SPEC FILE

Product Number : PT-AX200

Product Name : High-Definition Home Cinema Projector

As of October 2008. Specifications subject to change without notice.

SPEC FILE

PT-AX200

High-Definition Home Cinema Projector

As of October 2008 < 2 >

Specifications

Main Unit

Power supply:

Power consumption:

LCD*1panel: Panel size:

Display method:

Drive method:

Pixels:

Lamp*2:

Lens:

Screen size:

Throw distance:

Colours:

Brightness*3:

Centre-to-corner uniformity ratio*3:

Contrast*3:

Resolution:

Scanning frequency: RGB:

YPBPR(YCBCR):

S-Video/Video:

Optical axis shift*5:

Keystone correction range:

Installation:

OSD languages:

Terminals: HDMI IN:

COMPUTER IN:

R, G, B:

HD/SYNC, VD:

COMPONENT IN:

PB/CB, PR/CR:

VIDEO IN:

S-VIDEO IN:

SERIAL IN:

100–240 V AC, 50/60 Hz

290 W (0.08 W in standby mode with fan stopped)

0.7˝ diagonal (16:9 aspect ratio)

Transparent LCD panel (x 3, R/G/B)

Active matrix

921,600 (1,280 x 720) x 3, total of 2,764,800 pixels

220 W UHM lamp

Manual zoom/focus lens (1:1 –1:2), F 1.9–3.1, f 21.7– 43.1 mm

40– 200 inches (1,016 – 5,080 mm) diagonally, 16:9 aspect ratio

1.2–12.4 m (3´11˝–40´8˝) (16:9 aspect ratio)

Full colour (1,073,741,824 colours)

2,000 lumens*4

85 %

6,000:1*4(full on/full off)

1,280 x 720 pixels (1,920 x 1,080 pixels with compression)

fH30–70 kHz, fV50– 87 Hz

Dot clock: Less than 150 MHz

480i (525i): fH15.75 kHz, fV60 Hz

480p (525p): fH31.5 kHz, fV60 Hz

576i (625i): fH15.63 kHz, fV50 Hz

576p (625p): fH31.25 kHz, fV50 Hz

720/50p (750/50p): fH45 kHz, fV60 Hz

720/60p (750/60p): fH37.5 kHz, fV50 Hz

1080/50i (1125/50i): fH28.125 kHz, fV50 Hz

1080/50p (1125/50p): fH56.3 kHz, fV50 Hz

1080/24p (1125/24p): fH27.0 kHz, fV24 Hz

1080/60i (1125/60i): fH33.75 kHz, fV60 Hz

1080/60p (1125/60p): fH67.5 kHz, fV60 Hz

fH15.75 kHz, fV60 Hz (NTSC, NTSC4.43, PAL-M, PAL60)

fH15.63 kHz, fV50 Hz (PAL, PAL-N, SECAM)

Horizontal: ±25%, vertical: ±63%

Vertical: approx. ±30°

Ceiling/floor, front/rear

English, French, German, Spanish, Italian, Chinese, Korean, Russian,

Swedish, Danish, Norwegian, Polish, Czech, Hungarian, Portuguese,

Thai

HDMI connector x 2

D-sub HD 15-pin (female) x 1,

0.7 Vp-p (1.0 Vp-p for Sync on G), 75 ohms

TTL, high impedance (positive/negative polarity)

RCA pin (Y, PB/CB, PR/CR) x 1

1.0 p-p, 75 ohms

0.7 Vp-p, 75 ohms

RCA pin x 1, 1.0 Vp-p, 75 ohms

Mini DIN 4-pin x 1, Y: 1.0 Vp-p, C: 0.286 Vp-p, 75 ohms

Mini DIN 8-pin (female) x 1, for external control (RS-232C compliant)

SPEC FILE

PT-AX200

High-Definition Home Cinema Projector

As of October 2008 < 3 >

Power cord length:

Cabinet material:

Dimensions (W x H x D):

Weight:

Operating temperature:

Operating humidity:

Remote Control

Power supply:

Operating range:

Dimensions (W x H x D):

Weight:

Supplied Accessories

Optional Accessories

3 m (9´10˝)

PC + ABS

395 x 112 x 300 mm (15-17/32˝ x 4-13/32˝ x 11-25/32˝)*6

4.9 kg (10.8 lbs)

0°–40°C (32°–104°F)

20%–80% (no condensation)

3 V DC (AA type battery x 2)

Approx. 7 m (23´) (when operated directly in front of signal

receptor)

48 x 138 x 28 mm (1-7/8˝ x 7-27/32˝ x 1-3/32˝)

125 g (4.4 oz.)

Power cord

Wireless remote control unit

Batteries for remote control (AA type x 2)

Replacement lamp: ET-LAX100

Ceiling mount bracket: ET-PKX200

Serial adapter: ET-ADSER (DIN 8-pin/D-sub 9-pin)

Weights and dimensions shown are approximate.

Specifications subject to change without notice.

*1: The projector uses a type of liquid crystal panel that typically consists of millions of pixels. This panel is built with very high-precision tech-

nology designed to provide one of the finest possible images. Occasionally, a few pixels may remain turned on (bright) or turned off (dark).

Please note that this is an intrinsic characteristic of the manufacturing technology that affects all products using LCD technology.

*2: The projector uses a high-voltage mercury lamp that contains high internal pressure. This lamp may break, emitting a large sound, or fail to

illuminate, due to impact or extended use. The length of time that it takes for the lamp to break or fail to illuminate varies greatly depending

on individual lamp characteristics and usage conditions.

*3: Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.

*4: In AI mode, with dynamic iris on

*5: Shift range is limited during simultaneous horizontal and vertical shifting.

*6: Lens and legs not included.

Weights and dimensions shown are approximate. Specifications are subject to change without notice. This product may be subject to

export control regulations. All other trademarks are the property of their respective trademark owners. Projection images simulated.

SPEC FILE

PT-AX200

High-Definition Home Cinema Projector

As of October 2008 < 4 >

271

300

103

395

112

121

309

(10-21/32)

(11-25/32)

(4-21/16)

(15-17/32)

(2-1/16)

(4-13/32)

(4-3/4)

(3-5/16)

(12-5/32)

unit : mm (inch)

NOTE: This illustration is not drawn to scale.

Dimensions

Terminals

RGB IN connector pin assignment

1 Serial input

2 HDMI 1 input

3 HDMI 2 input

4 Computer input

5 Component (Y/PB/PR) Input

6 S-Video input

7 Video input

no.

signal

GND

signal

GND

signal

GND

HD/SYNC

12 4 56

11615

510

D-sub HD 15-pin, female

SPEC FILE

PT-AX200

High-Definition Home Cinema Projector

As of October 2008 < 5 >

Standard setting-up positions

Projected image

179

Ø49

Ø43

(1-15/16˝)

62 (2-7/16˝)

366 – 446

(14-13/32˝–

17-9/16˝)

Adjustable in

20 mm (25/32˝) steps

(2-9/16˝)

(2-3/4˝)

(1-11/16˝)

(7-1/16˝)

Projected image

Lower edge of projected image

unit : mm (inch)

NOTE:

Illustrations show the projector installed

using optional ceiling bracket ET-PKX200.

This illustration is not drawn to scale.

Values shown are approximate.

NOTE: The values of L shown above vary due to characteristics of the zoom lens. Images may slightly distort due to characteristics of the zoom

lens when the zoom lens is set to the minimum throw distance.

NOTE: The accuracy of calculated value by the formula shown above is ±5%.

Projection distance (screen aspect ratio 16:9)

Diagonal length

Projection size (16:9) Height from the

edge of screen to

center of lens

(E)

Width from the

right edge of screen to

center of lens

(W)

Projection distance (L)

Min (Wide) Max (Telephoto)

1.01 m

1.52 m

2.03 m

2.54 m

3.05 m

3.81 m

5.08 m

1.2 m

1.8 m

2.4 m

3.1 m

3.7 m

4.6 m

6.2 m

2.4 m

3.7 m

4.9 m

6.2 m

7.4 m

9.3 m

12.4 m

0.57 m

0.85 m

1.13 m

1.40 m

1.68 m

2.11 m

2.81 m

0.67 m

1.00 m

1.33 m

1.66 m

2.00 m

2.49 m

3.32 m

-0.07 m

-0.10 m

-0.13 m

-0.16 m

-0.19 m

-0.24 m

-0.32 m

0.22 m

0.33 m

0.44 m

0.55 m

0.67 m

0.83 m

1.11 m

–

40˝

60˝

80˝

100˝

120˝

150˝

200˝

3´11˝

5´10˝

7´10˝

10´2˝

12´1˝

15´1˝

20´4˝

7´10˝

12´1˝

16´

20´4˝

24´3˝

30´6˝

40´8˝

2.8˝

3.9˝

5.1˝

6.3˝

7.5˝

9.4˝

12.6˝

9˝

1´1˝

1´5˝

1´10˝

2´2˝

2´9˝

3´8˝

1´10˝

4´11˝

3´8˝

4´7˝

5´6˝

6´11˝

9´3˝

2´2˝

3´3˝

4´4˝

5´5˝

6´7˝

8´2˝

10´11˝

Projection distance (screen aspect ratio 4:3)

Diagonal length

Projection size (4:3) Height from the

edge of screen to

center of lens

(E)

Width from the

right edge of screen to

center of lens

(W)

Projection distance (L)

Min (Wide) Max (Telephoto)

1.01 m

1.52 m

2.03 m

2.54 m

3.81 m

1.5 m

2.3 m

3.0 m

3.8 m

5.7 m

3.0 m

4.5 m

6.0 m

7.6 m

11.4 m

0.62 m

0.93 m

1.24 m

1.55 m

2.32 m

0.63 m

0.94 m

1.26 m

1.57 m

2.35 m

-0.01 m

-0.02 m

-0.03 m

0.19 m

0.28 m

0.37 m

0.46 m

0.69 m

–

40˝

60˝

80˝

100˝

150˝

4´11˝

7´7˝

9´10˝

12´6˝

18´8˝

9´10˝

14´9˝

19´8˝

24´11˝

37´5˝

0.4˝

0.8˝

1.2˝

7˝

11˝

1´3˝

1´6˝

2´3˝

2´

3´˝

4´1˝

5´1˝

7´7˝

2´

3´1˝

4´2˝

5´2˝

7´9˝

Calculation of the projection distance

For a screen size different from the above, use the equation below to calculate the projection distance.

16 : 9 minimum L (m) = (diagonal screen size in inches) x 0.0311 - 0.056

maximum L (m) = (diagonal screen size in inches) x 0.0621 - 0.056

4 : 3 minimum L (m) = (diagonal screen size in inches) x 0.0381 - 0.046

maximum L (m) = (diagonal screen size in inches) x 0.0761 - 0.056

SPEC FILE

PT-AX200

High-Definition Home Cinema Projector

As of October 2008 < 6 >

Shift range

Optical axis shift function allows to shift the position of a projected image as shown below.

0.63V 0.63V

0.25H0.25H

(Width of

projected image)

(Height of

projected image)

Standard position

of projected image

Installable angle

Install the projector at an angle within the range shown below.

• Vertical direction

The projector may be installed at a vertical angle of ±30°.

• Horizontal direction

The projector may not be angled horizontally.

+30°

-30°

0°

SPEC FILE

PT-AX200

High-Definition Home Cinema Projector

As of October 2008 < 7 >

List of Compatible Signals

NTSC/NTSC4.43/PAL-M/PAL60

PAL/PAL-N/SECAM

480i (525i)

576i (625i)

480p (525p)

576p (625p)

720 (750)/60p

720 (750)/50p

1080 (1125)/60i

1080 (1125)/50i

1080 (1125)/24p

1080 (1125)/60p

1080 (1125)/50p

VGA480

WIDE480

SVGA

WIDE600

WIDE720

XGA

WIDE768

MXGA

SXGA

WIDE768-2

720 x 480i

720 x 576i

720 x 480i

720 x 576i

720 x 480

720 x 576

1,280 x 720

1,920 x 1,080i

1,920 x 1,080

640 x 480

856 x 480

800 x 600

1,072 x 600

1,280 x 720

1,024 x 768

1,280 x 768

1,125 x 864

1,280 x 1,024

1,360 x 768

15.7

15.6

15.7

15.6

31.5

31.3

45.0

37.5

33.8

28.1

27.0

67.5

56.3

31.5

37.5

43.3

72.1

30.1

35.2

37.9

48.1

46.9

53.7

37.2

45.1

48.4

56.5

60.0

68.7

72.1

45.3

64.0

67.5

64.0

48.8

59.9

50.0

59.9

50.0

59.9

50.0

60.0

50.0

60.0

50.0

24.0

60.0

50.0

59.9

75.0

85.0

138.0

60.1

56.3

60.3

72.2

75.0

85.1

59.9

60.1

60.0

70.1

75.0

85.0

89.0

56.5

71.2

74.9

60.0

59.8

13.5

27.0

74.3

148.5

25.2

31.5

36.0

62.3

31.5

36.0

40.0

50.0

56.3

51.4

76.5

65.0

75.0

78.8

94.5

99.2

76.2

94.2

108.0

74.3

VIDEO/S-VIDEO

COMPONENT

COMPONENT/HDMI

COMPONENT/PC/HDMI

COMPONENT/HDMI

COMPONENT/PC/HDMI

PC/HDMI

Display mode Display

resolution

(dots)

(kHz)

Scanning frequency

(kHz)

Dot clock

frequency

(MHz)


quality

Format

Computer data compatibility

This projector accepts up to 70 kHz horizontal scanning frequency and 108 MHz dot clock.

NOTE: The display resolution of this projector is 1280 x 720 pixels. If the display resolution indicated in the above data does not match

this resolution, the input signal will be converted to 1280 x 720 pixels.

1. The “i” appearing after the resolution indicates an interlaced signal.

2. The following symbols are used to indicate picture quality.

AA Maximum picture quality can be obtained.

A Signals are converted by the image processing circuit before picture is projected.

SPEC FILE

PT-AX200

High-Definition Home Cinema Projector

As of October 2008 < 8 >

SERIAL

8-pin DIN (male)

Serial adapter

ET-ADSER

Communication cable (RS-232C)

Serial connector

The serial connector complies with RS-232C. To control the projector from a personal computer, com-

mands must be input through communication software, based on the format and satisfying the commu-

nication conditions shown below.

Pin assignments and signal names

Communication conditions (factory setting)

Basic format

Transmission from the computer begins with STX, then the ID, command, parameter, and ETX are sent

in this order. Add parameters according to the details of control.

CAUTIION

Be sure to see that an optional serial adapter ET-ADSER and a

RS-232C communication cable match the PC to be connected.

No.

Signal name

–

RXD

GND

Signal name

TXD

–

Description

Connected internally

Receive data

Ground

Description

Send data

Connected internally

Signal level

Synchronization method

Baud rate

Parity

Character length

Stop bit

X parameter

Sparameter

RS-232C-compliant

Start-stop synchronization

9,600 bps

None

8 bits

1 bit

None

Mini DIN 8-pin

STX ETXC1 C2 C3 : P1 P2 P3 P4

Start

(1 byte)

End

(1 byte)

Colon

(1 byte)

Parameter

(1-4 bytes)Command

(3 bytes)

(Control and/or query commands)

CAUTIION

When sending multiple commands, be sure to send the next command after receiving a response from the projector.

Cable specifications

–

PC (DTE)ProjectorSerial adapter

(ET-ADSER)

DSR

SPEC FILE

PT-AX200

High-Definition Home Cinema Projector

As of October 2008 < 9 >

Status asking commands

Command Description Callback

QPW

QIN

QPM

QFZ

QOT

QSH

Standby power status

Input signal status

Picture mode status

Freeze status

Off timer status

Shutter function status

Normal

Dynamic

Cinema 1

Cinema 2

Vivid cinema

Game

Natural

<NOR>

<DYN>

<CN1>

<CN2>

<VCN>

<GAM>

<NAT>

<off_on>

<off_timer>

<off_on>

Control commands

*Do not send PON, POF, or OSH commandscontinuously in a short period of time. Doing so may burst the lamp or shorten the lamp replacement cycle.

PON*

POF*

IIS:<input signal>

OST

OFZ:<off_on>

OEN

VPM:<picture mode>

<NOR>

<DYN>

<CN1>

<CN2>

<VCN>

<GAM>

<NAT>

OMN

OCU

OCD

OCL

OCR

OOT:<off_timer>

OSH*

OVM

VS1

OBK

Power on (standby mode on)

Power off (standby mode off)

Input signal selection

The same function as“DEFAULT” button

Freeze

Enter

Picture mode

Normal

Dynamic

Cinema 1

Cinema 2

Vivid cinema

Game

Natural

Cursor up

Cursor down

Cursor left

Cursor right

Off timer

Shutter

The same function as“PICTURE MODE” button

The same function as“ASPECT” button

The same function as“RETURN” button

PON

POF

IIS:<input signal>

OST

OFZ:<off_on>

OEN

VPM:<picture mode>

<NOR>

<DYN>

<CN1>

<CN2>

<VCN>

<GAM>

<NAT>

OMN

OCU

OCD

OCL

OCR

OOT:<off_timer>

OSH

OVM

VS1

OBK

–

Command: <Parameter> Function Callback: <Parameter> Parameter value

Min Max

SPEC FILE

PT-AX200

High-Definition Home Cinema Projector

As of October 2008 < 10 >

Parameter format

Parameter format Size (Byte) Difinition

<off_on>

<off_timer>

0 = off, 1 = on

VID = video, SVD = S-video, RG1 = computer, YUV = YPBPR,

HD1 = HDMI 1, HD2 = HDMI 2

000 = power on (standby mode on), 001 = power off (standby mode off)

0 = off, 1 = 60 min, 2 = 90 min, 3 = 120 min, 4 = 150 min, 5 = 180 min,

6 = 210 min, 7 = 240 min

Command example

To set the volume to +30, send the command as shown below.

STX AVL : 30 ETX

Start Command Parameter End

NOTE: If a wrong command is received, the projector will send an ER401 command to the computer.

NOTE: When sending commands without parameters, a colon (:) is not necessary.

Autres manuels pour PT-AX200

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Projecteur

Panasonic

Panasonic PT-VW345NZ Manuel utilisateur

Panasonic

Panasonic PT-AT5000E Manuel utilisateur

Panasonic

Panasonic PT-DZ680 Guide d'installation

Panasonic

Panasonic PT-AE3000E Manuel utilisateur

Panasonic

Panasonic PT-LB60 Manuel du système

Panasonic

Panasonic PTFW100NTU - LCD PROJEC. WIRELESS Manuel utilisateur

Panasonic

Panasonic PTL292U - LCD PROJECTOR Manuel utilisateur

Panasonic

Panasonic PT-D3500 - XGA DLP Projector Manuel du système

Panasonic

Panasonic PT-TW331R Manuel utilisateur

Panasonic

Panasonic PT-D1000 Manuel utilisateur

Panasonic

Panasonic PT AE1000E Manuel utilisateur

Panasonic

Panasonic PT-DW10000E Manuel utilisateur

Panasonic

Panasonic PTF100NTU - LCD PROJECTOR Manuel utilisateur

Panasonic

Panasonic PTL6500U - LCD PROJECTOR Manuel utilisateur

Panasonic

Panasonic PT-CW230EA Manuel utilisateur

Panasonic

Panasonic PT-AE3000E Manuel utilisateur

Panasonic

Panasonic PTL711U - LCD PROJECTOR Manuel utilisateur

Panasonic

Panasonic PT-CX200 Manuel du propriétaire

Panasonic

Panasonic PT-VX415NZ Manuel utilisateur

Panasonic

Panasonic PT-DW5100EL Manuel utilisateur

Panasonic

Panasonic PT-LB78 Manuel utilisateur

Panasonic

Panasonic PT-DW6300ES Manuel utilisateur

Panasonic

Panasonic PT-F200 Series Manuel utilisateur

Panasonic

Panasonic PTLB51NTU - LCD PROJECTOR - MULTI LANGUAGE Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur

Asus

Asus ZenBeam Latte Manuel utilisateur
