Basic Operating Instructions

Digital Camera

Model No. DMC-TS5

Please read these instructions carefully before using

this product, and save this manual for future use.

More detailed

instructions on

the operation of

this camera are contained in

“Operating Instructions for

advanced features

(PDF format)” in the supplied

CD-ROM. Install it on your PC

to read it.

VQT4U14

F0213YS0

DMC-FT5&TS5GH-VQT4U14_eng.book 1 ページ２０１３年１月３０日　水曜日　午後１２時８分

VQT4U14 (ENG)

Dear Customer,

We would like to take this opportunity to thank you for purchasing this Panasonic Digital

Camera. Please read these Operating Instructions carefully and keep them handy for

future reference. Please note that the actual controls and components, menu items, etc.

of your Digital Camera may look somewhat different from those shown in the

illustrations in these Operating Instructions.

Carefully observe copyright laws.

•Recording of pre-recorded tapes or discs or other published or broadcast material for

purposes other than your own private use may infringe copyright laws. Even for the purpose

of private use, recording of certain material may be restricted.

Information for Your Safety

∫Product identification marking

WARNING:

To reduce the risk of fire, electric shock or product damage,

•Do not let water or other liquids drip or splash inside the unit.

•Do not expose accessories (battery pack, battery charger, AC adaptor, SD memory

card and etc.) to rain, moisture, dripping or splashing.

•Use only the recommended accessories.

•Do not remove covers.

•Do not repair this unit by yourself. Refer servicing to qualified service personnel.

The socket outlet shall be installed near the equipment and shall be easily accessible.

Product Location

Digital Camera Bottom

Battery Charger Bottom

DMC-FT5&TS5GH-VQT4U14_eng.book 2 ページ２０１３年１月３０日　水曜日　午後１２時８分

(ENG) VQT4U14

∫About the battery pack

•Do not heat or expose to flame.

•Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time with

doors and windows closed.

∫About the battery charger

•

The battery charger is in the standby condition when the AC power supply cord is connected.

The primary circuit is always “live” as long as the power cord is connected to an electrical outlet.

∫Cautions for Use

•Do not use any other USB connection cables except the supplied one or a genuine

Panasonic USB connection cable (DMW-USBC1: optional).

•Always use a genuine Panasonic AV cable (DMW-AVC1: optional).

•Always use a genuine Panasonic HDMI micro cable (RP-CHEU15: optional).

Part number: RP-CHEU15 (1.5 m)

Keep this unit as far away as possible from electromagnetic equipment (such as

microwave ovens, TVs, video games etc.).

•If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be

disrupted by electromagnetic wave radiation.

•Do not use this unit near cell phones because doing so may result in noise adversely

affecting the pictures and/or sound.

•Recorded data may be damaged, or pictures may be distorted, by strong magnetic fields

created by speakers or large motors.

•Electromagnetic wave radiation generated by microprocessors may adversely affect this unit,

disturbing the pictures and/or sound.

•If this unit is adversely affected by electromagnetic equipment and stops functioning properly,

turn this unit off and remove the battery or disconnect AC adaptor (DMW-AC5G: optional).

Then reinsert the battery or reconnect AC adaptor and turn this unit on.

Do not use this unit near radio transmitters or high-voltage lines.

•If you record near radio transmitters or high-voltage lines, the recorded pictures and/or sound

may be adversely affected.

CAUTION

•Danger of explosion if battery is incorrectly replaced. Replace only with the type

recommended by the manufacturer.

•When disposing the batteries, please contact your local authorities or dealer and ask for

the correct method of disposal.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above 60

C or incinerate.

CAUTION!

To reduce the risk of fire, electric shock or product damage,

•Do not install or place this unit in a bookcase, built-in cabinet or in another

confined space. Ensure this unit is well ventilated.

DMC-FT5&TS5GH-VQT4U14_eng.book 3 ページ２０１３年１月３０日　水曜日　午後１２時８分

VQT4U14 (ENG)

-If you see this symbol-

∫How to replace the Fuse

The location of the fuse differ according to the type of AC cable (figures A and B).

Confirm the AC cable fitted and follow the instructions below.

Illustrations may differ from actual AC cable.

1 Open the fuse cover with a

screwdriver.

2 Replace the fuse and

close or attach the fuse

cover.

Information on Disposal in other Countries outside

the European Union

This symbol is only valid in the European Union.

If you wish to discard this product, please contact your

local authorities or dealer and ask for the correct

method of disposal.

Fuse cover

Figure A Figure B

Fuse

(5 ampere)

Fuse

(5 ampere)

DMC-FT5&TS5GH-VQT4U14_eng.book 4 ページ２０１３年２月１３日　水曜日　午後１時１４分

(ENG) VQT4U14

Contents

Information for Your Safety......................................................................................... 2

Before Use .................................................................................................................... 6

Standard Accessories.................................................................................................. 7

(Important) About the Waterproof/Dustproof and Anti-shock Performance of

the Camera.................................................................................................................... 8

Names and Functions of Main Parts ........................................................................ 13

Charging the Battery.................................................................................................. 15

Inserting and Removing the Card (optional)/the Battery ....................................... 16

Sequence of operations ............................................................................................ 17

Recording using the GPS function........................................................................... 19

Sensors (compass/altimeter/barometer) are operated ........................................... 22

Remote Shooting ....................................................................................................... 23

• Installing the smartphone/tablet app “Panasonic Image App” ............................ 23

• Connecting easily to a smartphone/tablet (NFC)................................................ 24

• Connecting to a smartphone/tablet..................................................................... 26

• Taking pictures via a smartphone/tablet (remote recording)............................... 28

• Playing back pictures in the camera ................................................................... 28

Reading the Operating Instructions (PDF format) .................................................. 29

Installing supplied software ...................................................................................... 30

Specifications ............................................................................................................. 31

DMC-FT5&TS5GH-VQT4U14_eng.book 5 ページ２０１３年２月６日　水曜日　午後３時２８分

VQT4U14 (ENG)

Before Use

•Do not apply strong shock or vibration by dropping or knocking the camera. Also, do

not apply strong pressure to the camera.

–Waterproof performance may be impaired.

–Lens or LCD monitor may be damaged.

–It may cause malfunction in the performance or the function.

∫When inner side of the lens is fogged (condensation)

This unit has been designed to prevent condensation by

Anti-fog glass, however it may be caused by the

environment in which the camera is used. It is not a

malfunction or failure of the camera.

What to do when inner side of the lens is fogged

•Turn off the power and open the side door in a place with constant

ambient temperature, away from high temperatures, humidity, sand and dust. The fog will

disappear naturally in 10 minutes to 2 hours with the side door open when the temperature of

the camera gets close to the ambient temperature.

•Contact Panasonic if the fogging does not disappear.

Conditions in which inner side of the lens may be fogged

Condensation may occur and the inner side of the lens may be fogged when the

camera is used in areas that undergo a significant change in temperature or in high

humidity, such as the following:

•When the camera is used underwater suddenly after being on a hot beach etc.

•When the camera is moved to a warm area from a cold area, such as at a ski resort or

at high altitude

•When the side door is opened in a high-humidity environment

Please be sure to read “(Important) About the Waterproof/Dustproof and Anti-shock

Performance of the Camera”(P8) before using this unit underwater to prevent the unit

from being mishandled, which may cause water to seep in.

DMC-FT5&TS5GH-VQT4U14_eng.book 6 ページ２０１３年１月３０日　水曜日　午後１２時８分

(ENG) VQT4U14

Standard Accessories

Check that all the accessories are supplied before using the camera.

Product numbers correct as of January 2013. These may be subject to change.

1 Battery Pack

(Indicated as battery pack or battery in

the text)

Charge the battery before use.

2 Battery Charger

(Indicated as battery charger or

charger in the text)

3 AC Cable

4 USB Connection Cable

5 CD-ROM

•Software

•Operating Instructions for advanced

features

Install on your PC before use.

6 Hand Strap

•Supplied accessories are not waterproof.

•SD Memory Card, SDHC Memory Card and

SDXC Memory Card are indicated as card in

the text.

•The card is optional.

You can record or play back pictures on the built-in memory when you are not using a

card.

•Consult the dealer or your nearest Service Centre if you lose the supplied accessories. (You

can purchase the accessories separately.)

DMW-BCM13E VSK0801

K1HY08YY0031

VFF1163

VFC4297

K2CT3YY00034

DMC-FT5&TS5GH-VQT4U14_eng.book 7 ページ２０１３年２月６日　水曜日　午後３時２８分

VQT4U14 (ENG)

(Important) About the Waterproof/

Dustproof and Anti-shock Performance

of the Camera

This does not guarantee no destruction, no malfunction, or waterproofing in all

conditions.

¢1 This means that the camera can be used underwater for specified time in specified

pressure in accordance with the handling method established by Panasonic.

¢2 “MIL-STD 810F Method 516.5-Shock” is the test method standard of the U.S. Defense

Department, which specifies performing drop tests from a height of 122 cm, at

26 orientations (8 corners, 12 ridges, 6 faces) using 5 sets of devices, and passing the

26 orientation drops within 5 devices. (If failure occurs during the test, a new set is used to

pass the drop orientation test within a total of 5 devices)

Panasonic’s test method is based on the above “MIL-STD 810F Method 516.5-Shock”.

However, the drop height was changed from 122 cm to 200 cm dropping onto 3 cm thick

plyboard. This drop test was passed.

(Disregarding appearance change such as loss of paint or distortion of the part where

drop impact is applied.)

¢3 According to the test conditions specified by Panasonic.

Waterproof/Dustproof Performance

This camera’s waterproof/dustproof rating complies with the “IPX8” and

“IP6X” ratings. Provided the care and maintenance guidelines described in

this document are strictly followed, this camera can operate underwater, to a

depth not exceeding 13 m for a time not exceeding 60 minutes. (¢1)

Anti-shock Performance

This camera also complies with “MIL-STD 810F Method 516.5-Shock”. The

camera has cleared a drop test from a height of 2 m onto 3 cm thick plywood.

In most cases this camera should not sustain any damage if dropped from a

height not exceeding 2 m. (¢2)

Withstand Load Performance

This camera complies with 100 kgfload tests. (¢3)

DMC-FT5&TS5GH-VQT4U14_eng.book 8 ページ２０１３年１月３０日　水曜日　午後１２時８分

(ENG) VQT4U14

∫Handling of the camera

•Waterproofing is not guaranteed if the unit is subject to an impact as a result of being hit or

dropped etc. If an impact to the camera occurs, it should be inspected (subject to a fee) by a

Panasonic to verify that the waterproofing is still effective.

•When the camera is splashed with detergent, soap, hot spring, bath additive, sun oil, sun

screen, chemical, etc., wipe it off immediately.

•Waterproof function of the camera is for sea water and fresh water only.

•Any malfunction caused by customer misuse, or mishandling will not be covered by the

warranty.

•The inside of this unit is not waterproof. Water leakage will cause malfunction.

•Supplied accessories are not waterproof.

•Card and battery are not waterproof. Do not handle with a wet hand. Also, do not insert wet

card or battery into the camera.

•Do not leave the camera for a long period of time in places where temperature is very low

(at ski resorts or at high altitude etc.) or very high (above 40 oC), inside a car under strong

sunlight, close to a heater, on the beach, etc. Waterproof performance may be degraded.

∫About the [Precautions] demonstration display

([Requirements for Underwater use])

•[Precautions] is displayed when the power is turned on for the first time after purchase, with

the side door completely closed.

•Please check beforehand to maintain the waterproof performance.

1Press 2to select [Yes], and press [MENU/SET].

•It will automatically skip to the clock setting screen if [No] is selected before it starts.

2Press 2/1to select the picture.

•It can be forcefully ended by pressing [MENU/SET].

•When it is forcefully ended while checking by turning the unit off or pressing [MENU/

SET], [Precautions] is displayed every time the power is turned on.

3After the final screen (12/12), press [MENU/SET] to finish.

•When [MENU/SET] is pressed after the final screen (12/12), [Precautions] is not

displayed from the next time the power is turned on.

•This can also be viewed from [Precautions] in the [Setup] menu.

2: Return to the previous screen

1: View the next screen

DMC-FT5&TS5GH-VQT4U14_eng.book 9 ページ２０１３年１月３０日　水曜日　午後１２時８分

VQT4U14 (ENG)

1Check that there are no foreign objects on the inner side of the side door.

•If there is any foreign object, such as lint, hair, sand, etc., on the surrounding area,

water will leak within a few seconds, causing malfunction.

•Wipe it off with a soft, dry cloth if there is any liquid.

It may cause water leaks and malfunction if you use the camera with liquid adhered.

•If foreign objects are present, wipe them off with a dry, lint-free cloth.

•Be extremely careful to remove the small sand etc. that may adhere to the sides and

corners of the rubber seal.

2Check for cracks and deformation of the rubber seal on the side door.

•The integrity of the rubber seals may decrease after about 1 year, with use and age. To

avoid permanently damaging the camera, the seals should be replaced once each

year. Please contact Panasonic for related costs and other information.

3Close the side door securely.

ARed part

B[LOCK] switch (grey part)

CReleased state

DLocked state

•Lock the [LOCK] switch securely until the

red part is no longer visible.

•To prevent water intrusion, be careful not to

catch foreign objects such as liquids, sand,

hair, dust, or the strap cord.

Check before using underwater

Always wipe the rubber seal on the side door and the area where rubber seal

sits with a dry, lint-free cloth.

Do not open or close the side door in places with sand and dust, close to water,

or with wet hands. Sand or dust adhering may cause water leaks.

DMC-FT5&TS5GH-VQT4U14_eng.book 10 ページ２０１３年１月３０日　水曜日　午後１２時８分

Autres manuels pour Lumix DMC-TS5

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Appareil photo numérique

Panasonic

Panasonic DMCFP2 - DIGITAL STILL CAMERA Caractéristiques techniques

Panasonic

Panasonic NV-VX55A Manuel utilisateur

Panasonic

Panasonic DMC-SZ5K Instructions d'installation et d'entretien

Panasonic

Panasonic Lumix DMC-TZ57 Manuel utilisateur

Panasonic

Panasonic DMCFZ20 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FX78 Instructions d'installation et d'entretien

Panasonic

Panasonic Lumix DMC-LX100 Manuel du propriétaire

Panasonic

Panasonic AWHE100N - HD INTEGRATED CAMERA Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FZ150 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FX180 Manuel utilisateur

Panasonic

Panasonic PalmCam PV-DC1000 Manuel utilisateur

Panasonic

Panasonic DMC-ZS10S Instructions d'installation et d'entretien

Panasonic

Panasonic DMCFZ30PP - DIGITAL STILL CAMERA Manuel utilisateur

Panasonic

Panasonic Lumix DMC-LX1EG-K Manuel utilisateur

Panasonic

Panasonic Lumix DC-GH5S Manuel du propriétaire

Panasonic

Panasonic DMC-SZ9 Manuel utilisateur

Panasonic

Panasonic LUMIX DMC-LX100SG Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-FS15 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-GF2C Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-XS3 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-TZ10 Caractéristiques techniques

Panasonic

Panasonic SVAV30U - SD MULTI MEDIA TERMI Manuel utilisateur

Panasonic

Panasonic SDR-S7P Manuel utilisateur

Panasonic

Panasonic LUMIX DMC-FS25 Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
