SQT0625
M0115KZ0
Basic Operating Instructions
Digital Camera
Model No. DMC-TZ70/DMC-ZS50
Please read these instructions carefully before using this product, and
save this manual for future use.
More detailed instructions on the operation of this camera
are contained in “Operating Instructions for advanced
features (PDF format)” in the supplied CD-ROM.
GA GH
2 SQT0625 (ENG)
Dear Customer,
We would like to take this opportunity to thank you for purchasing this Panasonic
Digital Camera. Please read these Operating Instructions carefully and keep
them handy for future reference. Please note that the actual controls and
components, menu items, etc. of your Digital Camera may look somewhat
different from those shown in the illustrations in these Operating Instructions.
Carefully observe copyright laws.
• Recording of pre-recorded tapes or discs or other published or broadcast
material for purposes other than your own private use may infringe copyright
laws. Even for the purpose of private use, recording of certain material may
be restricted.
Information for Your Safety
WARNING:
To reduce the risk of fire, electric shock or product damage,
•Do not expose this unit to rain, moisture, dripping or
splashing.
•Use only the recommended accessories.
•Do not remove covers.
•Do not repair this unit by yourself. Refer servicing to
qualified service personnel.
The socket outlet shall be installed near the equipment and shall be
easily accessible.
■Product identification marking
Product Location
Digital camera Bottom
(ENG) SQT0625 3
■About the battery pack
CAUTION
• Danger of explosion if battery is incorrectly replaced. Replace
only with the type recommended by the manufacturer.
• When disposing of the batteries, please contact your local
authorities or dealer and ask for the correct method of disposal.
• Do not heat or expose to flame.
• Do not leave the battery(ies) in a car exposed to direct sunlight for a
long period of time with doors and windows closed.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above
60 °C or incinerate.
■About the AC adaptor (supplied)
CAUTION!
To reduce the risk of fire, electric shock or product damage,
•Do not install or place this unit in a bookcase, built-in cabinet or in
another confined space. Ensure this unit is well ventilated.
• The unit is in the standby condition when the AC adaptor is connected. The
primary circuit is always “live” as long as the AC adaptor is connected to an
electrical outlet.
4 SQT0625 (ENG)
■Cautions for Use
• Do not use any other USB connection cables except the supplied one or a
genuine Panasonic USB connection cable (DMW-USBC1: optional).
• Always use a genuine Panasonic AV cable (DMW-AVC1: optional).
• Use a “High Speed HDMI micro cable” with the HDMI logo. Cables that do not
comply with the HDMI standards will not work.
“High Speed HDMI micro cable” (Type D-Type A plug, up to 2 m long)
Keep this unit as far away as possible from electromagnetic equipment
(such as microwave ovens, TVs, video games etc.).
• If you use this unit on top of or near a TV, the pictures and/or sound on this
unit may be disrupted by electromagnetic wave radiation.
• Do not use this unit near cell phones because doing so may result in noise
adversely affecting the pictures and/or sound.
• Recorded data may be damaged, or pictures may be distorted, by strong
magnetic fields created by speakers or large motors.
• Electromagnetic wave radiation may adversely affect this unit, disturbing the
pictures and/or sound.
• If this unit is adversely affected by electromagnetic equipment and stops
functioning properly, turn this unit off and remove the battery or disconnect AC
adaptor (supplied). Then reinsert the battery or reconnect AC adaptor and turn
this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
• If you record near radio transmitters or high-voltage lines, the recorded
pictures and/or sound may be adversely affected.
(ENG) SQT0625 5
For Singapore only
Complies with
IDA Standards
DB01017
6 SQT0625 (ENG)
Contents
Information for Your Safety .... 2
Before use................................ 7
Standard accessories ............. 8
Names and Functions
of Main Parts............................ 9
Inserting and removing the
battery or SD memory card
(optional) ................................ 12
Charging the battery ............. 13
Setting the clock.................... 15
Setting the menu ................... 16
Holding the camera ............... 17
Recording pictures using
the viewfinder ........................ 17
Taking pictures with
automatic settings
[Intelligent Auto] Mode.......... 18
Recording motion pictures... 21
Using the control ring/
control dial ............................. 23
Registering preferred
functions to the
[Fn1] / [Fn2] button................ 25
Taking pictures with the
composition determined
[Composition Guide]............. 25
Viewing your pictures ........... 26
Deleting pictures ................... 26
What you can do with the
Wi-Fi®function/
NFC function.......................... 27
Using the camera by
connecting it to a
smartphone/tablet ................. 28
Reading the Operating
Instructions (PDF format) ..... 32
Storing recorded still
pictures and motion pictures
on your PC ............................. 33
Copying still pictures and
motion pictures...................... 34
Troubleshooting .................... 35
Specifications ........................ 37
(ENG) SQT0625 7
Before use
■Camera handling
●Keep the camera away from excessive vibration, force, or pressure.
●The camera is not dust resistant, splash resistant, or waterproof.
Avoid using the camera in places with excessive dust or sand, or where
water can come into contact with the camera.
●Do not allow camera to come into contact with pesticides or volatile
substances (can cause surface damage or coating to peel).
■
Condensation (When the lens, the LCD monitor or the viewfinder is fogged up)
●
Condensation may occur when the camera is exposed to sudden changes of
temperature or humidity. Avoid these conditions, which may make the lens,
the LCD monitor or the viewfinder dirty, cause mould, or damage the camera.
●If condensation does occur, turn off the camera and wait about two hours
before using it. Once the camera adjusts to the surrounding temperature,
the fogging will clear naturally.
■Caring for your camera
●Before cleaning the camera, remove the battery or disconnect the power
plug from the outlet.
●Do not press the LCD monitor with excessive force.
●Do not press the lens with excessive force.
●Do not keep rubber or plastic products in contact with the camera for a long
period of time.
●Do not use solvents such as benzine, thinner, alcohol, kitchen detergents,
etc., to clean the camera, since it may deteriorate the external case or the
coating may peel off.
●Do not leave the camera with the lens facing the sun, as rays of light from
the sun may cause it to malfunction.
●Do not extend the supplied cord or cable.
●While the camera is accessing the card or built-in memory (for an operation
such as picture writing, reading, deleting, or formatting), do not turn off the
camera or remove the battery, card, AC adaptor (supplied).
●The data on the built-in memory or the card may be damaged or lost due to
electromagnetic waves, static electricity or breakdown of the camera or the
card. We recommend storing important data on a PC etc.
●Do not format the card on your PC or other equipment. Format it on the
camera only to ensure proper operation.
8 SQT0625 (ENG)
Standard accessories
Check that all the accessories are supplied before using the camera. Part
numbers are as of January 2015. These may be subject to change.
Battery pack
DMW-BCM13E
• Charge the battery
before use.
Battery pack is indicated as
battery pack or battery in the text.
AC adaptor
VSK0772
(DMC-TZ70GA)
VSK0775
(DMC-ZS50GH)
Hand strap
VFC4297
USB connection cable
K1HY08YY0031
CD-ROM
SFM0067
• Software:
Use it to install the software on
your PC.
• Operating Instructions for
advanced features
• SD Memory Card, SDHC Memory Card and SDXC Memory Card are
indicated as card in the text.
• Cards are optional. You can record or play back pictures on the built-in
memory when you are not using a card.
•Compatible memory cards (optional)
The following SD standard-based cards (Panasonic brand recommended) can be used.
SD Memory Card (8 MB to 2 GB) / SDHC Memory Card (4 GB to 32 GB) /
SDXC Memory Card (48 GB, 64 GB)
• Consult the dealer or your nearest Service Centre if you lose the supplied
accessories. (You can purchase the accessories separately.)
• Please dispose of all packaging appropriately.
• Keep small parts in a safe place out of the reach of children.
• The illustrations and screens in this manual may differ from the actual product.
• SILKYPIX Developer Studio SE is not provided on the supplied CD-ROM.
Download this software from the website and install it on your computer to use. (→34)
(ENG) SQT0625 9
Names and Functions of Main Parts
12345678 11
13
14
910
11
26
25
28
34
30
33
31
27
(Top)
16 17 18 20
(Bottom)
22 23 24
15 2119
32
29
12
10 SQT0625 (ENG)
Names and Functions of Main Parts
1 Flash
2 Self-timer indicator/
AF Assist Lamp
3 Control ring
4 Lens barrel
5 Lens
• Do not touch the lens barrier.
6 Viewfinder (LVF)
7 Diopter adjustment dial
• Adjusts the focus in the viewfinder.
8 Eye sensor
• The display is automatically switched
to viewfinder when your eye or an
object moves close to the viewfinder.
9 [LVF] button/[Fn2] button
• Use this to switch display between
viewfinder and LCD monitor.
10 Charging lamp (Red)/
Wi-Fi®connection lamp (Blue)
• The colour of the lamp differs
depending on the function.
11 Strap eyelet
• We recommend using the supplied
hand strap to avoid dropping the
camera.
12 Monitor
13 [HDMI] socket
• Do not connect any other cables
except the HDMI micro cable. Doing
so may cause malfunction.
14 [AV OUT/DIGITAL] socket
• This socket is also used when
charging the battery.
15 Speaker
16 Microphones
17 Mode dial
• Use this to select the recording mode.
18 Shutter button
19 Zoom lever
20 Motion picture button
21 Camera [ON/OFF] button
22 Tripod mount
• Do not attach this unit to tripods that
have screws with a length of 5.5 mm
or more. Doing so may damage
this unit.
• If you are not holding the camera
while using zoom, such as during
self-timer recording, [Time Lapse
Shot] recording, or remote recording,
the camera could tilt when the lens
barrel extends, so be sure to secure
the camera in place on a tripod or by
other means.
• It may not be possible to attach
certain types of tripods properly.
23 Card/Battery door
24 Release lever
25 [Wi-Fi] antenna
26 NFC antenna
27 [Wi-Fi] button
28 Playback button
• Use this to select the recording mode
or playback mode.
29 [MENU/SET] button
30 [Q.MENU/ ] / [ ] button
• You can display the Quick Menu and
erase pictures.
31 [DISP.] button
• Use this to change display.
32 Control dial
• Turn the dial to select setting items
and change setting values.
33 [Fn1] button
34 Cursor button
Autres manuels pour Lumix DMC-TZ70
4
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Panasonic Appareil photo numérique
Panasonic
Panasonic Lumix DMC-ZS8 Instructions d'installation et d'entretien
Panasonic
Panasonic LUMIX DC-G9M2 Manuel utilisateur
Panasonic
Panasonic Lumix DMC-FX9GN Manuel utilisateur
Panasonic
Panasonic DMCG10K - DIGITAL CAMERA/LENS KIT Manuel utilisateur
Panasonic
Panasonic LUMIX DMC-FX50 Manuel utilisateur
Panasonic
Panasonic DMC-FZ2000 Caractéristiques techniques
Panasonic
Panasonic DMCGF2 - DIGITAL CAMERA-ADV FEATURES Manuel utilisateur
Panasonic
Panasonic Lumix DMC-FS22 Manuel utilisateur
Panasonic
Panasonic DMC-GX1 Lumix Instructions d'installation et d'entretien
Panasonic
Panasonic DMC-TZ35 Caractéristiques techniques
Panasonic
Panasonic Lumix DC-GH5SP Manuel utilisateur
Panasonic
Panasonic Lumix DC-ZS80 Manuel utilisateur
Panasonic
Panasonic Lumix DMC-FT4 Caractéristiques techniques
Panasonic
Panasonic Lumix DMC-G6X Caractéristiques techniques
Panasonic
Panasonic S-S50 Manuel utilisateur
Panasonic
Panasonic Lumix DMC-G1 Manuel utilisateur
Panasonic
Panasonic PalmCam PV-DC2090 Manuel utilisateur
Panasonic
Panasonic DMC FS7P - Lumix Digital Camera Manuel utilisateur
Panasonic
Panasonic LUMIX DMC-LX9 Manuel du propriétaire
Panasonic
Panasonic DMC-3D1K Instructions d'installation et d'entretien
