Panasonic FV-10VEC2 Manuel utilisateur

FV-10VEC2

FV-10VEC2H

FV-10VE2

FV-10VE2H

CONTENTS

GENERAL SAFETY INFORMATION

DESCRIPTION

Model No.

2~3

READ AND SAVE THESE INSTRUCTIONS

Thank you for purchasing this Panasonic product.

Please read these instructions carefully before attempting to install, operate or service the

Panasonic product. Please carefully read the “GENERAL SAFETY INFORMATION” (P.2~3) of

this manual before use. Failure to comply with instructions could result in personal injury or

property damage. Please explain to users how to operate and maintain the product after

installation, and this booklet should be presented to users.

Please retain this booklet for future reference.

Installation and Operating Instructions

Energy Recovery Ventilator

WIRING DIAGRAM

WIRING METHOD

DUCT INSTALLATION

INSTALLATIONⅠ(WALL MOUNT)

INSTALLATIONⅠⅠ (CHAIN MOUNT)

START-UP PROCEDURE

OPERATION 13~15

TROUBLESHOOTING 18

MAINTENANCE 16~17

SPECIFICATIONS

PRODUCT SERVICE BACK COVER

7~8

5~6

8~11

4~5

10VC2M450A

This symbol is used to alert users not to disassemble the equipment.

When cutting or drilling into wall or ceiling, be careful not to damage electrical wiring

and other hidden utilities.

Canada only: Not to be installed in a ceiling thermally insulated to a value greater than

R40.

Never install the unit in a high humidity space, such as a bathroom, kitchen or laundry

room.

Do not disassemble the unit. It may cause fire or electric shock.

Use this unit only in the manner intended by the manufacturer. If you have any

questions, contact the manufacturer.

Installation work and electrical wiring must be performed by qualified person(s) in

accordance with all applicable codes and standards, including fire-rated construction.

Do not install with a method which is not approved in the instructions.

Ducted fans must always be vented to the outdoors.

Solid state controls may cause harmonic distortion which can cause motor humming

noise. To reduce the risk of fire or electric shock, do not use this unit with any solid-

state control device.

This symbol is used to alert users to a specific operating procedure that must be

followed in order to operate the unit safely.

This symbol is used to alert users to a specific operating procedure that must not be

performed.

This symbol is used to alert users to make sure of grounding when using the

equipment with the grounding terminal.

For Your Safety

Explanation of symbol word panels

To reduce the risk of injury, loss of life, electric shock, fire, malfunction, and damage to

equipment or property, always observe the following safety precautions.

The following symbols are used to classify and describe the type of instructions to be

observed.

The following symbol word panels are used to classify and describe the level of hazard, injury,

and property damage caused when the denotation is disregarded and improper use is

performed.

CAUTION

Denotes a potential hazard that could result in death or

serious injury.

Denotes a hazard that could result in minor injury.

Denotes a hazard that could result in property damage.

WARNING

GENERAL SAFETY INFORMATION

NOTICE

Ceiling joist and wall stud must be subjected to static load more than five times the

weight of the product.

The special-purpose or dedicated parts, such as mounting fixtures, must be used if such

parts are provided.

Do not kink the power cord.

The OA duct and EA duct must be connected directly to the outside.

Make certain that the electric service supply voltage is AC 120 V, 60 Hz.

These fans are intended for residential use only.

Do not install the unit where ducts are configured as shown below.

Adapter

Protect the power cord from sharp edges, oil, grease, hot surfaces, chemicals or other

objects.

When the product is to no longer be used, it must not be left in place but removed,

to prevent it from possibly falling.

Follow all local electrical and safety codes, as well as the National Electrical Code (NEC)

and the Occupational Safety and Health Act (OSHA).

Always disconnect the power source before working on or near the fan, motor, fixture

or wiring cover.

For general ventilating use only. Do not use to exhaust hazardous or explosive materials

and vapors.

Sufficient air is needed for proper combustion and exhausting of gases through the

flue (chimney) of fuel burning equipment to prevent backdrafting. Follow the heating

equipment manufacturer’s guideline and safety standards such as those published by

the National Fire Protection Association (NFPA), and the American Society for Heating

Refrigeration and Air Conditioning Engineers (ASHRAE) and the local code authorities.

Excessive bending Successive bending Squeezed duct Bend close to duct adapter

Disconnect power by switching off wall switch first, then main switch and unplug

before working on unit when replacing the jumper cable with wall switch.

Install the unit in the area where air temperature is above 50 °F (10 °C) to avoid

condensation in unit.

Do not install the unit in the area where the air stream temperature may exceed 104 °F

(40 °C).

The unit must be installed in a mechanical room, basement, or other conditioned space.

CAUTION

GENERAL SAFETY INFORMATION

NOTICE

Energy Recovery Introduction: Compared to HRV (Heat Recovery Ventilator), ERV can also

transfer humidity and recover energy from that humidity. ERV can exchange energy

between “stale” EA and “fresh” OA, by transferring heat and moisture into the incoming cold

air, and pre-cooling and reducing the humidity of the incoming hot air. This helps maintain a

fresh environment even when the heating or cooling system is not operating.

Heat&

Moisture

Fresh air Fresh air

Exhaust air

(EA)

Outside air

(OA)

Exhaust air

(EA)

Outside air

(OA)

Stale air

Indoor

Stale air

Indoor

Outdoor Outdoor

DESCRIPTION

WIRING DIAGRAM

Heat&

Moisture

FV-10VEC2/FV-10VE2

OnlyFV-10VEC2

WIRING DIAGRAM

WIRING

METHOD

Open knock out hole

Junction box

For FV-10VEC2H, FV-10VE2H

Earth

ground

AC 120 60Hz (Power supply)

Neutral

Earth

ground

Live

WHITE

BLACK

GREEN

Wire Nuts

FV-10VEC2H/FV-10VE2H

OnlyFV-10VEC2H

JUNCTION BOX

GREEN

WHITE

BLACK

GROUND

NEUTRAL

LIVE

R G

Installation work and electrical wiring must be performed by qualified person(s) in

accordance with all applicable codes and standards, including fire-rated construction.

WARNING

WIRING

METHOD

HVAC/AHU signal

Wall Switches

(1)The terminal of wall switch has been connected by jumper cable as factory default.

If connecting with wall switch, please remove the jumper cable.

Note

(2)The HVAC/AHU signal cord is optional, please connect it when you want to control

the HVAC/AHU.

If connecting with HVAC/AHU, the HVAC/AHU will turn on while ERV turns on.

(3)If you are not connecting to the HVAC/AHU, please open knock-out holes for wall

switch and boost switch connection only.

(4)Insert wires into the corresponding terminals deeply through the ribs.

Make sure the screw of terminal securely fastens the copper wire and the copper

wire is not exposed.

(5)Reinstall the wiring cover and maintenance plate.

Open knock out holes

Maintenance plate

Wiring cover

Jumper cable

Unit: inches (mm)

Wall switch cord/

HVAC/AHU signal

cord/Boost switch

cord

Copper wire

1/4 (7)

3 1/2~4

(90~100)

CAUTION

The capacity of wall switch, boost switch should be more than 120 V~3 A to control

the power of the product.

INSTALLATIONⅠ(WALL MOUNT)

This method can be used in stud as below.

Unit: inches (mm)

Note

(1)Attach with flanged edge facing outward and edge without flange facing upward

when mounting wall bracket.

(2)Choose the mounting hole on wall bracket according to the distance between studs.

Unit: inches (mm)

A B

24 (609.6)

16 (406.4)

19 (482.6) 17 1/2 (444.5)

14 1/2 (368.3)

22 1/2 (571.5)

Stud

4-long screws

(ST4.2X30)

Stud

Wall bracket

Floor

Edge without flange

Flange

>31 1/2 (800)

24 (609.6)

16 (406.4)

19 (482.6)

2-screws

(M4X8)

4-screws

(M4X8)

L plate

Install L plates

HangerⅠ

Install HangerⅠ

Claw

24 (609.6)

16 (406.4)

19 (482.6)

Mount hangerⅠand L plates.

Mount wall bracket.

2-long screws

(ST4.2x30)

INSTALLATIONⅠ(WALL MOUNT)

4-plug covers

Control panel comes to this side

Wall bracket

MethodⅠ- Simplified ducted installation (Return method)

Note

DUCT INSTALLATION

This method draws return air from the return air duct

of the air furnace and supplies an equal amount of

outside air farther downstream into the return duct.

(1)The ERV unit must be balanced.

(2)

It is mandatory that HVAC/AHU signal cord be connected.

(3)Check local codes and authority having

jurisdiction for acceptance.

Note

(1)Must Have 2-3 ft straight run on all duct attachments points

before elbow is more than 2 ft (610 mm).

(2)Unit is normally balanced on high speed with the furnace blower on.

(3)A minimum separation of 40 inches (1 m) is recommended between the two

direct connections.

(4)The exhaust air connection shall be upstream of the supply air connection to

prevent exhausting any fresh air.

(5)The distance between two outdoor hoods please see P.11.

(6)The airflow must be confirmed on site using the balancing procedures found in P.13.

36”

Air

furnace

(914 mm)

Min.

Dampers for

balancing

airflows

40" (1 m) Min.

Outdoors

Return

air Return air

HangerⅠ

Hang ERV on to wall bracket.3

Please use 3rd hole

in case it is not easy to

put screws due to Junction box.

DUCT INSTALLATION

This method draws return air from specific points in the house and supplies an equal

amount of outside air into the return air duct of the air furnace.

Return air ducts of ERV should be installed in areas of the home where the poorest indoor

air quality exists (bathroom and kitchen).

The air furnace blower should be running when the ERV is operating to evenly distribute the

outside air throughout the house.

Method

ⅠⅠ

- Partially dedicated ducted installation

Note

(1)The ERV unit must be balanced.

(2)It is mandatory that HVAC/AHU signal cord be

connected.

(3)Check local codes and authority having

jurisdiction for acceptance.

Note

(1)Must Have 2-3 ft straight run on all duct attachments points before elbow is more

than 2 ft (610 mm).

(2)Unit is normally balanced on high speed with the furnace blower on.

(3)The distance between two outdoor hoods please see P.11.

(4)The airflow must be confirmed on site using the balancing procedures found in P.13.

Air

furnace

(914 mm)

Min.

Dampers for

balancing airflows

Outdoors

Return air

Return air36”

Return air from various parts of home.

(i.e. bathrooms, kitchens, utility areas)

DUCT INSTALLATION

This method draws return air from specific points in the

house and supplies outside air to specific locations of

the house. This system is not connected to an air

furnace.

Return air ducts should be installed in areas of the

home where the poorest indoor air quality exists (bath-

room and kitchen). Supply air ducts should be installed

to all bedrooms and living areas.

Method

ⅠⅠⅠ

- Fully dedicated ducted installation

Note

(1)The ERV unit must be balanced.

(2)Check local codes and authority having jurisdiction for acceptance.

Note

(1)Must Have 2-3 ft straight run on all duct attachments points before elbow

is more than 2 ft (610 mm).

(2)The distance between two outdoor hoods please see P.11.

(3)The airflow must be confirmed on site using the balancing procedures

found in P.13.

Outdoors

Return air from various parts of home

(e.g. bathrooms, kitchens, utility areas)

Supply air to main

living areas (e.g.

bedrooms, living

room)

Autres manuels pour FV-10VEC2

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Ventilateur

Panasonic

Panasonic FV-12NS3 Manuel utilisateur

Panasonic

Panasonic FV-08VRE1 Manuel utilisateur

Panasonic

Panasonic Whisper Value-Lite FV-10VS1 Manuel utilisateur

Panasonic

Panasonic F-35TMH Manuel utilisateur

Panasonic

Panasonic Whisper Value-Lite FV-08VSL1 Manuel utilisateur

Panasonic

Panasonic FV-0510VSC1 Manuel utilisateur

Panasonic

Panasonic FV-05VS1 Manuel utilisateur

Panasonic

Panasonic WhisperSense FV-08VQCL5 Manuel utilisateur

Panasonic

Panasonic Whisper Green FV-08VKM3 Manuel utilisateur

Panasonic

Panasonic FV-0511VQ1 Manuel utilisateur

Panasonic

Panasonic FV-10NLF1 Manuel utilisateur

Panasonic

Panasonic F-60MZ2 Manuel utilisateur

Panasonic

Panasonic FV-20VEC1 Manuel utilisateur

Panasonic

Panasonic WhisperLite FV-11VQL5 Manuel utilisateur

Panasonic

Panasonic WhisperCeiling FV-30VQ3 Manuel utilisateur

Panasonic

Panasonic RG-R811HA Manuel utilisateur

Panasonic

Panasonic WhisperWelcome FV-05VFM2 Manuel utilisateur

Panasonic

Panasonic FV-05VFL1 Manuel utilisateur

Panasonic

Panasonic FV-15NLFS1 Manuel utilisateur

Panasonic

Panasonic WhisperWelcome FV-05VFM2 Manuel utilisateur

Panasonic

Panasonic FV-05VF2 Manuel utilisateur

Panasonic

Panasonic RG-C1315LA Manuel utilisateur

Panasonic

Panasonic F-48DFL Manuel utilisateur

Panasonic

Panasonic FV-0511VQC1 Manuel utilisateur

Manuels Ventilateur populaires d'autres marques

ELTA FANS

ELTA FANS H03VV-F Manuel utilisateur

Hunter

Hunter 20714 Manuel d'instructions

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manuel utilisateur

Hunter

Hunter Caraway Manuel d'instructions

Kompernass

Kompernass KH 1150 Manuel utilisateur

VES

VES FALA100/12V/TR Manuel utilisateur

Vertiv

Vertiv Liebert DCD Manuel utilisateur

Westinghouse

Westinghouse GFP Series Manuel utilisateur

Venmar

Venmar KUBIX HRV PLUS Series Manuel utilisateur

Maico

Maico ECR 31 Manuel utilisateur

Sonnenkonig

Sonnenkonig Dinky Manuel utilisateur

S&P

S&P ECOWATT HXBR Manuel utilisateur

Wider

Wider IMP03369BH Manuel utilisateur

Hinkley

Hinkley HIGHLAND Manuel utilisateur

Broan

Broan 766BN Manuel utilisateur

Premium

Premium PFS16022 Instructions de montage

Litex Industries

Litex Industries E-CGL52CB5C1 Manuel utilisateur

Lindab

Lindab LTDF Manuel utilisateur
