Panasonic MC-UG471-00 Manuel utilisateur

COMPANY, DIVISION OF MATSUSHITA

ELECTRIC CORPORATION OF AMERICA. All rights

reserved. Unauthorized copying and distribution is a

violation of law.

MC-UG471-00

Vacuum Cleaner

Specifications are subject to change without notice for further improvement.

;Order Number MAC0705001CE

1 WIRING DIAGRAM AND DRAWING 3

1.1. Wiring Diagram 3

1.2. Pictoral Diagram 4

2 EXPLODED VIEW AND PARTS LIST 5

2.1. Body 5

2.2. Nozzle Housing 7

2.3. Packing Materials 8

3 REPLACEMENT INSTRUCTIONS 9

3.1. Lower Plate Replacement 9

3.2. Agitator Assembly Replacement 9

3.3. Belt Replacement 10

3.4. Bulb Replacement 10

3.5. Motor Replacement 10

3.6. On-Off Switch Replacement 12

3.7. Cord Reel Replacement 12

3.8. Motor Protector Replacement 12

CONTENTS

Page Page

MC-UG471-00

1 WIRING DIAGRAM AND DRAWING

1.1. Wiring Diagram

MC-UG471-00

1.2. Pictoral Diagram

NOTE:

For general servicing, it is necessary to eliminate pinching of any wire during reassembly. After servicing any electrical

component or electrical enclosure, the unit should be reassembled and checked for dielectric breakdown or current leakage.

MC-UG471-00

2 EXPLODED VIEW AND PARTS LIST

2.1. Body

2.1.1. Exploded View

MC-UG471-00

2.1.2. Parts List (Body)

Ref.

No. Part No. Part Name & Description Quantity Remarks

1AC40KCRBZV07 Dust Compartment 1

2AC60KCRBZR0W Dust Cover 1

3AC70PBXZZV07 Wand Holder 1

4AC98EARFZ0U ON/OFF Switch 1

5AC43GBJAZ000 Lead Wire - White 1

6AC38GBJAZ000 Lead Wire - Black 1

7AC69KJMZV07 Protector 1

8AC70KBKFZK00 Protector Spring 1

9AC68KAJDZV07 Protector Cover 1

10 AC39ACSCZV00 Body Packing Right 1

11 AC40ACRAZV00 Body Packing Left 1

12 AC92FCHPZ000 Motor 1

13 AC02FCHPZ000 Motor Support 1

14 AC43GAWYZ000 Lead Wire 1

15 AC44DCNZZ000 Crimp Connector 6Shipped 10 per package

16 AC47NATCZ000 Cord Reel Spring 1

17 AC94NCRAZY05 Brake Lever Assembly 1

18 AC99WCHRZ000 Lead Wire Assembly 1

19 AC03FCHPZ000 Motor Support 1

20 AC99GAMMZ00 Noise Suppressor 1

21 AC93HCHRZ000 Bulb Socket 1

22 AC28GBKHZ000 Bulb 1

23 AC21HCRAZ000 Window 1

24 AC16CUSZ00 Wheel Shaft 1

25 AXWG6E115FY Washer 2Shipped 10 per package

26 AC01CVZV07 Wheel 2

27 AC74SUSZ00 Wheel Stopper 2Shipped 10 per package

28 AXTN4+16BFY Screw 10 Shipped 10 per package

29 AC52PBXZZV06 Connector Pipe 1

30 AC78NZAZ000 Plastic Holder 1

31 AC37KCRBZ000 Secondary Filter 1

32 AC66KCRBZ000 Dust Compartment Packing 1

33 AMC596-702 Wire Tie 1Shipped 10 per package

34 AC95BCRAZV07 Handle Assembly 1

35 AC39ACSDZV00 Body Packing Right 1

36 AC66PCRAZV07 Tool Caddy 1

37 AC36NCRAZV06 Cord Reel Cover 1

38 AC14NCRAZV06 Cord Guide 1

39 AC99NCRAZV06 Cord Reel Assembly 1

40 AC98NCRAZ000 Contact Disc Assembly 1

41 AC73BCJUZ000 Handle Screw 1

42 AC38KBRMZ000 Exhaust Filter 1

43 AC16KBYTZ000 Dust Bag 1

44 AC48HDDHZRUW Cover 1

45 AC84PCRAZV06 Hose Assembly 1

46 AC64HAMMZ00 Packing 1

47 AC60RZFZVU6 Crevice Tool 1

48 AC40PBRKZV06 Extension Wand 1

49 AC40PBRLZV06 Extension Wand (With Tabs) 1

50 AC80SCXZZV07 Air Turbine 1

51 AC88RYUZV06 Dusting Brush 1

MC-UG471-00

2.2. Nozzle Housing

2.2.1. Exploded View

2.2.2. Parts List (Nozzle Housing)

Ref. No. Part No. Part Name & Description Quantity Remarks

1AC01ADDHZRUW Nozzle Housing 1

2AMC68A-V30 Screw 2

3AC10ACKPZV06 Furniture Guard 1

4AC84RCKPZ000 Agitator 1

5AC27ACRAZV07 Lower Plate 1Shipped 10 per package

6AC68NCRAZV06 Latch 2

7AC43SAFXZ000 Belt Guard 1

8AC28SCZPZ000 Belt 1Shipped 10 per package

9AXTN4+10BFY Screw 1

10 AMC43A-2V0 Frame 1

11 AXTN4+16BFY Screw 2

12 AMC51A-V30 Pedal Shaft 1

13 AC58AAFVZ00 Pedal Spring 1

14 AC47A2VZV06 Pedal 1

15 AC34PCRAZV06 Nozzle Hose 1

16 AC02ACRAZV06 Upper Body 1

17 AC12ACRAZV06 Upper Body Cap 1

18 AXTN4+16BFY Screw 3Shipped 10 per package

19 AC61KDDHZV06 Nozzle Roller Cam 1

20 AC16CNXZ00 Roller Shaft 2

21 AC90QNGZV06 Wheel 2

22 AC40RCKPZ000 Floor Nozzle Spring 1

MC-UG471-00

2.3. Packing Materials

2.3.1. Exploded View

2.3.2. Parts List (Nozzle Housing)

Ref. No. Part No. Part Name & Description Quantity Remarks

1AC61ZDDHZ000 Packaging Assembly 1Includes items A-G

2AC01ZDDHZ000 Operating Instruction 1

MC-UG471-00

3.1. Lower Plate Replacement

3.1.1. Removal

1.Disconnect power cord from electrical outlet, and place on

paper to protect the floor surface. Place vacuum cleaner in

the full upright posiiton.

2.Turn the unit over so the agitator and nozzle base are

facing upward.

3.Locate the two latches and the two locking tabs which

secure the base plate.

4.To remove the nozzle base, press the two latches inward.

5.Push in on the locking tabs toward the center of the vacuum

cleaner.

6.Rotate the nozzle base away from the nozzle. The sides of

the nozzle base need to be pulled slightly outward to clear

the wheels.

3.1.2. Installation

1.To re-attach the nozzle base, place the vacuum cleaner in

full upright position. Insert the tabs into the slots along the

front edge of the base. Lower the nozzle base to its original

position.

2.As the base is lowered the inner areas will brush against the

dust compartment wheels. A gentle pull outward may assist

in reassembly.

3.Press the nozzle base down until the two locking tabs snap

into place .

4.Fasten the lower plate by pushing the two (2) latches

outward.

5.Return the vacuum cleaner to the upright position before

plugging into the electrical outlet.

3.2. Agitator Assembly

Replacement

3.2.1. Removal

1.Remove the lower plate as outline in NOZZLE BASE

REMOVAL/INSTALLATION.

2.Carefully remove any residue that may exist in the belt area.

If the belt is still attached to the motor shaft, there will be

tension on the agitator. If the belt is not broken, remove it

from the motor shaft before lifting the agitator.

3.Carefully lift the one end of the agitator and then lift the

other end.

3.2.2. Installation

1.Place the belt around the motor shaft.

2.Place the belt around the agitator pulley on the agitator

assembly.

NOTE: There is a place for the belt to fit on one end of

the agitator assembly only. This is the agitator pulley.

3.Insert the new agitator assembly back into the nozzle

housing by placing the side opposite the belt partially into

the slot. The small tabs should be aligned against the

nozzle and the other against the lower plate. This will hold

the agitator in place and leave both hands free to place

enough tension on the belt to allow that side of the agitator

to return to the nozzle housing slot.

NOTE: Care must be taken due to the belt tension

during reassembly.

4.Use both hands to pull the belt tight, and slide the agitator

assembly firmly into the slots on each end of the nozzle

3 REPLACEMENT INSTRUCTIONS

MC-UG471-00

housing.

5.Press firmly, checking to see that each end is completely

inserted.

6. Check to see that the belt is centered in the belt groove.

7. Rotate the agitator assembly by hand to insure nothing

rubs and check for correct assembly.

8.Replace the lower plate as outlined in the LOWER PLATE

REMOVAL/INSTALLATION section.

3.3. Belt Replacement

3.3.1. Removal

1.Remove the lower plate as outlined in LOWER PLATE

REMOVAL/INSTALLATION section.

2.Remove the agitator assembly as outlined in the

AGITATOR ASSEMBLY section.

3.Remove old belt.

3.3.2. Installation

1.Place the new belt around the motor shaft.

2.Install the agitator assembly as outlined in the AGITATOR

ASSEMBLY section.

3.Install the lower plate as outline in LOWER PLATE

REMOVAL/INSTALLATION section.

3.4. Bulb Replacement

3.4.1. Removal

1.Ensure ON-OFF switch is OFF and disconnect power cord

from electrical outlet.

2.Press handle release pedal and rotate the handle down so

the vacuum cleaner is laying flat on the floor.

3.Pry out light lens at slots. Remove old bulb from the socket

by pulling from socket.

3.4.2. Installation

1.Replace bulb by pressing into socket. Only use a bulb rated

13 V AC-9 Watts.

2.Reinstall light lens by snapping into place.

3.Return the vacuum cleaner to the upright position.

3.5. Motor Replacement

3.5.1. Removal

1.Pull outward on the cover grip, located near the top of the

dust cover and remove the cover.

2.Grasp the dust bag collar and pull gently, carefully removing

the dust bag.

MC-UG471-00
