SIP Telephones

KX-UT Series

Home & Business Communications

Panasonic System Networks Company of America

Home and Business Communications

SIP Communication Solutions

Flexible, Cost-Effective

Communications Solutions

Businesses large and small are discovering the proven efciencies and cost benets of a SIP-based communi-

cations system. Transmitting voice and data over a single unied network simplies a company’s IT infrastruc-

ture while VoIP technology combined with a Hosted or Open Source PBX solution lowers monthly phone bills.

Now, changing work locations within your ofce means simply taking your phone with you and plugging it into

an Ethernet port. Extensions and other preferences are preserved when you move the phone to a new location.

A pioneer in world-class telephony solutions, Panasonic offers a wide range of SIP endpoints—from feature-

rich desktop models to cordless options that let you cost-effectively outt an entire ofce. Engineered with

extensive, intuitive provisioning options, the Panasonic line of SIP phones features plug and play simplicity to

get you up and running right away.

The Panasonic SIP Phone UT Series

The latest offering in our line of feature-rich SIP endpoints, the new UT Series combines state-of-the-art telephony

with business-friendly features. Choose from entry-level models with conferencing capability and a low power

consumption mode to executive desk terminals with color, touchscreen displays, wireless headset compatibility and

integration with Panasonic network cameras.

Powerful, Business-friendly Features

Crystal Clear Audio

The UT Series features wide-band, high-denition voice for crisp, precise sound quality whether

delivered via the handset, speakerphone or optional headset. An Echo Cancellation feature combined

with an expanded acoustic chamber further enhances sound quality. All phones in the series feature

wideband-compliant, hearing aid compatible handsets along with built-in, high-quality speakers and

microphones

Wireless Capability

Select models in the series feature a built-in electronic hookswitch (EHS), enabling compatibility

with the Plantronics line of DECT wireless headsets—perfect for multi-taskers who need hands-

free convenience during a conversation.

High

Definition

Wireless

Easy Navigation Keys

3-Way Conferencing Capability 2-Position Tilt Function

Color Touchscreen Display

HD Voice

Enabled

(2) 1-Gigabit

Ethernet Ports, PoE

KX-UT670 shown

A Smarter Phone for the Desktop

The award-winning KX-UT670 is equipped with a large, 7-inch LCD touchscreen allowing easy access to

features and installed applications. The open-source operating system is programmable in Java enabling

development of third party business applications. Users can browse the web, access email and check daily

calendar appointments right on the phone. The UT670 can also sync with up to 16 Panasonic network secu-

rity cameras so you can monitor live security video directly from the phone.

Open Source Platform Certiﬁcation

Like all phones in the Panasonic SIP lineup, the UT Series is certied for Use with BroadSoft® BroadWorks®,

Digium® Asterisk®, Metaswitch, Brekeke and many others*. Panasonic SIP phones are a proven, cost-effective

endpoint solution for small to mid-size companies utilizing the latest in Hosted and Open

Source PBX technology.

*Consult your Panasonic representative for a complete, up-to-date list.

Conferencing Solutions

The convenient 3-Way Conferencing feature, available on all UT series phones, will

help you save time and resources. A paging function lets you quickly get two col-

leagues on the phone with you for a conference even if they’re located at

opposite ends of the country.

Low Total Cost of Ownership

The UT Series is designed to complement your existing com-

munications infrastructure, yielding a low TCO and maximiz-

ing ROI. Select models feature a second data port, so you

can connect a second device to the network without the

time and expense of running additional Ethernet cable.

All UT Series models are PoE ready, thus eliminating

the need for adaptors and saving on electricians’

fees. An energy-saving Eco Mode feature lets you

lower power consumption while a comprehen-

sive, two-year limited warranty protects your

investment well into the life of the phone.

1-52 keys include 24 keys, 12 dial keys, 4 soft keys and 12 feature keys. Feature keys include 2 navigation keys (direction and center key).

KX-UT Series

Speciﬁcations

KX-UT670 KX-UT248-B KX-UT136-B KX-UT133-B KX-UT123-B K X - UT 113 - B

LCD Display Color 262,000 Greyscale Graphical Monochrome Graphical

LCD Size 7 inch touchscreen 4.4 inch 242 x 109 pix. – 6 lines 242 x 55 pixels – 3 lines

LCD Contrast No 6 levels 6 levels

LCD Backlight 15/Auto On/Auto/Off On/Auto/Off None

INSTALL OPTIONS

Desk Mount Tilt Yes - 2 Positions No

Wall Mount KX-A434-B (optional) KX-A433-B (optional) KX-A432-B (optional)

Power Adaptor KX-A422 (optional) KX-A239 (optional)

NETWORKING

Ethernet Ports 2 – 10/100/1000 2 – 10/100 1 – 10/100

Power Over Ethernet (PoE) Yes Yes (Class 2)

AUDIO FEATURES

Audio Codec G.711, G.722, G.729a G.711, G.722, G.726, G.729a G.711, G.722, G.726, G.729a

Handset, Speaker,

Headset Volume 15 levels

8 levels

(includes echo cancellation

and distortion prevention)

8 levels (includes echo cancellation and distortion prevention)

Ringtones 32 27

Ringer Volume 7 levels + Off 6 levels + Off 6 levels + Off

Headset Port 2.5 mm

Electronic Hook Switch

Control Port 3.5mm Plantronics compatible None

Hearing Aid Compatible with Hearing Aid TIA-8013

KEYS

Keys (total1)24 (4 pages of 6) 28 52 28

FF Keys N/A 24 24 -

Navigator & Cancel Key On screen + menu keys Yes Yes

SOFTWARE FEATURES

Phone Book Entries Memory Dependent2500 - each with 5 numbers 500 - each with 5 numbers 100 - each with 5 numbers

Call Log Entries 100 in + 100 out 30 incoming calls + 30 outgoing calls

Conferencing 3 parties (within terminal – multi-party dependent on server)

IP FEATURES

SIP Accounts 642

SIP Compatibility RFC 3261 Standard SIP Server, Asterisk®,

BroadSoft®, Metaswitch, Brekeke RFC 3261 Standard SIP Server, Asterisk®, BroadSoft®, Metaswitch

IP Version IPv4

DHCP Client Yes

DNS Yes

HTTP/HTTPS Yes

SNTP Client Yes

VLAN (802.1q) Yes

QoS (DiffServ) Yes

CONFIGURATION

Plug & Play Configuration Server based configuration, TR-069, BroadSoft®Device Management Server

Manual Configuration Internal web Configurator, Local (LCD based) network configuration

KX-UT Series Highlights:

• HD Voice and PoE Enabled

• Two Data Ports for Simplied Wiring and Connecting a Second Device (select models)

• Certied for Use with BroadSoft® BroadWorks®, Digium® Asterisk®, Metaswitch, Brekeke and others

• Extensive CODEC support: G.711μ-law, G.711A-law, G722, G.726, G729a

• Environmentally Friendly—Power Consumption 1W in ECO Mode (select models)

• Two-year Limited Warranty

Home and Business Communications

SIP11127BROr1

Design and specications subject

to change without notice.

Home & Business Communications

Panasonic System Networks Company of America

Three Panasonic Way,

Secaucus, NJ 07094

(201) 348 - 7000

www.panasonic.com/sip
