Basic Operating Instructions

Digital Camera

Model No. DC-FT7/DC-TS7

Please read these instructions carefully before using this

product, and save this manual for future use.

More detailed operating instructions are available in “Operating

Instructions for advanced features (PDF format)”. To read it, download

it from the website. (P62)

GHGA

DVQX1518ZA

F0518HN0

until

2018/06/30

DC-FT7-TS7GAGH-DVQX1518_eng.book 1 ページ２０１８年５月１０日　木曜日　午後２時５０分

2DVQX1518 (ENG)

Dear Customer,

We would like to take this opportunity to thank you for purchasing this Panasonic

Digital Camera. Please read these Operating Instructions carefully and keep them

handy for future reference. Please note that the actual controls and components,

menu items, etc. of your Digital Camera may look somewhat different from those

shown in the illustrations in these Operating Instructions.

Carefully observe copyright laws.

• Recording of pre-recorded tapes or discs or other published or broadcast material for

purposes other than your own private use may infringe copyright laws. Even for the

purpose of private use, recording of certain material may be restricted.

Information for Your Safety

∫Product identification marking

WARNING:

To reduce the risk of fire, electric shock or product damage,

• Do not let water or other liquids drip or splash inside the unit.

• Do not expose accessories (battery pack, battery charger, AC adaptor, SD

memory card and etc.) to rain, moisture, dripping or splashing.

• Use the recommended accessories.

• Do not remove covers.

• Do not repair this unit by yourself. Refer servicing to qualified service

personnel.

The socket outlet shall be installed near the equipment and shall be easily

accessible.

Product Location

Digital camera Bottom

DC-FT7-TS7GAGH-DVQX1518_eng.book 2 ページ２０１８年５月１０日　木曜日　午後２時５０分

(ENG) DVQX1518

For Thailand only

This telecommunication equipment conforms to NTC/NBTC technical requirement.

∫About the battery pack

• Do not heat or expose to flame.

• Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time

with doors and windows closed.

∫About the AC adaptor (supplied)

• The AC adaptor is in the standby condition when the mains plug is connected. The

primary circuit is always “live” as long as the mains plug is connected to an electrical

outlet.

For Singapore only

CAUTION

• Danger of explosion if battery is incorrectly replaced. Replace only with the type

recommended by the manufacturer.

• When disposing of the batteries, please contact your local authorities or dealer and

ask for the correct method of disposal.

Warning

Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC or

incinerate.

CAUTION!

To reduce the risk of fire, electric shock or product damage,

• Do not install or place this unit in a bookcase, built-in cabinet or in another

confined space. Ensure this unit is well ventilated.

Complies with

IMDA Standards

DB01017

DC-FT7-TS7GAGH-DVQX1518_eng.book 3 ページ２０１８年５月１０日　木曜日　午後２時５０分

4DVQX1518 (ENG)

• Do not use any other USB connection cables except the supplied one.

• Use a “High Speed HDMI micro cable” with the HDMI logo.

Cables that do not comply with the HDMI standards will not work.

“High Speed HDMI micro cable” (Type D–Type A plug, up to 2 m (6.6 feet) long)

Keep this unit as far away as possible from electromagnetic equipment (such

as microwave ovens, TVs, video games etc.).

• If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be

disrupted by electromagnetic wave radiation.

• Do not use this unit near cell phones because doing so may result in noise adversely

affecting the pictures and/or sound.

• Recorded data may be damaged, or pictures may be distorted, by strong magnetic

fields created by speakers or large motors.

• Electromagnetic wave radiation may adversely affect this unit, disturbing the pictures

and/or sound.

• If this unit is adversely affected by electromagnetic equipment and stops functioning

properly, turn this unit off and remove the battery or disconnect AC adaptor. Then

reinsert the battery or reconnect AC adaptor and turn this unit on.

Do not use this unit near radio transmitters or high-voltage lines.

• If you record near radio transmitters or high-voltage lines, the recorded pictures and/or

sound may be adversely affected.

Cautions for Use

DC-FT7-TS7GAGH-DVQX1518_eng.book 4 ページ２０１８年５月１０日　木曜日　午後２時５０分

(ENG) DVQX1518

• Before cleaning the camera, remove the battery or disconnect the power plug

from the outlet.

• Do not press the monitor with excessive force.

• Do not press the lens with excessive force.

• Do not spray the camera with insecticides or volatile chemicals.

• Do not keep rubber or plastic products in contact with the camera for a long

period of time.

• Do not use solvents such as benzine, thinner, alcohol, kitchen detergents, etc., to

clean the camera, since it may deteriorate the external case or the coating may

peel off.

• Do not leave the camera with the lens facing the sun, as rays of light from the sun

may cause it to malfunction.

• Always use the supplied cords and cables.

• Do not extend the cords or the cables.

• During access (image writing, reading and deleting, formatting etc.), do not turn

this unit off, remove the battery, card or disconnect the AC adaptor. Furthermore,

do not subject the camera to vibration, impact or static electricity.

• The data on the card may be damaged or lost due to electromagnetic waves, static

electricity or breakdown of the camera or the card. We recommend storing important

data on a PC etc.

• Do not format the card on your PC or other equipment. Format it on the camera only to

ensure proper operation.

• The battery is not charged when the camera is shipped. Charge the battery before

use.

• The battery is a rechargeable lithium ion battery. If the temperature is too high or

too low, the operating time of the battery will become shorter.

• The battery becomes warm after using and during and after charging. The camera also

becomes warm during use. This is not a malfunction.

• Do not leave any metal items (such as clips) near the contact areas of the power

plug or near the batteries.

• Store the battery in a cool and dry place with a relatively stable temperature:

(Recommended temperature: 15 oC to 25 oC (59 oF to 77 oF), Recommended

humidity: 40%RH to 60%RH)

•Do not store the battery for a long time while fully charged. When storing the

battery for a long period of time, we recommend charging it once a year. Remove the

battery from the camera and store it again after it has completely discharged.

DC-FT7-TS7GAGH-DVQX1518_eng.book 5 ページ２０１８年５月１０日　木曜日　午後２時５０分

6DVQX1518 (ENG)

Contents

Information for Your Safety ....................2

Preparation/Basic

Care of the camera ................................7

Standard Accessories............................9

About cards that can be used with this

unit.......................................................10

(Important) About the Waterproof/

Dustproof and Anti-shock Performance

of the Camera ......................................11

Names and Functions of

Components ........................................17

Preparations before Recording............19

Basic Operations .................................23

Setting menu items ..............................29

Assigning frequently used functions to

the buttons (function buttons) ..............30

Using the Compass and Altimeter .......30

Recording

Taking Pictures using the Automatic

Function (Intelligent Auto Mode)..........32

Recording 4K Photos...........................34

Controlling Focus After Recording

(Post Focus) ........................................37

Recording Motion Picture/4K Motion

Picture..................................................40

Playback

Playing Back Pictures ......................... 43

Menu list ............................................. 44

Wi-Fi

What you can do with the Wi-Fi®

function ............................................... 46

Controlling with a

Smartphone/Tablet.............................. 47

Others

Monitor Display/Viewfinder Display..... 52

Troubleshooting .................................. 54

Specifications...................................... 57

Reading the Operating Instructions

(PDF format) ....................................... 62

DC-FT7-TS7GAGH-DVQX1518_eng.book 6 ページ２０１８年５月１０日　木曜日　午後２時５０分

Preparation/Basic

(ENG) DVQX1518

Care of the camera

• Do not apply strong shock or vibration by dropping or knocking the camera. Also,

do not apply strong pressure to the camera.

– Waterproof performance may be impaired.

– The lens or the monitor may get damaged.

If the monitor should get damaged, take care to avoid injury caused by the fragments

of broken glass and other damaged components.

– It may cause malfunction in the performance or the function.

• After the camera is used underwater, speaker and microphone performance may

be temporarily degraded, so motion pictures may be recorded or played back with

weak audio.

– After underwater use, perform steps 1 through 4 in “Caring of the camera after using

it underwater” on P15.

∫When inner side of the viewfinder or monitor is fogged (condensation)

It is not a malfunction or failure of the camera. It may be caused by the

environment in which the camera is used.

What to do when inner side is fogged

• Turn off the camera and open the side door in a place with constant ambient

temperature, away from high temperatures, humidity, sand and dust. The fog will

disappear naturally in approximately 2 hours with the side door open when the

temperature of the camera gets close to the ambient temperature.

• Contact Panasonic if the fogging does not disappear.

Conditions in which inner side may be fogged

Condensation may occur and cause the inner side of the lens, viewfinder, and

monitor to fog up when the camera is used under conditions with drastic

temperature changes or high humidity levels, such as the following:

• When the camera is used underwater suddenly after being on a hot beach etc.

• When the camera is moved to a warm area from a cold area, such as at a ski

resort or at high altitude

• When the side door is opened in a high-humidity environment

Please be sure to read “(Important) About the Waterproof/Dustproof and

Anti-shock Performance of the Camera” (P11) before using this unit underwater

to prevent the unit from being mishandled, which may cause water to seep in.

If you shake the camera while it is turned off, a rattling sound will be heard. This

is the sound of the lens moving and not a malfunction.

DC-FT7-TS7GAGH-DVQX1518_eng.book 7 ページ２０１８年５月１０日　木曜日　午後２時５０分

8DVQX1518 (ENG)

Preparation/Basic

∫When using in a cold climate or at low temperatures

• The performance of the battery (number of recordable pictures/operating time) may

decrease temporarily when using in a temperature between j10 oC and 0 oC (14 oF and

32 oF) (cold places such as ski resorts or places at high altitude). (Charge the battery

sufficiently before use)

• The battery cannot be recharged in a temperature less than 0 oC (32 oF). (The charging

lamp blinks when the battery cannot be recharged.) Charge it sufficiently in a location

where the ambient temperature is between 10 oC and 30 oC (50 oF and 86 oF).

• When using the camera in cold places such as ski resorts or places at high altitude, do

not leave the camera with snow or water droplets sticking to it. Some parts of the

camera may become hard to move or the sound may become dim with snow or water

droplets freezing in narrow spaces, such as the gaps of the buttons, dial, speaker, and

microphone. This is not a malfunction.

• When the camera is used at cold temperatures, speaker and microphone

performance may be temporarily degraded, so motion pictures may be recorded

or played back with weak audio.

– Keep the camera warm by placing it in a warm place such as inside your cold

protection gear or clothes during use.

• The screens used in these operating instructions are examples provided to describe

operations.

• The product design and specifications described in these operating instructions may

differ from the actual product due to improvements.

∫About the symbols in the text

Applicable modes:

In Recording Modes shown as black icons, you can select and use indicated menu

items and functions.

How to use this manual

: Indicates that the menu can be set by pressing [MENU/SET] button.

: Tips for skilful use and points for recording.

In these operating instructions, steps for setting a menu item are described as follows.

> [Rec] > [Quality] > [›]

DC-FT7-TS7GAGH-DVQX1518_eng.book 8 ページ２０１８年５月１０日　木曜日　午後２時５０分

Preparation/Basic

(ENG) DVQX1518

Standard Accessories

Check that all the accessories are supplied before using the camera.

Product numbers correct as of May 2018. These may be subject to change.

• Supplied accessories such as battery pack etc.

are not waterproof. (excluding hand strap)

• SD Memory Card, SDHC Memory Card and

SDXC Memory Card are indicated as card in the

text.

• The card is optional.

• Consult the dealer or Panasonic if you lose the

supplied accessories. (You can purchase the accessories separately.)

∫Digital Camera Accessory

• Some optional accessories may not be available in some countries.

Battery Pack

(Indicated as battery pack or battery in the

text)

• Charge the battery before use.

2AC Adaptor

• This is used for charging.

3USB Connection Cable

4Hand Strap

Battery Pack DMW-BCM13

DMW-BCM13E

K1HY04YY0106

DVPW1015Z

SAE0012F

SAE0012D

DC-FT7-TS7GAGH-DVQX1518_eng.book 9 ページ２０１８年５月１０日　木曜日　午後２時５０分

10 DVQX1518 (ENG)

Preparation/Basic

About cards that can be used with this

unit

∫About motion picture/4K photo recording and speed class ratings

Use a card that meets the following ratings of the SD Speed Class or UHS Speed

Class.

• SD Speed Class and UHS Speed Class are the speed standards regarding continuous

writing. To check the class, see the labelled side, etc. of the card.

• Please confirm the latest information on the following website.

http://panasonic.jp/support/global/cs/dsc/

(This Site is English only.)

• Keep the memory card out of reach of children to prevent swallowing.

SD Memory Card

(512 MB to 2 GB)

• This unit is compatible with UHS-I UHS Speed Class 3

standard SDHC/SDXC memory cards.

• Operation of the cards on the left has been confirmed

with Panasonic’s cards.

SDHC Memory Card

(4 GB to 32 GB)

SDXC Memory Card

(48 GB to 128 GB)

Size in [Rec Quality] Speed class Label example

4K UHS Speed Class 3

FHD/HD Class 4 or higher

When recording in 4K Photo/

[Post Focus] UHS Speed Class 3

DC-FT7-TS7GAGH-DVQX1518_eng.book 10 ページ２０１８年５月１０日　木曜日　午後２時５０分

Autres manuels pour Lumix DC-FT7

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Appareil photo numérique

Panasonic

Panasonic Lumix DMC-GF5X Caractéristiques techniques

Panasonic

Panasonic SVAV30U - SD MULTI MEDIA TERMI Manuel utilisateur

Panasonic

Panasonic DMC-FP1A Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-FZ50 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-TZ20 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FX65 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-TZ60 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-LX15 Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-G6 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-SZ1P Manuel utilisateur

Panasonic

Panasonic DMCTS2 - DIGITAL STILL CAMERA Manuel utilisateur

Panasonic

Panasonic DMC-FT2 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-LX5 Caractéristiques techniques

Panasonic

Panasonic LUMIX DMC-TS30K Manuel utilisateur

Panasonic

Panasonic LUMIX DMC-GM1K Caractéristiques techniques

Panasonic

Panasonic Lumix DMC-XS3 Manuel du propriétaire

Panasonic

Panasonic DMC-FX1GN Manuel utilisateur

Panasonic

Panasonic LUMIX L1 Manuel utilisateur

Panasonic

Panasonic DMC FX10 - Lumix Digital Camera Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FZ50 Manuel utilisateur

Panasonic

Panasonic Lumix DMC-FX700 Manuel utilisateur

Panasonic

Panasonic Lumix DC-G9 Manuel du propriétaire

Panasonic

Panasonic Lumix DMC-FX55 Mode d’emploi

Panasonic

Panasonic DMCFP2 - DIGITAL STILL CAMERA Caractéristiques techniques

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
