Panasonic KX-T206E Caractéristiques techniques

Electronic Modular

Switching System

KX-T206E

Product Description

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

Contents

SYSTEM PARAMETERS 4

SYSTEM HARDWARE 5

CABINETS 5

SYSTEM COMPONENTS 6

KX-T206E CENTRAL CONTROL UNIT 6

KX-T20691E DISA/FAX DETECT CARD 6

KX-T30865E DOORPHONE UNIT 6

HAND-SET OPTIONS 7

HAND-SET FEATURES 7

HAND-SET TYPES 7

ANSWERING CALLS 8

DIRECT INWARD SYSTEM ACCESS DISA 8

FLEXIBLE RINGING ASSIGNMENT 8

DELAYED RINGING 8

CALL PICK UP9

DOORPHONE ASSIGNMENT 9

FLEXIBLE FUNCTION KEYS 10

FLEXIBLE NIGHT SERVICE 11

HOLDING CALLS 11

TRANSFERRING & INTERCOM CALLS 12

INTERNAL VOICE / TONE CALLS 12

TRANSFER ( SCREENED / UNSCREENED)12

CONFERENCE CALLS 12

LOCATING CALLS 13

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

PAGING WITH MEET ME13

CALL SPLITTING 13

DO NOT DISTURB 13

CALL FORWARDING 13

OUTGOING CALLS 14

SPEED DIALLING - SYSTEM 14

LAST NUMBER RE-DIAL 14

AUTO CO HUNTING 14

OUTGOING PERMITTED CO ASSIGNMENT 14

LEAST COST ROUTING (LCR) 15

CALL RESTRICTION 16

OTHER FEATURES 17

HEADSET CONNECTION 17

AUTOMATIC ANSWER 17

AUTOMATIC RECALL 17

ON HOOK DIALLING 17

VOLUME AND LCD CONTRAST ADJUSTMENT 18

DUAL COLOUR LEDS18

MICROPHONE MUTE 18

DOORPHONE INTERFACE 18

PULSE / DTMF DIALLING 19

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

System Parameters

System Microprocessor 8 Bit

System Memory 64 Kilobit RAM

512 Kilobit ROM

Switching Space Division

Cabling (proprietary) 2 pairs (4 wires)

Analogue (SLTs) 1 pair (2 wires)

Exchange Paths Non Blocking

Intercom Paths 2

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

System Hardware

Cabinets

Note: This table shows the maximum values possible in the system, the actual values will depend upon the

configuration of the specific system and its components.

Maximum port configurations

Exchange line ports 2

Extension ports 6

Max number of Keyphones 6

Max number of SLTs 18 (3 per port)

Max number of Extensions 6

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

System Components

KX-T206E Central Control Unit

The central control unit is fully configured at 2 exchange lines and 6 extension ports. The following devices are

built in:

1. Doorphone interface

2. Door opener interface

3. Ring generator

4. DTMF receivers

5. All system control

KX-T20691E DISA/Fax detect Card

This optional card allows Direct Inward System Access with Greeting Message on both lines. It will also detect

incoming fax calls and route them to the fax extension.

KX-T30865E Doorphone Unit

Doorphone unit provides intercom to persons at the door.

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

Hand-set Options

1. Proprietary Keyphones (KX-T7050E, KX-T7020E and KX-T7130E)

3. Single Line Devices

The KX-T206E offers the choice of a wide range of key hand-set.

The features which are available to hand-set users will depend upon the type of hand-set being used.

Hand-set Features

Key features of the KX-T206E hand-sets are:

One-Touch keys The one-touch keys provide single key access to personal speed dials or system

features allowing them to be called up with a single key press.

Flexible keys Flexible keys are used as line use indicators. Unused Flexible keys can be

programmed with other system functions or used as extension calling and busy lamp

field keys.

Dual colour LEDs The Flexible keys each have a dual colour LED which is used when the key is

programmed as a line, extension, message waiting or call forward call key to show

the status.

Distinctive HOLD key The HOLD key’s orange colour and prominent position make it easy to locate and

operate.

Volume control To adjust ringing and speaker volumes independently..

LCD display The KX-T7130E has an alphanumeric display allowing the display of information and

messages which enhance its functionality.

Hand-set Types

The table below lists hand-set types and their key specifications.

Model Description Flexible

Keys One Touch

Keys Dual colour

LEDs Alphanumeric

Display Handsfree

KX-T7050E 12 key standard 12 4 4

KX-T7020E 12 key handsfree 12 4 4 4

KX-T7130E 12 key display 12 12 4 4 4

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

Answering Calls

Direct Inward System Access DISA

Description

Any number of exchange lines can be assigned as DISA lines. A line assigned as a DISA line automatically

answers an incoming call and presents the caller with a greeting message. The caller can then dial the

extension number they require and be connected to that extension without the need for assistance. Callers who

are unable to access their required extension (because they have a pulse dialling telephone) or dial an invalid

number will be connected to the first extension. If a call goes unanswered the system can be programmed to

ring all or any number of extensions on the system.

Benefits

Persons familiar with the facility can dial directly to the extension they require.

Flexible Ringing Assignment

Description

The ringing assignment is completely flexible so any line can be assigned to ring at any extension(s). The

ringing assignment can be different in day and night modes depending on user requirements

Benefits

Assures coverage for outside lines. Allows for customisation of the system in order to meet a wide variety of

applications.

Delayed Ringing

Description

The delayed ringing assignment is completely flexible so that any line can be assigned to ring at any

extension(s). Extensions can be set to ring after 1, 2, 3, or 4 rings delay. Other settings include visual indication

only or no indication of call arrival.

Benefits

Assures coverage for outside lines if unanswered at the first (immediate ringing) pattern of extensions. Allows

for customisation of the system in order to meet a wide variety of applications.

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

Call Pick Up

Description

Call pick up allows you to answer calls which are ringing at other extensions by activating a feature button or

dialling an access code.

Benefits

Provides improved call coverage by allowing you to answer ringing extensions without having to walk to them.

Doorphone Assignment

Description

Doorphone calls can be set to ring at any combination of extensions, the pattern may be different at night if

necessary. The extensions which may operate the door release can also be controlled to ensure security.

Benefits

Allows anyone to speak to callers at the door and to allow them in if desired.

Panasonic Digital Super Hybrid System

Product Description

ISSUE 1 E & O E

Flexible Function Keys

Description

The Flexible keys can be programmed to access a feature by pressing a single button. The features which can

be placed under a key are as follows:

1Exchange line key 7Call forward

2Direct line access 8Do not disturb

3Pooled line key 9Loud ring bell pick-up

4Extension selection key 10 Speed dial

5Paging access 11 Night transfer

6‘Meet me’ paging answer 12 Any feature accessible by dialling a code.......

Benefits

This provides the flexibility to customise a phone to the users needs. It makes easy, one step feature access

available as an alternative to feature access codes.
