Panasonic MS104 FA Manuel utilisateur

KNX Multi Functional Switch

Version: 1.0 Jan-20 Page 1/20

KNX Multi Functional Switch

Reference Manual

V1.0

KNX Multi Functional Switch MS104 FA WRKT62045FA

KNX Multi Functional Switch MS104-D FA WRKT62145FA

KNX Multi Functional Switch

Version: 1.0 Jan-20 Page 2/20

1Contents

1Contents.......................................................................................................................................... 1

2List of figure .................................................................................................................................... 3

3Document overview......................................................................................................................... 4

3.1 Document updates................................................................................................................... 4

3.2 List of abbreviations................................................................................................................. 4

4Product description ......................................................................................................................... 5

4.1 General information ................................................................................................................ 5

4.2 Main features .......................................................................................................................... 5

4.3 Technical information .............................................................................................................. 6

4.4 Product versions...................................................................................................................... 6

5Product parts .................................................................................................................................. 7

6Main screen .................................................................................................................................... 8

7Display menus............................................................................................................................... 11

7.1 User settings menu ................................................................................................................ 11

7.2 Advance settings menu.......................................................................................................... 13

7.3 Weekly program settings menu.............................................................................................. 17

7.4 Thermostat off....................................................................................................................... 20

KNX Multi Functional Switch

Version: 1.0 Jan-20 Page 3/20

2List of figure

Figure 1 Product front view .........................................................................................................................................................7

KNX Multi Functional Switch

Version: 1.0 Jan-20 Page 4/20

3Document overview

3.1 Document updates

Version

Date

Modifications

1.0

December 2019

Preparation of the final version

Table 1

3.2 List of abbreviations

Abbreviation

Description

Table 2

KNX Multi Functional Switch

Version: 1.0 Jan-20 Page 5/20

4Product description

4.1 General information

KNX Multi-Functional Switch is a room controller with 12 capacitive touch buttons over 4 Gang and

integrated real time clock, temperature sensor, humidity sensor, proximity sensor and brightness sensor. It

also has one digital input and one temperature sensor (NTC) input.

KNX Multi-Functional Switch is powered via KNX bus line without an external power supply. The device can

be programmed to enable, disable or configure its features and functions via ETS.

Thanks to thermostat function which is one of the most important feature of the product; heating and cool-

ing control can be done included 2/4 pipe fancoil systems. With the help of touch buttons, a lot of control

operations can be done especially blinds/shutter, switching and dimming. Additionally; the device also can

send temperature and humidity measured values to other KNX devices on the bus line.

KNX Multi-Functional Switch can be installed in flushed-mounted or hollow-wall boxes.

4.2 Main features

Configurable touch buttons up to 4 Gang for single or rocker operation

Sound feedback for touch buttons functions

Configurable feedback LEDs can be used with buttons or KNX group objects

Customized icon label stickers for touch buttons

Activating standby mode according to presence information determined via proximity sensor

Adjusting backlight of display and touch buttons according to ambient light information determined

via brightness sensor

Operating energy saving functions of thermostat according to information of the digital input

Controlling thermostat functions according to information of external temperature sensor input or

monitoring the sensor values via KNX

Temperature and humidity sensors can be calibrated before ETS programming by parameters or after

ETS programming by communication objects

Weekly Thermostat Program can be configured over the device (only LCD model) or DCA (Device

configuration app) inside ETS

Scene actuator functions

KNX Multi Functional Switch

Version: 1.0 Jan-20 Page 6/20

4.3 Technical information

Supply voltage

21 … 32 V DC via KNX Bus

Operating temperature

-5°C … +45°C

Type of protection

IP 20 to EN60529

Safety class

III to IEC 60664-1

Cable length for external inputs

Maximum 3 m

Temperature measurement

0°C to 45°C

Relative humidity

0% to 100%

Table 3

4.4 Product versions

Product Features

WRKT62045FA

WRKT62145FA

KNX Multi Functional

Switch 4 Gang

MS104-FA

KNX Multi Functional

Switch 4 Gang

MS104-D FA

Button Functions

✓

Thermostat Functions

✓

Scene Actuator

✓

LCD Display

✓

Table 4

KNX Multi Functional Switch

Version: 1.0 Jan-20 Page 7/20

5Product parts

Thermostat buttons

Figure 1 Product front view

Feedback LED

Icon LED

Down

Touch button surface

Gang B

Gang D

Gang C

Gang A

Thermostat

Buttons and Display

KNX Multi Functional Switch

Version: 1.0 Jan-20 Page 8/20

6Main screen

After start-up, the display enters main screen. At the main screen, some information like room

temperature, clock, operation mode, control mode, fan level etc. are given to users.

Power up Start-up delay Start-up Main screen

Icon

Name

Touch type

Current menu

Target menu

Short

Main screen

User settings menu

Short

Main screen

User settings menu

Down

Short

Main screen

User settings menu

Long

Main screen

Advance settings menu

Long

Main screen

Thermostat off

Down

Long

Main screen

Weekly settings menu

Table 5

The following table includes some basic information which are shown at main screen. For more

information about icons, check reference manual.

Information

Visual

Clock

Internal temperature sensor value

KNX Multi Functional Switch

Version: 1.0 Jan-20 Page 9/20

Information

Visual

External temperature input value

Internal humidity sensor value /

External humidity value

Current thermostat operation mode

Current thermostat control mode

Current thermostat control mode is active

Current thermostat fan level and fan mode

Thermostat weekly program is active

KNX Multi Functional Switch

Version: 1.0 Jan-20 Page 10/20

Information

Visual

Day of week

Table 6
