ORDERNo. ACED031221C7

AUTOMOTIVE AFTERMARKET

CQ-C3400U / CQ-C3300U / CQ-C3200U / CQ-C3100U

RemovableFull FrontMP3WMACD Player/ ReceiverwithCD

ChangerControl

SPECIFICATIONS

Specifications*

General

PowerSupply DC12V(11V-16V),

TestVoltage14.4V

NegativeGround

CurrentConsumption Less than 2.2A/ (CDmode;

0.5W 4-speaker)

MaximumPowerOutput 50W×4ch (at1kHz)

ToneAdjustmentRange Bass ;±12dBat100Hz

Treble;±12dBat10kHz

SpeakerImpedance 4-8

Pre-Amp OutputVoltage 2.5V(CDmode;1kHz0dB)

Pre-Amp OutputImpedance 200

<CQ-C3200U/CQ-C3400U>

Subwooferoutputvoltage 2.5V

Subwooferoutputimpedance 200

FMStereo Radio

FrequencyRange 87.9MHz-107.9MHz

UsableSensitivity 10.2dBf. (0.9 V, 75 )

Stereo Separation 35dB(1kHz)

Signal to Noise Ratio 62dB

AMRadio

FrequencyRange 530 -1,710kHz

UsableSensitivity 27dB/ V(11V, S/N20dB)

CDPlayer

Sampling Frequency 8 Times Oversampling

DA Converter 4 DACSystem

Pick-Up Type Astigma 3-beam

LightSource SemiconductorLaser

Wavelength 780nm

FrequencyResponse 20Hzto 20,000Hz(±1dB)

Signal to Noise Ratio 96dB

Total HarmonicDistortion 0.01%(1kHz)

Wowand Flutter Belowmeasurablelimits

Channel Separation 75dB

Dimensions** 7”×1-15/16”×6-1/8”/ (178mm×

50mm×155mm)

Weight** 3lbs. 1oz(1.4kg)

*Specificationsand thedesign aresubjectto possible

modification withoutnotice dueto improvements.

** Dimensionsand Weightshown areapproximate.

-Abovespecificationscomplywith EIAstandards.

1. ABOUTLEADFREE SOLDER (PbF)

Distinction ofPbF PCB:

PCBs(manufactured)using leadfree solderwill have aPbF stampon thePCB.

Caution :

-Pbfree solderhas ahighermelting pointthanstandardsolder;

Typicallythemelting pointis50 -70°F(30 -40°C)higher. Please

use asoldering iron withtemperaturecontrol and adjust itto700 ±

20°F(370 ±10°C). Incase ofusing high temperaturesoldering iron,

please becareful nottoheat too long.

-Pbfree solderwill tend tosplashwhenheatedtoo high (about

1100°F/600°C)

-Thisleadfree solderwill beusedfortheproducts afterserial No.

1,000,001.

2. LASER PRODUCTS

3. FEATUERS

-Digital servoforreliableplayback.

-PLL (Phase LockedLoop)synthesizedtuning.

-18-FM, 6-AMpresets withpreset scan.

-CD ChangerControl

-Removableface plate.

-MP3/WMAPlayback fromCD-R/RW. (CQ-C3300U, CQ-C3400U)

4. REPLACING THE FUSE

Use fuses ofthesamespecifiedrating (15amps). Using differentsubstitutes or fuses withhigher

ratings, or connecting theproductdirectlywithoutafuse, couldcause fireor damagetothe

stereounit.

5. MAINTENANCE

Your productisdesignedand manufacturedtoensureaminimum ofmaintenance. Use adry, a

soft clothfor routineexterior cleaning. Neveruse benzine, thinneror othersolvents.

6. NOTES

[RADIOBLOCK]

Donotalign theAM/FMpackageblock. Whenthepackageblock isnecessary, itwill besupplied

alreadyalignedatthefactory.

[CD DECK BLOCK]

Thismodel has no servoalignmentpointsbecause microcomputercontrolstheservocircuit.

7. DIMENSIONS

8. WIRING CONNECTION

9. TERMINALSDESCRIPTION

9.1. MainBlock

IC601 :YESAM230 [CQ-C3300U/CQ-C3400U]

No. Port Description I/O (V)

FM AM CD

1 CH SENS CD changerdetect I 5.0 5.0 5.0

2 SD/ST Radiostation detect I 5.0 5.0 5.0

3 EJECT EjectSW I 5.0 5.0 5.0

4AVSS Ground - 0 0 0

5EXT.MUTE

External mute O 5.0 5.0 5.0

6CDC 1/2 (Ground pull down) - 5.0 5.0 5.0

7AVREF1 (Conecting to+5V) - 5.0 5.0 5.0

8 SUB SO LCD data I 5.0 5.0 5.0

9LCD DI LCD data O 5.0 5.0 5.0

10 SUB SI LCD clock O 5.0 5.0 5.0

11 CDC

DATA CD Changerdata O 0 0 0

12 CD OSC

STP CD OSCstop O 5.2 5.2 0

13 CH CLK (Ground pull down) - 0 0 0

14 CDC

REM CD Changerremote

control data O5.2 5.2 5.2

15 BZOUT Buzzersignal

output O 0 0 0

16 CD SO CD dataoutput I 5.0 5.0 0

17 CD SI CD datainput O 0 0 3.3

18 CD SCK CD clock O 5.2 5.0 5.0

19 LCD CE LCD chipenable O 0 0 0

20 CD RST CD reset O 0 0 5.2

21 AMP CNT Ampcontrol signal O 5.2 5.1 5.2

22 ANTCNT ANTcontrol signal O 5.2 5.2 0

23 AMP

MUTE Ampmutecontrol O 5.2 5.2 5.2

24 CD STB CD strobe O 0 0 4.6

25 CD A0 CD A0 O 0 0 5.0

26 NC - - - - -

27 NC - - - - -

28 NC - - - - -

29 NC - - - - -

30 NC - - - - -

31 NC - - - - -

32 NC - - - - -

33 VSS1 Ground - 0 0 0

34 NC - - - - -

35 NC - - - - -

36 SCL Audiocontrol serial

clock O 5.2 5.2 5.2

37 SDA Audiocontrol data O 5.2 5.2 5.2

38 S LED S LEDdrive signal O 0 0 0

No. Port Description I/O (V)

FM AM CD

39 EJILL EjectLeddrive

signal O 5.2 5.2 5.2

40 NC - - - - -

41 PLL DI PLL data O 0 0 0

42 PLL DO PLL data I 5.0 5.0 5.0

43 PLL CLK PLL dataclock O 5.2 5.2 5.2

44 PLL CE PLL chipselect O 0 0 0

45 ROMCS (+5V pull up) - - - -

46 PANEL Panel switchsignal I 0 0 0

47 OP/CL Open/close detect I 5.1 5.1 5.1

48 LCD5V

CNT LCD 5V control O 0 0 0

49 EEPROM

DI(NC) - - - - -

50 EEPROM

SK(NC) - - - - -

51 DIM1 (Ground pull down) - 0 0 0

52 DIM2 (Ground pull down) - 0 0 0

53 EEPROM

DO(NC) (Ground pull down) - - - -

54 AFMUTE Audiomutesignal O 5.0 5.0 5.0

55 INV CNT Invertercontrol O 5.0 5.0 5.0

56 CD CNT CD powercontrol O 0 0 0

57 MAIN

CONT Mainpowercontrol O 5.0 5.0 5.0

58 SWCNT Sub Woofercontrol O - - -

59 RDS

DATA

(NC)

- - - - -

60 RESET System reset I 5.0 5.0 5.0

61 RMDATA Remotecontrol data I 5.0 5.0 5.0

62 BATT Batterydetekut I 5.2 5.2 5.2

63 RDS

CLK(NC) - - - - -

64 CDC STB (Ground pull down) - 0 0 0

65 ROTARY

1Rotaryencoder

input1 I5.0 5.0 5.0

66 ROTARY

2Rotaryencoder

input2 I5.0 5.0 5.0

67 VSS0 Ground - 0 0 0

68 VDD1 +5V powersupply - 5.2 5.2 5.2

69 X2 Crystal oscillator - 3.0 3.0 3.0

70 X1 Crystal oscillator - 2.5 2.5 2.5

71 TEST (Testterminal) - 0 0 0

72 XT2 Crystal oscillator - 2.9 2.9 2.9

No. Port Description I/O (V)

FM AM CD

73 XT1 Crystal oscillator - 2.6 2.6 2.6

74 VDD0 +5V powersupply - 5.2 5.2 5.2

75 AVDD +6V powersupply - 5.2 5.2 5.2

76 VSM VSM I 0 0 0

77 ACC ACC detect I 4.8 4.8 4.8

78 INIT/B (+5V pull up) - 5.0 5.0 5.0

79 SPEANA

AIN (Ground pull down) - 0 0 0

80 LEVELL Level in I 0 0 0.5

IC601 :YESAM231 [CQ-C3100U/CQ-C3200U]

No. Port Description I/O (V)

FM AM CD

1 CH SENS CD changerdetect I 5.0 5.0 5.0

2 SD/ST Radiostation detect I 5.0 5.0 5.0

3 EJECT EjectSW I 5.0 5.0 5.0

4AVSS Ground - 0 0 0

5EXT.MUTE

External mute O 5.0 5.0 5.0

6CDC 1/2 (Ground pull down) - 5.0 5.0 5.0

7AVREF1 (Conecting to+5V) - 5.0 5.0 5.0

8 SUB SO LCD data I 5.0 5.0 5.0

9LCD DI LCD data O 5.0 5.0 5.0

10 SUB SI LCD clock O 5.0 5.0 5.0

11 CDC

DATA CD Changerdata O 0 0 0

12 CD OSC

STP CD OSCstop O 5.2 5.2 0

13 CH CLK (Ground pull down) - 0 0 0

14 CDC

REM CD Changerremote

control data O5.2 5.2 5.2

15 BZOUT Buzzersignal

output O 0 0 0

16 CD SO CD dataoutput I 5.0 5.0 0

17 CD SI CD datainput O 0 0 3.3

18 CD SCK CD clock O 5.2 5.0 5.0

19 LCD CE LCD chipenable O 0 0 0

20 CD RST CD reset O 0 0 5.2

21 AMP CNT Ampcontrol signal O 5.2 5.1 5.2

22 ANTCNT ANTcontrol signal O 5.2 5.2 0

23 AMP

MUTE Ampmutecontrol O 5.2 5.2 5.2

24 CD STB CD strobe O 0 0 4.6

25 CD A0 CD A0 O 0 0 5.0

No. Port Description I/O (V)

FM AM CD

26 CD

RFOK RFOKsignal I 0 0 5.0

27 CD

LOCK CD lock signal I 0 0 5.0

28 CD LIMIT CD limitswitch

signal I 0 0 5.0

29 CD SW1 CD SW1 0 0 0

30 CD SW2 CD SW2 I 5.0 5.0 0

31 NC - - - - -

32 NC - - - - -

33 VSS1 Ground - 0 0 0

34 NC - - - - -

35 NC - - - - -

36 SCL Audiocontrol serial

clock O 5.2 5.2 5.2

37 SDA Audiocontrol data O 5.2 5.2 5.2

38 S LED S LEDdrive signal O 0 0 0

39 EJILL EjectLeddrive

signal O 5.2 5.2 5.2

40 NC - - - - -

41 PLL DI PLL data O 0 0 0

42 PLL DO PLL data I 5.0 5.0 5.0

43 PLL CLK PLL dataclock O 5.2 5.2 5.2

44 PLL CE PLL chipselect O 0 0 0

45 ROMCS (+5V pull up) - - - -

46 PANEL Panel switchsignal I 0 0 0

47 OP/CL Open/close detect I 5.1 5.1 5.1

48 LCD5V

CNT LCD 5V control O 0 0 0

49 EEPROM

DI(NC) - - - - -

50 EEPROM

SK(NC) - - - - -

51 DIM1 (Ground pull down) - 0 0 0

52 DIM2 (Ground pull down) - 0 0 0

53 EEPROM

DO(NC) (Ground pull down) - - - -

54 AFMUTE Audiomutesignal O 5.0 5.0 5.0

55 INV CNT Invertercontrol O 5.0 5.0 5.0

56 CD CNT CD powercontrol O 0 0 0

57 MAIN

CONT Mainpowercontrol O 5.0 5.0 5.0

58 NC - - - - -

No. Port Description I/O (V)

FM AM CD

59 RDS

DATA

(NC)

- - - - -

60 RESET System reset I 5.0 5.0 5.0

61 RMDATA Remotecontrol data I 5.0 5.0 5.0

62 BATT Batterydetekut I 5.2 5.2 5.2

63 RDS

CLK(NC) - - - - -

64 CDC STB (Ground pull down) - 0 0 0

65 ROTARY

1Rotaryencoder

input1 I5.0 5.0 5.0

66 ROTARY

2Rotaryencoder

input2 I5.0 5.0 5.0

67 VSS0 Ground - 0 0 0

68 VDD1 +5V powersupply - 5.2 5.2 5.2

69 X2 Crystal oscillator - 3.0 3.0 3.0

70 X1 Crystal oscillator - 2.5 2.5 2.5

71 TEST (Testterminal) - 0 0 0

72 XT2 Crystal oscillator - 2.9 2.9 2.9

73 XT1 Crystal oscillator - 2.6 2.6 2.6

74 VDD0 +5V powersupply - 5.2 5.2 5.2

75 AVDD +6V powersupply - 5.2 5.2 5.2

76 VSM VSM I 0 0 0

77 ACC ACC detect I 4.8 4.8 4.8

78 INIT/B (+5V pull up) - 5.0 5.0 5.0

79 SPEANA

AIN (Ground pull down) - 0 0 0

80 LEVELL Level in I 0 0 0.5

9.2. DisplayBlock

IC901 :YEAMLC75854T
