Advanced Hybrid System

KX-TA624-4

Manual Addendum

for the

Caller ID Feature

This Manual Addendum provides the additional information on Caller ID for the Panasonic

Advanced Hybrid System, KX-TA624.

[913] Caller ID Call Waiting Assignment

Description

Enables or disables the Caller ID Call Waiting feature for outside (CO) lines which have

contracted Caller ID Service with a Central Office.

Selection

• Outside (CO) line number: 1 –6,( = all outside (CO) lines)

•Enable / Disable

Default

All outside (CO) lines — Enable

Programming

1. Enter 913.

Display: C.W CID Assign

2. Press NEXT.

Display: CO NO?

3. Enter an outside (CO) line number.

Pressing NEXT also can enter outside (CO) line number 1.

Display example: CO 1:Enable

4. Keep pressing SELECT until the desired selection is displayed.

5. Press STORE.

6. To program another outside (CO) line, press NEXT or PREV, or SELECT and enter

the desired outside (CO) line number.

7. Repeat steps 4 through 6.

8. Press END.

Conditions

• To assign alloutside(CO) lines to thesame selection, press the keyin step 3. In this case,

the display will show: CO :Mixed.

• When “Disable” is assigned in program [900] “Caller ID Assignment”, the Caller ID Call

Waiting feature does not perform even if “Enable” is assigned in this program.

Feature References — in the Installation Manual

Caller ID Call Waiting

System Programming

[914] Caller ID Call Waiting CAS Receive Time

Description

The telephone company calls the system "Customer Premise Equipment (CPE)". If you have

a Caller ID Call Waiting during a conversation, the telephone company will send to the CPE a

CAS (CPE Alerting Signal). If the CAS duration is too long or too short, the CAS is ignored.

If the CAS is accepted, then the system will respond and the Caller ID Call Waiting feature will

be performed.

This program assigns the allowable CAS duration. Normally, it should not be necessary to

change the default setting.

Selection

•Mode 1 (40 ms through 120 ms) / Mode 2 (64 ms through 96 ms) /

Mode 3 (72 ms through 96 ms)

Default

Mode 3

Programming

1. Enter 914.

Display: C.W CID Receive

2. Press NEXT.

Display example: Mode 3

3. Keep pressing SELECT until the desired selection is displayed.

4. Press STORE.

5. Press END.

Conditions

• This program is available when “Enable” is assigned in programs [900] “Caller ID

Assignment” and [913] “Caller ID Call Waiting Assignment”.

Feature References — in the Installation Manual

Caller ID Call Waiting

System Programming

[915] Caller ID Checksum

Description

Enables or disables to select the checksum mode. Normally, it should not be necessary to

change the default setting.

For further details on the checksum, consult your dealer.

Selection

•Enable / Disable

Default

Enable

Programming

1. Enter 915.

Display: CID Check Sum

2. Press NEXT.

Display example: Enable

3. Keep pressing SELECT until the desired selection is displayed.

4. Press STORE.

5. Press END.

Conditions

None

Feature References — in the Installation Manual

Caller ID

Caller ID Call Waiting

System Programming

Printed in the United Kingdom PSQX2931ZA KK0203HK0
