Panasonic Toughbook CF-18 Series Manuel utilisateur

Personal Computer

Reference Manual

Model No. CF-18 Series

XP We recommend that this Reference Manual be printed.

Read Me First

Some of the illustrations in this manual may differ slightly in shape from the actual items in

order to make the explanation easier to understand.

If the user has logged on without the administrator authority, some functions may not be

executable, and some screens may be not displayed as shown in this manual.

If this happens, log on with the administrator authority to enable these functions.

Confirm the latest information on optional products in catalogs, etc.

The following drives may be described as "CD/DVD drive".

CD-ROM drive, DVD-ROM drive, CD-R/RW drive, DVD-ROM & CD-R/RW drive, DVD

MULTI drive

Illustrations and Terminology in this Reference Manual

NOTE NOTE provides a useful fact or helpful information.

CAUTION CAUTION indicates a condition that may result in

minor or moderate injury.

Enter

This illustration means to press the [Enter] key.

This illustration means to press and hold the [Fn] key,

then press the [F5] key.

[start] - [Run] This illustration means to click [start], then to click

[Run]. For some applications, you may need to double-

click.

or ⇒These symbols indicated related pages.

: Refer to the page in this Reference Manual

⇒: Refer to the Operating Instructions

cccc*1 If *1 is selected, it will jump to a related explanatory

note.

Read Me First

The terminology in ( ) is the one used in [Intel(R) 82852/82855 GM/GME Graphics Controller

Properties].

To display [Intel(R) 82852/82855 GM/GME Graphics Controller Properties]:

Select [start] - [Control Panel] - [Other Control Panel Options] - [Intel(R) Extreme Graphics].

About Display Mode

Internal LCD (Notebook) This computer's display

External Display (Monitor) External display connected to this computer

Simultaneous display

(Intel(R) Dual Display Clone)

To display the same screen on both the LCD and

external display

Extended Desktop To use both the internal LCD and the external display as

an extended display domain. You can drag a window

from the internal LCD to the external display.

Key Combinations

CAUTION

Do not press the following key combinations repeatedly in (quick) succession. Also, do

not press different key combinations quickly one after another.

Do not press the following key combinations while using the touch pad (external

mouse), touchscreen, tablet buttons, or other keys.

NOTE

Do not press the following key combinations until you log on to Windows and the hard

disk drive indicator turns off. Note, however, that the key combinations

and

are operable in the Setup Utility.

The key combinations below may not work while some applications are running. The

popup window may not be displayed depending on the state of the application you are

using (e.g., when [Command Prompt] is set to "Full Screen").

Key Functions Popup Window

(Displayed after logging

on to Windows)

LCD brightness control (down)

LCD brightness control (up)

Pressing this key combination adjusts the

brightness of LCD.

You can select a different brightness level setting

for when the AC adaptor is connected and for when

it is not connected.

Key Combinations

Display change

(When the external display is connected)

By pressing this key combination, you can select

either an external display, internal LCD or

simultaneous. (page 67)

This key combination does not work when

[Command Prompt] is set to "Full Screen".

CAUTION

Do not press another key until the display

destination has been completely switched.

Do not press this key combination in the

following conditions.

When the external display is not connected.

• When a video such as an MPEG file is

playing.

• When the Extended Desktop is being

utilized.

• When a game such as pinball is

displayed.

NOTE

When switching to a different user with the

Fast User Switching function, this key

operation may not work. In this case, log off

all users and restart the computer.

Key Functions Popup Window

(Displayed after logging

on to Windows)

Key Combinations

Speaker on/off switch

Pressing this key combination turns on/off audio

from the internal speaker and headphone jack.

NOTE

Disabling the speakers will also disable the

warning beep.

Speakers connected to the USB port

cannot be muted.

OFF

(MUTE)

Volume control (down)

Volume control (up)

Pressing this key combination adjusts the volume

of the internal speaker and headphone jack.

NOTE

This key combination cannot be used to

adjust the volume of the warning beep or

speakers connected to the USB port.

Power off using the standby function

Pressing this key combination causes the current

status of the computer to be saved to the memory,

and powers off the computer. (page 36)

Key Functions Popup Window

(Displayed after logging

on to Windows)

Key Combinations

Remaining capacity of the battery pack

Pressing this key combination displays the

remaining battery capacity on the screen.

When the battery pack is

inserted in the computer

(example)

In normal

temperature mode

(page 52)

In high temperature

mode (page 52)

When the battery pack is

not inserted in the

computer

F10

Power off using the hibernation function

Pressing this key combination causes the current

status of the computer to be saved to the hard disk,

and powers off the computer. (page 36)

Key Functions Popup Window

(Displayed after logging

on to Windows)

Key Combinations

There are two Fn key functions as follows:

Fn key lock function

After

is pressed once, it stays in the "pressed" position until another key is pressed.

This is convenient when it is difficult to press two buttons simultaneously.

Popup windows display ON/OFF

1Run the Hotkey Settings.

Select [start] - [All Programs] - [Panasonic] - [Hotkey Settings].

2Set the parameters.

A. Use Fn key lock

Add the check mark if you want to enable the Fn key lock function. The following

Fn key lock function will then be enabled.

To use

only once:

APress

once. (Locked)

BPress another key for combination. (Lock released)

To use

successively:

APress

twice. (Locked)

BPress another key for combination.

Fn key remains locked until

is pressed once more.

B. Notification

This setting is only available when [Use Fn key lock] is checked.

[Make sounds when Fn key is pressed]*1

Notifies the user with a sound when

is locked or released.

[Show status on screen]:

Displays the Fn key status on the taskbar.

is locked

is not locked

C. Disable popup

Add the check mark if you want to turn the popup window display function OFF.

The full-screen display of [Command Prompt] screen or MPEG files may change

to a window display if

*2 keys are pressed. To prevent this, turn the popup

window display function OFF.

Hotkey Settings

Key Combinations

3Select [OK].

NOTE

The Fn key lock function also works with

and other keys (e.g. , ) aside from

*2.

Each user can select separate settings for whether or not to use the Hotkey settings.

*1 If MUTE is set, you will not hear a beep.

*2 "

" indicates any function key from

F10

LED Indicators

Power status Not lit

Power off / Hibernation mode

Green

Power on

Blinking green

Standby mode

Battery pack status page 50

Caps Lock This indicator lights green when

Caps Lock

pressed. Subsequent non-shifted input is

capitalized.

NumLk

(Numeric key)

This indicator lights green when

NumLk

pressed. This causes a portion of the keyboard

to function as a numeric keypad. The [Enter] key

functions differently depending on the

application.

ScrLk

(Scroll lock)

This indicator lights green when

ScrLk

are

pressed. Scroll lock functions differently

depending on the application.

Hard disk drive status This indicator lights when the hard disk drive is

accessed.
