Panasonic PT-DW17KU Manuel utilisateur

SPEC FILE

Product Number : PT-DW17K

Product Name : 3-Chip DLP ™Projector

As of Se tember 2012. S ecifications and a earance are subject to change without notice.

SFD12M007-1

1/16

The PT-DW17K is not equi ed with a lens.

SPEC FI L E

PT-DW17K

3-Chip DLP™Projector

As of September 2012

SFD12M007-1

2/16

Specifications

ain unit

Power supply

Power consumption

DLP™ chip Panel size

Display method

Pixels

Lens

Lamp

Screen size

Brightness*2

Center-to-corner uniformity*2

Contrast*2

Resolution

Scanning frequency HDM /DV -D

RGB

YPBPR(YCBCR)

Video/S-Video

Optical axis shift Vertical

Horizontal

Keystone correction range

nstallation

200–240 V AC, 12 A, 50/60 Hz (3-wire single-phase)

2,300 W (2,350 VA) (0.3 W with STANDBY MODE set to ECO.* 19Wwith

STANDBY MODE set to NORMAL.),

max. 7,848 BTU (without light output: 7,585 BTU )

21.6 mm (0.85 inches) diagonal (16:10 aspect ratio)

DLP™ chip × 3 (R, G, B), DLP™ projection system

1,049,088 (1,366 × 768) × 3, total of 3,147,264 pixels

Optional powered zoom/focus lenses

465 W UHM lamps (× 4) (four lamp system)

1.78–15.24 m (70–600 inches) (1.78–7.62 m (70 – 300 inches) with the

ET-D75LE50), 16:9 aspect ratio

17,000 lumens (four lamp)

90%

10,000:1 (full on/full off, in dynamic iris 3 mode)

1,366 × 768 pixels ( nput signals that exceed this resolution will be

converted to 1,366 × 768 pixels.)

480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p,

1080/24sF, 1080/25p, 1080/30p, 1080/60p, 1080/50p,

VGA (640 × 480) – WUXGA (1,920 × 1,200), compatible with

non-interlaced signals only, dot clock: 25 –162 MHz

Horizontal: 15–100 kHz, vertical: 24 – 120 Hz,

dot clock: 162 MHz or less

480i (525i): fH15.75 kHz; fV60 Hz,

576i (625i): fH15.63 kHz; fV50 Hz,

480p (525p): fH31.50 kHz; fV60 Hz,

576p (625p): fH31.25 kHz; fV50 Hz,

720 (750)/60p: fH45.00 kHz; fV60 Hz,

720 (750)/50p: fH37.50 kHz; fV50 Hz,

1035/60i: fH33.75 kHz; fV60 Hz,

1080 (1125)/60i: fH33.75 kHz; fV60 Hz,

1080 (1125)/50i: fH28.13 kHz; fV50 Hz,

1080/25p: fH28.13 kHz; fV25 Hz,

1080/24p: fH27.00 kHz; fV24 Hz,

1080/24sF: fH27.00 kHz; fV48 Hz,

1080/30p: fH33.75 kHz; fV30 Hz,

1080/60p: fH67.50 kHz; fV60 Hz,

1080/50p: fH56.25 kHz; fV50 Hz

fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60]

fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]

±70% (±60% with the ET-D75LE6) from center of screen, powered

±30% (±20% with the ET-D75LE6) from center of screen, powered

NOTE: Optical axis shift function cannot be operated when used with the

ET-D75LE50.

Vertical ±40° (±22° with the ET-D75LE50, ±28° with the ET-D75LE6)

Ceiling/floor, front/rear

SPEC FI L E

PT-DW17K

3-Chip DLP™Projector

As of September 2012

SFD12M007-1

3/16

Terminals HDM N

DV -D N

RGB 1 N

R, G, B

Y, PB, PR(Y, CB, CR)

S-Video signal

RGB 2 N

R, G, B

Y, PB, PR(Y, CB, CR)

V DEO N

SER AL N

SER AL OUT

REMOTE 1 N

REMOTE 1 OUT

REMOTE 2 N

LAN

Power cord length

Cabinet materials

Dimensions (W × H × D):

Weight*7

Operation noise*2

Operating temperature

Operating humidity

HDM 19-pin × 1, Deep Color, compatible with HDCP,

480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p,

1080/24sF, 1080/25p, 1080/30p, 1080/60p, 1080/50p

VGA (640 × 480) – WUXGA*4(1,920 × 1,200),

dot clock: 25 MHz–162 MHz

NOTE: Compatible with non-interlaced signals only.

DV -D 24-pin × 1, DV 1.0 compliant, HDCP compatible,

for single link only

480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p,

1080/24sF, 1080/25p, 1080/30p, 1080/60p, 1080/50p,

VGA (640 × 480) – WUXGA*4(1,920 × 1,200),

dot clock: 25 MHz–162 MHz

NOTE: Compatible with non-interlaced signals only.

BNC ×5

R: 0.7 Vp-p, 75 ohms,

G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,

B: 0.7 Vp-p, 75 ohms

HD, VD/SYNC: TTL, high impedance, positive/negative automatic

NOTE: SYNC/HD and VD terminals do not accept tri-level sync signals.

Y: 1.0 Vp-p (including sync signal), PB/PR(CB/CR): 0.7 Vp-p, 75 ohms

Y: 1.0 Vp-p, C: 0.286 Vp-p, 75 ohms

D-sub HD 15-pin (female) ×1

R: 0.7 Vp-p, 75 ohms,

G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,

B: 0.7 Vp-p, 75 ohms

HD, VD/SYNC: TTL, high impedance, positive/negative automatic

NOTE: SYNC/HD and VD terminals do not accept tri-level sync signals.

Y: 1.0 Vp-p (including sync signal), PB/PR(CB/CR): 0.7 Vp-p, 75 ohms

BNC × 1, 1.0 Vp-p, 75 ohms

D-sub 9-pin (female) × 1 for external control (RS-232C compliant)

D-sub 9-pin (male) × 1 for link control

M3 jack × 1 for wired remote control

M3 jack × 1 for link control

D-sub 9-pin × 1 for external control (parallel)

RJ-45 × 1 for network connection, 100Base-TX/10Base-T, compliant

with PJLink™ (class 1)

3.0 m (9 ft 10 in)

Molded plastic

620 × 291*5× 800*6mm

(24-7/16 × 11-15/32*5× 31-1/2*6inches) (without lens)

Approx. 43 kg (94.8 lbs) (without lens)

49 dB (quad lamp operation)

0°– 45°C (32°–113°F)*8

10%–80% (no condensation)

SPEC FI L E

PT-DW17K

3-Chip DLP™Projector

As of September 2012

SFD12M007-1

4/16

Remote control unit

Power supply

Operation range*9

Dimensions (W × H × D)

Weight

Supplied accessories

Optional accessories

Zoom lens (1.0 – 1.2:1)

Zoom lens (1.4 – 1.9:1)

Zoom lens (1.8–2.7:1)

Zoom lens (2.7–5.2:1)

Zoom lens (5.1– 8.2:1)

Zoom lens (8.2 – 15.4:1)

Fixed-focus lens (0.8:1)

Lens motor cover

Ceiling mount bracket

Frame

Smoke cut filter

Upgrade kit

Replacement lamp unit

Replacement lamp unit for portrait mode

Replacement filter unit

3 V DC (AA type battery × 2)

Approx. 30 m (98 ft 5 in) when operated from directly in front of the

signal receptor

51 × 176 × 28 mm (2 × 6-15/16 × 1-3/32 inches)

Approx. 134 g (4.7 oz) (including batteries)

Power cord with security lock (× 1)

Wireless/wired remote control unit (× 1)

Batteries for remote control (AA type × 2)

Software CD-ROM (Logo Transfer Software, Multi Projector Monitoring

& Control Software) (× 1)

ET-D75LE6

ET-D75LE10

ET-D75LE20

ET-D75LE30

ET-D75LE40

ET-D75LE8

ET-D75LE50

ET-D75MC1

ET-PKD510H (for high ceilings)

ET-PKD510S (for low ceilings)

ET-PFD510

ET-SFR510

ET-UK20

ET-LAD510 (one bulb)

ET-LAD510F (a set of four bulbs)

ET-LAD510P (one bulb)

ET-LAD510PF (a set of four bulbs)

ET-EMF510

Weights and dimensions shown are approximate. Specifications and appearance are subject to change without notice.

*1 When the standby mode is set to eco, network functions such as power on over the LAN network will not operate, and the serial output termi-

nal cannot be used. Also, only certain commands can be received for external control using the serial terminal.

*2 easurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.

*3 Up to a total of ±55° during simultaneous horizontal and vertical correction.

*4 WUXGA resolution is supported only when the signals are compliant with VESA CVT-RB (Coordinated Video Timing-Reduced Blanking).

*5 With legs at shortest position.

*6 Excluding the optional lens.

*7 Average value (excluding the optional lens). ay differ depending on models.

*8 The operating temperature range is 0 °C to 40 °C (32 °F to 104 °F) when the FAN CONTROL is set to HIGH ALTITUDE ODE (for altitudes from 1,400 m

to 2,700 m (4,593 ft to 8,858 ft) above sea level). When the projector is used with the ET-SFR510 Smoke Cut Filter, the operating temperature

range is 0 °C to 35 °C (32 °F to 95 °F), and the projector cannot be used in places at high altitude. The operating temperature range is 0 °C to

40 °C (32 °F to 104 °F) when the ET-LAD510P/LAD510PF lamp is mounted and the projector is used in portrait configuration. The operating tem-

perature range is 0 °C to 35 °C (32 °F to 95 °F) when the FAN CONTROL is set to HIGH ALTITUDE ODE (for altitudes from 1,400 m to 2,700 m (4,593 ft

to 8,858 ft) above sea level). When the projector is used with the ET-SFR510 Smoke Cut Filter, the operating temperature range is 0 °C to 30 °C

(32 °F to 86 °F).

*9 Operation range differs depending on environments.

73 0 ( 28 - 3 /4 )

8 00 ( 31-1/ 2 )

( 2- 3 /4 )

620 (24-13/32)

244

( 9 -19 / 32 ) 608

(23-15/16 )

(1-27/32)

244

( 9 -19 / 32 )

177

( 6 -31/ 3 2)

291 (11-15/ 32)

(1-13 / 32)

Dimensions

SPEC FILE

PT-DW17K

3-Chip DLP™Projector

As of September 2012

SFD12M007-1

5/16

Terminals

6 7 8 9 10 11

23 4 5

1 Remote 1 input

2 Remote 1 output

3 Remote 2 input

4 Serial input

5 Serial output

6 HDM input

7 RGB 1 input

8 RGB 2 nput

9 DV -D input

10 Video input

11 LAN connector

unit : mm (inch)

NOTE: This illustration is not drawn to scale.

SPEC FI L E

PT-DW17K

3-Chip DLP™Projector

As of September 2012

SFD12M007-1

6/16

Standard setting-up position

Upper edge of projected image

432

(18)

∅60.5

(2-3/8)

298

(11-23/32)

Lower edge of projected image

Projected image

419– 539

(16-1/2–

21-7/32)

560– 680

(22-1/16–

26-25/32)

157

(6-3/16)

314

(12-3/8)

157

(6-3/16)

87.5

(3-7/16)

175

(6-7/8)

87.5

(3-7/16)

Projected image

unit : mm (inch)

*1 When the lens protrudes to the

maximum.

212 mm (8-11/32) with the ET-D75LE6

125 mm (4-29/32) with the ET-D75LE10

121 mm (4-3/4) with the ET-D75LE20

121 mm (4-3/4) with the ET-D75LE30

124 mm (4-7/8) with the ET-D75LE40

254 mm (10) with the ET-D75LE8

203 mm (8) with the ET-D75LE50

*2 Adjustable in 40 mm (1-9/16) steps.

Caution:

• All construction work should be done by a qualified technician.

• When mounting to the ceiling, use the special mounting bracket. To prevent the projector from swaying or drop-

ping, attach the wire that is included with the projector between the mounting bracket and the ceiling.

NOTE:

Illustrations show the projector installed

using optional ceiling mount bracket

ET-PKD510H and an optional lens.

This illustration is not drawn to scale.

SPEC FI L E

PT-DW17K

3-Chip DLP™Projector

As of September 2012

SFD12M007-1

7/16

[m] / [in]

1.78

2.03

2.29

2.54

3.05

3.81

5.08

6.35

7.62

10.16

12.70

15.24

100

120

150

200

250

300

400

500

600

Screen size

(diagonal) Zoom

Zoom lenses

Fixed-focus

Fixed-

focus

lens

Distance to screen (L) Height from the edge of screen

to center of lens (H)

ET-D75LE10

Zoom lens

min. max. min. max. min. max. min. max. min. max. min. max.

ET-D75LE6

Zoom lens

ET-D75LE20

Zoom lens

ET-D75LE30

Zoom lens

ET-D75LE40

Zoom lens

ET-D75LE8

Zoom lens

ET-D75LE50

Fixed-focus

lens

Except

ET-D75LE6

–

-0.09

-0.10

-0.11

-0.13

-0.15

-0.19

-0.25

-0.31

-0.37

-0.50

-0.62

-0.75

0.96

1.10

1.23

1.37

1.64

2.06

2.74

3.42

4.11

5.48

6.85

8.22

–

-0.17

-0.20

-0.22

-0.25

-0.30

-0.37

-0.50

-0.62

-0.75

-1.00

-1.25

-1.49

1.05

1.20

1.35

1.49

1.79

2.24

2.99

3.74

4.48

5.98

7.47

8.97

1.16

1.34

1.51

1.69

2.04

2.57

3.45

4.33

5.21

–

0.44

0.50

0.56

0.62

0.75

0.93

1.25

1.56

1.87

–

1.87

2.14

2.42

2.70

3.25

4.08

5.47

6.85

8.24

11.01

13.78

16.55

2.82

3.24

3.66

4.08

4.92

6.18

8.27

10.36

12.46

16.65

20.84

25.02

4.10

4.70

5.31

5.91

7.11

8.92

11.93

14.95

17.96

23.98

30.01

36.03

7.94

9.10

10.26

11.42

13.75

17.23

23.03

28.83

34.63

46.23

57.83

69.43

12.62

14.45

16.27

18.10

21.75

27.23

36.36

45.49

54.62

72.88

91.14

109.40

23.65

27.08

30.51

33.94

40.80

51.10

68.25

85.40

102.55

136.85

171.16

205.46

1.56

1.79

2.02

2.25

2.72

3.41

4.56

5.72

6.87

9.18

11.49

13.80

2.18

2.51

2.83

3.16

3.80

4.78

6.40

8.02

9.64

12.88

16.12

19.36

2.82

3.23

3.65

4.06

4.89

6.14

8.21

10.28

12.36

16.50

20.65

24.80

4.07

4.67

5.27

5.87

7.07

8.86

11.85

14.84

17.83

23.81

29.80

35.78

7.86

9.01

10.15

11.30

13.59

17.02

22.75

28.48

34.20

45.66

57.11

68.56

12.43

14.26

16.09

17.92

21.59

27.08

36.23

45.39

54.54

72.85

91.16

109.47

[m] / [in]

1.78

2.03

2.29

2.54

3.05

3.81

5.08

6.35

7.62

10.16

12.70

15.24

100

120

150

200

250

300

400

500

600

Screen size

(diagonal) Zoom

Zoom lenses

Fixed-focus

Fixed-

focus

lens

Distance to screen (L) Height from the edge of screen

to center of lens (H)

ET-D75LE10

Zoom lens

min. max. min. max. min. max. min. max. min. max. min. max.

ET-D75LE6

Zoom lens

ET-D75LE20

Zoom lens

ET-D75LE30

Zoom lens

ET-D75LE40

Zoom lens

ET-D75LE8

Zoom lens

ET-D75LE50

Fixed-focus

lens

Except

ET-D75LE6

–

-0.3

-0.4

-0.5

-0.6

-0.8

-1.0

-1.2

-1.6

-2.0

-2.5

3.1

3.6

4.0

4.5

5.4

6.7

9.0

11.2

13.5

18.0

22.5

27.0

–

-0.6

-0.7

-0.8

-1.0

-1.2

-1.6

-2.0

-2.5

-3.3

-4.1

-4.9

3.4

3.9

4.4

4.9

5.9

7.4

9.8

12.3

14.7

19.6

24.5

29.4

3.8

4.4

5.0

5.5

6.7

8.4

11.3

14.2

17.1

–

1.4

1.6

1.8

2.0

2.5

3.1

4.1

5.1

6.1

–

6.1

7.0

7.9

8.8

10.7

13.4

17.9

22.5

27.0

36.1

45.2

54.3

9.3

10.6

12.0

13.4

16.1

20.3

27.1

34.0

40.9

54.6

68.4

82.1

13.5

15.4

17.4

19.4

23.3

29.3

39.2

49.0

58.9

78.7

98.5

118.2

26.1

29.9

33.7

37.5

45.1

56.5

75.5

94.6

113.6

151.7

189.7

227.8

41.4

47.4

53.4

59.4

71.4

89.3

119.3

149.2

179.2

239.1

299.0

358.9

77.6

88.9

100.1

111.4

133.9

167.6

223.9

280.2

336.4

449.0

561.5

674.1

5.1

5.9

6.6

7.4

8.9

11.2

15.0

18.8

22.5

30.1

37.7

45.3

7.2

8.2

9.3

10.4

12.5

15.7

21.0

26.3

31.6

42.2

52.9

63.5

9.2

10.6

12.0

13.3

16.0

20.1

26.9

33.7

40.5

54.1

67.7

81.3

13.4

15.3

17.3

19.3

23.2

29.1

38.9

48.7

58.5

78.1

97.8

117.4

25.8

29.5

33.3

37.1

44.6

55.8

74.6

93.4

112.2

149.8

187.4

224.9

40.8

46.8

52.8

58.8

70.8

88.8

118.9

148.9

178.9

239.0

299.1

359.1

Projection distance for 16:9 aspect ratio screen

(ET-D75LE6/D75LE10/D75LE20/D75LE30/D75LE40/D75LE8/D75LE50)

Unit: feet

Unit: meters

• The value for L (distance to screen) varies slightly within ±5% depending on the zoom lens characteristics.

• At the shortest projection distance, the zoom lens characteristics may cause slight image distortion.

• When vertical keystone correction is used, the image is corrected in the direction that reduces its projected size.

NOTE: When the ET-D75LE50 is mounted, the optical lens shift function cannot be used.

SPEC FI L E

PT-DW17K

3-Chip DLP™Projector

As of September 2012

SFD12M007-1

8/16

Calculation of the projection distance

For a screen size different from the above, use the equation below to calculate the projection distance.

Aspect ratio 16:9

minimum L (m) = (diagonal screen size in inches) × 0.0231 – 0.0566

maximum L (m) = (diagonal screen size in inches) × 0.0277 – 0.0736

minimum L (m) = (diagonal screen size in inches) × 0.0324 – 0.0857

maximum L (m) = (diagonal screen size in inches) × 0.0419 – 0.1085

minimum L (m) = (diagonal screen size in inches) × 0.0415 – 0.0832

maximum L (m) = (diagonal screen size in inches) × 0.0602 – 0.1162

minimum L (m) = (diagonal screen size in inches) × 0.0598 – 0.1131

maximum L (m) = (diagonal screen size in inches) × 0.1160 – 0.1765

minimum L (m) = (diagonal screen size in inches) × 0.1145 – 0.1577

maximum L (m) = (diagonal screen size in inches) × 0.1826 – 0.1615

minimum L (m) = (diagonal screen size in inches) × 0.1831 – 0.3862

maximum L (m) = (diagonal screen size in inches) × 0.3430 – 0.3598

L (m) = (diagonal screen size in inches) × 0.0176 – 0.0713

Zoom lenses

ET-D75LE6

ET-D75LE10

ET-D75LE20

ET-D75LE30

ET-D75LE40

ET-D75LE8

Fixed-focus lens

ET-D75LE50

• Distances calculated with the above equations will include slight deviations.

SPEC FI L E

PT-DW17K

3-Chip DLP™Projector

As of September 2012

SFD12M007-1

9/16

(Width of

projected image)

(Height of

projected image)

0.2V

0.7V

0.2V

0.3H0.3H

Standard postition of projected image

Shift range

Optical axis shift fu ctio allows to shift the positio of a projected image as show below.

• When the lens except the ET-D75LE6 is mounte

(Width of

projected image)

(Height of

projected image)

0.2V

0.6V

0.2V

0.2H0.2H

Standard postition of projected image

• When the ET-D75LE6 is mounte

• Because the ET-D75LE50 is a fixe short-throw lens, the lens shift function cannot be use with it.

360°

-15°

+15°

Installable angle

I stall the projector at a a gle withi the ra ge show below.

• Vertical irection

The projector may be i stalled at a vertical

a gle of 360°.

• Horizontal irection

The projector may be i stalled at a horizo tal

a gle of ±15°.

+15°

-15°

+15°

• Vertical irection in portrait mo e with the

ET-LAD510P/LAD510PF mounte

The projector may be i stalled at a vertical

a gle of ±15°.

• Horizontal irection in portrait mo e with

the ET-LAD510P/LAD510PF mounte

The projector may be i stalled at a horizo tal

a gle of ±15°.

NOTE: The projector cannot be vertically installe all by itself. Also, the terminal si e must face ownwar when vertically installe .

SPEC FI L E

PT-DW17K

3-Chip DLP™Projector

As of September 2012

SFD12M007-1

10/16

List of compatible signals

The signals that can be input to this projector are shown in the table below. Horizontal scanning fre-

quencies of 15 kHz to 100 kHz, vertical scanning frequencies of 24 Hz to 120 Hz, and a dot clock of

162 MHz maximum can be input.

NOTE: The native resolution of this projector is 1,366 × 768 pixels. If the display resolution of the input signal is different from the

native resolution, image compression or expansion will be used to convert the input signal to a level within the native resolution.

Display mode Display

resolution

(dots)*1

Scanning frequency

(kHz)

Dot clock

frequency

(MHz)

Format

720 × 480i

720 × 576i

720 × 480i

720 × 576i

720 × 483

720 × 576

1280 × 720

1920 × 1080i

1920 × 1080

1920 × 1080i

1920 × 1080

640 × 400

640 × 480

800 × 600

832 × 624

1024 × 768

1152 × 864

1152 × 870

15.7

15.6

15.7

15.6

31.5

31.3

45.0

37.5

33.8

28.1

27.0

28.1

33.8

67.5

56.3

31.5

37.9

31.5

35.0

37.9

37.5

43.3

35.2

37.9

48.1

46.9

53.7

49.7

39.6

48.4

56.5

60.0

65.5

68.7

81.4

98.8

53.7

64.0

67.5

76.7

68.7

59.9

50.0

59.9

50.0

59.9

50.0

60.0

50.0

60.0

50.0

24.0

25.0

30.0

60.0

50.0

70.1

85.1

59.9

66.7

72.8

75.0

85.0

56.3

60.3

72.2

75.0

85.1

74.6

50.0

60.0

70.1

75.0

81.6

85.0

100.0

120.0

60.0

71.2

74.9

85.0

75.1

−

13.5

27.0

74.3

148.5

25.2

31.5

25.2

30.2

31.5

36.0

40.0

50.0

49.5

56.3

57.3

51.9

65.0

75.0

78.8

86.0

94.5

113.3

139.1

81.6

94.2

108.0

121.5

100.0

NTSC/NTSC4.43/PAL-M/PAL60

PAL/PAL-N/SECAM

480i (525i)

576i (625i)

480p (525p)

576p (625p)

720/60p

720/50p

1080/60i

1080/50i

1080/24p

1080/24sF

1080/25p

1080/30p

1080/60p

1080/50p

VGA400

VGA480

SVGA

MAC16

XGA

MXGA

MAC21

VIDEO/S-VIDEO

SDI/RGB/YCBCR

HDMI/DVI-D/

RGB/YCBCR

SDI/HDMI/DVI-D/

RGB/YPBPR

SDI*2/HDMI/DVI-D/

RGB/YPBPR

HDMI/DVI-D/RGB

*1 The “i” appearing after the resolution indicates an interlaced signal.

*2 For dual-link connection only.

Ce manuel convient aux modèles suivants

Autres manuels Panasonic Projecteur

Panasonic

Panasonic PT-LB10NTU - Mobile Proj XGA 2000 Lumens 4.9LBS Cross Platform... Manuel utilisateur

Panasonic

Panasonic PT-EX620 Manuel utilisateur

Panasonic

Panasonic PTLC76U - LCD PROJECTOR Manuel utilisateur

Panasonic

Panasonic PT-F100NT Manuel du système

Panasonic

Panasonic PT-DW105XEA Mode d'emploi

Panasonic

Panasonic PT-F300 Series Manuel utilisateur

Panasonic

Panasonic PT-TW330 Manuel utilisateur

Panasonic

Panasonic PT-DW530U Manuel utilisateur

Panasonic

Panasonic PT-RZ475EA Manuel utilisateur

Panasonic

Panasonic PT-LB3EA Manuel utilisateur

Panasonic

Panasonic PT51G63 - 51" PROJECTION TV Manuel utilisateur

Panasonic

Panasonic PT-D4000 Manuel du système

Panasonic

Panasonic PT-REZ12 Manuel utilisateur

Panasonic

Panasonic PT-F200NT Manuel utilisateur

Panasonic

Panasonic PT-D6000K Manuel utilisateur

Panasonic

Panasonic PT-F300NTE Instructions d'installation et d'entretien

Panasonic

Panasonic PT-VX505N Manuel du système

Panasonic

Panasonic PT-LB50EA Manuel utilisateur

Panasonic

Panasonic PT-AE500E Manuel utilisateur

Panasonic

Panasonic AX200U - LCD Projector - HD 720p Manuel utilisateur

Panasonic

Panasonic PT-MZ670 Manuel utilisateur

Panasonic

Panasonic PT-DW730UK Manuel utilisateur

Panasonic

Panasonic PT-DZ16KE Manuel utilisateur

Panasonic

Panasonic PT-VX430 Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur

Asus

Asus ZenBeam Latte Manuel utilisateur
