English 3-15

Model No. NI-JU700C

Operating Instructions

Steam Iron

Household Use Only

i8200ō-ōP73A

NI-JU700C.indd1NI-JU700C.indd1 2017/10/0516:20:552017/10/0516:20:55

NI-JU700C.indd2NI-JU700C.indd2 2017/10/0413:43:272017/10/0413:43:27

Before operating this unit, please read these instructions completely and save them for future use.

Thank you for purchasing this Panasonic product.

Model No. NI-JU700C

Operating Instructions

Steam Iron

Household Use Only

English

Contents

Safety precautions-----------------------------------------------------------------------04-07

Parts identification----------------------------------------------------------------------------07

Before use--------------------------------------------------------------------------------------08

How to use as an iron--------------------------------------------------------------------08-09

Guide for Steam/Dry selector--------------------------------------------------------------10

Using the “ power shot ”---------------------------------------------------------------------10

Using the “ vertical shot ” -------------------------------------------------------------------11

Using the “ spray ” ----------------------------------------------------------------------------11

How to care for and store your iron-------------------------------------------------11-14

Q&A---------------------------------------------------------------------------------------------14

Trouble shooting-----------------------------------------------------------------------------15

Specification-----------------------------------------------------------------------------------15

NI-JU700C.indd3NI-JU700C.indd3 2017/10/0516:20:572017/10/0516:20:57

Safety precautions

To reduce the risk of injury, loss of life, electric shock, fire,

and damage to equipment or property, always observe the

following safety precautions.

Explanation of symbols

The following symbols are used to classify and describe the

level of hazard, injury, and property damage caused when the

denotation is disregarded and improper use is performed.

Denotes a potential hazard that could

result in serious injury or death.

The following symbols are used to classify and describe the

type of instructions to be observed.

This symbol is used to alert users to a specific

operating procedure that must not be performed.

Denotes a hazard that could result

in minor injury or damage your

belongings.

This symbol is used to alert users to a specific

operating procedure that must be followed in order to

operate the unit safely.

CAUTION

Do not connect or disconnect the power plug to a

household outlet with wet hands.

Do not damage, modify, forcibly bend, pull, or

twist the power cord.

Do not place anything heavy on or pinch the

power cord.

Do not wrap the power cord around the

iron

when

storing.

Do not use with the power cord bundled.

Do not use in proximity of Àammable materials

(such as benzine or the like).

Never modify, disassemble, or repair.

- Doing so may cause ignition or injury due to

abnormal operation. Contact an authorized service

center for repair.

Do not leave the iron unattended while it is

connected to the

outlet

WARNING

English

To reduce the risk of personal injury, electric shock or

fire, please observe the following:

Do not use when the power plug or power cord is

damaged or hot. Never use the

iron

if the power

plug ¿ts loosely in a household outlet.

Do not immerse the iron in water or other

liquids.

Do not supply water to the unit directly from the

faucet.

- Doing so may cause burns, electric shocNRU¿UH

due to a short circuit.

Do not use the

iron

with wet hands.

NI-JU700C.indd4NI-JU700C.indd4 2017/10/0413:43:282017/10/0413:43:28

English

To reduce the risk of personal injury, electric shock or

fire, please observe the following:

Always ensure the appliance is operated on an

electric power source matched to the rated

voltage indicated on the

iron

. Fully insert the

power plug.

The power plug must be unplugged before filling

water to the water tank.

The iron must be used and rested on a flat,

stable surface. When placing the iron on its

stand, ensure that the surface on which the

stand is placed is stable.

- If placed on a shaggy rug or other unstable

location, the iron may fall over and cause damage

to the rug, injury or burns.

Regularly clean the power plug to prevent dust

from accumulating.

Disconnect the power plug and wipe with a dry cloth.

Immediately stop using and unplug the power

plug if there is an abnormality or malfunction.

Examples of abnormalities:

· The iron stops occasionally, the power cord or

the power plug is abnormally hot or discolored.

· The iron is deformed or smells of burning.

- Refer servicing to authorized service personnel.

This appliance is not intended for use by persons

(including children) with reduced physical,

sensory or mental capabilities, or lack of

experience and knowledge, unless they have

been given supervision or instruction concerning

use of the appliance by a person responsible for

their safety.

Children should be supervised to ensure that

they do not play with the

appliance

- Failure to do so may cause an accident or injury.

Do not touch the hot surface (such as soleplate,

and the hot surface around it).

To reduce the risk of personal injury, property

damage, electric shock or fire, please observe the

following:

CAUTION

WARNING

If the power cord is damaged, it must be replaced

by the manufacturer, its service center, or

similarly qualified persons in order to avoid a

hazard.

- Failure to do so may cause an accident or injury.

The

iron

is not to be used if it has been dropped,

and there are visible signs of damage or if it is

leaking.

- Refer servicing to authorized service personnel.

NI-JU700C.indd5NI-JU700C.indd5 2017/10/0413:43:292017/10/0413:43:29

Do not insert pins or needles into the iron or use

it on clothes with sewing needles or the like

inserted.

Do not put the soleplate too close to you or

others since steam may unexpectedly erupt from

it.

Do not use the iron with the exception of fabric.

Do not store the iron until it has fully cooled

down.

Only use tap water in the iron.

Do not add perfume, vinegar, starch, descaling

agents, ironing aids or other chemicals in the

water tank.

- Doing so may it will cause scalds or getting dirty

due to the damage product.

Do not repeatedly and quickly press the power

shot button.

If repeating operation over an interval of less than

2 seconds, burns due to hot water leaks may result.

Do not store the power cord coiled with sharp

angles.

- This may damage the cord.

If the shot intensity is low, do not operate the

power shot button.

- Doing so may cause burns due to hot water leaks.

Do not tilt or violently move the iron back and

forth.

- Doing so may cause burns due to hot water leaks.

Do not use any ironing accessories available on

the market.

- Doing so may cause burns or damage to cloth due

to incorrect operation.

Do not use the iron near walls or furniture that

cannot withstand high temperature or humidity.

- Doing so may damage the wall or furniture.

CAUTION

Do not add hot water in the water tank.

- Doing so may cause burns due to hot water

splashes.

Do not touch the steam or "power shot "during

use.

• When using an ironing board through which steam

can penetrate, do not put your hand, leg, etc.,

under the ironing board.

• Do not aim the steam towards your hand, knee, or

any other part of the body.

• Do not use steam or " power shot "when the iron is

partially sticking out from the ironing board.

• Do not iron the clothes that you are wearing.

English

NI-JU700C.indd6NI-JU700C.indd6 2017/10/0413:43:292017/10/0413:43:29

English

Disconnect the power plug by holding the wire

instead of pulling on the power cord.

- Failure to do so may break the wire, and may

cause burns, electric shocNRU¿UHGXHWRDVKRrt

circuit.

Use a dry iron on moist clothing (spray misted).

Care should be taken when using the iron.

- Steam emission may cause personal injury.

Drain water from the water tank after use.

- Failure to do so may cause the water to leak out

from the soleplate when the iron is used next time.

To reduce the risk of personal injury, property

damage, electric shock or fire, please observe the

following:

Always unplug the power plug during not in use.

- Failure to do so ma\FDXVH¿Ue, electric shock.

Parts identification

Thermostat operating

indicator light

Handle

Power shot button

Spray mist button

Steam/Dry selector

Water fill cover

Spray nozzle

Soleplate

Maximum water level

indicator

Self-cleaning button

Water tank

Heel rest

Power plug

Plug type may vary

comply with respective

country or region

requirement.

Temperature selector

Power cord

Dry Low steam High steam

Temperature select

scale position

MLJ

C A

D B

When using with following fabric, test on an

inconspicuous area, or place a cloth over the

fabric to prevent the fabric from marking.

• Expensive or specially processed fabrics (velvet,

acrylic, nylon, cashmereHWF

• Fabrics that are labeled as " low heat "or

" medium heat ", or dark colored fabrics.

CAUTION

NI-JU700C.indd7NI-JU700C.indd7 2017/10/0413:43:302017/10/0413:43:30

English

Before use How to use as an iron

The temperature selector of the iron has words, dots and

steam symbols.

The dots are symbols for 3 temperature ranges:

1. Move the steam/dry selector to the dry position to

avoid water leakage.

• Low temperature

• • Medium temperature

• • • High temperature

Some fabrics are labeled with these dots as a guide for

selecting the proper ironing temperature setting.

Use a press cloth if necessary.

Notes:

・The thermostat operating indicator light goes on and off

alternately to indicate the changing temperature of soleplate.

If you turn the temperature selector from a high temperature

to a lower temperature, wait until the indicator light goes on

before using the iron.

・Do not place the hot iron on cloth for extended time or wrap

cloth over the hot iron.

Note:

Do not overfill the water tank. The steam will release through

the vents when the iron is positioned vertically.

①Open the water fill cover.

Hold the iron as shown

and fill the iron with water

up to " MAX " (about 300 mL).

Use a claen cup for filling.

②Place iron in vertical position to check water level.

③Close water tank cover firmly to prevent spillage

during ironing.

2. Fill water in the water tank when using steam, power

shot, vertical steam or spray.

“ MAX ”

NI-JU700C.indd8NI-JU700C.indd8 2017/10/0413:43:302017/10/0413:43:30

English

3. Position the iron in the heel

rest position and make sure

the temperature selector is

set to "0 ".

4. Plug the power plug into an outlet.

5. Set the temperature selector.

The thermostat operating indicator light goes on.

Note:

If the temperature of soleplate is high, the light does not go on.

6. Wait until the thermostat operating indicator light goes

off. Hold the iron horizontally and move the steam/dry

selector into the steam position when using the

" power shot ".（P10)

• Please make sure the temperature select indicator

setting is on " MAX " when using " high steam " and

" power shot ".

7. After each use

①Set the steam/dry selector to the

dry position. If the steam/dry selector

is not in the dry position after using,

remaining water will move into the

soleplate and can result in burns when

the iron is used next time.

②Empty the water tank immediately

after using. Do not store the iron

with water in it. If you empty the

water tank after it has cooled,

heat the iron for about 5 minutes

with the temperature selector set

to " MAX ".

• Do not wind the power cord around the iron.

It may be damaged by the hot soleplate.

③Wait until the iron has cooled before

storing it, and always set it on the

heel rest to protect the soleplate

from scratches, corrosion or stains.

Refer to "Guide for Steam/Dry selector" on P10

NI-JU700C.indd9NI-JU700C.indd9 2017/10/0413:43:322017/10/0413:43:32

Please make sure the temperature select indicator setting is on

" MAX " when using " high steam ".

Notes:

•

The anti-drip system will activate when the temperature of

the soleplate’s surface drops. The thermostat operating

indicator light will go on and steam will stop. It is normal to

hear clicking sound during this process. Resume usage only

after the thermostat operating indicator light has turned off.

•

Use an ironing board supports a steam iron.

CAUTION:

Do not aim the steam at any parts of your body or others.

Dry

Low

steam

High

steam

Steam/Dry

selector

Temperature

zone

Recommendations

Choose

according to

the type of

fabrics

For polyester and other

synthetic fiber material.

For thin or delicate

fabrics requiring a small

amount of steam.

For fabrics requiring a

lot of steam. (i.e. thick

materials, items with

VWXEERUQZULQNOHV

Guide for Steam/Dry selector

steam zone

English

The

power shot

feature provides extra steam which goes

deep into the garment and is helpful for removing stubborn

wrinkles. It is necessary to clean the inside of the iron before

using the "power shot" feature, if you have not used the

“power shot” feature for a prolonged period. Simply test the

“power shot” feature several times away from the ironing

board and clothes to be ironed. This will prevent brown

spotting or water spotting on the clothes.

Set the steam/dry selector to the dry position.

Set the temperature selector to the " MAX " position.

Using the “power shot”

• Pump the power shot button several times at the beginning of

each ironing session.

•

Press the power shot button in intervals of at least 2 seconds

between use to prevent water spotting.

• If the power shot weakens, wait until the thermostat

operating Indicator light goes on, and then off.

• Use a press cloth if necessary.

Simply pump the power shot button

NI-JU700C.indd10NI-JU700C.indd10 2017/10/0413:43:322017/10/0413:43:32

Table des matières

Langues :

Autres manuels Panasonic Fer

Panasonic

Panasonic NI-H10NS Manuel utilisateur

Panasonic

Panasonic NI-C55SR Manuel utilisateur

Panasonic

Panasonic NI-N50NR Manuel utilisateur

Panasonic

Panasonic NI-W750TS Manuel utilisateur

Panasonic

Panasonic NI-H20NR Manuel utilisateur

Panasonic

Panasonic NI-L45NR Manuel utilisateur

Panasonic

Panasonic NI-W950A Manuel utilisateur

Panasonic

Panasonic NI33GX - ELEC. STEAM IRON-LOW Manuel utilisateur

Panasonic

Panasonic NI-GWF150 Manuel utilisateur

Panasonic

Panasonic NI-S300TR Manuel utilisateur

Panasonic

Panasonic NIS200TS - ELECTRIC STEAM IRON Manuel utilisateur

Panasonic

Panasonic NI-L45NR Manuel utilisateur

Panasonic

Panasonic NI-JWT980 Manuel utilisateur

Panasonic

Panasonic NI33GX - ELEC. STEAM IRON-LOW Manuel utilisateur

Panasonic

Panasonic NI-GT150 Manuel utilisateur

Panasonic

Panasonic NI-N50NR Manuel utilisateur

Panasonic

Panasonic NI-GT500 Manuel utilisateur

Panasonic

Panasonic NI-S300TR Manuel utilisateur

Panasonic

Panasonic NI-FS780 Manuel utilisateur

Panasonic

Panasonic NI-U550C Manuel utilisateur

Panasonic

Panasonic NI-A56NR Manuel utilisateur

Panasonic

Panasonic NI-L70SR - Steam Iron With Micro-Mist Spray Manuel utilisateur

Panasonic

Panasonic NI-A56NR Manuel utilisateur

Panasonic

Panasonic NI-W950A Manuel utilisateur

Manuels Fer populaires d'autres marques

Clatronic

Clatronic DB 3703 Manuel utilisateur

TEFAL

TEFAL FV4093Z0 Manuel utilisateur

Gorenje

Gorenje SIH 2200 BS Manuel utilisateur

Philips

Philips GC6012 Manuel utilisateur

Bosch

Bosch 2 Series Manuel utilisateur

Riffel

Riffel Catena KB-819 Manuel utilisateur

Texi

Texi Hestia Manuel utilisateur

Maxwell

Maxwell MW-3010 Manuel utilisateur

TREVIDEA

TREVIDEA Girmi ST60 Manuel utilisateur

Philips

Philips HI5914/30 Manuel utilisateur

Primula

Primula Vapormat Manuel utilisateur

Magio

Magio MG-541 Manuel utilisateur

Scarlett

Scarlett SC-1334S Manuel utilisateur

Bosch

Bosch Sensixx B22L Manuel utilisateur

Philips

Philips GC651 Manuel utilisateur

Vitek

Vitek VT-1247 VT Manuel utilisateur

Cleanmaxx

Cleanmaxx 3397 Manuel utilisateur

Philips

Philips GC800 Manuel utilisateur
