For details of operating Remote Operation Panel AK-HRP1005G, please

visit the Panasonic website (https://pro-av.panasonic.net/manual/en/index.

html), and refer to the Operating Instruction (HTML or PDF).

Read this document when using the AK-HRP1005G Remote Operation Panel in

conjunction with AJ-PX5000G Memory Card Camera-Recorder.

Operating Guide

Remote Operation Panel

Model No. AK-HRP1005G

Connecting the Unit to AJ-PX5000G Cameras 3

Connections 3

Compatible Functions List 4

ROP Menu (during AJ-PX5000G Connection) 7

ROP menu list 7

01 PAINT SWITCH 12

02 SHUTTER SPEED 13

03 PEDESTAL 14

04 CHROMA 15

05 GAIN 16

06 WHITE BALANCE MODE 17

07 FLARE 18

08 GAMMA 19

09 BLACK GAMMA 21

10 KNEE 22

11 DRS 23

12 HD DETAIL 24

13 HD SKIN TONE DTL 25

14 MATRIX 26

15 COLOR CORRECTION 27

16 IRIS RELATIVE 29

17 HI-COLOR 30

18 CAMERA MENU CONTROL 31

19 ROP SETTING 32

20 CONNECT SETTING 32

21 ROP IP SETTING 32

22 CAMERA IP SETTING 32

- 2 -

Table of Contents

Connecting the Unit to AJ-PX5000G Cameras

Connections

Use a dedicated cable to connect the <REMOTE> connector at the rear of the AJ-PX5000G to the AK-HRP1005G’s <CCU> con-

nector.

Set the connection setting to “Serial(AJ)” in the [CONNECT SETTING] menu.

ヒチバチヒヘ

ヤヰワワユヤヵチヴユヵヵリワヨヴㄆㄓㄊ㄂ㄍドモルナワヰワワヰワワヰワワヰワワヰワヤモヮヒヤモヮピヤモヮプヤモヮフヤモヮブヤモヮビヤヰワワユヤヵチヮヰュユドㄑㄖㄔㄉナヤヰワワユヤヵチヮヰュユドㄑㄖㄔㄉナ

- 3 -

Connecting the Unit to AJ-PX5000G Cameras

Compatible Functions List

When the unit is used in conjunction with an AJ-PX5000G Memory Card Camera-Recorder, a portion of the unit’s button, dial, and other

control functions will be limited or disabled. Be sure to refer to the following table.

Front panel 1

Front panel 2

Front panel 3

Front panel 4

Front panel 5

Front panel 6

Number Part name

✓: Enabled

×: Disabled

Remarks

Front panel 1

[PANEL LOCK] button ✓

[AUTO] button ✓Only auto white balance and auto black balance will

function.

[BARS] button ✓Only the ON/OFF for the color bar signal output will

function.

[TALLY/CALL] lamp/button ×

[REF. RECALL] button ×

[FILES] button ×

[SETUP] button ✓

[AUTO IRIS] button ✓

Front panel 2

Function buttons ✓

LCD panel ✓

Menu operation dials ✓

- 4 -

Connecting the Unit to AJ-PX5000G Cameras

Number Part name

✓: Enabled

×: Disabled

Remarks

Front panel 3

[GAIN] button ✓When this is set to ON, the [GAIN] menu appears on

the LCD panel.

[SHT] button ✓When this is set to ON, the [SHUTTER SPEED]

menu appears on the LCD panel.

[COLOR] button ✓The menus will switch with each press of the button.

[CHROMA] > [MATRIX] > [COLOR CORRECTION] >

Menu off (status screen)

[FILTER] button ×

[GAMMA] button ✓The menus will switch with each press of the button.

[GAMMA] > [BLACK GAMMA] > Menu off (status

screen)

[FLARE] button ✓The menus will switch with each press of the button.

[FLARE] > Menu off (status screen)

[KNEE] button ✓The menus will switch with each press of the button.

[KNEE] > Menu off (status screen)

[DTL] button ✓The menus will switch with each press of the button.

[HD DETAIL] > [HD SKIN TONE DTL] > Menu off

(status screen)

Front panel 4

[GAIN], [TEMP], [GAMMA], [SKIN]

adjustment block

✓When [GAIN] is lit:

Adjust [R GAIN] with the red (R) adjustment dial.

Adjust [B GAIN] with the blue (B) adjustment dial.

When [TEMP] is lit:

Adjust [COLOR TMP PRE] with the red (R) adjust-

ment dial.

Adjust [AWB A TEMP] with the green (G) adjust-

ment dial.

Adjust [AWB B TEMP] with the blue (B) adjustment

dial.

When [GAMMA] is lit:

Adjust [GAMMA R] with the red (R) adjustment dial.

Adjust [GAMMA MASTER] with the green (G) adjust-

ment dial.

Adjust [GAMMA B] with the blue (B) adjustment dial.

When [SKIN] is lit:

Adjust [Q PHASE] with the red (R) adjustment dial.

Adjust [I CENTER] with the green (G) adjustment

dial.

Adjust [CRISP] with the blue (B) adjustment dial.

[PED], [FLARE], [B.GAM] adjustment

block

✓When [PED] is lit:

Adjust [PED R] with the red (R) adjustment dial.

Adjust [MASTER PED] with the green (G) adjust-

ment dial.

Adjust [PED B] with the blue (B) adjustment dial.

When [FLARE] is lit:

Adjust [FLARE R] with the red (R) adjustment dial.

Adjust [FLARE G] with the green (G) adjustment

dial.

Adjust [FLARE B] with the blue (B) adjustment dial.

When [B.GAM] is lit:

Adjust [BLACK GAMMA MASTER] with the green

(G) adjustment dial.

- 5 -

Connecting the Unit to AJ-PX5000G Cameras

Number Part name

✓: Enabled

×: Disabled

Remarks

Front panel 5

[ALM] indicator ×

[OPT] indicator ×

[EXT] indicator ×

[D.EXT] indicator ×

Adjustment value display ✓ND filter/CC filter adjustment values are only dis-

played.

[ND] indicator ✓Displayed but cannot be adjusted.

[CC] indicator ✓Displayed but cannot be adjusted.

[IRIS] indicator ✓

[GAIN] indicator ✓

[PED] indicator ✓

[SHT] indicator ✓

[SYNC] indicator ✓

[DISP] button ✓

[UP (FREE)] button ✓

[DOWN (CHARA)] button ✓

[LOCK] indicator ✓

[SEL] dial ✓

Front panel 6

Memory card slot ✓

Memory card access indicator ✓

Camera number/tally display ✓Only camera numbers are displayed.

[IRIS RELATIVE] button ✓

Torque adjustment screw ✓

IRIS lever ✓

Master pedestal dial ✓

[PREVIEW] button ×

- 6 -

Connecting the Unit to AJ-PX5000G Cameras

ROP Menu (during AJ-PX5000G Connection)

ROP menu list

When an AJ-PX5000G Memory Card Camera-Recorder is connected, the ROP menu will be as follows.

For details on menu operations, refer to the following sections in the Operating Instructions.

“Displaying menus”

“Basic menu operations”

01 PAINT SWITCH

FLARE “FLARE” (see page 12)

GAMMA “GAMMA” (see page 12)

WHITE CLIP “WHITE CLIP” (see page 12)

KNEE MANUAL “KNEE MANUAL” (see page 12)

MATRIX “MATRIX” (see page 12)

COLOR CORRE “COLOR CORRE” (see page 12)

HD DTL “HD DTL” (see page 12)

SKIN DTL “SKIN DTL” (see page 12)

HI COLOR “HI COLOR” (see page 12)

02 SHUTTER SPEED

SHUTTER SPEED “SHUTTER SPEED” (see page 13)

SHUTTER SYNCHRO “SHUTTER SYNCHRO” (see page 13)

SW “SW” (see page 13)

MODE “MODE” (see page 13)

SYNCHRO SCN DSP “SYNCHRO SCN DSP” (see page 13)

03 PEDESTAL

PED R “PED R” (see page 14)

PED G “PED G” (see page 14)

PED B “PED B” (see page 14)

04 CHROMA CHROMA LEVEL “CHROMA LEVEL” (see page 15)

05 GAIN

AWB A R “AWB A R” (see page 16)

AWB A B “AWB A B” (see page 16)

AWB B R “AWB B R” (see page 16)

AWB B B “AWB B B” (see page 16)

AWB PRE R “AWB PRE R” (see page 16)

AWB PRE B “AWB PRE B” (see page 16)

06 WHITE BALANCE MODE

COLOR TEMP PRE “COLOR TEMP PRE” (see page 17)

AWB A TEMP “AWB A TEMP” (see page 17)

AWB B TEMP “AWB B TEMP” (see page 17)

WB CH SEL “WB CH SEL” (see page 17)

07 FLARE

FLARE R “FLARE R” (see page 18)

FLARE G “FLARE G” (see page 18)

FLARE B “FLARE B” (see page 18)

FLARE “FLARE” (see page 18)

- 7 -

ROP Menu (during AJ-PX5000G Connection)

08 GAMMA

GAMMA R “GAMMA R” (see page 19)

GAMMA MASTER “GAMMA MASTER” (see page 19)

GAMMA B “GAMMA B” (see page 19)

GAMMA SEL “GAMMA SEL” (see page 19)

F-REC DYNMC(%) “F-REC DYNMC(%)” (see page 19)

F-REC BLK STR(%) “F-REC BLK STR(%)” (see page 19)

V-REC KNEE SLOPE(%) “V-REC KNEE SLOPE(%)” (see page 20)

V-REC KNEE POINT(%) “V-REC KNEE POINT(%)” (see page 20)

GAMMA “GAMMA” (see page 20)

ABB (push) “ABB (push)” (see page 20)

09 BLACK GAMMA

BLACK GAMMA CURVE “BLACK GAMMA CURVE” (see page 21)

BLACK GAMMA RANGE “BLACK GAMMA RANGE” (see page 21)

10 KNEE

MASTER POINT % “MASTER POINT %” (see page 22)

MASTER SLOPE “MASTER SLOPE” (see page 22)

WHITE CLIP SW “WHITE CLIP SW” (see page 22)

WHITE CLIP LEVEL “WHITE CLIP LEVEL” (see page 22)

AUTO KNEE POINT % “AUTO KNEE POINT %” (see page 22)

AUTO KNEE LEVEL “AUTO KNEE LEVEL” (see page 22)

AUTO KNEE RSPNS “AUTO KNEE RSPNS” (see page 22)

KNEE MANUAL “KNEE MANUAL” (see page 22)

11 DRS

MODE “MODE” (see page 23)

EFFECT DEPTH “EFFECT DEPTH” (see page 23)

12 HD DETAIL

MASTER DETAIL “MASTER DETAIL” (see page 24)

DETAIL LV H “DETAIL LV H” (see page 24)

DETAIL LV V “DETAIL LV V” (see page 24)

FREQ “FREQ” (see page 24)

LEVEL DEPENDENT “LEVEL DEPENDENT” (see page 24)

CORING “CORING” (see page 24)

DETAIL SOURCE “DETAIL SOURCE” (see page 24)

CLIP “CLIP” (see page 24)

GAIN (+) “GAIN (+)” (see page 24)

GAIN (-) “GAIN (-)” (see page 24)

KNEE APE LV “KNEE APE LV” (see page 24)

HD DTL “HD DTL” (see page 24)

13 HD SKIN TONE DTL

SKIN DTL “SKIN DTL” (see page 25)

EFFECT “EFFECT” (see page 25)

DETECT TBL “DETECT TBL” (see page 25)

SKIN GET “SKIN GET” (see page 25)

ZEBRA MONI “ZEBRA MONI” (see page 25)

I CENTER “I CENTER” (see page 25)

I WIDTH “I WIDTH” (see page 25)

Q PHASE “Q PHASE” (see page 25)

Q WIDTH “Q WIDTH” (see page 25)

SKIN DTL SW “SKIN DTL SW” (see page 25)

- 8 -

ROP Menu (during AJ-PX5000G Connection)

14 MATRIX

TABLE “TABLE” (see page 26)

R-G “R-G” (see page 26)

R-B “R-B” (see page 26)

G-R “G-R” (see page 26)

G-B “G-B” (see page 26)

B-R “B-R” (see page 26)

B-G “B-G” (see page 26)

MATRIX “MATRIX” (see page 26)

15 COLOR CORRECTION

SAT R “SAT R” (see page 28)

SAT R-MG “SAT R-MG” (see page 28)

SAT MG “SAT MG” (see page 28)

SAT MG-B “SAT MG-B” (see page 28)

SAT B “SAT B” (see page 28)

SAT B-CY “SAT B-CY” (see page 28)

SAT CY “SAT CY” (see page 28)

SAT CY-G “SAT CY-G” (see page 28)

SAT G “SAT G” (see page 28)

SAT G-YI “SAT G-YI” (see page 28)

SAT YI “SAT YI” (see page 28)

SAT YI-R “SAT YI-R” (see page 28)

PHASE R “PHASE R” (see page 28)

PHASE R-MG “PHASE R-MG” (see page 28)

PHASE MG “PHASE MG” (see page 28)

PHASE MG-B “PHASE MG-B” (see page 28)

PHASE B “PHASE B” (see page 28)

PHASE B-CY “PHASE B-CY” (see page 28)

PHASE CY “PHASE CY” (see page 28)

PHASE CY-G “PHASE CY-G” (see page 28)

PHASE G “PHASE G” (see page 28)

PHASE G-YI “PHASE G-YI” (see page 28)

PHASE YI “PHASE YI” (see page 28)

PHASE YI-R “PHASE YI-R” (see page 28)

COLOR CORRE “COLOR CORRE” (see page 28)

16 IRIS RELATIVE

SENSE Refer to the following section in the Operating Instructions.

“29 IRIS RELATIVE”

COARSE

RELATIVE

17 HI-COLOR

HI-COLOR SW “HI-COLOR SW” (see page 30)

HI-COLOR LEVEL “HI-COLOR LEVEL” (see page 30)

18 CAMERA MENU CONTROL

MENU ON/OFF “MENU ON/OFF” (see page 31)

CURSOR/PARAMETER “CURSOR/PARAMETER” (see page 31)

EXECUTE “EXECUTE” (see page 31)

- 9 -

ROP Menu (during AJ-PX5000G Connection)

19 ROP SETTING

IRIS LEV MODE Refer to the following section in the Operating Instructions.

“37 ROP SETTING”

M.PED CONT

LOCK SELECT

AUTO BUTTON

G/M PED VOL

FREE+LOCK

CAM SEL

DTL BUTTON

SKIN VOL

LCD BRIGHT

PANEL BRIGHT

B.GAMMA VOL

BUZZER

PERIOD

CYCLE

STD POSITION M.GAIN

STD POSITION VAR

STD POSITION ND

STD POSITION CC

IRIS PRIORITY

ROP DATA SAVE

ROP DATA LOAD

SD CARD FORMAT

INITIAL with NW

INITIAL

UPGRADE

IRIS CALIBRATION TOP

IRIS CALIBRATION BOTTOM

SYSTEM VERSION

SOFT VERSION

FPGA VERSION

20 CONNECT SETTING

CONNECT MODE CAM1(push) Refer to the following section in the Operating Instructions.

“38 CONNECT SETTING”

CONNECT MODE CAM2 to CAM99

(push)

21 ROP IP SETTING

IP ADDRESS 1 Refer to the following section in the Operating Instructions.

“39 ROP IP SETTING”

IP ADDRESS 2

IP ADDRESS 3

IP ADDRESS 4

IP ADDRESS PORT

IP ADDRESS UPLOAD

SUBNET MASK 1

SUBNET MASK 2

SUBNET MASK 3

SUBNET MASK 4

SUBNET MASK UPLOAD

DEFAULT GATEWAY

DEFAULT GATEWAY UPLOAD

MAC ADDRESS

- 10 -

ROP Menu (during AJ-PX5000G Connection)

Autres manuels pour AK-HRP1005G

Table des matières

Autres manuels Panasonic Télécommande

Panasonic

Panasonic AW-RP50 Manuel utilisateur

Panasonic

Panasonic CZ-RTC6W Manuel utilisateur

Panasonic

Panasonic CZ-RTC2 Manuel utilisateur

Panasonic

Panasonic AW-RP150G Manuel utilisateur

Panasonic

Panasonic WV-RC35 Manuel utilisateur

Panasonic

Panasonic PVCC50 - COLOR CORRECTOR Manuel utilisateur

Panasonic

Panasonic CZ-RTC2 Manuel utilisateur

Panasonic

Panasonic AW-RP120G Manuel utilisateur

Panasonic

Panasonic CZ-RTC6BL Manuel utilisateur

Panasonic

Panasonic EUR511151C Manuel utilisateur

Panasonic

Panasonic CZ-RTC6BLW Manuel utilisateur

Panasonic

Panasonic AKHRP931P - RMT PANEL - AKHC930 Manuel utilisateur

Panasonic

Panasonic EUR511171B Manuel utilisateur

Panasonic

Panasonic OneRemote RMB4 Manuel utilisateur

Panasonic

Panasonic AK-HRP1015G Manuel utilisateur

Panasonic

Panasonic CZ-RTC6WBL Manuel utilisateur

Panasonic

Panasonic TY-RM50VW Manuel utilisateur

Panasonic

Panasonic WVCU650 - SYSTEM CONTROLLER ADDENDUM Manuel utilisateur

Panasonic

Panasonic EUR7722KM0 Manuel utilisateur

Panasonic

Panasonic CZ-RD52CU Manuel utilisateur

Panasonic

Panasonic WH-0M1201A Manuel utilisateur

Panasonic

Panasonic CZ-RTC4 Manuel utilisateur

Panasonic

Panasonic aw-rm50g Manuel utilisateur

Panasonic

Panasonic EUR7603Z50 Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation

Invacare

Invacare G91S Manuel utilisateur
