Panasonic ES-SA40 Manuel utilisateur

Operating Instructions

(Household) Rechargeable Shaver

Model No. ES‑SA40

Before operating this unit, please read these instructions completely and save

them for future use.

English 2

ES‑SA40_ARA.indb 1 2010/11/15 13:15:35

EN1

Important

Before use

This WET/DRY shaver can be used for wet shaving with shaving lather or

for dry shaving.You can use this watertight shaver in the shower and clean

it in water. The following is the symbol of Wet shaver. The symbol means

that the hand‑held part may be used in a bath or shower.

Treat yourself to wet lather shaves for at least three weeks and notice the

difference. Your Panasonic WET/DRY shaver requires a little time to get

used to because your skin and beard need about a month to adjust to any

new shaving method.

Using the shaver

Caution ‑ The outer foil is very thin and can be damaged if not used

correctly. Check that the foil is not damaged before using the shaver. Do

not use the shaver if the foil etc. is damaged as you will cut your skin.

Charging the shaver

Do not use any charging adaptor other than one speciﬁcally designed for

this model (RE7‑67). Plug in the adaptor into a household outlet where

there is no moisture and handle it with dry hands. The shaver may become

warm during use and charging. However, this is not a malfunction. Do not

charge the shaver where it will be exposed to direct sunlight or other heat

sources.

Adequate ambient temperature for charging is 0‑40 °C.

The supply cord cannot be replaced. If the cord is damaged, the appliance

should be scrapped.

Cleaning the shaver

Warning ‑ Remove the shaver from the charging adaptor before cleaning it

to prevent electric shock.

If you clean the shaver with water, do not use salt water or hot water. Do

not soak the shaver in water for a long period of time. Wipe it with a cloth

dampened with soapy water. Do not use thinner, benzine or alcohol.

Storing the shaver

Remove the shaver from the charging adaptor when storing it. This

appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction



ES‑SA40_ARA.indb 1 2010/11/15 13:15:35

EN2

concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the

appliance. Keep these operating instructions in a safe place.

SPECIFICATIONS

Power source: See the name plate on the product.

Motor voltage: 1.2 V DC

Charging time: Approx. 8 hours

This product is intended for household use only.

Parts identiﬁcation































Protective cap

Outer foil section

Outer foil

Foil frame

Inner blade

Main body

Foil frame release buttons

Switch lock button

0/1 switch

Appliance socket

Trimmer

Trimmer handle

Charging adaptor (RE7‑67)

Charging plug

Charge indicator lamp

Cleaning brush

ES‑SA40_ARA.indb 2 2010/11/15 13:15:35

EN3

Charging

Charge

Perform the following steps to charge the shaver if it seems to lose the speed.

You can fully charge the shaver in 8 hours.

A full charge will supply enough power for approx. 7 shaves of 3 minutes

each.

1Turn off the shaver and

insert it in the charging

adaptor as illustrated.

2Plug in the adaptor into a

household outlet.

The charge indicator lamp glows and stays on until the shaver is removed

from the charging adaptor.

•

ES‑SA40_ARA.indb 3 2010/11/15 13:15:36

EN4

Using the shaver

Shave

90˚

1Depress the switch lock

button and slide the 0/1

switch upwards.

2Hold the shaver as

illustrated above and

shave.

Start out shaving by applying gentle pressure to your face. Stretch your

skin with your free hand and move the shaver back and forth in the

direction of your beard.You may gently increase the amount of pressure

as your skin becomes accustomed to this shaver. Applying excessive

pressure does not provide a closer shave.

•

Using the trimmer

Slide the trimmer handle up. Place at a right

angle to your skin and move downwards to trim

your sideburns.



ES‑SA40_ARA.indb 4 2010/11/15 13:15:36

EN5

Cleaning

Clean

1. Remove the shaver from the charging

adaptor.

2. Apply some hand soap and some water

to the outer foil.

3. Turn the shaver on.

4. Turn the shaver off after 10‑20 seconds.

5. Remove the outer foil section and turn the

shaver on.

6. Clean the shaver and the outer foil

section with running water.

7. Wipe off any drops of water with a dry

cloth.

8. Dry the outer foil section and the shaver

completely.

9. Attach the outer foil section to the shaver.

ES‑SA40_ARA.indb 5 2010/11/15 13:15:36

EN6

Replacing the outer foil and the inner blade

outer foil once every year

inner blade once every two years

Replacing the outer foil

1. Press the foil frame release buttons and

lift the outer foil section upwards as

illustrated.

2. Gently push the outer foil in the way as

illustrated. Then it will pop up from the foil

frame.

3. The new outer foil should be slightly bent

and pushed in until it is hooked in the foil

frame.

Replacing the inner blade

1. Press the foil frame release buttons and

lift the outer foil section upwards as

illustrated.

2. Remove the inner blade as illustrated.

Do not touch the edges (metal parts) of

the inner blade to prevent injury to your

hand.

3. Insert the inner blade until it clicks as

illustrated.

•

2 3



ES‑SA40_ARA.indb 6 2010/11/15 13:15:37

EN7

Cleaning with the brush

(A)

(B)

1. Clean the inner blade using the short

brush by moving it in direction (A).

Clean the outer foil, the shaver body and

the trimmer using the long brush.

Do not move the short brush in direction

(B) as it will damage the inner blade and

affect its sharpness.

Do not use the short brush to clean the

outer foil.

•

Removing the built-in rechargeable battery

Remove the built‑in rechargeable battery before disposing of the shaver.

Please make sure that the battery is disposed of at an ofﬁcially designated

location if there is one. Do not dismantle or replace the battery so that you

can use the shaver again. This could cause ﬁre or an electric shock. Replace

it at an authorized service center.

Remove the shaver from the charging adaptor when removing the battery.

Perform steps 1to :and lift the battery, and then remove it.

•





















For environmental protection and recycling of materials

This shaver contains a Nickel‑Metal Hydride battery.

Please make sure that the battery is disposed of at an ofﬁcially assigned

location, if there is one in your country.

ES‑SA40_ARA.indb 7 2010/11/15 13:15:37
