Operating Instructions
Wireless Remote Controller
Model No. CZ-RWSU3U
CZ-RWST2U
CZ-RWSD2U
CZ-RWSC3
CZ-RWSK1U
Be sure to read the “Safety Precautions” before using. Keep them for future reference.
270573_EN.indb 1 2015-1-22 9:08:58
1(EN)
1
2
3
4
5
6
7
8
9
10
12
11
13
14
15
16
REMOTE CONTROLLER
Receiver
1543
2
CZ-RWSD2UCZ-RWSU3U
1543
2
CZ-RWST2U
Front side Rear side
CZ-RWSC3
1
2
5
4
3
1
2
3
4
5
6
ADDRESS 1
ADDRESS 2
ADDRESS 3
REM SUB/MAIN
1234
270573_EN.indb 2 2015-1-22 9:08:59
2
(EN)
Note:
zThis device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
zThis equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•Consult the distributor or an experienced radio/TV
technician for help.
zFCC Caution: To assure continued compliance, follow
the attached installation instructions. Any changes
ormodicationsnotexpresslyapprovedbytheparty
responsible for compliance could void the user’s authority
to operate this equipment.
Safety Precautions
270573_EN.indb 2 2015-1-22 9:09:00
3
(EN)
Safety Precautions
CAUTIONS
This appliance is intended to be used by expert or
trained users in shops, in light industry and on farms, or
for commercial use by lay persons.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
WARNING
Do not use this appliance in a potentially explosive
atmosphere.
•Do not operate with wet hands.
•Do not wash with water.
In case of malfunction of this appliance, do not repair
by yourself. Contact the sales or service distributor for
repair.
In case of emergency, remove the power plug
from the socket or switch off the circuit breaker
or the means by which the system is isolated
from the mains power.
WARNING CAUTION
This symbol refers to a hazard or unsafe
practice which can result in severe personal
injury or death.
This symbol refers to a hazard or unsafe
practice which can result in personal injury or
product or property damage.
Matters to be observed Prohibited matters
270573_EN.indb 3 2015-1-22 9:09:00
4
(EN)
Contents
1. Important Safety Instructions ................................................5
2. Names and Operations .........................................................6
3. Installing Batteries.................................................................8
4. Setting the Current Time.......................................................9
5. Operation ............................................................................10
6. Timer Operation ..................................................................12
7. Adjusting the Wind Direction...............................................14
8. Operating Multiple In/Outdoor Units Simultaneously ..........15
9. Using the Remote Controller...............................................16
10. For Best Results .................................................................16
11. Addresses ...........................................................................17
12. Emergency Operation .........................................................19
13. Miscellaneous Settings .......................................................20
14. Before Requesting Service .................................................21
15.Specications......................................................................22
270573_EN.indb 4 2015-1-22 9:09:00
1. Important Safety Instructions
5
(EN)
Before using the system, be sure to
read these “Important Safety
Instructions”.
After reading this manual, save it in a
convenient place.
WARNING
Installation Precautions
•Donotinstallthisequipment
yourself.
Installation should always be
performed by your distributor or a
professional service provider.
Electricshockorremayresultif
an inexperienced person performs
any installation or wiring
procedures incorrectly.
•Useonlyspeciedairconditioners.
Always use only air conditions
speciedbythedistributor.
Precautions for Use
•Donottouchswitcheswithwet
hands.
Electric shock and damage to the
system can result.
•Protecttheremotecontrollerfrom
water because it may cause
damage to the system.
•Stopthesystemandturnthe
power off if you notice unusual
smells or other irregularities.
Continuing operation when the
system is out of order can result in
electricshock,re,anddamageto
the system. Contact your
distributor.
•Donotswallowthebattery.
Moving and Repair
Precautions
•Donotrepair.
Never repair the system yourself.
•Contactyourdistributorbefore
moving the system.
Contact your distributor or a
professional service provider about
moving and reinstalling the system.
Electricshockorremayresultif
an inexperienced person performs
any installation procedures
incorrectly.
270573_EN.indb 5 2015-1-22 9:09:01
2. Names and Operations
6
(EN)
REMOTE CONTROLLER
One remote controller can control a group of
up to eight indoor units. (See page 15)
1. Operation Display
Displays the operation status.
(Thegureshowsallthepossible
segments that may appear on the
display.)
•Theauto-apdisplaymaybe
different depending on the
installed unit. (See page 14.)
2. Start/Stop button
Pressing this button once starts
and pressing again stops the
operation.
3. Fan speed button
4. Swing/Wind Direction button
5. Timer setting button
Use for operating with a timer.
6. RESET button
Use this button after changing the
batteries.
7. Cover
Press at the top center and then
slide down.
8. Transmitter
9. Remote control sensor
Detects the temperature at the
remote controller when detection
has been switched to the remote
controller by the SENSOR button.
10.Temperature setting buttons
raises the temperature
setting.
lowers the temperature
setting.
11.Filter button
CZ-RWSC3
Presstoturnoffthelterlampon
the receiver.
12.Mode Select button
Press to switch the operation
mode.
13.Ventilation button
Use this when connected to an
aftermarket fan. Pressing this
button starts and stops the fan.
When the air conditioner is started
or stopped, the fan starts or stops
at the same time. ( appears on
the display of the remote
controller when the fan is
operating.)
14.Address button
15.SENSOR button
Used this to activate the
temperature sensor on the remote
controller instead of the one on
the indoor unit.
The temperature sensor on the
indoor unit is selected at
shipment. At this time is shown
on the display.
16.Clock button
Use this to set the clock.
From this page, the names of
remote controller’s buttons will be
indicated with the above
illustrations.
E.g.: Start/Stop button
270573_EN.indb 6 2015-1-22 9:09:01
7
(EN)
1. Receiver
Receives the signal sent from the
remote controller.
2. Emergency operation button
Indicator lamps
When an error occurs, one of the lamps
ashes.Whenanindicatorlampis
ashing,referto“14.BeforeRequesting
Service”.
3. OPERATION lamp
Lights up when the unit is
operating.
4. TIMER lamp
Lights up when the timer is set.
5. STANDBY lamp
•ThelampintheHEATmode
lights up at the following times:
during the startup, during the
thermostat operation, and during
the defrosting.
•Thelampasheswhenanerror
occurs.
6. FILTER lamp
This lamp is for notifying you
whenthelterneedstobe
cleaned.
7. Address switch
See “11. Addresses”.
Note
• IfHEATPUMP(2WAY)typeisbeing
used, it will beep twice and the
operating lamp will light up on the
display; if the timer and standby lamps
blinkalternately,aconictbetweenthe
heating and cooling exists, so the unit
cannot operate in the desired mode.
(On models that do not have an Auto
function, even if Auto is selected, it
works in the same way.)
• Whenthelocaloperationisdisabled
by centralized control or similar cause,
and if the Start/Stop , Mode or
Temperature setting button
ispressed,theunitwillbeepvetimes
and the change will not be made.
2. Names and Operations (Cont.)
Receiver
270573_EN.indb 7 2015-1-22 9:09:02
3. Installing Batteries
8
(EN)
1. Remove the cover.
2. Insert two AAA alkaline batteries.
Put the batteries in with the polarity [+/–]
asshowninthegure.
3. Gently insert one end of an
unfolded paper clip (or a similar
object that can t) into the Reset
hole and press the RESET button
inside the hole, then put the cover
back on.
Notes
• Change the batteries when the display of the
remote controller gets weak, or if it will not work
unless close to the receiver.
(Alkaline batteries generally last about one year.)
• Whenchangingbatteries,alwaysusetwofreshbatteriesofthesamemake.
• Iftheremotecontrollerwillnotbeusedforalongperiodoftime,removethebatteries.
• Pleasedisposeofusedbatteriesproperly,followinganylocalregulations.
• After changing the batteries, follow the procedures on the next page to reset the
current time.
How to Remove Batteries
1. Remove the cover.
2. Press the battery toward the
negative end and lift it out by
its positive end. (See the
gure on the right.)
3. Remove the other battery in
the same way.
Note
• Disposeoftheusedbatteriesatthedesignatedlocationincompliancewiththe
applicable local ordinances.
WARNING
• Donotswallowthebattery.
•
After removing the battery from the remote controller, keep it out of the reach of children.
The battery can cause death by suffocation if swallowed.
• Wheninsertingthebatteries,makesurethepolarities(+and-)arecorrect.
Reset hole
Cover
270573_EN.indb 8 2015-1-22 9:09:02
4. Setting the Current Time
9
(EN)
After changing the batteries and pressing the RESET
button, be sure to reset the current time.
(When the RESET button is pressed, the current
time reverts to [ ].)
1. Press for two seconds or more.
Once the clock displays starts blinking, the clock
can be set.
2. Set the hour with / of the .
If you press and hold the button, the time changes
quickly.
3. Set the minutes with / of the .
If you press and hold the button, the time changes
quickly.
4. Pressing completes the time setting.
• Whileyouaresettingthecurrenttime,thetime
displayashesandthecolonlightsup.
• Ifthebuttonsarenotpressedforthreeminutes
while setting the current time, it is set to the
displayed time.
Note
• When the RESET button is pressed, the timer settings are canceled.
2 1, 4
3
270573_EN.indb 9 2015-1-22 9:09:02
Ce manuel convient aux modèles suivants
4
Table des matières
Autres manuels Panasonic Télécommande
Panasonic
Panasonic AK-HRP1015G Manuel utilisateur
Panasonic
Panasonic AK-HRP1015G Manuel utilisateur
Panasonic
Panasonic AWCB400N - REMOTE OPERATION PANEL Manuel utilisateur
Panasonic
Panasonic CZ - RD52CP-1 Manuel utilisateur
Panasonic
Panasonic FV-SCGPW1 Manuel utilisateur
Panasonic
Panasonic CZ-RL511D Manuel d'installation et d'exploitation
Panasonic
Panasonic CZ-RTC4A Manuel utilisateur
Panasonic
Panasonic EUR511501 Manuel utilisateur
Panasonic
Panasonic AK-HRP1015G Manuel utilisateur
Panasonic
Panasonic CZ-RWSU3 Manuel utilisateur
Panasonic
Panasonic CZ-RTC5 Manuel utilisateur
Panasonic
Panasonic Lumix DMW-RSL1 Manuel utilisateur
Panasonic
Panasonic EUR511511 guide Manuel utilisateur
Panasonic
Panasonic WV-RC550 Manuel utilisateur
Panasonic
Panasonic TX LXD6 Series Manuel utilisateur
Panasonic
Panasonic WVCU650 - SYSTEM CONTROLLER ADDENDUM Manuel utilisateur
Panasonic
Panasonic AK-HRP200G Manuel utilisateur
Panasonic
Panasonic EUR646494 Mode d'emploi
Panasonic
Panasonic WV-CB550 Manuel utilisateur
Panasonic
Panasonic FV-SWGR1 Manuel utilisateur
