This manual contains supplementary instructions regarding the use of the

computer. It explains the cases where the operation of the computer differs from

that in the Operating Instructions.

Your computer is equipped with the HSPA modem enabling you to communicate

using radio frequencies.

Contents

Description of Parts............................................................ 2

Inserting/Removing a SIM Card......................................... 2

Supplied Accessories......................................................... 2

Installing the Software........................................................ 3

Troubleshooting.................................................................. 5

Speciﬁcations...................................................................... 6

Appendix.............................................................................. 7

NOTE:Useful and helpful information.

CAUTION:Condition that may result in minor or moderate injury.

(Start) - [All Programs] :

Click (Start), and then click [All Programs].

[start] - [Run]: Click [start], and then click [Run].

You may need to double-click in some cases.

: Page in these Supplementary Instructions or in the

Reference Manual for the computer.

: Reference to the on-screen manuals.

Some of the illustrations in this manual may differ slightly in shape from the

actual items in order to make the explanation easier to understand.

About the abbreviations in this manual, refer to the table on page 7.

Terms and illustrations in this Manual

Supplementary Instructions

for HSPA Modem

Personal Computer

This supplementary instructions manual is applied to the following models.

CF-H1mk2, CF-U1mk2

Description of Parts

Refer to the Operating Instructions for the computer.

Inserting/Removing a SIM Card

Before using the HSPA modem, set a SIM card to the SIM card slot.

Refer to the Operating Instructions for the computer.

Supplied Accessories

Wireless WAN (HSPA) Software CD-ROM ............................................................1

Installing the Software

The steps below must be taken before using the HSPA modem.

1<Only for CF-H1/CF-U1 series>

Turn off the computer and set the computer to the Cradle.

2<Only for CF-H1/CF-U1 series>

Connect the CD/DVD drive and an external keyboard to

the Cradle.

3Turn on the computer, and run the Setup Utility by

pressing

Del

while [Panasonic] boot screen is

displayed.

If [Enter Password] is displayed, input the Supervisor Password.

4Select the [Advanced] - [Wireless Conﬁguration] menu,

and set [Wireless WAN] to [Enabled].

5Save the settings and exit the Setup Utility.

6Log on to Windows as an administrator.

If the [Found New Hardware Wizard] screen is displayed, click [Cancel] to

close the screen.

7Install the Wireless WAN software by following

procedures.

ASet the Wireless WAN (HSPA) Software CD-ROM into the CD/DVD

drive.

BFollow the on-screen instructions, and install the Wireless WAN

Software Installer.

If the installer does not start up, proceed as follows to install the Wireless

WAN software.

Click (Start) and enter “x:*1\gb2kpack\setup.exe” in [Search programs

and ﬁles], and press

Enter

Click [start] - [RUN], enter “x:*1\gb2kpack\setup.exe”, and click [OK].

*1“x:” is the drive letter of the CD/DVD drive. Change this to match the drive letter

on your own computer.

Uninstalling the software

Click (Start) - [Control Panel] - [Uninstall a program] - [Wireless WAN

Software Installer for Gobi 2000], and then click [Uninstall] to uninstall the

software.

Click [start] - [Control Panel] - [Add or Remove Programs] - [Wireless WAN

Software Installer for Gobi 2000], and then click [Remove] to uninstall the

software.

If the [Found New Hardware Wizard] screen is displayed, click [Cancel] to

close the screen.

BAt [Uninstall Complete], conﬁrm that [Yes, I want to restart my computer now]

is set and click [Finish].

The computer will restart.

Installing the Software

Troubleshooting

Cannot

communicate.

•<Only for CF-U1 Serises>

Conﬁrm that wireless switch is in ON.

•Conﬁrm that [Wireless WAN] is set to [Enabled] in the

[Advanced] menu of the Setup Utility.

•Use the Wireless Switch Utility and conﬁrm that the

wireless WAN is on.

•Conﬁrm that the SIM card is inserted correctly.

If communication is not established after proceeding with

the above remedies, the wireless WAN device may not

be correctly recognized. Quit Windows, and restart the

computer.

<When using the

GPS function on

the model with

the built-in HSPA

modem>

GPS data is not

output when

the computer

resumes from the

sleep

standby or

hibernation.

• If the computer has entered the sleep /

standby or hibernation mode while the

GPS port is open on the map software, GPS data may not

be output when the computer resumes. If the computer

has entered the sleep /

standby or hibernation mode while the GPS port is open

on the map software, close the GPS port on the map

software and open it again after the computer resumes.

Cannot connect

to the mobile

broadband

network.

When you connect to the mobile broadband network for the

ﬁrst time, proceed as follows.

AClick to open [Connect to a Network], select [Mobile

Broadband Network] and then click [Connect].

A message appears to show that connection has failed.

BRight-click [Mobile Broadband Network] and select

[Properties].

CSet the APN, user name and password.

DRepeat step

Data Communication HSUPA Category 6, 5.7 Mbps

HSDPA Category 8, 7.2 Mbps

UMTS 3GPP Release 5

EDGE/

GPRS

MultiSlot Class 10

Other Features SMS Mobile Originated SMS (MO-SMS)

Mobile Terminated SMS (MT-SMS)

FAX No Support

Voice No Support

SIM 1.8/3V SIM Support

Speciﬁcations

Abbreviations

EDGE Enhanced Data rates for Global Evolution

GPRS General Packet Radio Service

HSDPA High Speed Downlink Packet Access

SIM Subscriber Identity Module

SMS Short Message Service

UMTS Universal Mobile Telecommunications System

HSPA High Speed Packet Access

HSUPA High Speed Uplink Packet Access

Appendix

Printed in U.K.

Importer’s name & address pursuant to the EU GPSD (General Product Safety

Directive) 2001/95/EC Art.5

ヱ㄂ㄏ㄂ㄔㄐㄏㄊ㄄チヤㄐㄎㄑㄖㄕㄆㄓチヱㄓㄐㄅㄖ㄄ㄕㄔチユㄖㄓㄐㄑㄆネチヱ㄂ㄏ㄂ㄔㄐㄏㄊ㄄チヮ㄂ㄓㄌㄆㄕㄊㄏㄈチ

ユㄖㄓㄐㄑㄆチヨㄎ㄃ラ

Hagenauer Straße 43

65203 Wiesbaden

Germany

UK0110-0

CPE02180ZA
