Panasonic TX-L42DT50B Manuel utilisateur

TQB0E2279

Operating Instructions

LCD Television

Model No.

TX-L42DT50B

TX-L47DT50B

TX-L55DT50B

Thank you for purchasing this Panasonic product.

Please read these instructions carefully before operating this product and

retain them for future reference.

The images shown in this manual are for illustrative purposes only.

English UK and Ireland model

Specifications

121

Specifications

■Product fiche

Manufacturer Panasonic Corporation

Model No. TX-L42DT50B TX-L47DT50B TX-L55DT50B

Energy efficiency class A+ A+ A+

Visible screen size

(diagonal) 107 cm / 42 inches 119 cm / 47 inches 139 cm / 55 inches

On mode average power

consumption 56 W 69 W 91 W

Annual energy

consumption∗178 kWh 95 kWh 127 kWh

Rated power consumption 116 W 129 W 149 W

Standby power

consumption∗20.20 W

Off mode power

consumption 0.18 W

Display resolution 1,920 (W) × 1,080 (H)

■Other information

Model No. TX-L42DT50B TX-L47DT50B TX-L55DT50B

Power source AC 220-240 V, 50 / 60 Hz

Panel LED LCD panel

Dimensions (W × H × D)

958 mm × 615 mm ×

258 mm (With Pedestal)

958 mm × 569 mm ×

27 mm (TV only)

1,067 mm × 677 mm ×

265 mm (With Pedestal)

1,067 mm × 631 mm ×

27 mm (TV only)

1,237 mm × 773 mm ×

290 mm (With Pedestal)

1,237 mm × 726 mm ×

27 mm (TV only)

Mass 14.5 Net (With Pedestal)

11.0 Net (TV only)

17.0 Net (With Pedestal)

13.0 Net (TV only)

22.5 Net (With Pedestal)

17.0 Net (TV only)

Sound

Speaker 8 train speakers × 2, Woofer (Φ75 mm) × 1

Audio output 18 W (4 W + 4 W + 10 W)

Headphones M3 (3.5 mm) stereo mini Jack × 1

Specifications

122

Receiving systems /

Band name

Check the latest

information on the

available services at

the following website.

http://panasonic.jp/

support/global/cs/tv/

DVB-S / S2

(

freesat

Other Sat.

)

freesat services via Satellite dish input.

Receiver frequency range - 950 MHz to 2,150 MHz

LNB Power and Polarisation - Vertical: +13 V

Horizontal: +18 V

Current: Max. 500 mA (overload

protection)

22 kHz Tone - Frequency: 22 kHz ± 2 kHz

Amplitude: 0.6 V ± 0.2 V

Symbol Rate - Max. 30 MS/s

FEC Mode - 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10

Demodulation - QPSK, 8PSK

Not available for DiSEqC control.

DVB-T / T2 Digital terrestrial services.

PAL I UHF E21 - 68

PAL 525/60 Playback of NTSC tape from some PAL Video recorders (VCR)

or NTSC disc playback from DVD player and recorder.

M.NTSC Playback from M.NTSC Video recorders (VCR).

NTSC

(AV input only) Playback from NTSC Video recorders (VCR).

DVB-S / S2

Receiver frequency range - 950 MHz to 2,150 MHz

LNB Power and Polarisation - Vertical: +13 V

Horizontal: +18 V

Current: Max. 500 mA (overload

protection)

22 kHz Tone - Frequency: 22 kHz ± 2 kHz

Amplitude: 0.6 V ± 0.2 V

Symbol Rate - Max. 30 MS/s

FEC Mode - 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10

Demodulation - QPSK, 8PSK

Not available for DiSEqC control.

DVB-T Digital terrestrial services.

PAL I VHF A - J

CATV S1 - S20

UHF E21 - E69

CATV S21 - S41 (Hyperband)

PAL 525/60 Playback of NTSC tape from some PAL Video recorders (VCR)

or NTSC disc playback from DVD player and recorder.

M.NTSC Playback from M.NTSC Video recorders (VCR).

NTSC

(AV input only) Playback from NTSC Video recorders (VCR).

Satellite dish input Female F-type 75 Ω

Aerial input UHF VHF / UHF

Operating conditions Temperature: 0 °C - 35 °C

Humidity: 20 % - 80 % RH (non-condensing)

Connection terminals

AV1 input / output SCART (Audio/Video in, Audio/Video out, RGB in, Q-Link)

AV2 input

(COMPONENT /

VIDEO)

VIDEO RCA PIN Type × 1 1.0 V[p-p] (75 Ω)

AUDIO L - R RCA PIN Type × 2 0.5 V[rms]

Y 1.0 V[p-p] (including synchronisation)

PB, PR±0.35 V[p-p]

HDMI 1 / 2 / 3 / 4

input

TYPE A Connectors

HDMI1 / 3 / 4: 3D, Content Type, Deep Colour

HDMI2: 3D, Content Type, Audio Return Channel, Deep Colour

●

This TV supports “HDAVI Control 5” function.

Specifications

123

Connection terminals

HIGH-DENSITY D-SUB 15PIN

R,G,B: 0.7 V[p-p] (75 Ω)

HD, VD: TTL Level 2.0 – 5.0 V[p-p] (high impedance)

●

Applicable input signals:

VGA, SVGA, WVGA, XGA, SXGA, WXGA

Card slot SD Card slot × 1

Common Interface slot (complies with CI Plus) × 1

ETHERNET RJ45, IEEE802.3 10BASE-T / 100BASE-TX

USB 1 / 2 / 3 USB2.0 DC 5 V, Max. 500 mA

DIGITAL AUDIO

OUT PCM / Dolby Digital / DTS, Fibre optic

Built-in wireless LAN

Standard

compliance and

Frequency range∗3

IEEE802.11a/n

5.180 GHz - 5.320 GHz, 5.500 GHz - 5.580 GHz, 5.660 GHz - 5.700 GHz

IEEE802.11b/g/n

2.412 GHz - 2.472 GHz

Security WPA2-PSK (TKIP/AES) WPA-PSK (TKIP/AES) WEP (64 bit/128 bit)

Bluetooth wireless

technology∗4

Standard

Compliance Bluetooth 3.0

Frequency Range 2.402 GHz - 2.480 GHz

∗ 1: Energy consumption XYZ kWh per year, based on the power consumption of the television operating 4 hours per

day for 365 days. The actual energy consumption will depend on how the television is used.

∗ 2: when the TV is turned off with the remote control and no function is active

∗ 3:

The frequency and channel differ depending on the country.

∗ 4:

Not all the Bluetooth compatible devices are available with this TV.

Note

●

Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate.

●

This equipment complies with the EMC standards listed below.

EN55013, EN61000-3-2, EN61000-3-3, EN55020, EN55022, EN55024

LCD Television

Declaration of Conformity (DoC)

“Hereby, Panasonic Corporation declares that this TV is in compliance with the essential requirements and

other relevant provisions of the Directive 1999/5/EC, Directive 2004/108/EC, Directive 2006/95/EC and Council

recommendation 1999/519/EC.”

If you want to get a copy of the original DoC of this TV, please visit the following website:

http://www.doc.panasonic.de

Authorized Representative:

Panasonic Testing Centre

Panasonic Marketing Europe GmbH

Winsbergring 15, 22525 Hamburg, Germany

This TV is intended to be used in the following countries.

Ireland, United Kingdom

The WLAN feature of this TV shall exclusively be used inside buildings.
