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Figure 68 DHCP Enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Figure 69 Fill in the Port Forwarding Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Figure 70 Port Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Figure 71 Binding or Reserving a Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Figure 72 HD77 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Figure 73 Locate Static IP Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

8Paradox Insight ™ HD77 Installation Guide

Chapter 1 Introduction

The Paradox Insight™ HD77 camera is a highly reliable HD video (720p in color) and high-quality audio PIR

camera that delivers unlimited live HD video and audio streaming to allow users to see and hear events and

activities and to protect their homes or businesses anytime, anywhere, directly from a smartphone.

In case of a security breach, the HD77 camera provides HD videos with high-quality audio of events for visual

verification and reporting. When an alarm is triggered, the HD77 sends a pre-recorded video (360p) in color or

black and white (night vision) and 10 images (jpegs) to allow users and the CMS to view what triggered the

alarm. The user can also access HD 720p video and audio recordings, as required.

The HD77 fully complies with CE, and EN 50131certification.

1.1 HD77 Key Features

• HD video / audio - with 360p video and live streaming

•VideoonDemand(VOD)

•RecordonDemand(ROD)

• Record on Motion (ROM)

• Record on Trigger (ROT)

• HD video / audio alarm event verification (jpg still images and H.264 video files)

• Integrated video verification alarm event reporting to the CMS (IPRS-7 / CMSI) and user (email)

• Detection - high reliability PIR, auto pulse, auto dual edge, digital detector with a 110° beam spread

• HD 720p color recordings

• 1.4 mega pixel Image sensor HD video camera equipped with video auto gain control, white balance

and auto exposure

• Three second audio / video pre-alarm

• Zero-lux vision using high power IR LEDs

•LANconnection

• Multiple simultaneous multimedia streams

• Event file names and video file names are linked through naming convention for easy identification

• Digiplex bus connection enables easy HD77 system installation/ integration

• Fully compatible with the Paradox EVOHD control panel

1.1.1 Video on Demand (VOD)

The video on demand feature allows up to eight users of the security system (selected as permitted users

through the Paradox Insight™ phone application) to have viewing rights. The permitted users then have access

to the streaming video from the camera. This access is obtained through the Paradox Insight™ phone

application. The master user chooses these permitted users and also sets the permitted user’s viewing rights.

1.1.2 Record on Demand (ROD)

The record on demand feature allows permitted users to start and stop camera recording through the Paradox

Insight™ phone application. Record on demand records up to 2 minute long video files. Recordings are saved as

both 720p and 360p resolution. The 30 first seconds are sent by email to the master user and the user that

made the recording.

1.1.3 Record on Motion (ROM)

The record on motion feature starts the camera recording when the PIR detector in the HD77 camera detects

motion. The recording is started when the system is disarmed. The camera records for 10 seconds during ROM.

Paradox Insight™ HD77 Installation Guide 9

1.1.4 Record on Trigger (ROT)

The record on trigger feature starts the camera recording when another detector (zone) in the system is

triggered. Up to four detectors (zones) can be assigned to each camera. Whenever an assigned detector is

triggered the camera starts recording for 10 seconds. The recording can be started both if the detector is armed

or disarmed. The recorded files are saved in the camera and can be sent to pre-assigned emails.

Up to 4 HD77 cameras can each be assigned up to 4 different zones.

Configuring HD77 cameras for ROT is done by the master user through the Paradox Insight™ App.

1.2 Overview

The Paradox Insight™ HD77 camera is a highly reliable HD video (720p in color) and high-quality audio PIR

camera.

Figure 1 – Front View

1.3 LED Status Indicators

The following table describes the HD77 LEDS and their functionality.

Figure 2 – LED Arrangement

LEDs 1, 2, 4, and 5 are used for installer diagnostics. These LEDs are active when the lock mechanism is opened.

Camera

Microphone

IR LEDs

Information LEDs

LED1 LED2 LED3 LED4 LED5

TX RX

LED 2 LED 3

LED 1 LED 4 LED 5

10 Paradox Insight ™ HD77 Installation Guide

Note: LED3 — PIR indication can be set to On or Off by the installer, however, the VOD indication can be turned

off only by the master user using the Paradox Insight™ application.

Note: Turning the VOD LED off may be considered in some countries as a violation of applicable laws. Make

sure to install the HD77 according to local laws.

Table 1: LED Assignment

LED Functionality LED Display

LED1 Digiplex Data TX Flashing green = data

transmission

Off = No data transmission

LED2 Digiplex Data RX Flashing green = data

reception

Off = No data reception

LED3

(both with the front

cover locked and

unlocked)

HD77 module is up and running. There are currently

no PIR detections or requests for VOD/ROD.

OFF

Firmware upgrade in progress Flashing Purple

VOD Blue on

Power-up Flashing Blue

Locate mode (through the keypad only) Flashing Blue

General bus failure, wiring problem, or

communication problem

Red on

Bus low power Flashing Red

PIR alarm Red for 3 sec

LED4 Active Web connection Green

LED5 LAN 10/100Mbps link

LAN 10/100Mbps data transfer

Green = LAN active

Off = no connection

Flashing green = data transfer

Flashing red = UPnP failure

Autres manuels pour HD77

Table des matières

Autres manuels PARADOX INSIGHT Appareil photo numérique

PARADOX INSIGHT

PARADOX INSIGHT HD77 Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
