Panasonic F-30PLH Manuel utilisateur

.....................................

.......................................

............................................

.........................

F-30PLH

型號

30cm 起居室電風扇說明書

30cm Living Fan Operating Instructions

Model No.

電風扇

Electric Fan

Thank you for purchasing this Panasonic product.

多謝閣下選購本 Panasonic 產品。

在使用本產品之前，請仔細閱讀使用說明書，並將使用說明書妥善保管，以備將來需要時之用。

●

Before operating this product, please read the instructions carefully, and save this manual for future use.

●

頁數

Page

Contents

安全注意事項

如何裝配

使用方法

清潔 / 規格

Safety precautions

How to assemble

How to operate

Cleaning / Specifications

本產品只可在室內使用

This product is for indoor use only.

安全注意事項

Safety precautions

■切勿擅自拆散、修理或改造。

會引致火災或觸電。

禁止拆散

若本品故障時請找經銷商修理。

■不可接上220－230V∼，50Hz以外的電源。

否則可能會引起火警。

■裝配或拆除扇葉或保護網

　時不可按高度調節按紐。

馬達及柱部可能會快速升高而擊傷使用者。

■確定電源插頭完全插入插座。

若插頭插得不好，可能會引致觸電或

插頭過熱而造成火災。

不要使用已損壞的插頭或鬆脫的插頭。

Never try to take apart, repair

or modify this product.

It may cause fire or

electric shock.

Do not take apart

Contact the dealer for repairing

this product.

Do not connect this unit to power

supply other than 220－230V∼, 50Hz.

Otherwise it may cause fire.

禁止

Prohibited

禁止

Prohibited

Do not push the height

adjustment button when

assembling or removing blade

and guards.

Motor and pole may rise rapidly and

cause injury.

Make sure power plug is fully inserted into

socket.

Loose engagement of plug and socket

may cause electric shock or fire due to

overheat of plug.

Do not use damaged or loosen plug.

為了避免對您自己或其他人造成可能的傷害或財物損害，請務必注意以下安全注意事項。

The following symbols differentiate the levels of danger and injury that may result if the product is

not used specifically as instructed.

■無視或錯誤理解這些標誌，會產生下列兩種情況。

These safety precautions are provided for your protection. Please read and follow them carefully to

avoid unnecessary injury and damage to the product itself or other properties.

■

This symbol indicates that improper handling may cause a risk of death or

serious injury.

This symbol indicates that improper handling may cause a risk of injury or

damage to the product or to your properties.

This symbol indicates an action that

must not be performed.

This symbol indicates an action that

must be performed.

WARNING

CAUTION

■務必遵守的內容分類，用標誌區分說明如下：

本標誌所表示的內容為“可能造成人員重傷或死亡”。

本標誌所表示的內容為“可能造成人身傷害或其

他

物品損害”。

此標誌表示為禁止事項。此標誌表示為強制事項。

注意

警告

This manual uses a number of other symbols to indicate additional information for a particular item.

(The symbols given below are examples.)

請務必遵守

Always follow these precautions

30PLH

■勿令電線或插頭損壞。

■清潔本機前，請拔出電源插座。

引致受傷、觸電、甚至因短路引起火災。

■手濕時切勿接觸電源插頭。

可能會引致觸電。

■要定期清除電源插頭及插座上之灰塵。

如果電源插頭上積聚了灰塵，天氣潮濕時會

容易引致絕緣不良而導致火災。

請將電源插頭拔出，用乾布抹淨。

Do not damage power cord or power plug.

Be sure to disconnect the power plug before

cleaning the unit

Causing injury, electric shock or even

fire due to short circuit.

The unit may start operating unexpectedly

and electric shock may occur.

為免造成傷亡，如電源線損壞必須送交其製造商或製造商指定的維修代理或類似的合資格人士作更換。

If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly

qualified person in order to avoid a hazard.

禁止

Prohibited

手濕不可觸碰

No wet hand

拔掉插頭

Unplug

Never touch the plug if your hands are wet.

May cause electric shock.

Wipe off dust on the plug and socket periodically.

Accumulation of dust on plug in humid

season may cause poor insulation and

may result in fire.

Disconnect from power supply and use a piece of dry

cloth to clean the plug.

若長時期不使用風扇，請將電源插頭拔出。

Unplug the fan if it will not be used for a period.

例如對其加工、放在發熱器具附近，不正常地折曲或扭曲、

強行拉長、負重、把電線捆成一扎。

e.g. modify, put near heat generating appliance,

abnormally twist or bend, forcefully elongate, pull heavy

weight, bundle up power cord.

■扇葉或保護網未裝好時切勿開機。

引致受傷

■不可讓風扇沾水。

引起火災或觸電。

禁止沾水

禁止

Prohibited

Do not turn on the unit if blade or

guard is not installed properly.

Causing injury

Do not contact with water.

Causing fire or electric shock.

Avoid water

WARNING

警告

本機可能會無預期地開始運作，

且可能引致觸電。

WARNING

警告

■移動時切勿拉扯電源線。

可能損壞電線內部，

導致火災或觸電事故。

■切勿在電風扇運作時拉緊電線。

可能導致短路或折斷電線內的

金屬線，這樣可能會發生火災

或觸電。

■切勿將電風扇放近熱源。

塑膠零件可能會

熔化並導致火災。

禁止

Prohibited

禁止

Prohibited

禁止

Prohibited

禁止

Prohibited

Do not pull on the power cord when

carrying the unit.

It may damage the wires

inside the cord, and fire or

electric shocks may occur.

■請勿擠壓電源線。

若未能注意這種情況，

電源線可能發生短路或破損，

並可能導致火災或電擊。

禁止

Prohibited

Do not clamp the power cord.

If this is not observed, short-circuits

or breakages may occur in the cord,

and fire or electric shocks may result.

Do not stretch the power cord while

the unit is in use.

It may cause shortcircuits or

broken wires which may cause

fire or electric shocks.

Do not place the unit near a heat source.

Plastic parts may melt

and cause fire.

Do not do anything that may damage

the power cord or power plug.

● Power cord must not be damaged, modified, bent,

pulled, twisted or wrapped into a bundle.

Also, do no place heavy objects on top of it or clamp in.

(If damaged power cord is being used, electric shock or

fire may occur.)

● Consult distributors to carry out any repairs.

● If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

■切勿損壞電源線或插座。

˙切勿割劃、改裝、過度扭曲、拉扯、扭轉和擰絞電源線。

　切勿在電源線上放置重物或擠壓。

　(使用已破損的電源線可能會導致觸電或火災事故。)

˙要修理時，請與商戶聯繫。

˙如果機器的電源線損壞了，必須找該機器的廠商，

　維修服務中心或合資格技術人員替您更換以防危險發生。

安全注意事項

Safety precautions

請務必遵守

Always follow these precautions

30PLH

■不要在以下場所使用風扇：接近氣體爐具；

有易燃氣體的地方；有雨淋或容易被滴水的地方。

可能會吹熄爐火，引致漏氣及爆炸；

引致觸電、短路、火災。

■不要把風扇放置在不平坦的地方或障礙物周圍。

容易引致風扇倒下而導致受傷。

禁止

Prohibited

禁止

Prohibited

Do not use under the following situations:

Near gaseous fuel cooker and inflammable gas;

place which is exposed to rain fall or water pour.

Don’t place the fan on unstable surface or nearobstacles.

Risk on injury by falling fan.

May cause gaseous fuel leakage and explosion;

Leading to electric shock, over heat, fire and

explosion.

■不要長時間把風扇吹著身體。

導致身體不適。

禁止

Prohibited

Avoid continuous exposure to direct wind from the fan.

■切勿用手指插入網罩中或各可動部分。

■請勿在直接日照、雨淋風吹的位置使用。

引致受傷。

禁止接觸

Don’t touch

Do not put your fingers into the guard or any

moving part of the fan.

It may cause discomfort.

Causing injury.

■要拔出電源插頭時，必須抓住電源插頭來拔，

　不能拉電源線。

■將機桿牢固地插入底座之前，切勿操作機組。

可能會造成電線短路或

斷線而引致火災或觸電。

Hold the plug when disconnect from

main supply, never pull the cord.

Do not operate the set before the

pole is firmly inserted onto the base.

May cause short circuit or damage of

power supply cord and lead to fire or

electric shock.

注意 Notice

Do not put the fan near insecticide, oil corrosive solvent (may cause bad effects on quality or damages).

Do not put the fan in high temperature, high humidity or dusty place (may cause bad effects on quality or damages).

■不要把風扇放在接近殺蟲劑、油或腐蝕性物品的地方使用 (引致風扇變質或損壞)。

■不要把風扇放在高溫、濕度高或塵埃多的地方使用 (引致風扇變質或損壞)。

禁止

Prohibited

禁止

Prohibited

Being unstable, may cause the fan to fall.

This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance

by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the appliance.

■本產品不適合有殘障、智障或精神障礙的人士、缺乏經驗及常識者 (包括兒童) 使用，除非負責他們安全的人士在場看護或指導。

　兒童在使用本產品期間，需要有人在場看護，以防將產品當作玩具。

如果風扇狀態不穩定，則可能會倒下。

Do not use in places which are exposed to

direct sunlight, rain or wind.

The unit may overheat, and fire or electric shocks may occur.

本機可能會過熱、著火或引致觸電。

如何裝配 How to assemble

裝上後保護網

除下套管

逆時針方向擰下

Assemble Rear Guard

Remove Shaft Tube

除下套管

Remove

Shaft Tube

Turn anti-clockwise

to release

Assemble Blade

Blade slot

扇葉的安裝

凹位

扇葉固定針

Assemble Front Guard

安裝前保護網

If guard ring falls out from front guard

Clip on all remaining notches

Front Guard

Place the “Marked spot” directly

under the notch

Guard Ring

Notch

Marked Spot

■如果保護網套環由前保護網脫落

將「配合標記」扣入爪部

將餘下的爪全部扣上

保護網套環

爪

配合標記

前保護網

Installing the base

Insert the projection on the stand into the

hole in the base, and then push the stand

into the base until it clicks into place.

Projection

Hole

Hold the main unit so that it is facing

downward as shown in the illustration,

and then turn the nut clockwise to secure

the stand to the base.

Tighten the nut

securely so that

it will not loosen.

Nut

When removing the stand from the base

Remove the nut, and then slide the two tabs

of the base in the directions of the arrows to

remove the base.

Tabs

調整片

移除螺帽，然後將底座的兩個調整片朝箭頭的

方式移動來移除底座。

從底座移除架子時

螺帽

牢牢地鎖緊螺帽，

讓螺帽不致鬆脫。

握住主機體，讓它面朝下 (如圖例所示)，

然後以順時針方向旋轉螺帽，

將架子固定到底座。

孔洞

凸桿

將架子的凸桿插入底座的孔洞中，

然後將架子推入底座中，

直到卡入定位為止。

安裝底座

Motor

Control panel

Projections

(3 places)

Height adjustment

button

Motor shaft (wipe off oil)

Power plug

Stand

Power cord

Base

馬達

凸桿 (3個位置)

馬達軸 (擦去油料)

Motor shaft (wipe off oil)

馬達軸 (擦去油料)

電源插座

架子

電源線

底座

操作面板

Align the pin on the motor shaft with the groove in the fan.

將馬達軸上的固定針對齊風扇中的凹槽。

後保護網

保護網固定螺母

(以順時針方向旋轉)

旋蓋

(

逆時針方向轉

)

前保護網

鉤子

扣

鉤子

鎖緊

孔洞 (3 個位置)

標記

Rear Guard

Guard Set Nut

(Turn clockwise)

Spinner

(Turn anti-clockwise)

Front guard

Hook

Clip

扣

Clip

Hook

鉤子

Hook

Tighten

Mark

Holes (3 places)

Note on installation method for front guard

Insert in order from top

to bottom

(all the way around)

Securely engage the clip in the

position shown in the illustration

at right.

Push in until it clicks into place.

Engage the clip.

前保護網安裝方法之注意事項

以由上到下的順序插入

(一路到底)

將扣固定在右圖所示的位置。

推入扣，直到卡入定位為止。

使用扣。

搖頭控制手柄

Oscillation knob

扇葉

固定針

高度調節按鈕

注意 Notice

請確保擰緊保護網固定螺母和旋蓋以防在使用中鬆脫。

Please tighten the guard set nut and spinner firmly

to prevent them from loosening.

Blade

扇葉

Match front and rear guards

Rear Guard

前後保護網對位後保護網

請不要扔掉套管，以便收藏風扇時套回 (有助防止馬達軸氧化)。

Please keep the plastic tube for future storing

(Prevent motor shaft from rusting).

30PLH

裝上後保護網

除下套管

逆時針方向擰下

Assemble Rear Guard

Remove Shaft Tube

除下套管

Remove

Shaft Tube

Turn anti-clockwise

to release

Assemble Blade

Blade slot

扇葉的安裝

凹位

扇葉固定針

Assemble Front Guard

安裝前保護網

If guard ring falls out from front guard

Clip on all remaining notches

Front Guard

Place the “Marked spot” directly

under the notch

Guard Ring

Notch

Marked Spot

■如果保護網套環由前保護網脫落

將「配合標記」扣入爪部

將餘下的爪全部扣上

保護網套環

爪

配合標記

前保護網

Installing the base

Insert the projection on the stand into the

hole in the base, and then push the stand

into the base until it clicks into place.

Projection

Hole

Hold the main unit so that it is facing

downward as shown in the illustration,

and then turn the nut clockwise to secure

the stand to the base.

Tighten the nut

securely so that

it will not loosen.

Nut

When removing the stand from the base

Remove the nut, and then slide the two tabs

of the base in the directions of the arrows to

remove the base.

Tabs

調整片

移除螺帽，然後將底座的兩個調整片朝箭頭的

方式移動來移除底座。

從底座移除架子時

螺帽

牢牢地鎖緊螺帽，

讓螺帽不致鬆脫。

握住主機體，讓它面朝下 (如圖例所示)，

然後以順時針方向旋轉螺帽，

將架子固定到底座。

孔洞

凸桿

將架子的凸桿插入底座的孔洞中，

然後將架子推入底座中，

直到卡入定位為止。

安裝底座

Motor

Control panel

Projections

(3 places)

Height adjustment

button

Motor shaft (wipe off oil)

Power plug

Stand

Power cord

Base

馬達

凸桿 (3個位置)

馬達軸 (擦去油料)

Motor shaft (wipe off oil)

馬達軸 (擦去油料)

電源插座

架子

電源線

底座

操作面板

Align the pin on the motor shaft with the groove in the fan.

將馬達軸上的固定針對齊風扇中的凹槽。

後保護網

保護網固定螺母

(以順時針方向旋轉)

旋蓋

(

逆時針方向轉

)

前保護網

鉤子

扣

鉤子

鎖緊

孔洞 (3 個位置)

標記

Rear Guard

Guard Set Nut

(Turn clockwise)

Spinner

(Turn anti-clockwise)

Front guard

Hook

Clip

扣

Clip

Hook

鉤子

Hook

Tighten

Mark

Holes (3 places)

Note on installation method for front guard

Insert in order from top

to bottom

(all the way around)

Securely engage the clip in the

position shown in the illustration

at right.

Push in until it clicks into place.

Engage the clip.

前保護網安裝方法之注意事項

以由上到下的順序插入

(一路到底)

將扣固定在右圖所示的位置。

推入扣，直到卡入定位為止。

使用扣。

搖頭控制手柄

Oscillation knob

扇葉

固定針

高度調節按鈕

注意 Notice

請確保擰緊保護網固定螺母和旋蓋以防在使用中鬆脫。

Please tighten the guard set nut and spinner firmly

to prevent them from loosening.

Blade

扇葉

Match front and rear guards

Rear Guard

前後保護網對位後保護網

請不要扔掉套管，以便收藏風扇時套回 (有助防止馬達軸氧化)。

Please keep the plastic tube for future storing

(Prevent motor shaft from rusting).

使用方法 How to operate

1 2 3

SPEED Button

Press this button to change wind speed.

Light on

Properly adjust wind speed and activate oscillation can

enhance the cooling effect.

風量掣

SPEED Button

風量掣

按此鍵切換風量

亮燈

適當地調節風力及啟動風扇搖頭能增強涼快感覺

OFF·ON Button

Press to toggle OFF·ON

The speed is “1” at the first time after connecting to

power supply.

Other buttons will not function when the fan is turned off.

Memory function

When turn on the fan, it operates at previously set mode,

No memory function for “Timer”

Memory will be cleared when cut off power

Using with air-conditioner can save energy

開關鍵

OFF·ON Button

開關鍵

每按鍵一次切換開關狀態

記憶功能

第一次接通電源後，開始是慢檔

風扇未開時其他按掣沒有作用

關機後再次關機，運轉狀態和關機前相同

時間掣並無記憶功能

切斷電源後記憶會消失

與空調配合使用能有效節能

注意 Notice

In order to save energy, disconnect unit from power source if it will not be used for a period.

(The fan consumes about 1W power even at “OFF” mode)

When the button is pressed there will be a sound that indicates the operation.

To avoid the possibility of causing injury to users or damaging properties, please follow all the explanation

written below.

The manufacturer is not responsible for accidents and injuries caused by defective or deficient installation.

The fan may vibrate and make a loud noise if the supporting surface is not flat or level. If this happens,

please move the fan a little bit or adjust its height until the vibration and noise stop.

若長時間不使用風扇時，請拔電源插頭以節省能源 (即使在關機狀態風扇仍會消耗若1W的電能)

按下按鈕時，會響起操作指示聲。

有時風扇會因承托面凹凸不平而震動並發出雜聲，這時請略為移動風扇的位置或調較風扇的高度直到風扇

不再震動及發出雜聲。

請根據以下書面說明操作，以避免使用者受傷或損害財物。

製造商無須對因安裝瑕疵或安裝不完全所造成的事故或傷害負責。

注意 Notice

Use different combinations of speed,

timer setting and rhythm function to

achieve most comfortable feeling.

RHYTHM Button

Press to toggle “Rhythm” or “Continuous” operation

The wind strength is automatically changed at about 4 sec.

intervals. (Speed indicating light will blink when rhythm

mode is activated)

善用不同的風量、時間掣和自然

風的組合能令使用者倍感舒適。

自然風掣

RHYTHM Button

自然風掣

按此鍵以切換自然風或連續運轉模式

自然風就是每隔4秒自動改變風速 (自然風模式啟動時風速

指示燈會閃爍)

1 2 4

Proper use of Timer can save energy

and prevent user from discomfort.

TIMER Button

Press this button to set the timer as shown below.

Light on

Indicating lamp will change accordingly as remaining

time reduces.

Cancel

適當地使用時間掣既可省電又可避免

睡著時著涼

每按一次時間掣如下圖所示變換時間掣的設定

時間掣

TIMER Button

時間掣

取消

亮燈

指示燈會隨剩餘時間減少而改變

30PLH

1 2 3

SPEED Button

Press this button to change wind speed.

Light on

Properly adjust wind speed and activate oscillation can

enhance the cooling effect.

風量掣

SPEED Button

風量掣

按此鍵切換風量

亮燈

適當地調節風力及啟動風扇搖頭能增強涼快感覺

OFF·ON Button

Press to toggle OFF·ON

The speed is “1” at the first time after connecting to

power supply.

Other buttons will not function when the fan is turned off.

Memory function

When turn on the fan, it operates at previously set mode,

No memory function for “Timer”

Memory will be cleared when cut off power

Using with air-conditioner can save energy

開關鍵

OFF·ON Button

開關鍵

每按鍵一次切換開關狀態

記憶功能

第一次接通電源後，開始是慢檔

風扇未開時其他按掣沒有作用

關機後再次關機，運轉狀態和關機前相同

時間掣並無記憶功能

切斷電源後記憶會消失

與空調配合使用能有效節能

注意 Notice

In order to save energy, disconnect unit from power source if it will not be used for a period.

(The fan consumes about 1W power even at “OFF” mode)

When the button is pressed there will be a sound that indicates the operation.

To avoid the possibility of causing injury to users or damaging properties, please follow all the explanation

written below.

The manufacturer is not responsible for accidents and injuries caused by defective or deficient installation.

The fan may vibrate and make a loud noise if the supporting surface is not flat or level. If this happens,

please move the fan a little bit or adjust its height until the vibration and noise stop.

若長時間不使用風扇時，請拔電源插頭以節省能源 (即使在關機狀態風扇仍會消耗若1W的電能)

按下按鈕時，會響起操作指示聲。

有時風扇會因承托面凹凸不平而震動並發出雜聲，這時請略為移動風扇的位置或調較風扇的高度直到風扇

不再震動及發出雜聲。

請根據以下書面說明操作，以避免使用者受傷或損害財物。

製造商無須對因安裝瑕疵或安裝不完全所造成的事故或傷害負責。

注意 Notice

Use different combinations of speed,

timer setting and rhythm function to

achieve most comfortable feeling.

RHYTHM Button

Press to toggle “Rhythm” or “Continuous” operation

The wind strength is automatically changed at about 4 sec.

intervals. (Speed indicating light will blink when rhythm

mode is activated)

善用不同的風量、時間掣和自然

風的組合能令使用者倍感舒適。

自然風掣

RHYTHM Button

自然風掣

按此鍵以切換自然風或連續運轉模式

自然風就是每隔4秒自動改變風速 (自然風模式啟動時風速

指示燈會閃爍)

1 2 4

Proper use of Timer can save energy

and prevent user from discomfort.

TIMER Button

Press this button to set the timer as shown below.

Light on

Indicating lamp will change accordingly as remaining

time reduces.

Cancel

適當地使用時間掣既可省電又可避免

睡著時著涼

每按一次時間掣如下圖所示變換時間掣的設定

時間掣

TIMER Button

時間掣

取消

亮燈

指示燈會隨剩餘時間減少而改變

使用方法 How to operate

36° 36°

14°

Oscillation

搖頭

Adjustment of Wind Direction

風向調節

Height Adjustment

高度調節

搖頭角度80°

按下搖頭拉上停止

搖頭控制手柄

可左右自由調節可上下調節

高度調節按鈕

升高：按下調節鈕，將升降桿提高至所

　　　需位置後放開按鈕。

下降：將升降桿按下至所需位置。

Oscillation angle 80º

Push down to

oscillate

Pull up to stop

Oscillation knob

Adjust

horizontally

Adjust vertically

Height adjustment button

Elevating: Push and hold the adjustment

button, pull up the slide pole to

desired position, then release

the button.

Lowering: Push down the slide pole to

desired position.

須知 Notice

清潔 Cleaning

Specifications

防止刮花塑膠部份，請不要用乾布大力擦拭。

防止機身變質、變色，請不要用稀釋劑、石油精、酒精、去污粉、鹼性清潔劑等清洗。

使用化學抹布時，請先詳閱其使用說明。

去污粉

鹼性清潔劑

石油精

酒精稀釋劑

規格

電壓

50 36 1040 200220

230

50 38 1050 202 44

2 3.6

高H 690∼875

闊W 367

深D 350

0°, 80°

頻率轉速搖頭角度電線長度重量尺寸風速風量耗電量

Be sure to disconnect the power plug before cleaning the unit.

Rubbing too heavily with dry cloth may scratch the surface of plastic parts.

Do not use thinner, benzine, alcohol, cleaning powder, alkaline detergent, etc.

When using chemically treated cloth, please follow its instructions.

Cleaning

powder

Benzine Thinner

Alkaline

Detergent

Alcohol

Voltage

(V~)

Frequency

(Hz)

Power

(W)

Cord Length

(m)

Weight

(kg)

Dimension

(mm)

r.p.m.

(r/min.)

Air Velocity

(m/min.)

OscillationAir Volume

(m3/min.)

扣環

扇葉

升降桿

控制面板

底座

Rear guard

Guard ring

Front guard

Blade

Slide pole

Control panel

Base

清潔本機前，請拔出電源插座。

後保護網

前保護網

Stand

架子

Dampen a cloth, wring it out firmly, and then use it to wipe the

outer part of the main unit.

· For stubborn stains, use water mixed with a small amount of

diluted kitchen detergent.

弄濕抹布，用力扭乾，然後用來抹拭主機外圍。

˙要清除頑固污漬，可用水混合少量稀釋的廚房清潔劑一起清洗。

Autres manuels Panasonic Ventilateur

Panasonic

Panasonic WhisperCeiling FV-15VQ4 Manuel utilisateur

Panasonic

Panasonic FV-10CG2H Guide de l'utilisateur

Panasonic

Panasonic FV-0511VQ1 Manuel utilisateur

Panasonic

Panasonic fv-30bg2h Manuel utilisateur

Panasonic

Panasonic F-60XDN Manuel utilisateur

Panasonic

Panasonic FY-150ZDY8 Manuel utilisateur

Panasonic

Panasonic RG-C1315LA Manuel utilisateur

Panasonic

Panasonic FV-0511VQ1 Manuel utilisateur

Panasonic

Panasonic F-M14D9 Instructions de montage

Panasonic

Panasonic WhisperSense FV-08VQCL6 Manuel utilisateur

Panasonic

Panasonic F-25UGA Manuel utilisateur

Panasonic

Panasonic F-48MZ2 Manuel utilisateur

Panasonic

Panasonic F-35TMH Manuel utilisateur

Panasonic

Panasonic FV-17CU8 Manuel utilisateur

Panasonic

Panasonic WhisperCeiling FV-20VQ3 Manuel utilisateur

Panasonic

Panasonic FV-0511VF1 Manuel utilisateur

Panasonic

Panasonic FV-11VH1 Manuel utilisateur

Panasonic

Panasonic FV-30BY1 Manuel utilisateur

Panasonic

Panasonic Whisper Green-Lite FV-08VKL1 Manuel utilisateur

Panasonic

Panasonic FY-E15DZ1 Manuel technique

Panasonic

Panasonic F-60TAN Manuel utilisateur

Panasonic

Panasonic RG-R811A Manuel utilisateur

Panasonic

Panasonic WhisperGreen FV-13VKS3 Manuel utilisateur

Panasonic

Panasonic WhisperCeiling FV-20VQ3 Manuel utilisateur

Manuels Ventilateur populaires d'autres marques

ELTA FANS

ELTA FANS H03VV-F Manuel utilisateur

Hunter

Hunter 20714 Manuel d'instructions

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manuel utilisateur

Hunter

Hunter Caraway Manuel d'instructions

Kompernass

Kompernass KH 1150 Manuel utilisateur

VES

VES FALA100/12V/TR Manuel utilisateur

Vertiv

Vertiv Liebert DCD Manuel utilisateur

Westinghouse

Westinghouse GFP Series Manuel utilisateur

Venmar

Venmar KUBIX HRV PLUS Series Manuel utilisateur

Maico

Maico ECR 31 Manuel utilisateur

Sonnenkonig

Sonnenkonig Dinky Manuel utilisateur

S&P

S&P ECOWATT HXBR Manuel utilisateur

Wider

Wider IMP03369BH Manuel utilisateur

Hinkley

Hinkley HIGHLAND Manuel utilisateur

Broan

Broan 766BN Manuel utilisateur

Premium

Premium PFS16022 Instructions de montage

Litex Industries

Litex Industries E-CGL52CB5C1 Manuel utilisateur

Lindab

Lindab LTDF Manuel utilisateur
