CD-ROM DRIVE UNIT
CR-594-B / CR-594-C
INSTRUCTION MANUAL
Please read through these instructions before operating this unit.
Interface : ATAPI
ENGLISH
iii
CD-ROM DRIVE UNIT
CR-594-B / CR-594-C
INSTRUCTION MANUAL
Please read through these instructions before operating this unit.
Interface : ATAPI
TABLE OF CONTENTS
IMPORTANT SAFETY NOTICE
1. PRECAUTIONS WHEN OPERATING................................................................... A-3
1.1 PRECAUTIONS WHEN TRANSPORTING...................................................... A-3
1.2 INSTALLATION LOCATION ............................................................................ A-3
1.3 PRECAUTIONS FOR USE .............................................................................. A-3
1.4 PRECAUTIONS FOR OPERATION ................................................................ A-3
1.5 PRECAUTIONS WHEN HANDLING DISCS.................................................... A-3
2. PARTS AND FUNCTIONS .................................................................................... A-5
2.1 FRONT VIEW................................................................................................... A-5
2.2 REAR VIEW ..................................................................................................... A-5
3. CONNECTIONS..................................................................................................... A-6
3.1 CONNECTING VIEW....................................................................................... A-6
4. GUIDE TO OPERATION ....................................................................................... A-6
4.1 INSTALLATIONS ............................................................................................. A-6
5. GENERAL DESCRIPTION .................................................................................... A-7
5.1 FEATURE SUMMARY ..................................................................................... A-7
5.2 SYSTEM SET UP ............................................................................................ A-7
5.3 POWER SAVING ............................................................................................. A-7
6. SPECIFICATION SUMMARY................................................................................ A-7
6.1 PERFORMANCE ............................................................................................. A-7
6.2 ERROR RATES ............................................................................................... A-8
6.3 AUDIO PERFORMANCE................................................................................. A-8
6.4 GENERAL PERFORMANCE ........................................................................... A-9
6.5 ENVIRONMENTAL CONDITIONS................................................................... A-9
6.6 PICK UP LASER .............................................................................................. A-9
7. BEFORE REQUESTING SERVICE....................................................................... A-9
7.1 TROUBLESHOOTING ..................................................................................... A-9
APPENDIX ...............................................................................................................A-10
* Model CR-594-B
iv
IMPORTANT SAFETY NOTICE
NOTICE
(1) You may not reproduce or transcribe any part of this publication without permission.
(2) We reserve the right to revise this document at any time without notice.
(3) If you have any questions about this document, contact your sales representative.
SAFETY NOTICE
(1) To prevent fire or electric shock, do not expose this appliance to rain or moisture.
(2) To avoid electric shock or damage to the eyes due to laser beam, do not attempt to
disassemble the cabinet.
FEDERAL COMMUNICATIONS COMMISSION (FCC) RADIO
FREQUENCY INTERFERENCE STATEMENT
Class B Computing Device
NOTE : This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and , if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures :
- - Reorient or relocate the receiving antenna.
- - Increase the separation between the equipment and receiver.
- - Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- - Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING : Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
For USA (Model CR-594-B only)
A-1
ENGLISH
LASER SAFETY INFORMATION
Class 1 LASER Product
This equipment is certified to comply with DHHS Rule 21 CFR Chapter 1,Subchapter J in
effect as of date of manufacture.
Elsewhere, the drive is certified to conform to the requirements of the International
Electrotechnical Commission (IEC) 825 and CENELEC EN60825 for Class 1 laser
products.
Class 1 laser products are not considered to be hazardous. To ensure continued product
safety, the following precautions should be heeded.
• This label is attached to the upper shield at the top of the drive unit.
• Märkningen återfinns på den översta kåpan överst på drivenheten. (For Swedish)
• Denne merkelappen er festet til det øverste dekselet på toppen av spilleren.(For Norwegian)
• Denne etiket er sat fast på den øverste skærm på drev-enhedens top. (For Danish)
• Tämä etiketti on liimattu voimayksikön yläosan suojalevyyn. (For Finnish)
• This label is attached to the bottom of the drive unit.
• Märkningen återfinns på drivenhetens undersida. (For Swedish)
• Denne merkelappen er festet til undersiden av spilleren. (For Norwegian)
• Denne etiket er sat fast i bunden af drev-enheden. (For Danish)
• Tämä etiketti on liimattu laitteen pohjaan. (For Finnish)
Caution :
(1) The use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
(2) The drive is designed to be incorporated into a computer-based system or unit which
has an enclosing cover. The drive may not be used as a stand-alone unit.
(3) Do not open the drive unit; no user adjustments or serviceable parts are inside.
CLASS 1 LASER PRODUCT
LASER KLASSE 1
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
APPAREIL A LASER DE CLASSE 1
EN60825
CAUTION –INVISIBLE
LASER RADIATION WHEN OPEN
DO NOT STARE INTO BEAM OR VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS
VORSICHT–UNSICHTBARE
LASERSTRAHLUNG, WENN ABDECKUNG GEÖFFNET
NICHT IN DEN STRAHL BLICKEN
AUCH NICHT MIT OPTISCHEN INSTRUMENTEN
ADVARSEL–USYNLIG
LASERSTRÅLING VED ÅBNING.
SE IKKE IND I STRÅLEN – HELLER
IKKE MED OPTISKE INSTRUMENTER.
ADVARSEL–USYNLIG
LASERSTRÅLING NÅR DEKSEL ÅPNES.
STIRR IKKE INN I STRÅLEN ELLER SE
DIREKTE MED OPTISKE INSTRUMENTER.
VARNING–OSYNLIG
LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD.
STIRRA EJ IN I STRÅLEN OCH BETRAKTA
EJ STRÅLEN MED OPTISKA INSTRUMENT.
VARO! NÄKYMÄTÖNTÄ AVATTAESSA
OLET ALTTIINA LASERSÄTEIL YLLE.
ÄLÄ TUIJOTA SÄTEESEEN ÄLÄKÄ
KATSO SITÄ OPTISEN LAITTEEN LÄPI.
A-2
INTRODUCTION
CD-ROM drive is read-only memory using an audio compact disc system as a media
package which handles digital data. To enjoy audio CD, please insert the Headphone plug
into the Headphone jack. (Model CR-594-B only)
This drive unit uses CD-ROM discs which bear the following mark.
Only compact discs having this mark can be used with this unit.
VAROITUS! Laitteen käyttäminen muulla kuin tässä käyttöohjeessa mainitulla tavalla
saattaa altistaa käyttäjän turvallisuusluokan 1 ylittävälle näkymättömälle
lasersäteilylle.
VARNING! Om apparaten används på annat sätt än i denna bruksanvisning
specificerats, kan användaren utsättas för osynlig laserstrålning, som
överskrider gränsen för laserklass 1.
For Finnish
For Swedish
LASER Specification
Type: Semiconductor laser AlGaAs
Wave Length: 760 ~ 815 nm
(Typical 785 nm)
Divergence:
θ
= 53.5 °
Output Power: 0.15 mW
Laser- specifikationer: (For Swedish)
Typ: Laserhalvedare AlGaAs
Våglängd: 760 ~ 815 nm
(Typiskt 785 nm)
Divergens:
θ
= 53,5 °
Uteffekt: 0,15 mW
LASER Spesifikasjon: (For Norwegian)
Type: Halvleder laser AlGaAs
Bølgelengde: 760 ~ 815 nm
(Typisk 785 nm)
Divergens:
θ
= 53,5 °
Utgangseffekt: 0,15 mW
System Requirements
• Computer
IBM PC-AT or Compatible • Operating System
PC-DOS Ver. 5.0 or later
MS-DOS Ver. 5.0 or later
MS Windows 3.1
MS Windows 95 / 98
MS Windows NT3.5 / NT3.51 / NT4.0
OS/2 2.1X or later
COMPACT
COMPACT
DIGITAL AUDIO
Laser Specifikationer: (For Danish)
Type: Semiconductor AlGaAs
Bølge-længde: 760 ~ 815 nm
(Typisk 785 nm)
Divergens:
θ
= 53,5 °
Udgang-effekt: 0,15 mW
LASERin tekniset tiedot: (For Finnish)
Tyyppi: Laserpuolijohdin AlGaAs
Aallon pituus: 760 ~ 815 nm
(Tyypillinen 785 nm)
Hajaantuminen:
θ
= 53,5 °
Teho: 0,15 mW
A-3
ENGLISH
CHAPTER 1 PRECAUTIONS WHEN OPERATING
1.1 PRECAUTIONS WHEN TRANSPORTING
To avoid damage
* Keep the original packing materials for the drive unit.
* Before you transport the drive unit, remove the disc from the drive unit and repack
the drive unit in its original packing.
1.2 INSTALLATION LOCATION
Do not place unit in the following environments.
* High-temperature, high-humidity, extreme temperature changes.
* Dusty
* Excessive vibration/ sudden shock.
* Inclined place.
* Direct sunlight.
1.3 PRECAUTIONS FOR USE
* Never push objects of any kind through the Cabinet slots, never spill liquid of any
kind on the unit.
* Do not place objects on the product.
* Do not attempt to service this product yourself.
* Do not open or remove covers.
* Do not place foreign objects in the disc insertion slot and attempt to operate.
* Do not use CD-ROM drive when vertically installed. (Horizontal installation type only)
1.4 PRECAUTIONS FOR OPERATION
To avoid error
* Do not move the drive unit during operation.
* Do not operate the unit directly after a sudden increase in temperature.
NOTE :
A great proportion of problems are usually caused by the following.
➀Dust or Finger-prints on the surface of the CD-disc.
➁Random Electrical Noise.
➂Scratches and Defects on the surface of the CD-disc.
1.5 PRECAUTIONS WHEN HANDLING DISCS
➀Hold the disc by the edges, do not touch
the surface of the disc.
➁To remove dust or fingerprint, use a clean,
soft, dry cloth.
A-4
➂Do not write on, or paste paper
to the surface of the disc.
Should not paste any label to the
outer back surface (the label
side) of the disc, or it generates
drive vibration due to imbalance
of the disc.
➃Do not store the disc in a place where
the temperature is high.
➄Do not use benzine, thinners and
cleaners, etc.
➅Do not make the center hole larger.
➆Do not bend the disc.
➇Do not drop the disc, or subject it to
shock.
T
h
i
n
n
e
r
s
C
l
e
a
n
e
r
s
B
e
n
z
i
n
e
A-5
ENGLISH
CHAPTER 2 PARTSAND FUNCTIONS
2.1 FRONT VIEW
➀DISC TRAY
Accepts a disc.
➁HEAD PHONE JACK
Headphone can be connected using a 3.5mm stereo mini plug.
➂VOLUME
Adjusts audio output level of Headphone.
➃BUSY INDICATOR
Lights when data is being accessed from the disc, or the drive is playing an audio CD.
➄EJECT / LOAD BUTTON
Ejects and loads the disc tray.
➅EMERGENCY EJECT HOLE
Insert an instrument such as straightened paper clip into this hole to manually
eject the tray. (See 4.1)
2.2 REAR VIEW
➀INTERFACE CONNECTOR
Connects to host computer’s interface connector.
➁DC (IN) CONNECTOR
➂AUDIO OUT CONNECTOR (Analog)
➃JUMPER PIN
Insert the jumper according to the Master / Slave / CSEL drive.
(See the figure in the next page.)
➄DIGITAL AUDIO OUT CONNECTOR
➀➁
➂➃
➄
➀
➁➂➃ ➄➅
(Model CR-594-B only)
(Model CR-594-B only)
NOTE:
The serial format of digital data (not Audio data) output functions with some model.
A-6
CHAPTER 3 CONNECTIONS
3.1 CONNECTING VIEW
Jumper Pin
Audio Out Connector
DC (IN) Connector
DC Power Connector
Jumper
Drive-Select (Master/Slave/CSEL)
Cable select (CSEL)
Slave
Master (default)
Interface Connector
CHAPTER 4 GUIDE TO OPERATION
4.1 INSTALLATIONS
• Starting the drive.
➀Turn on the power supply.
➁Press the eject button. The tray is ejected from
the drive.
➂Place the disc in the tray with the disc’s label fac-
ing up.
➃Press the eject button or press the tray lightly as
in the following figure.
The tray is retracted automatically.
➄Loading start.
CAUTION:
•Do not insert any foreign objects into the disc tray. This could result in a
malfunction.
• Do not manually force the tray to open.
• When the drive is not in use, keep the tray closed to protect against dust and dirt.
• Do not press down hard on the tray when loading a disc, since this may result
in damage to or malfunction of the tray.
• In case of emergency, eject the tray manually
If for some reason the tray will not eject automatically, press
the eject-bar (for example, insert a straightened paper clip
minimum straight length = 45mm, Diameter = 1~ 1.5mm)
into the emergency eject hole to manually eject the tray. (Be-
fore proceeding with this emergency step, make sure that
the power is switched OFF.)
* This figure shows in case of
Horizontal Installation.
Min. 45 mm
Paper clip
Interface Cable
Digital Audio Out
Connector
A-7
ENGLISH
CHAPTER 5 GENERAL DESCRIPTION
5.1 FEATURE SUMMARY
➀Embedded ATAPI Interface.
➁Automatic Loading with tray.
➂Horizontal and Vertical Installation.
(Vertical : Vertical installation type only, 12 cm Disc only)
➃Audio Playback Capability.
➄5 1/4" Half Height Design.
5.2 SYSTEM SET UP
The ATAPI Devices are selected by the Address field in the Drive Select Register. When
a single Device is attached to the interface, it shall be set as Device 0. When the ATAPI
Device is attached along with an ATA Mass Storage Device, the ATAPI Device will be
set as Device 1 and respond as a Slave.
5.3 POWER SAVING
➀When the drive waits for a command from the Host for more than five minutes,
then the drive enters Power Save Mode. Laser and Spindle motor stop.
➁Re-start is automatic when the Host Command is received.
NOTE :
• ATAPI : AT Attachment Packet Interface.
• MS-DOS and MS Windows are trademarks or registered trademarks of Microsoft
Corporation.
•IBM PC-AT and OS/2 are registered trademarks of International Business Machines
Corporation.
CHAPTER 6 SPECIFICATION SUMMARY
6.1 PERFORMANCE
➀Disc diameter 12 cm, 8 cm
➁Disc speed
(48x mode) *1 10000 r/min [Max] (CAV) *2
➂Data capacity 656 MBytes (Mode 1)
748 MBytes (Mode 2)
➃Data transfer Rate
Sequential (48x mode) 3103 ~ 7200 KBytes/s (Mode 1)
(mean value; 5152 KBytes/s)
From buffer 16.7 MBytes/s (PIO Mode 4)
16.7 MBytes/s (Multi-word DMA Mode 2)
8.3 MBytes/s (Single word DMA Mode 2)
33.3 MBytes/s (Ultra DMA Mode 2)
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Panasonic Lecteur CD/CDR
Panasonic
Panasonic KX-LRW10A Manuel utilisateur
Panasonic
Panasonic KX-L783A Manuel utilisateur
Panasonic
Panasonic CF-VCW282U Manuel utilisateur
Panasonic
Panasonic KX-L840A Manuel utilisateur
Panasonic
Panasonic CF-VDR Series Manuel utilisateur
Panasonic
Panasonic KX-LD742 Manuel utilisateur
Panasonic
Panasonic LF-1007AD Manuel utilisateur
Panasonic
Panasonic LK-MC686BP Manuel utilisateur
Panasonic
Panasonic KX-LD721 Manuel utilisateur
Panasonic
Panasonic CF-VCW281 Manuel utilisateur
Panasonic
Panasonic KX-L783M Manuel utilisateur
Panasonic
Panasonic KX-LD745 Manuel utilisateur
Panasonic
Panasonic CF-VCW721 Manuel utilisateur
Panasonic
Panasonic LF-J100A2 Manuel utilisateur
Panasonic
Panasonic CF-VCW Series Schéma de câblage
Panasonic
Panasonic FJ1202-1124 Manuel utilisateur
Panasonic
Panasonic CF-VCD711W Manuel utilisateur
Panasonic
Panasonic LF-1600A Manuel utilisateur
Panasonic
Panasonic CF-VCD252 Manuel utilisateur
Panasonic
Panasonic KX-L810A Manuel utilisateur
Manuels Lecteur CD/CDR populaires d'autres marques
SmartDisk
SmartDisk Firewire CD-R/W Manuel utilisateur
Axis
Axis CD-ROM SERVER Manuel utilisateur
LG
LG CRD-8322B Manuel utilisateur
Memorex
Memorex 32023234 - 52x32x52x External USB2.0 CD... Instructions d'installation
Yamaha
Yamaha CD Recordable/Rewritable Drive CRW3200 Manuel utilisateur
Sony
Sony CRX230AE Manuel utilisateur
