ParaBody 870 Manuel utilisateur

870 VERTICAL DUMBBELL RACK

CLASSH

PART # 7081401

REV.A Revision: 03/26/01

USER’S GUIDE

WARNING:

Read and follow all directions

for each step to insure proper

assembly of this product.

Version: 870107

THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF

EQUIPMENT. TO MINIMIZE RISK FOLLOW THESE RULES!

1. Before using, read all the warnings and instructions

on the use of this machine. Use only for intended

exercise. DO NOT modify the machine.

2. Obtain a medical exam before beginning any

exercise program.

3. Keep body and clothing free of all moving objects.

4. Inspect the machine before use. DO NOT use it if it

appears damaged. DO NOT attempt to fix a broken or

ammed machine. Notify your authorized ParaBody

dealer before use and have repairs made by an

authorized service technician.

5. Be certain that weight pin is completely inserted.

Use only the pin provided by the manufacturer. If

unsure, call your authorized ParaBody dealer.

6. Never pin the weights or prop plate into an elevated

position. DO NOT use the machine if found in this

condition. DO NOT attempt to fix. Notify your

authorized ParaBody dealer.

7. Inspect cables and their connections before using

machine. Pay particular attention to the cable ends.

DO NOT attempt to fix. Notify your authorized

ParaBody dealer before use and have repairs made by

an authorized service technician.

8. Make sure all spring loaded pull pins are fully

engaged in the adjustment position and fully tighten

thumbscrew before use.

9. Children must not be allowed near this machine.

Supervise teenagers.

IMPORTANT SAFETY INFORMATION

TABLE OF CONTENTS

Safety Statement.............2

General Notes..................3

Tools Required................3

Parts List.........................4

NOTE: In a continual effort to improve our products, specifications are subject to change

ParaBody is a trademark of Brunswick Corporation

www.parabody.com

Assembly Instructions.....4

General Maintenance.......5

Warranty Statement..........6

Product Services..............7

Insert-Registration Card

IMPORTANT NOTES

Please note:

Tools Required forAssembly

* Thank you for purchasing the ParaBody 870 DUMBBELL RACK. Please read these

instructions thoroughly and keep them for future reference. This product must be assembled

on a flat, level surface to assure its proper function.

* 3/4” inch socket

* 9/16” inch socket

*Adjustable wrench

* Rubber mallet or hammer

NOTE:BOLTLENGTHISMEASUREDFROMTHEUNDERSIDEOFTHEHEADOFTHE BOLT.

BOLT LENGTH RULER:

* This product must be assembled on a flat, level surface to assure its proper function. DO NOT

securely tighten any frame connections until the entire frame has been assembled, unless

otherwise stated.

Bolt Length Ruler

0123456

1/2 1/2 1/2 1/2 1/2 1/2

BOLT LENGTH

PARTS LIST

0123456

1/2 1/2 1/2 1/2 1/2 1/2

PART #

6215708

6284702

6013708

3102942

3102501

3102802

KEY

QTY

PART #

6011401

6405201

6236701

6177001

DESCRIPTION

SAFETYLOCK PIN

2” SQ. END CAP

1-3/4” SQ. END CAP

2-1/2 X 5-1/2” NON SKID STRIP

QTY

DESCRIPTION

FOOT BRACE ASSY

ADJUSTABLE TUBEASSY

CONNECTOR PLATE

3/8 X 3-1/2” BOLT

3/8” FLATWASHER

3/8” LOCK NUT

KEY

STEP5:

FIGURE 5

• Remove the hardware from the FRONT LEG of BENCH assembly

• Insert one 1-3/4 END CAP(9) into the open end of theADJUSTABLE TUBEASSEMBLY (2) as shown

• Assemble theADJUSTABLE TUBEASSEMBLY(2) and the CONNECTOR PLATE (3) to the BENCH using

two 3/8 X 3-1/2” BOLTS (4), four 3/8” FLAT WASHERS (5) and two 3/8” LOCK NUTS (6).

(NOTE: THE BRACKET ONTHEADJUSTABLE TUBEASSEMBLYIS FLUSH (EVEN) WITHTHE

TUBE,ASSEMBLEFLUSH SIDE UP)

• Insert one 2” SQ END CAP (8) into the front end of the FOOT BRACE (1) as shown

• Attach four NON SKID STRIPS (10) to the FOOTBRACE (1)

• Slide the FOOT BRACE (1) over theADJUSTABLE TUBEASSEMBLY(2) to the desired hole setting and

hold in place with the SAFETY LOCK PIN (7)

FRONT

BENCH

FRAME
