Panasonic EY37A3 Manuel utilisateur

© Panasonic corporation 2018. All rights reserved.

Unauthorized copying and distribution is a violation

of law.

Order Number PTD1805X46CE

Cordless Vacuum Cleaner

Model No. EY37A3

Europe

Oceania

TABLE OF CONTENTS

PAGE PAGE

1 Warning -------------------------------------------------------------- 2

2 Specifications ----------------------------------------------------- 2

3 Troubleshooting Guide ----------------------------------------- 3

4 Disassembly and Assembly Instructions ---------------- 5

5 Exploded View and Replacement Parts List ------------ 7

2

1Warning

Caution:

• Pb free solder has a higher melting point that standard solder; Typically the melting point is 50 - 70°F (30 - 40°C) higher. Please

use a soldering iron with temperature control and adjust it to 750 ± 20°F (400 ± 10°C). In case of using high temperature solder-

ing iron, please be careful not to heat too long.

• Pb free solder will tend to splash when heated too high (about 1100°F / 600°C).

2 Specifications

3

3 Troubleshooting Guide

3.1. Troubleshooting Guide

4

3.2. Trial Operation (after checking Troubleshooting Guide).

3.2.1. Assembly

• Confirm if there is no gap between housing A and B by pinching lead wires.

• There is no dust or deformation on battery terminals.

3.2.2. Operation

• Check whether the switch can be moved between the “ HIGH “ and “ LOW “ positions.

• Press the switch OFF button and verify that the unit powers off.

• Check for any abnormal sounds during tool operation.

• Check whether the dust cup can be detached and reattached smoothly.

• Check whether the dust cup suction is normal (Check whether a 1/2” ball bearing (approx. 8 g) can be picked up).

3.2.3. Integrity

• There should be no abnormal sound when shaking the unit.

• confirm if there is no dirt when repairing.

5

4 Disassembly and Assembly Instructions

* To assemble the tool, start with 4-6 and proceed to 4-1.

4.1. Removing the Exterior components.

4.2. Removing the Housing.

4.3. Removing the Motor assembly and Module assembly.

4.4. Removing Solder Connections.

6

4.5. Removing the Support rubber.

4.6. Wiring and Assembly Points.

Model No. : EY37A3 Exploded View

5 Exploded View and Replacement Parts List

Model No. : EY37A3 Parts List

Change Safety Ref.

No. Part No. Part Name & Description Q'ty Remarks

1 WEY37A3K3497 DUST CUP ASSEMBLY 1

2 WEY37A3L0247 DUST FILTER 1 * Only available as an optional a

ccessory in EU area.

3 WEY37A3W3037 FILTER GRID 1 * Only available as an optional a

ccessory in EU area.

4 WEY3780L0138 PROTECTION FILTER 1 * Only available as an optional a

ccessory in EU area.

5 WEY508B9617 TAPPING SCREW 8 （K3* 20)

6 WEY37A3K3167 SWITCH COVER ASSEMBLY 1

7 WEY37A3K3078 HOUSING AB SET 1 (For Europe)

7 WEY37A3K3079 HOUSING AB SET 1 (For Oceania)

8 WEY37A3L2147 MAIN SWITCH BLOCK 1

9 WEY37A3L2107 MODULE ASSEMBLY 1

10 WEY37A3L1008 MOTOR ASSEMBLY 1

11 WEY3780L0317 SUPPORT RUBBER 1

12 WEY37A3K7307 EXTENSION PIPE 1 * Only available as an optional a

ccessory in EU area.

13 WEY37A3K3847 HOLDER FOR CREVICE NOZZLE 1

14 WEY3782K7617 FLOOR BRUSH 1 * Only available as an optional a

ccessory in EU area.

15 WEY37A3K7557 CREVICE NOZZLE 1 * Only available as an optional a

ccessory in EU area.

16 WEY37A3K3107 CUSHION RUBBER 1

- WEY37A3L8108 OPERATING INSTRUCTIONS 1
